2013 HONDA ODYSSEY System message

371Maintenance
BatteryChecking the Battery
The battery condition is being monitored by
the sensor on the negative terminal. If there is
a problem with the sensor, the warning
message on information display
*/multi-
information display
* will let you know. Have
your vehicle checked by a dealer.
Check the battery terminals for corrosion
monthly.
If your vehicle's battery is disconnected or goes dead:
•The audio system is disabled.
2Reactivating the audio system P. 196
•The clock resets.
2Setting the Clock P. 108
•The navigation system
* is disabled.
2Refer to the navigation system manual
Charging the BatteryDisconnect both battery cables to prevent damaging your vehicle's electrical system.
Always disconnect the negative (–) cable first, and reconnect it last.
1BatteryWARNING: Battery post, terminals,
and related accessories contain lead
and lead compounds.
Wash your hands after handling.When you find corrosion, clean the battery terminals
by applying a baking powder and water solution.
Clean terminals with a damp towel. Cloth/towel dry
the battery. Coat the terminals with grease to help
prevent future corrosion.
3
WARNING
The battery gives off explosive hydrogen
gas during normal operation.
A spark or flame can cause the battery to
explode with enough force to kill or
seriously hurt you.
When conducting any battery
maintenance, wear protective clothing and
a face shield, or have a skilled technician do
it.
* Not available on all models

376Maintenance
Heating and Cooling System
*/Climate Control System
* Maintenance
Dust and Pollen FilterThe heating and cooling system/climate control system is equipped with a dust and
pollen filter that collects pollen, dust, and other debris in the air. The Maintenance
Minder
TM messages will let you know when to replace the filter.
We recommend that you replace the dust and pollen filter sooner when using your
vehicle in areas with high concentrations of dust.
1Dust and Pollen Filter
If the airflow from the heating and cooling system/
climate control system deteriorates noticeably, and
the windows fog up easily, the filter may need to be
replaced. Please contact a dealer for replacement.
* Not available on all models

391
uuIf a Tire Goes FlatuChanging a Flat Tire
Handling the Unexpected
If you replace a flat tire with the spare tire, the low tire pressure indicator comes on
while you are driving. After driving for a few miles (kilometers), the indicator will go
off and the TPMS indicator comes on, but this is normal.
If you replace the tire with a specified regular tire, the low tire pressure or TPMS
indicator will go off after a few miles (kilometers).
If you replace a flat tire with the spare tire, the low tire pressure/TPMS indicator
comes on while you are driving. After driving for a few miles (kilometers), the
indicator will start blinking for a short time and then stay on. CHECK TPMS
SYSTEM appears on the multi-information display, but this is normal.
If you replace the tire with a specified regular tire, the warning message on the
multi-information display and the TPMS indicator will go off after a few miles
(kilometers).■
TPMS and the Spare Tire
1TPMS and the Spare Tire
The system cannot monitor the pressure of the spare
tire. Manually check the spare tire pressure to be sure
that it is correct.
Use TPMS specific wheels. Each is equipped with a
tire pressure sensor mounted inside the tire behind
the valve stem.
Models with information displayModels with multi-information display

399
uuIndicator, Coming On/BlinkinguIf the Malfunction Indicator Lamp Comes On or Blinks
Handling the Unexpected
If the Malfunction Indicator Lamp Comes On or Blinks
■Reasons for indicator lamp to come on or blink
•Comes on when there is a problem with the engine emissions control
system, or the fuel fill cap is missing, or loose.
•Blinks when engine misfiring is detected.■What to do when the indicator lamp comes on
Avoid high speeds and immediately get your vehicle inspected at a
dealer.■What to do when the indicator lamp blinks
Park the vehicle in a safe place with no flammable items and wait at least
10 minutes or more with the engine stopped until it cools.
■The message appears on when:
An evaporative system leak is detected. This may be caused by the fuel fill cap being
loose or not being installed.■What to do when the message appears:
1.Stop the engine.
2.Check that the fuel fill cap is fully installed.
uIf not, loosen the cap, and then retighten it until it clicks at least once.
3.Drive for several days of normal driving.
uThe message should go off.■When the malfunction indicator lamp comes on
Malfunction indicator lamp comes on if the system continues to detect a leak of
gasoline vapor. If this happens, check the fuel fill cap using the procedures described
above.■
Check/Tighten Fuel Cap Message
1If the Malfunction Indicator Lamp Comes On or BlinksNOTICEIf you drive with the malfunction indicator lamp on,
the emissions control system and the engine could be
damaged.
If the malfunction indicator lamp blinks again when
restarting the engine, drive to the nearest dealer at
31 mph (50 km/h) or less. Have your vehicle
inspected.

