2013 INFINITI EX Quick Reference Guide

2013 Infiniti EXQuick Reference Guide

*See your Owner’s Manual for information.
01
INSTRUMENT BRIGHTNESS
cONTROL SwITcH*
02
TRIP cOMPUTER S wITcHES
03
LO w TIRE PRESSURE wARNING LIGHT
04
HEADLIGHT AND TURN SIGNAL cONTROL
05 wINDSHIELD wIPER / w
ASHER SwITcH
06
STEERING wHEEL SwITcHE S FOR
AUDIO* / BLUETOOTH® / NAVIGATION
07
INTELLIGENT cRUISE c ONTROL BUTTONS
08
PUSH BUTTON IGNITION
09 w
ARNING SYSTEMS S wITcH*
10
INTELLIGENT BRAKE ASSIST (IBA)
OFF S wITcH*
11
DYNAMIc DRIVER ASSISTANc E SwIT cH*
12
INTELLIGENT KEY PORT
13
TILT / TELESc OPIc STEERING
wHEEL S wITcH*
14
HOOD RELEASE*
15
VEHIcLE DYNAMIc cONTROL (VDc)
OFF S wITcH*
16 c
ONTROL PANEL DISPLAY ScREEN*
17
AUDIO SYSTEM
18
AUTOMATIc cLIMATE cONTROLS
19
FRONT PASSENGER AIR BAG STATUS LIGHT*
01
Behind
steering wheel Behind
steering wheel
On
steering column
0405
08
0910
16
17
18
19
11
1213
14
02
03
0706
15Behind
steering wheel

table of contents
Additional information about your vehicle is also available in your Owner’s Manual, Navigation System Owner’s Manual and at www.InfinitiUSA.com.
• A cellular telephone should not be used for any purpose while driving so full attention
may be given to vehicle operation.
• Always wear your seat belt.
• Supplemental air bags do not replace proper seat belt usage.
• Children 12 and under should always ride in the rear seat properly secured in child
restraints or seat belts according to their age and weight.
• Do not drink and drive.
For more information, refer to the “Safety –– Seats, seat belts and supplemental
restraint system (section 1)”, “Monitor, climate, audio, phone and voice recognition
systems (section 4)” and the “Starting and driving (section 5)” of your Owner’s Manual.
new system features Blind Spot warning (BS w) System (if so equipped) ....................2
essential information Loose Fuel c ap ................................................. 3
Tire Pressure Monitoring System (TPMS) ............................ 3
first drive features INFINITI Intelligent Key™ System .................................. 4
Liftgate Release ................................................ 5
Seat Adjustments ............................................... 5
Automatic Drive Positioner (if so equipped) ..........................6
Outside Mirror c ontrol Switch ..................................... 6
Starting/Stopping the Engine ..................................... 7
Headlight control Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . 7
w indshield wiper/w asher Switch .................................. 8
c limate c ontrols (if so equipped) .................................. 9
FM/AM/SiriusXM
™ Satellite Radio with cD/DVD Player
(with Navigation System - if so equipped) .......................... 11
USB/iPod
® Interface (models with Navigation System - if so equipped) .... 12
c onventional (Fixed Speed) c ruise control ......................... 12
Intelligent c ruise control (Icc) System (if so equipped) ...............13
Fuel-Filler Door ................................................ 14
system guide Trip c omputer ..................................................... 15
Bluetooth® Hands-free Phone System (if so equipped) ..................15
System Operating Tips ........................................ 16
Bluetooth
® System with Navigation (if so equipped) ................16
Bluetooth® System without Navigation (if so equipped) .............18
Navigation System (if so equipped) ............................... 20
DVD Player (if so equipped) ...................................... 21
HomeLink
® Universal Transceiver (if so equipped) ................... 22

2
new system features
Blind Spot Warning (BSW) System (if so equipped)
The control switch is located on the left side of the
instrument panel.

The system automatically turns on when the engine
is started and the indicator light on the switch

01
illuminates.


The BS w indicator lights
02 , located next to the
outside mirrors, will activate when the BS w system
detects a vehicle in the detection zone.

If the turn signal is activated in the direction of a
detected vehicle, a chime sounds twice and the BS w
indicator light will flash.

To cancel the system, push the control switch and the
warning systems ON indicator will turn off.
For more information, refer to the “Instruments and controls (section 2)” and
the “Starting and driving (section 5)” of your Owner’s Manual.
01
02

3
Loose Fuel Cap
A LOOSE FUEL CAP warning message will appear in
the dot matrix liquid crystal display

01 when the
fuel-filler cap is not tightened correctly.

To tighten, turn the cap clockwise until a single click
is heard.

The warning message will disappear when the vehicle
detects the fuel-filler cap is properly tightened and the
reset button

02 is pressed.

If the cap is not properly tightened, the Malfunction
Indicator Light
may illuminate.
For more information, refer to the “Instruments and controls (section 2)” and
the “Pre-driving checks and adjustments (section 3)” of your Owner’s Manual.
Tire Pressure Monitoring System (TPMS)

A ChECk tIrE PrESSUrE warning message will
appear in the dot matrix liquid crystal display

01
and the low tire pressure warning light
02 will

illuminate when one or more tires are low on
pressure and air is needed.
• The tire pressures should be checked when the
tires are cold. The tires are considered cold after
the vehicle has been parked for 3 hours or more or
driven less than 1 mile (1.6km) at moderate speeds.

After tire pressures are adjusted, drive the vehicle at
speeds above 16 MPH (25km/h). The ChECk tIrE
PrESSUrE warning message and the low tire pressure
warning light will disappear.

when the low tire pressure warning light flashes for 1 minute and then remains on, the TPMS
is not functioning properly. Have the system checked by an INFINITI retailer.

