2013 Citroen DS5 traction control

Warning / indicator lampStateCauseAction / Observations



Dynamic stability control(DSC/ASR)
flashing. The DSC/ASR regulation is
operating. The system optimises traction and improves the
directional stability of the vehicle.
fixed. Unless it has been deactivated(button pressed and its indicator lamp
on) the DSC/ASR system has a fault.Have it checked b
y a CITROËN or a qualified
workshop.

Engine autodiagnosis system
flashing.The engine management system hasa fault. Risk of destruction of the catalytic conver ter.
Have it checked by a CITROËN dealer or a qualified
workshop.
fixed. The emission control system hasa fault. The warning lamp should go off when the engine is started. If it does not go off, contact a CITROËN dealer or
qualified workshop without delay.



Low fuel levelfixed with the two last
bars flashing.When it first comes on there remainsapproximately 6 litres offfuelin thetank.You must re
fuel as soon as possible to avoid runningout of fuel.This warning lamp will come on every time the ignition
is switched on, until a sufficient addition of fuel is made.
Fuel tank capacit
y: approximately 60 litres.
Never continue to drive until you run out of fuel as
this could damage the emission control and injectionsystems.



Anti-lock
Braking System(ABS)
fixed. The anti-lock braking system has a
f
ault. The vehicle retains conventional brakin
g.
Drive carefull
y at reduced speed and contact a CITROËN dealer or a qualified workshop without
delay.

173Safety
Electronic Stability Programme incorporating
the following systems:


- the anti-lock braking system (ABS) and the electronic brake force distribution (EBFD),

- the emergency braking assistance,

- the anti-slip regulation (ASR) or tractioncontrol,

- the dynamic stability control (DSC).






























Electronic stability programme (ESP)
Definitions
Anti-lock braking system (ABS)and electronic brake force
distribution (EBFD)
This system improves the stability and
manoeuvrability of your vehicle when braking and provides improved control in corners, in par ticular on poor or slippery road surfaces.
The ABS prevents wheel lock in the event of
emergency braking.
The electronic brake force distribution system
manages the braking pressure wheel by wheel.
Emergency braking assistance
In an emergency, this system enables you to reach the optimum braking pressure more quickly and therefore reduce the stopping distance. It is triggered in relation to the speed at which
the brake pedal is pressed. This is felt by a reduction in the resistance of the pedal and an increase in the effectiveness of the braking.

Anti-slip regulation (ASR)

The ASR system (also known as Traction Control) optimises traction in order to avoid
wheel slip b
y acting on the brakes of the drivingwheels and on the engine. It also improves
the directional stability of the vehicle onacceleration.


Dynamic stability control (DSC)

If there is a difference between the path followed by the vehicle and that required bythe driver, the DSC monitors each wheel and
automatically acts on the brake of one or more
wheels and on the engine to return the vehicle
to the required path, within the limits of the laws of physics.

Intelligent traction control
s
ystem ("Snow motion")
Your vehicle has a system to help driving onsnow: intelligent traction control.This system detects situations of difficult surface adhesion that could make it difficult to move off or make progress on deep fresh snow
or compacted snow.In these situations, the intelligent traction control
limits the amount of wheel slip to provide the best traction and trajectory control
for your vehicle.

Operation


Anti-lock braking system (ABS)
and electronic brake force
distribution
(EBFD)
In emergency braking, press very firmly without releasing the pressure.

When changing wheels (tyres and rims),make sure that these are approved for your vehicle.
Normal operation of the ABS may make itself felt by slight vibrations of the brake pedal. When this warnin
g lamp comes on,
accompanied by an audible signal
and a message, it indicates that
there is a fault with the ABS, which
could cause loss of control of the vehicle whenbraking.
When this warnin
g lamp comes on, coupled with the STOPwarning lamp,
accompanied by an audible signal
and a message, it indicates that
th
ere is a fault with the electronic brake forcedistribution (EBFD), which could cause loss of control of the vehicle when braking.
You must stop as soon as it is safe to do so. In both cases, contact a CITROËN dealer or a qualified workshop. The use o
f snow tyres is strongly recommended on surfaces offering low levels of adhesion.
