Practical information




















Changing a fuse
Procedure for replacing a failed fuse with a new fuse to rectify a failure of the corresponding function.
Th
e fuse extraction tweezer is fitted to the back of the dashboard fusebox cover.
For access to it:)remove the cover completely,)remove the tweezer.


Access to tooling
Before changing a fuse, the cause of the failure must be identified andrectified.)
Identify the failed fuse by checking
the condition of its filament.
Changing a fuse
Good Failed
)
Use the special tweezer to extract the fuse
from its housin
g.) Always replace the failed fuse with a fuse
of the same rating. ) Check that the number marked on thefusebox, the rating marked on the fuse and
the following tables all agree.

CITROËN will not accept responsibility for the cost incurred in repairing your vehicle or for rectifying malfunctions resulting from the installation of accessories not supplied and not recommended by CITROËN andnot installed in accordance with itsinstructions, in par ticular when the combined consumption of all of the additional equipment connectedexceeds 10 milliamperes.


Installing electricalaccessories

Your vehicle's electrical system isdesigned to operate with standard or optional equipment.
Before installing other electrical equipment or accessories on your vehicle, contact a CITROËN dealer or a qualified workshop.

Dashboard fuses
The fusebox is placed in the lower dashboard (left-hand side).
Access to the fuses
)Remove the cover.

Fuse
N°


Rating (A)

Functions
F6 A or B
15 Audio system.
F8
3 Alarm.
F13
10 Front cigarette lighter, front 12 V socket.
F14
10 Rear 12 V socket.
F1
63 Rear map reading lamps.
F173 Courtesy mirror.
F28 A or B
15 Audio system.
F3
020
Rear wiper.
F32
10 Audio amplifier.

209Practical information

Engine compartment fuses

The fusebox is placed in the engine compartment near the battery.


Access to the fuses
)Unclip the cover. )Change the fuse (see corresponding paragraph).)When you have finished, close the cover carefully to ensure correct sealing of the
f
usebox.


Fuse
N°


Rating(A)Functions
F20 15
Front
/ rear screenwash pump.
F2120 Headlamp wash pump.
F2215
Horn.
F2
315 Right-hand main beam headlamp.
F2
415 Left-hand main beam headlamp.
F275
Left hand lamp mask.
F2
85 Right hand lamp mask.

12 V battery
The presence of this label indicatesthe use of a 12 V lead-acid battery withspecial technology and specification, for which the involvement of a CITROËN dealer or qualified workshop is requiredwhen replacing or disconnecting thebattery.
Failure to observe this recommendation may cause premature wear of thebattery. The battery is located under the bonnet.
To
gain access to it:)
open the bonnet using the interior releaselever, then the exterior safety catch, )
remove the plastic cover on the (+)
terminal,) if necessary, unclip the fusebox to remove
the battery.

Access to the battery



Disconnecting the (+) cable
)Raise the locking tab Dfully to release the cable terminal clamp E
.



Reconnecting the (+) cable
)Position the open clamp Eof the cable on
the positive post
(+) of the battery. )Press ver tically on the clamp E to positionit correctly on the battery. )Lock the clamp by spreading the positioning lug and then lowering the tab D.

Do not apply excessive force on thetab as locking will not be possible if the clamp is not positioned correctly; star tthe procedure again. Procedure
for starting the engine using another battery or charging a discharged battery.

The fitting of electrical equipment or accessories which are not recommended by CITROËN may resultin a failure of your vehicle's electronicsystem and excessive electricalconsumption.
Please note this precaution. You are advised to contact a CITROËNrepresentative to be shown the range of recommended equipment and accessories.


Installation of radio communication transmitters

Before installing any after-market radiocommunication transmitter, you can contact a CITROËN dealer for the specification of transmitters which can be fitted (frequency, maximum power, aerial position, specific installation requirements), in line with the Vehicle Electromagnetic Compatibility Directive (2004/10 4/EC).
Depending on the legislation in force in the country, it may be compulsoryto have a high visibility safety vest,warning triangle and spare bulbs andfuses available in the vehicle.
B
y visiting a CITROËN dealer you can also
obtain cleaning and maintenance products
(interior and exterior) - including ecological
products in the "TECHNATURE" range,
products for topping up (screenwash...), paint
touch-up pens and aerosols for the exact colour
of
your vehicle, refills (sealant car tridge for the
temporary puncture repair kit...), ...
"Multimedia":
audio systems, steering mounted audio controls, speakers, Hi-Fi module, Bluetooth hands-free system, por table satellite navigationsystem, semi-integral suppor t bracket for portable navigation system, driving assistancesystems, USB Box, reversing camera, por table
video screen, por table video support bracket,
230 V/50 Hz socket, 230 V/12 V adaptor, Wi-Fion board...

The various caps and covers allow access for
checking the levels of the various fluids and for replacing cer tain components.














Petrol engines
1.
Power steering reservoir.2.
Screenwash and headlamp wash reser voir.3.
Coolant reservoir. 4.
Brake fluid reservoir.5.
Battery / Fuses.
6.Fusebox.
7. Air filter.8.Engine oil dipstick. 9.
Engine oil filler cap.THP 155 6- SPEED AUTOTHP 200 6- SPEED MANUAL

227Checks
The various caps and covers allow access for
checking the levels of the various fluids, for
replacing cer tain components and for primingthe fuel system.

*

According to engine.















Diesel engines
1.
Power steering reservoir.2.Screenwash and headlamp wash reser voir.3.Coolant reservoir.4.
Brake fluid reservoir.
5. Battery / Fuses.
6.Fusebox.
7. Air filter.8.Engine oil dipstick.9.
Engine oil filler cap.10.Priming pump * . 11.
Bleed screw * .
e- HDi 110 6- SPEED ELECTRONIC
HDi 160 PEF 6- SPEED MANUAL / HDi 160 PEF 6- SPEED AUTO

337
