2013 HONDA FIT Owners Manual

264
Handling the Unexpected
Emergency Towing
Call a professional towing service if you need to tow your vehicle. ■Flat bed equipment
The operator loads your vehicle on the back of a truck.
This is the best way to transport your vehicle. ■ Wheel lift equipment
The tow truck uses two pivoting arms that go under the front tires and lift them off
the ground. The rear tires remain on the ground. This is an acceptable way to
tow your vehicle.1Emergency Towing
NOTICE
Trying to lift or tow your vehicle by the bumpers will
cause serious damage. The bumpers are not designed
to support the vehicle’s weight.
NOTICE
Improper towing such as towing behind a
motorhome or other motor vehicle can damage the
transmission.
Never tow your vehicle with just a rope or chain.
It is very dangerous, since ropes or chains may shift from side to side or break.
Main Menu
Main MenuTable of Contents

Continued265
uuEmergency Towingu
Handling the Unexpected
For very short distances, such as freeing the vehicle, you can use the detachable
towing hook that mounts on the anchors in the front and rear bumpers.
1.Put cloth on the edge of the cover.
Carefully pry with a small flat-tip
screwdriver or a metal fingernail file to remove the cover.
2. Take the towing hook and the jack handle
bar out of the tool bag in the cargo area.
3. Screw the towing hook into the hole, and
tighten it with the jack handle bar.
■Towing Hook1Towing Hook
NOTICE
To avoid damage to your vehicle, use the towing hook for straight, flat ground towing only. Do not
tow at an angle. This hook should not be used to tow
the vehicle onto a flat bed. Do not use it as a tie down.
Make sure to use the properly-designed and attached
towing equipment.
NOTICE
Do not slip the clutch for a long time to get unstuck.
This may overheat and damage the transmission.
Cover
Towing Hook
Jack Handle Bar
Main Menu
Main MenuTable of Contents

uuEmergency Towingu
266
Handling the Unexpected
If you cannot open the tailgate use the following procedure.1.Use a flat-tip screwdriver and remove the
cover on the back of the tailgate.
2. To open the tailgate, push the tailgate
while pushing the lever to the unlocking
direction.
■When You Cannot Open the Tailgate
Models without tailgate key cylinder
1When You Cannot Open or Close the Tailgate
What to do-Following up
After taking these steps, contact a dealer to have the
vehicle checked.
When you open the tailgate from inside, make sure
there is enough space around the tailgate, and it
does not hit anyone or any object.
Cover
Lever
Lock Unlock
Main Menu
Main MenuTable of Contents

267
Information
This chapter includes your vehicle’s specifications, locations of identification numbers, and other
information re quired by regulation.
Specifications.................................... 268
Identification Numbers Vehicle Identification Number (VIN) .. 270
Engine Number and Transmission
Number.......... ............................ 270
Devices that Emit Radio Waves ....... 271
Reporting Safety Defects ................. 272Emissions Testing
Testing of Readiness Codes.............. 273
Warranty Coverages ........................ 275
Authorized Manuals ......................... 277
Customer Service Information ......... 278
Main Menu
Main Menu

