Page 11 of 382
9
FAMILIARISATION
INSTRUMENTS AND CONTROLS
1.
Cruise control / speed limiter
switches.
2.
Steering wheel adjustment control.
3.
Lighting and direction indicator
control stalk.
4.
Instrument panel.
5.
Driver's airbag.
Horn.
6.
Gear lever.
7.
Parking brake lever.
8.
Panoramic sunroof blind control.
9.
Heated seat control.
10.
Bonnet release.
11 .
Door mirror controls.
Electric window controls.
12.
Fusebox.
13.
Manual headlamp height
adjustment.
Stop & Start button.
14.
Front side window demisting vent.
15.
Speaker (tweeter).
16.
Windscreen demisting vent.
Page 13 of 382
11
FAMILIARISATION
SITTING COMFORTABLY
Driver's seat
Manual adjustment
Electric adjustment
Forwards-backwards
68
69
Seat back angle
Height
Page 14 of 382
FAMILIARISATION
Steering wheel adjustment
1.
Unlocking the control.
2.
Adjustment for height and reach.
3.
Locking the control.
SITTING COMFORTABLY
Front seats
Other functions available...
Table position for the front passen-
ger seat (SW).
Storing driving positions (driver's
electric seat).
Heated seats.
Head restraint height
Lumbar
Front armrest
70
11 3
82
For your comfort, the height and longi-
tudinal position of the front armrest can
be adjusted.
It also has a storage compartment. As a safety precaution, these op-
erations must only be carried out
when stationary.
Page 15 of 382
13
FAMILIARISATION
SITTING COMFORTABLY
Door mirrors
Adjustment
Other functions available...
Folding / Unfolding.
Automatic tilting of the mirror in re-
verse gear for parking.
Rear view mirror
Manual day/night model
Front seat belts
1.
Fastening the buckle.
2.
Height adjustment.
A.
Selection of the mirror to be adjusted.
B.
Adjustment of the position of the
mirror in the four directions.
C.
De-selection of the mirror.
82
141
80
1.
Selection of the "day" position of
the mirror.
2.
Adjusting the mirror.
Automatic day/night model
A.
Light sensor.
B.
Adjusting the mirror.
82
Page 20 of 382
18
FAMILIARISATION
PASSENGER COMFORT
Operating the rear seats
2nd row rear seats
1.
Forwards-backwards adjustment.
2.
Seat back angle adjustment / Table
position.
3.
Head restraint height adjustment.
4.
Folding.
5.
Removal / Installation.
6.
Carrying.
74
3rd row additional seats
A.
Seat back angle adjustment / Table
position.
B.
Head restraint height adjustment.
C.
Folding.
D.
Removal / Installation.
E.
Carrying.
76
Operating the front
passenger seat
Table position
A.
Placing in the partial table position.
B.
Placing in the full table position.
70
Page 70 of 382
3
68
COMFORT
FRONT SEATS WITH MANUAL
ADJUSTMENTS
Seat consisting of a seat cushion, a seat
back and a head restraint which can all
be adjusted to adapt your position for
ease of driving and comfort.
Height
)
Pull the control upwards to raise
or push it downwards to lower, as
many times as required, to obtain
the position required.
Seat back angle
)
Push the control rearwards.
Forwards-backwards
)
Raise the control and slide the seat
forwards or backwards.
Page 71 of 382
3
69
COMFORT
FRONT SEATS
Seat consisting of a seat cushion, a seat
back and a head restraint which can all
be adjusted to adapt your position for
ease of driving and comfort.
Forwards-backwards
)
Push the control forwards or rear-
wards to slide the seat.
Cushion height and angle
)
Tilt the rear part of the control up-
wards or downwards to obtain the
required height.
)
Tilt the front part of the control up-
wards or downwards to obtain the
required angle.
Seat back angle
)
Tilt the control forwards or rearwards
to adjust the angle of the seat back.
Driver's seat electric
adjustments
The electrical functions of the driv-
er's seat are deactivated approxi-
mately one minute after the ignition
is switched off.
To reactivate them, switch on the
ignition.
Page 72 of 382
3
70
COMFORT
Table position for front
passenger seat
Head restraint height adjustment
)
To raise the head restraint, pull it for-
wards and upwards at the same time.
)
To remove the head restraint, press
the lug A
and pull the head restraint
upwards.
)
To put the head restraint back in
place, engage the head restraint
stems in the openings keeping them
in line with the seat back.
)
To lower the head restraint, press
the lug A
and the head restraint at
the same time. The head restraint is fi tted with a
frame with notches which prevents
it from lowering; this is a safety de-
vice in case of impact.
The adjustment is correct when
the upper edge of the head re-
straint is level with the top of the
head.
Never drive with the head restraints
removed; they must be in place and
adjusted correctly.
Manual lumbar adjustment
)
Turn the knob to obtain the desired
level of lumbar support.
Additional adjustments
Placing this seat in the table position, with
the rear seats also in the table position,
allows you to transport long objects.
)
Pull the control upwards to fold the
seat back onto the seat cushion.
To lower the seat back fully, tilt the
seat back angle adjustment control.
)
Pull the control again to release the
seat back and raise it.
When put back in place, the seat
back returns to its initial position.
Do not forget to fold the "aircraft"
type table fi xed on the back of the
seat fi rst.