Index
425Index
Index
AABS (Anti-lock Brake System).................. 310
AC Power Outlet...................................... 176
Accessories and Modifications................ 322
Accessory Power Sockets......................... 175
Additives
Coolant .................................................. 342
Engine Oil ............................................... 337
Washer ................................................... 346
Additives, Engine Oil............................... 337
Adjusting
Armrest .................................................. 167
Front Seats.............................................. 153
Head Restraints ....................................... 156
Mirrors.................................................... 151
Rear Seats ............................................... 161
Steering Wheel ....................................... 150
Temperature ........................................... 100
Air Conditioning System
(Climate Control System)....................... 186
Changing the Mode................................ 186
Defrosting the Windshield
and Windows........................................ 187
Dust and Pollen Filter .............................. 376
Recirculation/Fresh Air Mode................... 186
Sensors ................................................... 191
Using Automatic Climate Control............ 186
Air Conditioning System
(Heating and Cooling System)............... 182
Cooling................................................... 184Defrosting the Windshield
and Windows ........................................ 184
Dust and Pollen Filter ............................... 376
Heating ................................................... 183
Air Pressure....................................... 363, 413
Airbags........................................................ 39
Advanced Airbags ..................................... 45
After a Collision......................................... 43
Airbag Care ............................................... 53
Event Data Recorder .................................. 22
Front Airbags (SRS) .................................... 42
Indicator ........................................ 50, 76, 80
Passenger Airbag Off Indicator .................. 51
Sensors...................................................... 39
Side Airbag Cutoff System ......................... 48
Side Airbag Off Indicator ........................... 52
Side Airbags .............................................. 46
Side Curtain Airbags .................................. 49
AM/FM Radio............................................ 200
Anti-lock Brake System (ABS).................. 310
Indicator .................................................... 75
Armrest..................................................... 167
Audio Remote Controls............................ 198
Audio System............................................ 194
Adjusting the Sound ................................ 199
Auxiliary Input Jack .................................. 195
Error Messages ........................................ 230
General Information ................................ 232
MP3/WMA/AAC ...................................... 221
Reactivating............................................. 196
Recommended CDs ................................. 233Recommended Devices............................ 235
Remote Controls ..................................... 198
Security Code .......................................... 196
Theft Protection ...................................... 196
USB Adapter Cable.................................. 195
USB Flash Drives ...................................... 235
Audio/Information Display........................ 91
Authorized Manuals................................ 421
Auto Door Locking/Unlocking................. 115
Customize ............................................... 116
Automatic Lighting.................................. 142
Automatic Transmission........................... 294
Creeping ................................................. 294
Fluid ........................................................ 344
Kickdown ................................................ 294
Operating the Shift Lever................... 16, 296
Shift Lever Does Not Move ...................... 395
Shifting ................................................... 295
Auxiliary Input Jack.................................. 195
Average Fuel Economy.................. 88, 92, 99
Average Speed................................... 92, 100
BBattery...................................................... 371
Charging System Indicator................. 73, 398
Jump Starting .......................................... 393
Maintenance (Checking the Battery) ........ 371
Maintenance (Replacing) ................. 372, 374
Belts (Seat).................................................. 30
Beverage Holders..................................... 173