Tire pressure rises and falls depending on the heat caused by the vehicle’s operation and the
outside temperature. Low outside temperature can lower the temperature of the air inside the
tire, which can cause a lower tire inflation pressure. This may cause the low tire pressure
warning light to illuminate. If the warning light illuminates in low ambient temperature,
check the tire pressure in your tires.
• Check the tire pressure (including the spare tire) often and always prior to long distance trips.

The Tire and Loading Information label contains valuable information. Please refer to section 9,
“Technical and consumer information”, in your Owner’s Manual for the location of the Tire and
Loading Information label.
For more information, refer to the “Instruments and controls (section 2)”, the “Starting and driving (section 5)” and the
“Maintenance and do-it-yourself (section 8)” of your Owner’s Manual.
essential information
01
01
02
02

4
first drive features
INFINITI Intelligent Key™ System
The INFINITI Intelligent Key™ System allows you to lock or
unlock your vehicle, open your liftgate and start the engine.
NOTE: It is important to make sure the Intelligent Key is
with you (that is, in your pocket or purse).

The operating range of the Intelligent Key is within
31.5 in (80 cm) from each request switch.

To lock the vehicle, push either door handle request
switch

01 or the liftgate request switch
02 or press
the

button
03 on the keyfob.

To unlock the vehicle, perform one of the following
procedures:
• Push either door handle request switch

01 or the
liftgate request switch
02 ; the corresponding door will unlock.
Push the door handle request switch
01 or the liftgate request
switch
02 again within 1 minute; all other doors will unlock, or
• Press the

button
04 on the keyfob to unlock the driver’s side

door. Press the

button again; all other doors will unlock.

The Intelligent Key can also be used to activate the panic alarm by
pressing and holding the

button
05 for more than 1 second. Once

activated, the panic alarm and headlights will stay on for 25 seconds.
INFINITI INTELLIGENT KEY
™ BATTERY DIScHARGE

If the battery in the Intelligent Key is almost discharged,
the guide light

06 of the Intelligent Key port blinks and
the Intelligent Key insertion indicator
07 is displayed
in the dot matrix liquid crystal display.

To start the engine under these circumstances, insert
the Intelligent Key into the key port with the keyring
side facing backward until it latches into place. Then
push the ignition switch to start the engine.

To remove the Intelligent Key from the port, push the
ignition switch to turn the engine off and then pull the
Intelligent Key out of the port.

The Intelligent Key port does not charge the Intelligent
Key battery. If you see the Intelligent Key warning light

08 , replace the battery in the Intelligent Key.
For more information, refer to the “Pre-driving checks and adjustments
(section 3)”, “Starting and driving (section 5)” and the “Maintenance
and do-it yourself (section 8)” of your Owner’s Manual.
01
02
03
04
05
F
E
07
08
06

5
Liftgate Release
Use one of the following methods to unlock the liftgate:
• Press the

button
01 on the INFINITI Intelligent
Key™ twice.
• Push the liftgate request switch

02 .

To open the liftgate, once unlocked, push the opener
switch

03 located just above the license plate and pull
the opener handle.
NOTE: It is important to make sure the Intelligent Key is with
you (that is, in your pocket or purse).
For more information, refer to the “Pre-driving checks and adjustments
(section 3)” of your Owner’s Manual.
Seat Adjustments
To slide the seat forward or backward, push the control
switch

01 forward or backward .


To recline the seatback, push the switch
02
forward or backward.
SEAT LIFTER

To adjust the angle of the front portion or height of the
seat, push the front or rear end of the switch


01 up or down.

PO wER LUMBAR SUPPORT (if so equipped for driver’s seat)

To adjust the seat lumbar support, push the front or back end of the switch
03 .
For more information, refer to the “Safety —— Seats, seat belts and supplemental restraint system (section 1)” of your

Owner’s Manual.
03
03
02
02
01
01

Outside Mirror Control Switch
To select the right or left side mirror, turn the control
switch

01 right or left.

To adjust the mirror angle, move the control switch

01 up, down, right or left.

To prevent accidentally moving the mirror, turn and
set the switch to the middle “neutral” position.
REVERSE TILT-DO wN FEATURE

when backing up the vehicle, the right or left outside mirror can be selected to automatically turn
downward to provide better rear visibility.
1. Push the ignition switch to the ON position.
2. Move the shift lever to the r (rEVErSE) position.
3. choose the right or left outside mirror by operating the outside mirror control switch

01 .
4. The selected outside mirror surface moves downward.

when one of the following conditions has occurred, the outside mirror surface will return to its
original position:

• The shift lever is moved to any position other than r (rEVErSE).
• The outside mirror control switch is set to the center “neutral” position.
• The ignition switch is pushed to the OFF position.
For more information, refer to the “Pre-driving checks and adjustments (section 3)” of your Owner’s Manual.
6
first drive features
Automatic Drive Positioner (if so equipped)

Two positions for the driver’s seat, steering column
and outside mirrors can be stored in the automatic
drive positioner memory.

Follow these procedures to set the memory positions:
• Confirm the shift lever is in the P (PArk) position.
• Push the ignition switch to the ON position.
• Adjust the driver’s seat, steering column and outside mirrors to the desired positions using
the adjusting switches for each feature.
• Push the SE t switch and within 5 seconds, push the memory switch (1 or 2) for at least
1 second.
• The indicator light on the memory switch you select will illuminate for approximately 5 seconds.
• The driver’s seat, steering column and outside mirror positions are now set to your preference.

These memorized positions can also be linked to your INFINITI Intelligent Key™.
For more information, refer to the “Pre-driving checks and adjustments (section 3)” of your Owner’s Manual.
01
