2013 HONDA INSIGHT bulb

This indicator reminds you that the
exterior lights are on. It comes on
when the light switch is in either theor position. If you turn the
ignition switch to the ACCESSORY
(I) or the LOCK (0) position without
turning of f the light switch, this
indicator will remain on. A reminder
chime will also sound when you open
the driver’s door.
This indicator comes on with the
high beam headlights. For more
inf ormation, see page .
This indicator also comes on with
reduced brightness when the
daytime running lights (DRL) are on
(see page ).
The lef t or right turn signal indicator
blinks when you signal a lane change
or turn. If an indicator does not blink
or blinks rapidly, it usually means
one of the turn signal bulbs is
burned out (see pages and ).
Replace the bulb as soon as possible,
since other drivers cannot see that
you are signaling.
When you press the hazard warning
button, both turn signal indicators
and all turn signals on the outside of
the vehicle f lash.
This indicator comes on when you
turn on the cruise control system by
pressing the CRUISE button on the
steering wheel (see
page).
This indicator comes on when you
set the cruise control. See page
f or inf ormation on operating the
cruise control.
121
123
325 327
222
222On LX and EX models
On LX and EX models
Cruise Main Indicator
Lights On Indicator
High Beam Indicator
Turn Signal and
Hazard Warning
Indicators
Cruise Control Indicator
Instrument Panel Indicators
69
12/07/13 16:45:59 31TM8630_074
Inst rument s and Cont rolsTOC
2013 Insight

CONT INUED
Open the hood.
Your vehicle has halogen headlight
bulbs. When replacing a bulb,
handle it by its base, and protect the
glass from contact with your skin or
hard objects. If you touch the glass,
clean it with denatured alcohol and a
clean cloth. Theheadlightswereproperlyaimed
when your vehicle was new. If you
regularly carry heavy items in the
cargo area, readjustment may be
required. Adjustments should be
done by your dealer or another
qualif ied technician.
To change the bulb on the right
side, remove the upper part of the
windshield washer reservoir tank.
Use a f lat-tip screwdriver to
remove the holding clip, then
remove the upper part by pulling it
straight up.Remove the electrical connector
f rom the cover by pushing on the
tab to unlock it, then slide the
connector of f the cover.
Remove the cover on the back of
the headlight assembly by turning
it counterclockwise.
1.
2.
3.
Headlight A iming
Replacing a Headlight Bulb
Lights
High Beam Headlight
321
HOLDING CLIP
CONNECTOR
Halogen headlight bulbs get very hot
when lit. Oil, perspiration, or a scratch
on the glass can cause the bulb to
overheat and shatter.
12/07/13 17:17:39 31TM8630_326
Maint enanceTOC
2013 Insight

Remove the electrical connector
from the bulb by pushing onRemove the bulb f rom the
headlight assembly by turning it
one-quarter turn counterclockwise.Install the new bulb, and turn it
one-quarter turn clockwise to lock
it in place.
Push the electrical connector back
onto the bulb. Make sure it is on
all the way.
Reinstall the cover over the back
of the headlight assembly and turn
it clockwise to lock it in place.
Push the electrical connector back
onto the cover.
Turn on the headlights to test the
new bulb.
4.
5. 6.
7.
8.
9.
Lights
322
BULB
COVER
CONNECTOR
12/07/13 17:17:46 31TM8630_327
Maint enanceTOC
the tab and pulling the
connector down.
Install the upper part of the
windshield washer reservoir tank
in the reverse order of removal. (Right side)
10.
2013 Insight

Install the new bulb, and turn it
one-quarter turn clockwise to lock
it in place.
Push the electrical connector back
onto the bulb. Make sure it is on
all the way.
Turn on the headlights to test the
new bulb.
Remove the bulb f rom the
headlight assembly by turning it
one-quarter turn counterclockwise. Remove the electrical connector
f rom the bulb by pushing on the
tab and pulling the connector
down. Open the hood.
3. 4.
5.
6.
2. 1.
Lights
L ow Beam Headlight
323
BULB
CONNECTOR
12/07/13 17:17:54 31TM8630_328
Maint enanceTOC
2013 Insight

Open the hood.
To change the bulb on the right
side, remove the upper part of the
windshield washer reservoir tank.
Use a f lat-tip screwdriver to
remove the holding clip, then
remove the upper part by pulling it
straight up.Remove the socket from the
headlight assembly by turning it
one-quarter turn counterclockwise.
Pull the bulb straight out of its
socket. Push the new bulb straight
into the socket until it bottoms.Install the socket back into the
headlight assembly. Turn it
clockwise to lock it in place.
Turn on the lights to make sure
the new bulb is working.
Install the upper part of the
windshield washer reservoir tank
in the reverse order of removal. (Right side)
6.
1. 2.
3.4.
5.
Lights
Replacing a Front
Parking Light Bulb
324
BULB
HOLDING CLIP
SOCKET
12/07/13 17:18:03 31TM8630_329
Maint enanceTOC
2013 Insight

Remove the socket f rom the f ront
turn signal light assembly by
turning it one-quarter turn
counterclockwise.Pull the bulb straight out of its
socket. Push the new bulb straight
into the socket until it bottoms.
Insert the socket back into the
f ront turn signal light assembly.
Turn it clockwise to lock it in place.
Turn on the lights to make sure
the new bulb is working.
Install the garnish in the original
position securely.
Placeaclothonthenotchof the
light assembly garnish to prevent
scratches. Remove the cover by
caref ully prying in the notch with a
f lat-tip screwdriver. Remove the bolts and pull the
f ront turn signal light assembly
from the bumper while taking the
tab out from the holder.
Install the light assembly in the
reverse order of removal. Make
sure to secure the bolts.
5.
6.
1. 7.
8.
3. 4.
2.
Lights
Replacing the Front
Turn Signal Light Bulb
325
NOTCH
COVER
BOLTSBULB
SOCKET
12/07/13 17:18:12 31TM8630_330
Maint enanceTOC
2013 Insight

Open the hood.
Remove the socket from the
headlight assembly by turning it
one-quarter turn counterclockwise.Pull the bulb straight out of its
socket. Push the new bulb straight
into the socket until it bottoms.
Install the socket back into the
headlight assembly. Turn it
clockwise to lock it in place.
Turn on the lights to make sure
the new bulb is working.
2. 3.
4.
5.
1.
Lights
Replacing a Front
Side Marker Light Bulb
326
BULB
SOCKET
12/07/13 17:18:19 31TM8630_331
Maint enanceTOC
2013 Insight

CONT INUED
Open the hatch.
Push on the area of the trim as
shown in the illustration above to
detach the upper hooks f rom the
light assembly.Pry on the gap between the trim
and light assembly caref ully with a
flat-tip screwdriver to detach the
lower hooks.
Make sure that all hooks are
removed f rom the light assembly.
Unclip the top half of the trim
fromthebodybypullingitout.
Then unclip the bottom half.
1.
2. 3.
4.
Lights
Replacing the Rear Bulbs
327
HOOKS
TRIM HOOKS CLIP
CLIP
12/07/13 17:18:27 31TM8630_332
Maint enanceTOC
2013 Insight
