To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.
AUToMAT iC C liMA TE C o NTRol S (if so equipped)
01 AUTo BUTTo N/DRiv ER’S SiD E TEMPERATURE C o NTRol Di A l
The auto mode may be used year-round. Press the AUTo button to turn the system on
and the system will automatically control the inside temperature (autom\
atic cooling and/or
dehumidified heating), air flow distribution and fan speed.
Turn the driver’s side temperature control dial left for cooler air or right for warmer \
air.
02 D UA l BUTTo N/PASSENGER’S SiD E TEMPERATURE C o NTRol Di A l
Press the passenger ’s side D UAl control button to turn the passenger ’s side temperature
controls on or off. This will allow the passenger’s side temperature to be adjusted
independently from the driver’s side.
Turn the passenger’s side temperature control dial left for cooler air or right for warmer \
air.
01
070608
03
05
02
Wi NDSH i E lD Wi PER
AND WASHER SW i TCH
Move the lever to the following positions to operate the
windshield wipers:
01 Mist (MiST) - One sweep operation of the wipers.
02 Intermittent ( iNT) - Move the lever down to the iNT
position and then rot ate the control ring
03 away
from you to increase
i
NT
wiper speeds.
04 Low ( lo ) - Wipers operate at a continuous low-speed.
05 High (Hi ) - Wipers operate at a continuous high-speed.
06 Pull the lever toward you to activate the washer .
The wipers will operate several times.
For more information, refer to the “instruments and controls (section 2)”
of your Owner ’s Manual.06
01
02
04
05
MiST
o
FF
iNT
lo
H
i03
9
04