427Index
Keys........................................................ 109
Locking/Unlocking the Doors
from the Inside...................................... 113
Locking/Unlocking the Doors
from the Outside................................... 111
Lockout Prevention System ..................... 112
DOT Tire Quality Grading........................ 365
Driving...................................................... 279
Automatic Transmission .......................... 294
Braking ................................................... 308
Cruise Control ........................................ 297
Shifting Gear .......................................... 295
Starting the Engine ................................. 291
Driving Position Memory System............ 148
Dust and Pollen Filter.............................. 376EElapsed Time........................................ 92, 99
Electronic Stability Control (ESC)............ 300
Emergency................................................ 409
Emissions Testing (Readiness Codes)...... 417
Engine....................................................... 414
Coolant .................................................. 342
Jump Starting ......................................... 393
Oil .......................................................... 337
Starting................................................... 291
Switch Buzzer ......................................... 140
Engine Coolant........................................ 342
Adding to the Radiator ........................... 343
Adding to the Reserve Tank .................... 342Overheating ............................................ 396
Temperature Gauge .................................. 86
Engine Oil................................................. 337
Adding .................................................... 339
Checking ................................................. 338
Displaying Oil Life ............................ 327, 331
Low Oil Pressure Indicator.................. 72, 398
Recommended Engine Oil........................ 337
Exhaust Gas Hazard
(Carbon Monoxide).................................. 68
Exterior Care (Cleaning)........................... 379
Exterior Mirrors........................................ 152
FFeatures..................................................... 193
Filters
Dust and Pollen ....................................... 376
Oil ........................................................... 340
Flat Tire..................................................... 383
Flip-up Trash Bag Ring............................. 171
Floor Mats................................................. 378
Fluids
Automatic Transmission........................... 344
Brake....................................................... 345
Engine Coolant........................................ 342
Power Steering ........................................ 346
Windshield Washer.................................. 346
Fog Light Indicator..................................... 80
Folding Down the Rear Seats.......... 161, 165
Foot Brake................................................. 309Front Airbags (SRS)..................................... 42
Front Seats................................................ 153
Adjusting ................................................ 153
Fuel...................................................... 17, 318
Economy ................................................. 321
Gauge ....................................................... 86
Instant Fuel Economy .................... 88, 92, 99
Low Fuel Indicator ..................................... 75
Range ........................................... 88, 92, 99
Recommendation .................................... 318
Refueling................................................. 318
Fuel Economy........................................... 321
Fuel Fill Cap........................................ 17, 320
Message.................................................. 399
Fuel Fill Door...................................... 17, 319
Fuses.......................................................... 403
Inspecting and Changing......................... 408
Locations................. 403, 404, 405, 406, 407
GGasoline (Fuel)
Economy ................................................. 321
Gauge ....................................................... 86
Information ............................................. 318
Instant Fuel Economy .................... 88, 92, 99
Low Fuel Indicator ..................................... 75
Refueling................................................. 318
Gauges........................................................ 86
Gear Shift Lever Positions
Automatic Transmission .......................... 295

428Index
Glass (care)................................................ 380
Glove Box.................................................. 170
Grocery Bag Hooks................................... 178HHalogen Bulbs................................... 347, 351
Handling the Unexpected........................ 381
HandsFreeLink® (HFL)............................... 254
Automatic Answering .............................. 265
Automatic Import of Cellular Phonebook and
Call History ............................................ 267
Automatic Transferring ............................ 265
HFL Buttons ............................................. 254
HFL Menus .............................................. 256
HFL Status Display.................................... 255
Making a Call .......................................... 271
Options During a Call .............................. 276
Phone Setup ............................................ 259
Receiving a Call ....................................... 275
Speed Dial ............................................... 268
To Clear the System ................................. 266
To Create a Security PIN........................... 264
Hazard Warning Button............................... 2
Head Restraints......................................... 156
Headlights................................................. 141
Aiming .................................................... 347
Automatic Operation ............................... 142
Dimming ......................................... 141, 143
Operating ................................................ 141
Heaters (Seat)............................................ 180Heating and Cooling System................... 182
Cooling ................................................... 184
Defrosting the Windshield
and Windows ........................................ 184
Dust and Pollen Filter............................... 376
Heating ................................................... 183
HFL (HandsFreeLink®)............................... 254
High Beam Indicator.................................. 79
IIdentification Numbers............................ 414
Engine and Transmission ......................... 414
Vehicle Identification ............................... 414
Ignition Switch......................................... 140
Illumination Control................................. 146
Knob ....................................................... 146
Immobilizer System.................................. 133
Indicator.................................................... 80
Indicators.................................................... 72
ABS (Anti-lock Brake System)..................... 75
BSI (Blind Spot Information) System ........... 83
Charging System ............................... 73, 398
CRUISE CONTROL ............................. 81, 298
CRUISE MAIN .................................... 81, 297
Daytime Running Lights............................. 77
Door and Tailgate Open ...................... 29, 77
Fog Light ................................................... 80
Fuel Economy ............................................ 81
Hazard Warning ........................................ 79
High Beam ................................................ 79Immobilizer System ................................... 80
Lights On .................................................. 79
Low Fuel ................................................... 75
Low Oil Pressure ............................... 72, 398
Low Tire Pressure .............................. 78, 302
Low Tire Pressure/TPMS ............ 78, 302, 303
Maintenance Minder......................... 82, 327
Malfunction Indicator Lamp .............. 73, 399
Parking Brake and Brake System ....... 72, 400
Parking Sensor .......................................... 77
Power Sliding Door ................................... 83
Power Tailgate .......................................... 82
Seat Belt Reminder.............................. 31, 75
Security System Alarm............................... 81
Shift Lever Position.................................... 74
Side Airbag Off ................................... 52, 80
Starter System........................................... 81
Supplemental Restraint System ........... 50, 76
System Message ....................................... 79
TPMS ................................................ 78, 304
Transmission ............................................. 74
Turn Signal ............................................... 79
VSA® (Vehicle Stability Assist)
System ............................................ 76, 300
VSA® OFF.......................................... 76, 301
Washer Level ............................................ 82
Information.............................................. 411
Information Display................................... 87
Instant Fuel Economy.................... 88, 92, 99
Instrument Panel........................................ 71
Brightness Control .................................. 146

