2013 HONDA CIVIC HYBRID odometer

83
uuGauges and intelligent Multi-Information Display (i-MID)uintelligent Multi-Information Display (i-MID)
Continued
Instrument Panel
intelligent Multi-Information Display (i-MID)The i-MID shows the odometer, trip meter, outside temperature indicator, and other
gauges.
It also displays important messages such as warnings and other helpful information.
Press the button to change the display.■Switching the Display

(Display/
Information
Button)
Fuel Consumption
Power Flow Monitor
Full Size Analogue Clock/Wallpaper Audio/HFL Display
Black Screen Ecological Drive
Display

84
uuGauges and intelligent Multi-Information Display (i-MID)uintelligent Multi-Information Display (i-MID)
Instrument Panel
■Trip computer
Press the (Select/Reset) knob to change the display.
Odometer
Outside temperatureTrip A
Trip B
(Select/Reset) Knob

uuGauges and intelligent Multi-Information Display (i-MID)uintelligent Multi-Information Display (i-MID)
86Instrument Panel
Shows the total number of miles or kilometers that your vehicle has accumulated.
Shows the total number of miles or kilometers driven since the last reset. Meters A
and B can be used to measure two separate trips.■Resetting a trip meter
To reset a trip meter, display it, then press and hold the knob. The trip meter is
reset to 0.0.
Shows the estimated average fuel economy of each trip meter in mpg or l/100 km.
The display is updated at set intervals. When a trip meter is reset, the average fuel
economy is also reset.
Shows the estimated distance you can travel on the remaining fuel. This distance is
estimated from the fuel economy of your trips in the past.
Shows the time elapsed since the last time Trip A or Trip B was reset.■Odometer■Trip Meter■Average Fuel Economy■Range■Elapsed Time
1Trip Meter
Switch between trip meter A and trip meter B by
pressing the knob, or by using the customized
features on the i-MID.
2Customized Features P. 911Average Fuel Economy
You can change the way the average fuel economy is
reset.
2Customized Features P. 911Range
You can choose an item to be displayed in the fuel
consumption screen. Range, elapsed time, or average
speed can be selected.
2Customized Features P. 91

92
uuGauges and intelligent Multi-Information Display (i-MID)uintelligent Multi-Information Display (i-MID)
Instrument Panel
■Customization flow
Press the MENU button.
1Customized Features
You can exit the customizing screen at any time by
pressing the MENU button.
Vehicle MenuVehicle InformationOdometer/Trip MeterAdjust Clock
*
Fuel Consumption HistoryMaintenance infoTrip Meter ResetSelect Trip/Odometer
* Not available on all models

95
uuGauges and intelligent Multi-Information Display (i-MID)uintelligent Multi-Information Display (i-MID)
Continued
Instrument Panel
■List of customizable options
*1: Models without navigation system
*2: Default SettingSetup Group Customizable Features Description Selectable settingsVehicle
Information
Fuel Consumption
History
Show the fuel consumption history.
—
Maintenance
Information
Reset the Maintenance Minder
TM.
No/Yes
Odometer/
Trip MeterTrip Meter ResetReset the trip meter.Trip A/Trip B
Select Trip/OdometerSwitch between odometer, trip meter A, and trip
meter B.Odometer/Trip A/Trip B
Adjust
Clock
*1
Select Time Display
Select time display 12 hour or 24 hour and adjust
the time.
12 h
*2/24 h

336Information
Customer Service InformationHonda dealership personnel are trained professionals.
They should be able to answer all your questions. If you encounter a problem that
your dealership does not solve to your satisfaction, please discuss it with the
dealership’s service manager or general manager. If you are dissatisfied with the
decision made by the dealership’s management, contact Honda Customer Services.
U.S. Owners:
American Honda Motor Co., Inc.
Honda Automobile Customer Services
Mail Stop 500-2N-7A
1919 Torrance Blvd.
Torrance, CA 90501-2746
Tel: (800) 999-1009Canadian Owners:
Honda Canada Inc.
Customer Relations
180 Honda Boulevard
Markham, ON
L6C 0H9
Tel: 1-888-9-HONDA-9
Fax: 1-877-939-0909
E-mail: [email protected]
In Puerto Rico and the U.S. Virgin
Islands:
Bella International
P.O. Box 190816
San Juan, PR 00919-0816
Tel: (787) 620-7546
1Customer Service Information
When you call or write, please give us the following
information:•Vehicle Identification Number
2Vehicle Identification Number (VIN)
P. 328•Date of purchase•Odometer reading of your vehicle•Your name, address, and telephone number•A detailed description of the problem•Name of the dealer who sold the vehicle to you

342Index
Multi-Information Display.......................... 83NNumbers (Identification).......................... 328OOdometer.................................................... 86
Oil (Engine)............................................... 261
Adding .................................................... 263
Checking ................................................. 262
Displaying Oil Life .................................... 255
Low Oil Pressure Indicator .................. 72, 317
Recommended Engine Oil ........................ 261
Viscosity .................................................. 261
Opening/Closing
Hood ....................................................... 260
Power Windows ...................................... 117
Trunk....................................................... 112
Outside Temperature Display.................... 87
Overheating.............................................. 315PPandora®................................................... 161
Panic Mode............................................... 116
Parking...................................................... 244
Parking Brake............................................ 240
Parking Brake and Brake System
Indicator............................................ 68, 319
Passenger Airbag Off Indicator................. 50Passing Indicators..................................... 120
Playing Bluetooth® Audio........................ 166
Power Flow Monitor.................................. 90
Power Windows....................................... 117
Precautions While Driving....................... 217
Rain ........................................................ 217
Pregnant Women....................................... 37
Puncture (Tire).......................................... 305
RRadiator.................................................... 267
Radio (AM/FM)......................................... 150
Radio Data System (RDS)......................... 152
Range.......................................................... 86
RDS (Radio Data System)......................... 152
Readiness Code (Emissions Testing)........ 331
Rear Defogger/Heated Door Mirror
Button..................................................... 126
Rearview Mirror....................................... 128
Refueling.................................................. 246
Fuel Gauge................................................ 82
Gasoline .......................................... 246, 326
Low Fuel Indicator ..................................... 70
Regulations............................... 238, 281, 329
Remote Transmitter................................. 107
Replacement
Battery .................................................... 288
Bulbs ....................................................... 271
Fuses ............................................... 321, 322
Tires ........................................................ 285Wiper Blade Rubber ................................ 277
Reporting Safety Defects......................... 330
Resetting a Trip Meter............................... 86
SSafe Driving................................................ 27
Safety Check............................................... 31
Safety Labels.............................................. 65
Safety Message.......................................... 25
Seat........................................................... 129
Adjusting ................................................ 129
Front Seat ............................................... 129
Seat Belts.................................................... 32
Adjusting the Shoulder Anchor ................. 36
Automatic Seat Belt Tensioners ................. 34
Checking .................................................. 38
Fastening .................................................. 35
Installing a Child Seat with a Lap/Shoulder
Seat Belt ................................................. 59
Pregnant Women...................................... 37
Reminder .................................................. 33
Warning Indicator ............................... 33, 70
Seat Heaters............................................. 139
Security System
Immobilizer System Indicator..................... 75
Security System Alarm Indicator ................ 76
SEL/RESET Knob.......................................... 84
Select Lever........................................ 18, 219
Operation ......................................... 18, 220
Releasing ................................................ 314
