2013 INFINITI JX Quick Reference Guide

2013 Infiniti JXQuick Reference Guide

*See your Owner’s Manual for information.
01
INSTRUMENT BRIGHTNESS
CONTROL SWITCHES*
02
BACKUP COLLISION INTERVENTION
(BCI) SWITCH
03
TWIN TRIP ODOMETER RESET SWITCH*
04
VEHICLE INfORMATION DISPLA y
05
HEADLIGHT AND TURN SIGNAL SWITCH
06
LOW TIRE PRESSURE WARNING LIGHT
07
WINDSHIELD WIPER AND
WASHER SWITCH
08
VEHICLE INfORMATION DISPLA y
SWITCH
09
STEERING WHEEL SWITCHES fOR
AUDIO* / BLUETOOTH / NAVIGATION®
10
INTELLIGENT CRUISE CONTROL
11
VEHICLE D yNAMIC CONTROL
(VDC) Off SWITCH*
12
POWER LIf TGATE SWITCH
13
POWER LIf TGATE MAIN SWITCH
14
DISTANCE CONTROL ASSIST
(DCA) S ySTEM SWITCH*
01
04
0605
08
07
22
23
25
24
282726
16171819
20
11121314
02
0321
15
TILT/TELESCOPIC STEERING
WHEEL SWITCH*
16
HEADLIGHT AIMING CONTROL
SWITCH*
17
WARNING S ySTEMS SWITCH
18
HEATED STEERING WHEEL SWITCH*
19
POWER INVERTER SWITCH
20
HOOD RELEASE*
21
CONTROL PANEL DISPLA y SCREEN*
22
CLIMATE CONTROL S ySTEM
23
AUDIO S ySTEM
24 fRONT PASSENGER AIR BAG
STATUS LIGHT*
25
POWER OUTLET
26
DRIVER’S CLIMATE CONTROLLED
SEAT SWITCH*
27
INfINITI DRIVE MODE SELECTOR*
28
PASSENGER’S CLIMATE
CONTROLLED SEAT SWITCH*
1009
Behind
steering wheel
Behind
steering wheel Behind
steering wheel
15

table of contents
new system features Remote Engine Start (if so equipped) ...............................2
INfINITI Connection™ System (if so equipped) ....................... 2
Around View Monitor with Moving Object Detection (MOD)
(if so equipped) ................................................ 4
Warning Systems Switch (if so equipped) ........................... 6
essential information Loose f uel Cap ................................................. 7
Tire Pressure Monitoring System (TPMS) with Tire Inflation Indicator .....7
Accessing the front Cup Holders ................................... 8
front Armrest/Center Console Storage Box ..........................8
first drive features INfINITI Intelligent Key™ System .................................. 9
Power Liftgate ................................................. 10
front Seat Adjustments ......................................... 11
2nd Row Seats ................................................ 11
3rd Row Seats ................................................. 12
Automatic Drive Positioner (if so equipped) .........................12
Outside Mirror Control Switch .................................... 12
Starting/Stopping the Engine .................................... 13
Headlight Control Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . 14
Windshield Wiper/Washer Switch ................................. 15
Automatic Climate Controls ...................................... 16
Rear Climate Controls ........................................... 18
fM/AM/XM
® Satellite Radio with CD/DVD Player (if so equipped) .......18
USB/iPod® Interface ........................................... 19
Conventional (fixed Speed) Cruise Control .........................19
Intelligent Cruise Control (ICC) System (if so equipped) ...............20
Power Outlets (if so equipped) ................................... 21
f uel-filler Door ................................................ 21
system guide Vehicle Information Display ..................................... 22
Bluetooth® Hands-free Phone System ............................. 23
System Operating Tips ....................................... 23
Bluetooth
® System without Navigation (if so equipped) . . . . . . . . . . . .24
Bluetooth® System with Navigation (if so equipped) ...............25
Navigation System (if so equipped) ............................... 28
Theater Package (if so equipped) ................................. 29
HomeLink
® Universal Transceiver (if so equipped) ................... 30
Additional information about your vehicle is also available in your Owner’s Manual,
Navigation System Owner’s Manual and at www.InfinitiUSA.com.
• A cellular telephone should not be used for any purpose while driving so full attention
may be given to vehicle operation.
• Always wear your seat belt.
• Supplemental air bags do not replace proper seat belt usage.
• Children 12 and under should always ride in the rear seat properly secured in child
restraints or seat belts according to their age and weight.
• Do not drink and drive.
For more information, refer to the “Safety –– Seats, seat belts and supplemental
restraint system (section 1)”, “Monitor, climate, audio, phone and voice recognition
systems (section 4)” and the “Starting and driving (section 5)” of your Owner’s Manual.