430Index
OOdometer.............................................. 87, 99
Oil (Engine)............................................... 337
Adding .................................................... 339
Checking ................................................. 338
Displaying Oil Life ............................ 327, 331
Low Oil Pressure Indicator .................. 72, 398
Recommended Engine Oil ........................ 337
Viscosity .................................................. 337
Opening/Closing
Hood ....................................................... 336
Moonroof ................................................ 139
Power Windows ...................................... 136
Sliding Door............................................. 125
Tailgate ................................................... 119
Outside Temperature Display............ 89, 100
Overheating.............................................. 396PPanic Mode............................................... 135
Parking...................................................... 312
Parking Brake............................................ 308
Parking Brake and Brake System
Indicator............................................ 72, 400
Parking Sensor System.............................. 313
Passenger Airbag Off Indicator................. 51
Passing Indicators..................................... 141
Power Sliding Door................................... 127
Power Tailgate.......................................... 121
Power Windows........................................ 136Precautions While Driving....................... 293
Rain ........................................................ 293
Pregnant Women....................................... 37
Puncture (Tire).......................................... 383
RRadiator.................................................... 343
Radio (AM/FM)......................................... 200
Radio Data System (RDS)......................... 203
Range.............................................. 88, 92, 99
RDS (Radio Data System)......................... 203
Readiness Codes (Emissions Testing)....... 417
Rear Defogger/Heated Door Mirror
Button..................................................... 147
Rear Entertainment System..................... 236
Rear Seats (Folding Down).............. 161, 165
Rearview Camera..................................... 317
Rearview Mirror....................................... 151
Refueling.................................................. 318
Fuel Gauge................................................ 86
Gasoline .......................................... 318, 412
Low Fuel Indicator ..................................... 75
Regulations............................... 303, 365, 415
Remote Transmitter................................. 111
Removable Center Console...................... 170
Removing a Second Row Outer Seat...... 162
Removing the Second Row
Center Seat............................................. 164
Replacement
Battery ............................................ 372, 374Bulbs ...................................................... 347
Fuses ...................... 403, 404, 405, 406, 407
Tires........................................................ 368
Wiper Blade Rubber ................................ 358
Reporting Safety Defects......................... 416
Resetting a Trip Meter......................... 88, 99
SSafe Driving................................................ 25
Safety Check............................................... 29
Safety Labels.............................................. 69
Safety Message.......................................... 23
Seat Belts.................................................... 30
Adjusting the Shoulder Anchor ........... 34, 35
Automatic Seat Belt Tensioners ................. 32
Checking .................................................. 38
Fastening .................................................. 33
Installing a Child Seat with a Lap/Shoulder
Seat Belt ................................................. 62
Pregnant Women...................................... 37
Reminder .................................................. 31
Warning Indicator ............................... 31, 75
Seat Heaters............................................. 180
Seats.......................................................... 153
Adjusting ................................................ 153
Front Seats.............................................. 153
Rear Seats ............................................... 161
Seat Heaters ........................................... 180
