2013 Lexus GX460 service indicator

587
3-7. Other interior features
3
Interior features
GX460_OM_OM60J63U_(U)
Safety Connect∗
∗: If equipped
Safety Connect is a subscription-based telematics service that uses Global
Positioning System (GPS) data and embedded cellular technology to pro-
vide safety and security features to subscribers. Safety Connect is sup-
ported by Lexus’ designated response center, which operates 24 hours per
day, 7 days per week.
Safety Connect service is available by subscription on select, telematics
hardware-equipped vehicles.
By using the Safety Connect service, you are agreeing to be bound by the
Telematics Subscription Service Agreement and its Terms and Conditions,
as in effect and amended from time to time, a current copy of which is avail-
able at Lexus.com. All use of the Safety Connect service is subject to such
then-applicable Terms and Conditions.
■ System components
Microphone
LED light indicators
“SOS” button
GX460_OM_OM60J63U_(U).book Page 587 Thursday, March 29, 2012 9:10 AM

590
3-7. Other interior features
GX460_OM_OM60J63U_(U)
Safety Connect LED light IndicatorsWhen the “ENGINE START STOP” switch is turned to IGNITION ON
mode, the red indicator light comes on for 2 seconds then turns off.
Afterward, the green indicator light comes on, indicating that the service
is active.
The following indicator light patterns indicate specific system usage con-
ditions:
● Green indicator light on = Active service
● Green indicator light flashing = Safety Connect call in process
● Red indicator light (except at vehicle start-up) = System malfunction
(contact your Lexus dealer)
● No indicator light (off) = Safety Connect service not active
Safety Connect services
■ Automatic Collis ion Notification
In case of either airbag deployment or severe rear-end collision, the
system is designed to automatically call the response center. The
responding agent receives the vehicle’s location and attempts to speak
with the vehicle occupants to assess the level of emergency. If the
occupants are unable to communicate, the agent automatically treats
the call as an emergency, contacts the nearest emergency services
provider to describe the situation, and requests that assistance be sent
to the location.
GX460_OM_OM60J63U_(U).book Page 590 Thursday, March 29, 2012 9:10 AM

611
4-2. Maintenance
4
Maintenance and care
GX460_OM_OM60J63U_(U)
Emission inspection and maintenance (I/M) programs
Some states have vehicle emission inspection programs which include
OBD (On Board Diagnostics) checks. The OBD system monitors the oper-
ation of the emission control system.
■If the malfunction indicator lamp comes on
The OBD system determines that a problem exists somewhere in
the emission control system. Your vehicle may not pass the I/M test
and may need to be repaired. Cont act your Lexus dealer to service
the vehicle.
■ Your vehicle may not pass the I/M test in the following situations:
● When the battery is disconnected or discharged
Readiness codes that are set du ring ordinary driving are erased.
Also, depending on your driving habits, the readiness codes may
not be completely set.
● When the fuel tank cap is loose
The malfunction indicator lamp comes on a temporary malfunc-
tion and your vehicle may not pass the I/M test.
■ When the malfunction indicator lamp still remains on after several
driving trips
The error code in the OBD system will not be cleared unless the
vehicle is driven 40 or more times.
■ If your vehicle does not pass the I/M test
Contact your Lexus dealer to prepare the vehicle for re-testing.
GX460_OM_OM60J63U_(U).book Page 611 Thursday, March 29, 2012 9:10 AM

772
6-1. Specifications
GX460_OM_OM60J63U_(U)
■Non-recommendation of the use of blended gasoline
●If you use gasohol in your Lexus, be sure that it has an octane rating no lower
than 87.
●Lexus does not recommend the use of gasoline containing methanol.
■Non-recommendation of the use of gasoline containing MMT
Some gasoline contains an octane enhancing additive called MMT (Methylcy
clopentadienyl Manganese Tricarbonyl).
Lexus does not recommend the use of gasoli ne that contains MMT. If fuel contain-
ing MMT is used, your emission control system may be adversely affected.
The malfunction indicator lamp on the inst rument cluster may come on. If this hap-
pens, contact your Lexus dealer for service.
●Use only gasoline containing a maximum
of 10 % ethanol.
DO NOT use any flex-fuel or gasoline
that could contain more than 10 % etha-
nol, including from any pump labeled E15,
E30, E50, E85 (which are only some
examples of fuel containing more than
10 % ethanol).
DO NOT use gasoline con-
taining more than 10 % etha-
nol.
(15 % ethanol)
(50 % ethanol)
(85 % ethanol)
GX460_OM_OM60J63U_(U).book Page 772 Thursday, March 29, 2012 9:10 AM

834
Alphabetical index
GX460_OM_OM60J63U_(U)
SeatsAdjustment................................67, 71, 82
Adjustment precautions ....................... 70, 80, 85
Child seats/child restraint system installation ........................... 155
Cleaning.................................................. 601
Driver’s seat position memory....... 82
Folding down the second seatbacks ...................................... 73, 74
Folding down the third seats .......... 76
Head restraint......................................... 86
Properly sitting in the seat ............... 124
Seat heaters .......................................... 557
Seat position memory ........................ 82
Ventilated seats .................................. 557
Service reminder indicators ............202
Shift lever Automatic transmission................... 190
If the shift lever cannot be shifted from P ....................................742
Shift lever lighting .................................525
Shift lock system .................................... 742
Side airbags.............................................. 126
Side marker lights Replacing light bulbs............ 675, 677
Switch ...................................................... 223
Wattage.................................................. 769 Side mirror
Adjusting and folding ..........................101
Mirror position memory ....................82
Side turn signal lights
Replacing light bulbs .......................680
Smart access system with
push-button startAntenna location ...................................34
Entry functions ......................................... 31
Starting the engine.............................. 183
Spare tire Inflation pressure ............................... 768
Storage location .................................726
Spark plug ............................................... 763
Specifications ......................................... 758
Speedometer ...........................................199
Steering Column lock release ......................... 187
Fluid .......................................................... 768
Steering wheel
Adjustment ............................................... 97
Audio switches ................................... 466
Heated steering wheel ................... 555
Steering wheel position memory ..................................................82
Stop light
Replacing light bulbs .......................680
Storage feature ..................................... 529
Stuck If your vehicle becomes stuck .....752
Sun visors ................................................. 544
GX460_OM_OM60J63U_(U).book Page 834 Thursday, March 29, 2012 9:10 AM
