2013 FORD F750 Owners Manual

TECHNICAL SPECIFICATIONS
Component Lubrication TypeViscosity / Ambient
Temperature / NotesEquivalent Ford
Part Name / Number
Non-driving front axle
Eaton-Spicer axle
(generic) - front axle
wheel bearing oilMultipurpose EP gear
lube of API GL-5
quality meeting
MIL-PRF-2105E
specifications including
synthetic lubricants.
Do not mix
conventional and
synthetic lubricants.SAE 75W:
–40°F to –15°F
(–40°C to –26°C)Motorcraft® SAE
75W-140 Synthetic
Rear Axle Lubricant /
XY–75W140–QL
SAE 75W-80:
–40°F to 80°F
(–40°C to 27°C)
SAE 75W-140:
–40°F and above
(–40°C and above)
SAE 80W-140:
–15°F and above
(–26°C and above)
SAE 85W-140:
10°F and above
(–12°C and above)
SAE 80W-90:
–15°F to 100°F
(–26°C to 38°C)Motorcraft® SAE
80W-90 Premium Rear
Axle Lubricant /
XY–80W90–QL
264Capacities and Specifications
2013 F-650/750(f67)
Owners Guide gf, 2nd Printing, March 2013
USA(fus)

Component Lubrication TypeViscosity / Ambient
Temperature / NotesEquivalent Ford
Part Name / Number
Spicer axle - front axle
wheel bearing oilMultipurpose EP gear
lube of API GL-5
quality meeting
MIL-PRF-2105E
specifications including
synthetic lubricants.
Do not mix
conventional and
synthetic lubricants.SAE 75W:
–40°F to 32°F
(–40°C to 0°C)Motorcraft® SAE
75W-140 Synthetic
Rear Axle Lubricant /
XY–75W140–QL
SAE 75W-140:
–40°F and above
(–40°C and above)
SAE 80W-140:
–15°F and above
(–26°C and above)
SAE 85W-140:
10°F and above
(–12°C and above)
SAE 140W:
40°F and above
(4°C and above)
SAE 80W:
–15°F to 70°F
(–26°C to 21°C)Motorcraft® SAE
80W-90 Premium Rear
Axle Lubricant /
XY–80W90–QL
SAE 90W:
10°F to 100°F
(–12°C to 38°C)
Capacities and Specifications265
2013 F-650/750(f67)
Owners Guide gf, 2nd Printing, March 2013
USA(fus)

Component Lubrication TypeViscosity / Ambient
Temperature / NotesEquivalent Ford
Part Name / Number
Eaton-Spicer axle,
Spicer axle - Front
axle wheel bearing
grease, tie rod ends,
drag link, kingpin and
bushingEP2 Lithium
complex-based moly
grease (or equivalent)
GC/LB NLGI #2
multi-purpose lithium
complex greaseNote:Eaton-Spicer
and Meritor Easy Steer
axles: With chassis
load on axle, force
grease through thrust
bearings; then with
axle lifted clear of the
floor, force grease
between kingpin and
bushing surfaces.Motorcraft® Premium
Long Life Grease /
XG-1-C
Steering
Power steering fluid MERCON® V ATF — MERCON® V /
XT-5-QMC; XT-5-QM;
XL-14
Steering gear Ross TAS
- Output Seal, Steering
column U-joints / slip
jointGC/LB NLGI #2 lithium
complex-based moly
grease or
multi-purpose lithium
complex grease— Motorcraft® Premium
Long Life Grease /
XG-1-C
266Capacities and Specifications
2013 F-650/750(f67)
Owners Guide gf, 2nd Printing, March 2013
USA(fus)

Component Lubrication TypeViscosity / Ambient
Temperature / NotesEquivalent Ford
Part Name / Number
Driveshaft
U-joint GC/LB NLGI #2 lithium
complex-based moly
grease or
multi-purpose lithium
complex grease— Motorcraft® Premium
Long Life Grease /
XG-1-C
Clutch
Release bearing /
shafts / forkGC/LB NLGI #2 lithium
complex-based moly
grease or
multi-purpose lithium
complex grease— Motorcraft® Premium
Long Life Grease /
XG-1-C
Reservoir DOT 3, WSS-M6C62-A
or WSS-M6C65-A1— High Performance DOT
3 Motor Vehicle Brake
Fluid, PM-1-C (U.S.) or
CPM-1-C (Canada)
Cooling System
Engine coolant WSS-M97B44-D2 — Motorcraft® Orange
Antifreeze/Coolant
Prediluted/
VC-3DIL-B (U.S.)
CVC-3DIL-B (Canada)
Capacities and Specifications267
2013 F-650/750(f67)
Owners Guide gf, 2nd Printing, March 2013
USA(fus)

