4
94
ACCESS
BOOT
Opening
)
After unlocking the vehicle using the
remote control or the key, pull the
handle and raise the tailgate.
Closing
)
Lower the tailgate using the interior
grab handle.
- when the engine is running
,
this warning lamp comes on,
accompanied by a message
in the multifunction screen for
a few seconds,
-
when the vehicle is moving
(speed
above 6 mph (10 km/h)), this warning
lamp comes on, accompanied by an au-
dible signal and a message in the multi-
function screen for a few seconds.
If the tailgate is not closed correctly:
Opening
)
After unlocking the vehicle using the
remote control or the key, pull the
handle and raise the tailgate.
BOOT
- when the engine is running
,
this warning lamp comes on,
accompanied by a message
in the multifunction screen for
a few seconds,
-
when the vehicle is moving
(speed
above 6 mph (10 km/h)), this warning
lamp comes on, accompanied by an
audible signal and a message in the
multifunction screen for a few seconds.
Tailgate release
System allowing the mechanical unlock-
ing of the boot in the event of a battery
or central locking system malfunction.
Unlocking
)
Fold back the rear seats to gain
access to the lock from inside the
boot.
)
Insert a small screwdriver into hole A
of the lock to unlock the tailgate.
)
Move the latch to the left.
Closing
)
Lower the tailgate using the interior
grab handle.
If the tailgate is not closed correctly:
Locking after closing
If the fault persists after closing again,
the boot will remain locked.
11
198
PRACTICAL INFORMATION
Changing third brake lamp bulbs
(4 bulbs W5W)
)
Unclip the tailgate upper trim from
left to right.
)
Unscrew the two lamp fi xing nuts A
.
)
Unclip the lamp's central pin.
)
Extract the lamp from the outside.
)
Disconnect the bulb holder connector
and the wash-wipe pipe.
)
Unclip the bulb holder from the lamp
by pressing on the two tabs B
.
)
Pull the bulb and change it.
To r efi t, carry out these operations in re-
verse order.
Do not apply force to the lamp when
tightening the nuts.
Changing the number plate lamp
bulbs (W5W)
)
Insert a thin screwdriver into one of
the outer holes of the lens.
)
Push it outwards to unclip.
)
Remove the lens.
)
Pull the bulb and change it.
