2013 DODGE DART Owners Manual

Overhead Console ..................... 248
▫ Front Map/Reading Lights ............. 248
▫ Sunglass Bin Door ................... 249
 Garage Door Opener — If Equipped ........ 249
▫ Before You Begin Programming
HomeLink ........................ 251
▫ Programming A Rolling Code ........... 251
▫ Programming A Non-Rolling Code ........ 253
▫ Canadian/Gate Operator Programming .... 254
▫ Using HomeLink ................... 256
▫ Security ........................... 256
▫ Troubleshooting Tips .................. 257
▫ General Information .................. 258
Power Sunroof — If Equipped ............ 258
▫ Opening Sunroof — Express ............ 259
▫ Opening Sunroof — Manual Mode ........ 260
▫ Closing Sunroof — Express ............. 260
▫ Closing Sunroof — Manual Mode ........ 260
▫ Pinch Protect Feature ................. 260
▫ Venting Sunroof — Express ............. 260
▫ Sunshade Operation .................. 261
▫ Wind Buffeting ...................... 261
▫ Sunroof Maintenance ................. 261
▫ Ignition Off Operation ................. 261
 Electrical Power Outlets — If Equipped ...... 262
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 103

Cupholders .......................... 265
▫ Front Seat Cupholders ................. 265
▫ Rear Seat Cupholders ................. 266
 Storage ............................. 267
▫ Glovebox Storage .................... 267
▫ Console Features .................... 268
▫ Door Storage ....................... 269
▫ Passenger Seat Storage — If Equipped ..... 270
▫ Rear Seat Armrest Storage — If Equipped . . . 271
Cargo Area Features ................... 271
▫ Cargo Area — Vehicles Equipped With 60/40
Split-Folding Rear Seat ................ 271
▫ Trunk Mat — If Equipped .............. 274
▫ Cargo Tie-Downs .................... 274
▫ Ski Pass-Through .................... 275
 Rear Window Features .................. 275
▫ Rear Window Defroster ................ 275
104 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

MIRRORS
Inside Day/Night Mirror
A two-point pivot system allows for horizontal and
vertical adjustment of the mirror. Adjust the mirror to
center on the view through the rear window. The mirror
should be adjusted while set in the day position (toward
the windshield).
Headlight glare can be reduced by moving the small
control lever under the mirror to the night position (lever
flipped toward the rear of vehicle).
Automatic Dimming Mirror — If Equipped
This mirror automatically adjusts for headlight glare
from vehicles behind you. This feature will be defaulted
on, and only be disabled when the vehicle is moving in
reverse.
Adjusting Rearview Mirror
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 105

NOTE:This feature is disabled when the vehicle is
moving in reverse.CAUTION!
To avoid damage to the mirror during cleaning, never
spray any cleaning solution directly onto the mirror.
Apply the solution onto a clean cloth and wipe the
mirror clean.
Outside Mirrors
To receive maximum benefit, adjust the outside mirror(s)
to center on the adjacent lane of traffic and a slight
overlap of the view obtained from the inside mirror.
NOTE: The passenger side convex outside mirror will
give a much wider view to the rear, and especially of the
lane next to your vehicle.
Automatic Dimming Mirror
106 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

WARNING!
Vehicles and other objects seen in the passenger side
convex mirror will look smaller and farther away
than they really are. Relying too much on your
passenger side convex mirror could cause you to
collide with another vehicle or other object. Use your
inside mirror when judging the size or distance of a
vehicle seen in the passenger side convex mirror.
Outside Mirrors Folding Feature — If Equipped
Some models have outside mirrors that are hinged. The
hinge allows the mirror to pivot forward and rearward to
resist damage. The hinge has three detent positions: full
forward, full rearward and normal.
Outside Mirrors With Turn Signal And Approach
Lighting — If Equipped
Driver and passenger outside mirrors with turn signal
and puddle lamp contain 3 LEDs.
Two of the LED’s are used as turn signal indicators,
which flash with the corresponding turn signal lights in
the front and rear of the vehicle. Turning on the Hazard
Warning flashers will also activate these LEDs.
The third LED supplies illuminated entry lighting, which
turns on in both mirrors when you use the Remote
Keyless Entry (RKE) transmitter or open any door. This
LED shines downward to illuminate the ground adjacent
to the Front and Rear Doors.
The Illuminated Entry lighting fades to off after about
30 seconds or it will fade to off immediately once the
ignition is placed into the RUN position.
NOTE:The approach lighting will not function when
the shift lever is moved out of the PARK position.
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 107

Power Mirrors
The power mirror controls are located on the drivers door
trim panel.The power mirror controls consist of mirror select but-
tons and a four-way mirror control switch. To adjust a
mirror, press either the L (left) or R (right) button to select
the mirror that you want to adjust.
Using the mirror control switch, press on any of the four
arrows for the direction that you want the mirror to
move.
Heated Mirrors — If Equipped
These mirrors are heated to melt frost or ice. This
feature is activated whenever you turn on the rear
window defroster. Refer to “Rear Window Features” in
“Understanding The Features Of Your Vehicle” for fur-
ther information.
Power Mirror Control
108 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Illuminated Vanity Mirrors — If Equipped
An illuminated vanity mirror is on each sun visor. To use
the mirror, rotate the sun visor downward and swing the
mirror cover upward. The light will turn on automati-
cally. Closing the mirror cover will turn off the light.
Sun Visor “Slide-On Rod” Feature — If Equipped
This feature allows for additional flexibility in position-
ing the visor to block out the sun.
1. Fold down the sun visor.
2. Unclip the visor from the center clip.
3. Pull the sun visor toward the inside rearview mirror to
extend it.
Illuminated Vanity Mirror
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 109

BLIND SPOT MONITORING — IF EQUIPPED
The Blind Spot Monitoring (BSM) system uses two radar-
based sensors, located inside the rear bumper fascia, to
detect highway licensable vehicles (automobiles, trucks,
motorcycles, etc.) that enter the blind spot zones from the
rear/front/side of the vehicle.When the vehicle is started, the BSM warning light will
momentarily illuminate in both outside rear view mirrors
to let the driver know that the system is operational. The
BSM system sensors operate when the vehicle is in any
forward gear or REVERSE and enters stand by mode
when the vehicle is in PARK.
Rear Detection ZonesBSM Warning Light
110 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