Component Lubrication TypeViscosity / Ambient
Temperature / NotesEquivalent Ford
Part Name / Number
Windshield Washer
Washer fluid WSB-M8B16-A2 — Motorcraft® Premium
Windshield Washer
Concentrate / ZC-32-A
(U.S.) or CXC-37-(A,
B, D, and F) (Canada)
Transmission
Six-speed automatic
(6R140)— — Motorcraft®
MERCON® LV ATF /
XT-10–QLV
Eaton-Fuller Petroleum oil: Engine
oil API-SL or API-CF
(MIL-L-2104E or
MIL-L-46152E)SAE 40W:
Below 10°F (–12°C)—
SAE 50W:
Above 10°F (–12°C)—
Mineral gear oil:
API-GL-1 (rust and
oxidation inhibited)SAE 75W:
Below 10°F (–12°C)—
SAE 80W–90:
Above 10°F (–12°C)—
Synthetic oil: Eaton®,
Roadranger® synthetic
CD-50 transmission
fluidCD SAE 50W:
All temperatures—
268Capacities and Specifications
2013 F-650/750(f67)
Owners Guide gf, 2nd Printing, March 2013
USA(fus)

Component Lubrication TypeViscosity / Ambient
Temperature / NotesEquivalent Ford
Part Name / Number
Spicer
(non-synchronized)
(Lubricants are listed
in order of
preference.)Petroleum oil: Engine
oil API-SL or API-CF
(MIL-L-2104E or
MIL-L-46152E)SAE 40W:
Below 0°F (–18°C)—
SAE 50W:
Above 0°F (–18°C)—
Mineral gear oil:
API-GL-1 (rust and
oxidation inhibited)
(EP gear oils are not
acceptable.)SAE 80W:
Below 0°F (–18°C)—
SAE 90W:
Above 0°F (–18°C)—
Synthetic oil: Synthetic
engine oil meeting
MIL-L-2104E or
MIL-L-46152E, API-SL
or API-CFCD SAE 50W:
All temperatures—
Capacities and Specifications269
2013 F-650/750(f67)
Owners Guide gf, 2nd Printing, March 2013
USA(fus)

Component Lubrication TypeViscosity / Ambient
Temperature / NotesEquivalent Ford
Part Name / Number
Spicer (synchronized)
(Lubricants are listed
in order of
preference.)Petroleum oil: Engine
oil API-SL or API-CF
(MIL-L-2104E or
MIL-L-46152E)SAE 40W:
Below 10°F (–12°C)—
SAE 50W:
Above 10°F (–12°C)—
Mineral gear oil:
API-GL-1 (rust and
oxidation inhibited)SAE 80W:
Below 10°F (–12°C)—
SAE 90W:
Above 10°F (–12°C)—
Synthetic oil: Synthetic
engine oil meeting
MIL-L-2104E or
MIL-L-46152E, API-SL
or API-CFSAE 50W:
All temperatures—
270Capacities and Specifications
2013 F-650/750(f67)
Owners Guide gf, 2nd Printing, March 2013
USA(fus)

Component Lubrication TypeViscosity / Ambient
Temperature / NotesEquivalent Ford
Part Name / Number
Meritor Petroleum oil: Heavy
Duty Engine Oil
MIL-L-2104E or API-SL
or API-CF (previous
API designations
acceptable)SAE 30W:
Below 10°F (–12°C)Motorcraft® SAE 30
Super Duty Motor Oil /
XO-30-QSD
SAE 40W or SAE 50W:
Above 10°F (–12°C)—
Mineral gear oil with
rust and oxidation
inhibitor API-GL-1.Do
not use multi-weight
and GL-5 EP gear
oils; they may cause
transmission failure
or damage.SAE 80W:
Below 10°F (–12°C)—
SAE 90W:
Above 10°F (–12°C)—
Synthetic oil:
MIL-L-2104E or
MIL-L-46152D.Do not
use multi-weight and
GL-5 EP gear oils;
they may cause
transmission failure
or damage.SAE 50W:
All temperatures—
Allison See transmission operator’s manual
