2013 Lexus GX460 back up

646
4-3. Do-it-yourself maintenance
GX460_OM_OM60J63U_(U)
CAUTION
■Proper inflation is critical to save tire performance
Keep your tires properly inflated. Otherwise, the following conditions may occur
and result in an accident causing death or serious injury.
●Excessive wear
●Uneven wear
●Poor handling
●Possibility of blowouts resulting from overheated tires
●Poor sealing of the tire bead
●Wheel deformation and/or tire separation
●A greater possibility of tire damage from road hazards
NOTICE
■When inspecting and adjusting tire inflation pressure
Be sure to reinstall the tire valve caps back on.
Without the valve caps, dirt or moisture could get into the valve and cause air leak-
age, which could result in an accident. If the caps are lost, replace them as soon as
possible.
GX460_OM_OM60J63U_(U).book Page 646 Thursday, March 29, 2012 9:10 AM

663
4-3. Do-it-yourself maintenance
4
Maintenance and care
GX460_OM_OM60J63U_(U)Under the instrument panel
FuseAmpereCircuit
1P/O U T L E T15 APo w e r o u t l e t
2ACC7. 5 A
Outside rear view mirror motor,
BODY ECU, air conditioning system,
audio system, navigation system,
parking assist system, back up relay,
DSS#2 ECU, AT indicator, EFI ECU,
shift lock ECU, DCM, MAYDAY
ECU
3BKUP LP10 A
Back-up lights, audio system, multi
information display, DSS#2 ECU,
parking assist sensor
4TOW I N G B K L P10 ATo w i n g
5AV S20 AAir suspension system
6KDSS10 AKDSS ECU
GX460_OM_OM60J63U_(U).book Page 663 Thursday, March 29, 2012 9:10 AM

664
4-3. Do-it-yourself maintenance
GX460_OM_OM60J63U_(U)
74WD20 A4WD system, rear differential lock
8P/ S E AT F L30 AFront power seat (left)
9D/ L N O. 225 ADoor lock motor, glass hatch
opener, BODY ECU
10PSB30 APSB ECU
11TI & TE15 ATilt and telescopic steering
12FOG FR15 AFront fog lights
13OBD7. 5 ADLC 3
14A/C7. 5 AAir conditioning system
15AM17. 5 AStarting system
16DOOR RL25 ARear power window (left)
17ECU-IG NO.110 A
Shift lock ECU, VSC ECU, steering
sensor, yaw rate sensor, sequential
switch, auto wiper ECU, back up
relay, tilt & telescopic steering, PSB
ECU, DSS#1 ECU, front radar sensor,
AFS ECU, TIRE PRESS ECU,
DRIVER MON ECU
18IG17. 5 A
Front turn signal light, rear turn signal
light, side turn signal light, meter turn
signal light, trailer light, ALT, VSC, C/
C switch
FuseAmpereCircuit
GX460_OM_OM60J63U_(U).book Page 664 Thursday, March 29, 2012 9:10 AM

671
4-3. Do-it-yourself maintenance
4
Maintenance and care
GX460_OM_OM60J63U_(U)
Replacing light bulbs■ Headlight low beams (vehicles with halogen bulbs)
Turn the cover counterclockwise
and remove it.
■Rear bulb locations
Rear turn signal light
Back-up light
Rear side marker light
STEP1
GX460_OM_OM60J63U_(U).book Page 671 Thursday, March 29, 2012 9:10 AM

677
4-3. Do-it-yourself maintenance
4
Maintenance and care
GX460_OM_OM60J63U_(U)■
Rear turn signal and re ar side marker lights
Open the back door.
Left-hand side:
Remove the bolts and lamp assem-
bly.
Right-hand side:
Remove the bolts.
Close the back door half way and
remove the lamp assembly.
STEP1
GX460_OM_OM60J63U_(U).book Page 677 Thursday, March 29, 2012 9:10 AM

679
4-3. Do-it-yourself maintenance
4
Maintenance and care
GX460_OM_OM60J63U_(U)■
Back-up lights
Remove the bolts and pull down
the under cover.
Turn the bulb base counterclock-
wise.
STEP1
STEP2
GX460_OM_OM60J63U_(U).book Page 679 Thursday, March 29, 2012 9:10 AM

5
When trouble arises
697
5-2. Steps to take in an emergency
GX460_OM_OM60J63U_(U)
Have the malfunction repaired immediately.After taking the specified steps to co rrect the suspected problem, check
that the warning light turns off.
Warning lightWarning light/DetailsCorrection procedure
Open door warning light
(warning buzzer)
*1
A door or a back door is not
fully closed.
Check that all doors and the
back door are closed.
Low fuel level warning light
Remaining fuel
(Approximately 3.4 gal. [13.0
L, 2.8 Imp.gal.] or less)
Refuel the vehicle.
(On the instru-
ment panel)
Driver’s seat belt reminder
light (warning buzzer)
*2
Warns the driver to fasten
his/her seat belt.Fasten the seat belt.
(On the center panel)
Front passenger’s seat belt
reminder light (warning
buzzer)
*2
Warns the front passenger to
fasten his/her seat belt.
Fasten the seat belt.
GX460_OM_OM60J63U_(U).book Page 697 Thursday, March 29, 2012 9:10 AM

716
5-2. Steps to take in an emergency
GX460_OM_OM60J63U_(U)
Sounds
onceSounds
3 times
(Flashes)
The electronic key
was carried out-
side the vehicle
and a door other
than the driver’s
door was opened
and closed while
the “ENGINE
START STOP”
switch was in a
mode other than
off.
Bring the elec-
tronic key back
into the vehicle.
The driver’s door
was opened and
closed while the
electronic key was
not in the vehicle,
the shift lever was
in P and the
“ENGINE START
STOP” switch was
not turned off.
Tu r n t h e
“ENGINE START
STOP” switch off
or bring the elec-
tronic key back
into the vehicle.
InteriorbuzzerExterior buzzerWarning messageDetailsCorrection
procedure
GX460_OM_OM60J63U_(U).book Page 716 Thursday, March 29, 2012 9:10 AM
