NISSAN INTELLIGENT KEY® SYSTEM
The NISSAN Intelligent Key® system allows you to lock
or unlock your vehicle, open your liftgate/trunk lid and
start the engine.
NOTE: It is important to make sure the Intelligent Key is
with you (that is, in your pocket or purse).
The operating range of the Intelligent Key is within
31.5 in (80 cm) from each request switch.
To lock the vehicle, push either door handle
request switch
01 once or press the
button02 on the keyfob.
To unlock the vehicle, perform one of the
following procedures:
• Push either door handle request switch
01 once;
the corresponding door will unlock. Push the door
handle request switch
01 again within 1 minute;
all other doors will unlock, or
• Press the
button 03 on the keyfob to unlock the driver’s side door. Press the
button
again; all other doors will unlock.
The Intelligent Key can also be used to activate the panic alarm by pressing and holding \
the
button 04 for more than 1 second. Once activated, the panic alarm and headlights w\
ill stay
on for 25 seconds.
NISSAN INTELLIGENT KEY
® BATTERY DISCHARGE
If the battery in the Intelligent Key is almost discharged,
the guide light
05 of the Intelligent Key port blinks and
the Intelligent Key battery discharge indicator 06 is
displayed in the dot matrix liquid crystal display.
To start the engine under these circumstances, insert
the Intelligent Key into the key port with the buttons
facing upward and the key ring end toward you until
it latches into place. Then push the ignition switch to
start the engine.
To remove the Intelligent Key from the port, push the
ignition switch to turn the engine off and then pull the
Intelligent Key out of the port.
The Intelligent Key port does not charge the Intelligent
Key battery. If you see the low battery indicator
06 ,
replace the battery in the Intelligent Key.
NOTE: Do not insert the mechanical key or other objects into the key port because it will damage
the key port.
For more information, refer to the “Pre-driving checks and adjustments (section 3)” , the “Starting and driving (section
5)” and the “Maintenance and do-it yourself (section 8)” of your Owner’s Manual.
6
first drive features
F
02
03
04
01
06
05
To view detailed instructional videos regarding these and other features,
please go to www.nissanownersinfo.mobi.
FRONT SEAT ADJUSTMENTS
MANUAL SEATS (if so equipped)
To slide the seat forward or backward, pull up on
the lever
01 under the front of the seat and slide
forward or backward. Release the lever to lock the
seat in position.
To adjust your seatback forward or backward, lift the
lever
02 on the side of the seat.
Release the lever when you have found a comfortable
angle and the seat belt fi ts properly.
SEAT LI FTE R (if so equipped)
To adjust the seat height, pull up or push down on
the adjusting lever
03 repeatedly.
LUMBAR SUPPORT (if so equipped)
Your driver’s seat lumbar support 04 is located on
the inboard side of the driver’s front seat.
Adjust by moving the lever up or down.
8
first drive features
SOFT TOP OPERATION (CrossCabriolet models)
The soft top can be operated only when the trunk is
separated by the luggage cover. The luggage cover must
be pulled out and hung on both hooks or the top will not
operate. Before opening or closing your soft top, refer to
the Owner’s Manual for detailed warnings and cautions
regarding soft top operation.
Soft Top Operation
1. Make sure the area around the vehicle is clear of obstructions and that \
there is more
than 10 feet (3 m) of clearance from the ground and more than 4.9 feet (1.5 m) of\
clearance from the rear of the vehicle.
2. Pull out the luggage cover and hang on both hooks
01 .
3. Apply the parking brake and move the shift lever to the P (PARK) position.
4. Depress the brake pedal.
5. Start the engine.
6. Push and hold the soft top operating switch, located
on the center console, to OPEN
02 or CLOSE
03
until the top is fully opened or closed.
For more information, refer to the “Instruments and controls (section 2)”
and the “Pre-driving checks and adjustments (section 3)” of your Owner’s Manual.
02
03
01
01
0203
04
P
S
L
F
O
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.