2
new system features
Remote Engine Start* (if so equipped)
your INfINITI Intelligent Key™ system allows the engine to start from
outside your vehicle. To use the remote start feature, perform the following:

1. Aim the INfINITI Intelligent Key at the vehicle. Operating range
is approximately 197 feet (60 m) from the vehicle.
2. Press the

button
01 to lock all doors.

3. Within 5 seconds press and hold the remote start

button
02
until the turn signal lights illuminate. If the vehicle is not within

view, press and hold the remote start button for about 2 seconds.

The parking lights will turn on and remain on as long as the engine
is running. The doors will be locked and the climate control system
may come on.

Repeat steps 1 - 3 to extend time an additional 10 minutes. A maximum of two remote starts,
or a single start with an extension, are allowed between ignition cycles.


Depress the brake and place the ignition switch in the ON position before driving.

To cancel a remote start, perform one of the following:
•
Aim the Intelligent Key at the vehicle and press and hold the

button until the parking
lights turn off.
•
Turn the hazard warning flashers on.
•
Cycle the ignition switch ON and then OFF.
*Laws in some communities may restrict the use of remote starters. Check local regulations before using this feature.
for more information, refer to the “Pre-driving checks and adjustments (section 3)” of your Owner’s Manual.
INFINITI Connection™ System* (if so equipped)
Infiniti Connection provides various types of information
and services by connecting your vehicle to the Infiniti
Connection Data Center. f or more details on the Infiniti
Connection service, terms and conditions, please refer
to www.Infiniticonnection.com.
Available services include:

Infiniti Personal Assistant – To access Infiniti Personal
Assistant, select “Connect to Voice Menu” from the Infiniti Connection menu or touch the


key (if available on the map screen). At the voice prompt, say “Infiniti Personal Assistant” to
be connected.
• your Infiniti Personal Assistant can send destination information directly to your vehicle.
To access, go to the Infiniti Connection menu and select “Sync All Information f eeds”.
Then go to the feeds menu page and download the desired destination information.

Automatic Collision Notification – In case of air bag deployment, a signal is sent containing
the vehicle location and customer information and notifies the proper authorities.
01
02
*Infiniti Connection™ is only available on vehicles equipped with optional Infiniti Connection™ subscription service.

3


Emergency Call (if so equipped) – This service provides emergency assistance by connecting
subscriber to an Infiniti Connection Specialist.
• In case of an emergency, press the in-vehicle
telematics SOS button

01 .
• A Response Specialist will provide assistance based
on the situation described by the vehicle’s occupant.

Enhanced Roadside Assistance (if so equipped) –
Roadside Assistance can be accessed by touching
the Infiniti Connection key on the Info menu, the

key (if available on the map screen) or by pressing the
SOS button.
• This service allows subscribers to receive assistance for a non-emergency incident such as
towing or a third party response.
• If warranted, Roadside Assistance may also be used in conjunction with the Emergency
Assistance service by pressing the SOS button.

My Schedule – Access your personal online Google Calendar™, hear details read via text-to-
speech** and select locations as a destination via the navigation system.

Report Stolen Vehicle – A Response Specialist will attempt to obtain location information
from a reported stolen vehicle and provide that information to local law enforcement agencies
to assist in the recovery of your stolen vehicle.

Remote Door Lock/Unlock – Remotely access your vehicle via Infiniti Connection Response
Specialist or designated website to remotely lock or unlock your vehicle.

Alarm Notification – This system will notify you when the factory-installed vehicle alarm
system has been activated.

Scheduled Maintenance Notification – Receive scheduled maintenance notifications based
on mileage data provided by your vehicle.

Maintenance Alert – Receive notification of a vehicle system malfunction that triggers
instrument panel warning lights.

Destination Assistance – Receive point-of-interest assistance via guided IVR (Interactive
Voice Response), Response Specialist, or Infiniti Connection web portal.

Destination Send-to Vehicle – find and download point-of interest information from
GoogleMaps™.

