2013 Lexus IS300h sensor

2574-5. Using the driving support systems
4
Driving
IS300h_EE(OM53B95E)
Radar sensor and grille cover
Always keep the sensor and grille cover clean to ensure that the vehicle-to-vehi-
cle distance control operates properly. (Some obstructions, such as snow, ice and
plastic objects, cannot be detected by the obstruction sensor.)
Dynamic radar cruise control is canceled if an obstruction is detected.
Operation guide display
When the dynamic radar cruise control switch is operated, a guidance display is
shown on the meters for a few seconds as to how to operate the dynamic radar
cruise control switch or distance switch. (P. 1 1 9 )
Warning messages and buzzers for dynamic radar cruise control
Warning messages and buzzers are used to indicate a system malfunction or to
inform the driver of the need for caution while driving. (P. 518) Grille cover
Radar sensor
1
2

2624-5. Using the driving support systems
IS300h_EE(OM53B95E)
Before using dynamic radar cruise control
Do not overly rely on vehicle-to-vehicle distance control.
Be aware of the set speed. If automatic deceleration/acceleration is not appro-
priate, adjust the vehicle speed, as well as the distance between your vehicle
and vehicles ahead by applying the brakes etc.
Cautions regarding the driving assist systems
Observe the following precautions.
Failure to do so may cause an accident resulting in death or serious injury.
Assisting the driver to measure following distance
The dynamic radar cruise control is only intended to help the driver in deter-
mining the following distance between the driver’s own vehicle and a desig-
nated vehicle traveling ahead. It is not a mechanism that allows careless or
inattentive driving, and it is not a system that can assist the driver in low-visi-
bility conditions. It is still necessary for driver to pay close attention to the
vehicle’s surroundings.
Assisting the driver to judge proper following distance
The dynamic radar cruise control determines whether the following distance
between the driver’s own vehicle and a designated vehicle traveling ahead is
appropriate or not. It is not capable of making any other type of judgement.
Therefore, it is absolutely necessary for the driver to remain vigilant and to
determine whether or not there is a possibility of danger in any given situa-
tion.
Assisting the driver to operate the vehicle
The dynamic radar cruise control has no capability to prevent or avoid a colli-
sion with a vehicle traveling ahead. Therefore, if there is ever any danger, the
driver must take immediate and direct control of the vehicle and act appropri-
ately in order to ensure the safety of all involved.
To avoid inadvertent cruise control activation
Switch the cruise control off using the “ON/OFF” button when not in use.
Situations unsuitable for dynamic radar cruise control
Do not use dynamic radar cruise control in any of the following situations.
Doing so may result in inappropriate speed control and could cause an accident
resulting in death or serious injury.
In heavy traffic
On roads with sharp bends
On winding roads
On slippery roads, such as those covered with rain, ice or snow
On steep downhills, or where there are sudden changes between sharp up and
down gradients
Vehicle speed may exceed the set speed when driving down a steep hill.
At entrances to expressways
When weather conditions are bad enough that they may prevent the sensors
from functioning correctly (fog, snow, sandstorm, heavy rain, etc.)
When an approach warning buzzer is heard often
When your vehicle is towing a trailer or during emergency towing

2634-5. Using the driving support systems
4
Driving
IS300h_EE(OM53B95E)
CAUTION
When the sensor may not be correctly detecting the vehicle ahead
Apply the brakes as necessary when any of the following types of vehicles are
in front of you.
As the sensor may not be able to correctly detect these types of vehicles, the
approach warning (P. 254) will not be activated, and a fatal or serious acci-
dent may result.
Vehicles that cut in suddenly
Vehicles traveling at low speeds
Vehicles that are not moving
Vehicles with small rear ends (trailers with no load on board etc.)
Motorcycles traveling in the same lane
Conditions under which the vehicle-to-vehicle distance control may not func-
tion correctly
Apply the brakes as necessary in the following conditions as the radar sensor
may not be able to correctly detect vehicles ahead, and a fatal or serious acci-
dent may result:
When water or snow thrown up by a the surrounding vehicles hinders the
functioning of the sensor
When your vehicle is pointing upwards (caused by a heavy load in the trunk
etc.)
When the road curves or when the lanes are narrow
When steering wheel operation or your position in the lane is unstable
When the vehicle ahead of you decelerates suddenly
Handling the radar sensor
Observe the following to ensure the cruise control system can function effec-
tively.
Otherwise, the system may not function correctly and could result in an acci-
dent.
Keep the sensor and grille cover clean at all times.
Clean the sensor and grille cover with a soft cloth so you do not mark or dam-
age them.
Do not subject the sensor or surrounding area to a strong impact.
If the sensor moves even slightly off position, the system may malfunction. If
the sensor or surrounding area is subject to a strong impact, always have the
area inspected and adjusted by any authorized Lexus dealer or repairer, or
another duly qualified and equipped professional.
Do not disassemble the sensor.
Do not attach accessories or stickers to the sensor, grille cover or surrounding
area.
Do not modify or paint the sensor and grille cover.
Do not replace them with non-genuine parts.