268
Information
Specifications
■Vehicle Specifications
ModelHonda Fit
No. of Passengers:
Front 2
Rear 3
Total 5
Weights:Gross Vehicle
Weight Rating U.S.: 3,512 lbs (1,594 kg)
Canada: 1,594 kg
Gross Axle Weight
Rating (Front)U.S.: 1,921 lbs (872 kg)
Canada: 872 kg
Gross Axle Weight
Rating (Rear)U.S.: 1,619 lbs (735 kg)
Canada: 735 kg
Air Conditioning:
Refrigerant Type HFC-134a (R-134a)
Charge Quantity 13.1 – 14.8 oz (370 – 420 g)
Lubricant Type SP-10
■Engine Specifications
■Fuel
■Battery
■Washer Fluid
Displacement91.3 cu-in (1,497 cm 3
)
Spark Plugs NGK IZFR6K13
DENSOSKJ20DR-M13
Fuel: TypeUnleaded gasoline, Pump octane number
of 87 or higher
Fuel Tank Capacity 10.6 US gal (40 )
Capacity/Type32AH(5)/40AH(20)
34AH(5)/40AH(20)
Tank CapacityU.S.: 2.6 US qt (2.5 )
Canada: 4.8 US qt (4.5 )
■Light Bulbs
*1: Sport models
*2: Not available on all models
Headlights (High/Low Beam)60/55W (HB2)
Fog Lights *1
55W (H11)
Parking/Side Marker Lights3.8W (Amber)
Front Turn Signal Lights 21W (Amber)
Brake/Taillights21/5W
Back-Up Lights 16W
Rear Turn Signal Lights21W (Amber)
High-Mount Brake Light LED
Rear License Plate Light5W
Cargo Area Light 5W
Center Console Light *21.4W
Interior Lights
Map Lights *28W
Ceiling Light 8W
Main Menu
Main MenuTable of Contents

269
uuSpecificationsu
Information
■Brake/Clutch Fluid
■Automatic Transmission Fluid
■Manual Transmission Fluid
SpecifiedHonda Heavy Duty Brake Fluid DOT 3
SpecifiedHonda ATF DW-1
(automatic transmission fluid)
Capacity Change 2.6 US qt (2.5 )
SpecifiedHonda Manual Transmission Fluid
Capacity Change 1.6 US qt (1.5 )
■Engine Oil
■Engine Coolant
*1: Automatic transmission models
*2: Manual transmission models
Recommended·Genuine Honda Motor Oil 0W-20
·API Premium-grade 0W-20 detergent oil
Capacity Change 3.6 US qt (3.4 )
Change
including filter
3.8 US qt (3.6 )
SpecifiedHonda Long-Life Antifreeze/Coolant Type2
Ratio 50/50 with distilled water
Capacity
1.18 US gal (4.47 ) *1
(change including the remaining
0.116 US gal (0.44 ) in the reserve tank)
1.15 US gal (4.37 ) *2

(change including the remaining
0.116 US gal (0.44 ) in the reserve tank)
■Tire
*1: All models except Sport models
*2: Sport models
*3: U.S. models and Canadian manual transmission models
RegularSize175/65R15 84S *1
185/55R16 83H *2
Pressure
psi (kPa[kgf/cm
2
])32 (220 [2.2]) *1
33 (230 [2.3]) *2
Compact
Spare Size T135/80D15 99M
*3
Pressure
psi (kPa[kgf/cm 2
]) 60 (420 [4.2])
*3
Wheel SizeRegular15 x 5 1/2J
*1
16 x 6J *2
Compact Spare15 x 4T *3
Main Menu
Main MenuTable of Contents

270
Information
Identification Numbers
Vehicle Identification Number (VIN)
Your vehicle has a 17-digit vehicle identification number (VIN) used to register your
vehicle for warranty purposes, and for licensing and insuring your vehicle. See the
image below for the VIN locations.
Engine Number and Transmission Number
See the image below for the locations of your vehicle’s engine number and transmission number.
Vehicle Identification Number
Engine Number
Certification Label
Manual Transmission
Number
Automatic Transmission
Number
Main Menu
Main MenuTable of Contents

271
Information
Devices that Emit Radio Waves
The following products and systems on your vehicle emit radio waves when in
operation.
Each of the above complies with the appropriate requirements or the required
standards of FCC (Federal Communications Commission) and Industry Canada
Standard, described below: As required by the FCC: This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any interference received, i ncluding interference that may cause
undesired operation. Changes or mo difications not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
This device complies with Ind ustry Canada Standard RSS-Gen/210/310.
Operation is subject to the following two conditions: (1) this device may not cause
interference, and (2) this device must accept any interference, including interference
that may cause undesired operation of the device.
Audio SystemBluetooth ® Audio
Bluetooth ® HandsFreeLink ®Immobilizer System
Remote TransmitterTire Pressure Monitoring System (TPMS)
U.S. models
U.S. models