Connected Search – Select “Connected Search” from the Destination menu on the vehicle’s
navigation system to conduct a point-of-interest search within a certain distance of the
vehicle’s location.

Drive Zone – Monitor the movement of your vehicle within a specified region. Set up boundaries
in the Monitoring section of the Infiniti Connection web portal.

Max Speed Alert – Set up a maximum speed on the Infiniti Connection web portal. you will
receive notifications if your vehicle exceeds the max speed setting.
01
**Laws in some communities may restrict the use of text-to-speech. Check local regulations before using this feature.

4
new system features
Start from any Control Panel screen
Press
Press
Press
Press
Around View Monitor with Moving Object Detection (MOD) (if so equipped)
With the ignition switch in the ON position, the Around
View Monitor is activated by pressing the CAMERA
button

01 , located on the control panel, or by moving
the shift lever to the R (REVERSE) position. The control
panel displays various views of the position of
the vehicle.

When the shift lever is in the P (PARK), N (NEUTRAL)
or D (DRIVE) position and the CAMERA button

01 is
pressed, the following views will display in order:
01

Mobile Information Service (if so equipped) – Receive the latest news headlines, stock
quotes and sports scores by setting up preferences on the Mobile Information Service page
in the Infiniti Connection web portal.

Valet Alert – Use Valet Alert to set up a 0.2 mile radius around your vehicle.
•
Activate alerts by pressing the “Connect to Voice Menu” button on the Infiniti Connection
screen or by pressing the

key on the map screen.
• At the prompt, say “Valet Alert” and then “Activate” or “Deactivate”.
for more information, refer to the “Viewing technical information (section 7)” of your Navigation System Owner’s Manual.
front wide view front view & bird’s-eye viewfront view & front-side view

5


When the shift lever is in the R (REVERSE) position and the CAMERA button
01 is pressed,

the following views will display in order:
02
03
04
The colored guide lines on the display screen indicate vehicle width and approximate distances
to objects with reference to the vehicle body line.
• Red 1.5 ft (0.5 m); Yellow 3 ft (1 m); Green 7 ft (2 m) and 10 ft (3 m).
NOTE:

There are some areas where the system will not show objects.
•
When in the front or the rear view display, an
object below the bumper or on the ground may
not be viewed
02 .
•
When in the bird’s-eye view, a tall object near
the seam of the camera viewing areas
03

will not appear in the monitor.

The distance between objects viewed on the
AVM differs from the actual distance.

Objects in the bird’s-eye view will appear further
than the actual distance.
MOVING OBJECT DETECTION (MOD)

If the MOD system detects moving objects surrounding
the vehicle, a yellow frame

01 will be displayed on the
camera image and a chime sounds.

In the bird’s-eye view, a yellow frame is displayed on
those camera images (front, rear, right, left) where
moving objects are detected.
Rear view & bird’s-eye view
Press
PressPress Rear view & front-side view
Rear wide view
0102
04
03

Warning Systems Switch (if so equipped)
The warning systems switch
01 will turn on and
off the systems enabled in the vehicle information
display. The systems controlled by the warning
systems switch include:
• Lane Departure Warning (LDW) system/Lane
Departure Prevention (LDP) system
• Blind Spot Warning (BSW) system/Blind
Spot Intervention
™ (BSI) system
• Forward Collisions Warning (FCW) system

When the warning systems switch is turned off, the indicator
02 on the switch is off. If the

warning systems switch is illuminated, the system is on. The indicator will also be off if all of
the warning systems are deactivated using the settings menu.

To enable or disable these systems, perform the following operation:
•
Press the

button
03 on the steering wheel
multiple times until you reach the Settings menu.
•
Press up or down on the

button
04 , to select

Driver Assistance 05 and
Driving Aids
06
menu items.
• Press the ENTER button
04 to change a menu item.
f
or more information, refer to the “Starting and driving (section 5)” of
your Owner’s Manual.
6
new system features
03
04
05
06
01
02
When the following are displayed:
•
Blue MOD icon

02 ; the system is
operative in this view.
•
Gray MOD icon

03 ; the system is
not operative in this view.
•
No MOD icon; the system is off.

To temporarily turn the system on or off, touch the
04 key.
f
or more information, refer to the “Monitor, climate, audio, phone and voice recognition systems (section 4)” of your Owner’s Manual.
05