2644-5. Using the driving support systems
IS300h_EE(OM53B95E)
While driving on a road that has lane markers, this system recognizes the
lane markers using a camera as a sensor to alert the driver when the vehi-
cle deviates from its lane.
If the system judges that the vehicle has deviated from its lane, it alerts
the driver using a buzzer and indications on the multi-information dis-
play.
Camera sensor
LDA (Lane Departure Alert)

: If equipped
Summary of function

2674-5. Using the driving support systems
4
Driving
IS300h_EE(OM53B95E)
Temporary cancelation of the LDA system functions
If any of the following occurs, the LDA system functions will be temporarily
canceled. The functions will resume after the necessary operating conditions
have returned.
The turn signal lever is operated.
The vehicle speed deviates from the operating range of the LDA system func-
tions.
When the lane lines cannot be recognized while driving.
When the lane departure warning sounds.
The lane departure warning function will not operate again for a several sec-
onds after it has been activated, even if the vehicle leaves the lane again.
The lane departure warning
Depending on the audio system sound level or air conditioning fan noise while
the audio system or air conditioning system is in use, it may be difficult to hear
the warning sound.
After the vehicle has been parked in the sun
The LDA system may not be available and a warning message (P. 518) will be
displayed for a while after driving has started. When the temperature in the cabin
decreases and the temperature around the camera sensor (P. 264) becomes suit-
able for its operation, the functions will begin to operate.
If there are lane markers on only one side of the vehicle
The lane departure warning will not operate for the side on which lane markers
could not be recognized.
Conditions in which the function may not operate correctly
In the following situations, the camera sensor may be unable to recognize lane
markers causing the lane departure warning function to operate incorrectly. How-
ever, this does not indicate a malfunction.
When driving through an area with no lane markers, such as a tollbooth, a
crossing or before a ticket checkpoint
When driving on a sharp curve
When lane markers are extremely narrow or extremely wide
When the vehicle leans to one side an unusual amount due to a heavy load or
improper tire inflation pressure
When the following distance between your vehicle and the vehicle ahead is
extremely short
When the lane markers are yellow (These may be more difficult for the system
to recognize compared to white markers.)
When the lane markers are broken, Botts’ dots (raised pavement markers) or
stones
When the lane markers are on a curb etc.
When lane markers are obscured or partially obscured by sand, dirt, etc.
When there are shadows on the road running parallel with lane markers, or if a
shadow covers the lane markers
When driving on a particularly bright road surface, such as concrete

2704-5. Using the driving support systems
IS300h_EE(OM53B95E)
NOTICE
To prevent damage to or incorrect operation of the LDA system
Do not modify the headlights or attach stickers to the surface of the lights.
Do not modify the suspension or replace it with non-genuine parts.
Do not install or place anything on the hood or the grille. Also, do not install a
grille guard (bull bars, kangaroo bar etc.).
If your windshield needs repairs, contact any authorized Lexus dealer or
repairer, or another duly qualified and equipped professional.
Camera sensor
Observe the following to ensure that the LDA system functions correctly.
Keep the windshield clean at all times.
Performance could be affected if the windshield is dirty, or if raindrops, con-
densation or ice are adhering to the windshield.
Do not spill liquid onto the camera sensor
Do not attach window tinting to the windshield.
Do not install an antenna in front of the camera lens.
If the windshield is fogged up, use the windshield defogger to remove fog
from the windshield.
When it is cold, using the heater with air blowing to the feet may allow the
upper part of the windshield to fog up. This will have a negative effect on the
images.
Do not scratch the camera lens, or let it get dirty.
When cleaning the inside of the windshield, be careful not to get any glass
cleaner etc. on the lens. Also, do not touch the lens.
For lens repair, contact any authorized Lexus dealer or repairer, or another
duly qualified and equipped professional.
Do not change the installation position or direction of the camera sensor or
remove it. The direction of the camera sensor is precisely adjusted.
Do not subject the camera sensor to strong impact or force, and do not disas-
semble the camera sensor.
Do not replace windshield with non-genuine windshield.
Contact any authorized Lexus dealer or repairer, or another duly qualified and
equipped professional.
Do not attach a sticker or other items to
the windshield near the camera sensor.

2714-5. Using the driving support systems
4
Driving
IS300h_EE(OM53B95E)
Types of sensors
Lexus parking assist-sensor switch
Turns the Lexus parking assist-
sensor on/off
When on, the indicator light
comes on to inform the driver that
the system is operational.
Lexus parking assist-sensor
: If equipped
The distance from your vehicle to nearby obstacles when parallel parking
or maneuvering into a garage is measured by the sensors and communi-
cated via the multi-information display, Lexus Display Audio screen (if
equipped) and a buzzer. Always check the surrounding area when using
this system.
Front center sensors
Front corner sensorsRear corner sensors
Rear center sensors1
2
3
4

2724-5. Using the driving support systems
IS300h_EE(OM53B95E)
When the sensors detect an obstacle, a graphic is shown on the multi-
information display and Lexus Display Audio screen (if equipped)
depending on the position and distance to the obstacle.
Multi-information display
Front corner sensor detection
Front center sensor detection
Rear corner sensor detection
Rear center sensor detection
Lexus Display Audio screen (if equipped)
When the rear view monitor
system is not displayed
A graphic is automatically dis-
played when an obstacle is
detected. The screen can be set so
that the graphic is not displayed.
(P. 275)
: Select to mute the
buzzer sounds.
When the rear view monitor
system is displayed (insert dis-
play)
A simplified image is displayed
on the upper right corner of the
Lexus Display Audio screen
when an obstacle is detected.
Display
1
2
3
4
1
2
