2013 HONDA CROSSTOUR key

507
Continued
Maintenance
Remote Transmitter Care
Replacing the Button Battery
If the indicator does not come on when the button is pressed, replace the battery.
1.Unscrew the cover with a small Phillips-
head screwdriver.
2. Open the remote transmitter.
uWrap the small flat-tip screwdriver with a
cloth to prevent scratching the
transmitter.
3. Remove the button battery with the small flat-tip screwdriver.
4. Make sure to replace the battery with the
correct polarity.
■Master Keys with Remote Transmitter *
1Replacing the Button Battery
NOTICEAn improperly disposed of battery can damage the
environment. Always confirm local regulations for battery disposal.
Replacement batteries are commercially available or
at a dealer.
ScrewBattery type: CR1620
Battery
* Not available on all models
Main MenuTable of contents

508
uuRemote Transmitter CareuReplacing the Button Battery
Maintenance
1.Remove the built-in key.
2. Remove the upper half by carefully prying
on the edge with a coin.
uRemove carefully to avoid losing the
buttons.
uWrap a coin with a cloth to prevent
scratching the smart entry remote.
3. Make sure to replace the battery with the
correct polarity.
■Smart Entry Remote *
Battery type: CR2032
Battery
* Not available on all models
Main MenuTable of contents

531
Handling the Unexpected
Shift Lever Does Not Move
Follow the procedure below if you cannot move the shift lever out of the (P
position.
1.Set the parking brake.
2. Remove the key from the ignition switch.
2. Remove the built-in key from the smart entry remote.
3. Wrap a cloth around the tip of a small flat-
tip screwdriver. Put it into the shift lock
release slot as shown in the image, and remove the cover.
4. Insert the key into the shift lock release slot.
5. While pushing the key down, press the shift
lever release button and place the shift lever
into
(N .uThe lock is now released. Have the shift
lever checked by a dealer as soon as
possible.
■Releasing the Lock
Slot
Cover
Models without smart entry system
Models with smart entry system
All models
Release
Button
Shift Lock Release Slot
Main MenuTable of contents

540
uuFusesuFuse Locations
Handling the Unexpected
*1:4-cylinder models
*2:6-cylinder models
*3:Sub fuse box
17Accessory, Key, Lock7.5 A18Accessory7.5 A19Left Power Seat Sliding20 A20Moonroof20 A21Left Power Seat Reclining20 A22Rear Left Power Window20 A
23Front Accessory Power Socket15 A
24Front Left Power Window20 A25Left Door Lock15 A26Front Left Fog Light10 A27Left Small Lights (Exterior)10 A28Left Headlight High Beam10 A29TPMS7.5 A30Left Headlight Low Beam15 A31−−
32*3 ST MG DIODE
*, *1
7.5 A
Stop *, *2
7.5 A
33*3STRLD *7.5 A
Circuit ProtectedAmps
Circuit ProtectedAmps1Right Headlight High Beam10 A2Right Small Lights (Exterior)10 A3Front Right Fog Light10 A4Right Headlight Low Beam15 A5−−6Interior Lights7.5 A7−−8Right Power Seat Reclining20 A9Right Power Seat Sliding20 A10Right Door Lock10 A11Rear Right Power Window20 A12SMART *10 A13Front Right Power Window20 A14−−15Audio Amp20 A
16Accessory Power Socket
(Cargo Area)15 A
17−−18Power Lumbar *7.5 A19Seat Heaters
*15 A20−−21−−22−−
Passenger side
* Not available on all models
Main MenuTable of contents

564
Index
Keys .......................................................... 91
Locking/Unlocking the Doors from the Inside ....................................................... 99
Locking/Unlocking the Doors from the
Outside .................................................... 94
Lockout Prevention System ........................ 98
DOT Tire Quality Grading ........................ 500
Driver

566
Index
Information Display.................................... 84
Instrument Panel ........................................ 69
Brightness Control ................................... 125
Interface Dial ............................................ 215
Interior Lights ........................................... 142
Interior Rearview Mirror .......................... 130
J
Jack (Wheel Nut Wrench) ......................... 521
Jump Starting ............................................ 528
K
Key Number Tag ......................................... 92
Keyless Lockout Prevention ....................... 98
Keys ............................................................. 91
Lockout Prevention .................................... 98
Master Keys ............................................... 91
Number Tag .............................................. 92
Rear Door Won’t Open ............................ 100
Remote Transmitter ................................... 94
Types and Functions .................................. 91
Valet Key ................................................... 92
Won’t Turn ................................................ 22
Kickdown (Automatic Transmission) ....... 425
L
Lane Departure Warning (LDW) .............. 439
LaneWatch

569
Index
Warning Indicators.................................... 70
Trunk Light Bulb ....................................... 546, 548
Turn Signals .............................................. 119
Indicators (Instrument Panel) ..................... 78
U
Unlocking the Doors .................................. 94
USB Adapter Cable .......................... 164, 165
USB Flash Drives ....................................... 280
Using the Smart Entry with Push Button
Start System .............................................. 96
V
Valet Key .................................................... 92
Vanity Mirrors .............................................. 5
Vehicle Identification Number ................ 550
Vehicle Stability Assist (VSA ®) ................. 442
Off Button .............................................. 443
Off Indicator ............................................. 73
System Indicator ....................................... 73
Ventilation ............................................... 158
Viscosity (Oil) ............................ 472, 547, 549
VSA ® (Vehicle Stability Assist) ................. 442
W
Warning and Information Messages ........ 82
Warning Indicator On/Blinking ............... 534
Warning Labels .......................................... 67 Warranties (Warranty Manual provided
separately) ............................................... 555
Watts ................................................. 546, 548
Wear Indicators (Tire) ............................... 502
Wheel Nut Wrench (Jack Handle) ........... 521
Window Washers ...................................... 123
Adding/Refilling Fluid............................... 483
Switch ..................................................... 123
Windows (Opening and Closing) ............. 110
Windshield ................................................ 123
Cleaning.................................................. 513
Defrosting/Defogging ...................... 156, 159
Washer Fluid ........................................... 483
Wiper Blades ........................................... 493
Wipers and Washers ................................ 123
Winter Tires .............................................. 505
Snow Tires............................................... 505
Tire Chains .............................................. 505
Wipers and Washers ................................. 123
Checking and Replacing Wiper Blades ..... 493
Front ....................................................... 123
Rear ........................................................ 124
WMA ................. 173, 179, 200, 210, 239, 263
Worn Tires ................................................. 497
X XM ® Radio ......................................... 197, 236
