2013 Citroen DS5 Owner's Manual

71Access

003
Comfort

Front seats
Manual
1.Adjustments to the height and angleof
the head restraintTo raise it, pull upwards.
To lower it, press on the lug and the headrestraint at the same time.2.Adjustment of the backrest angleTurn the wheel to adjust the angle of thebackrest. 3.Adjustment of the seat heightRaise or lower the control lever the number
of times required to obtain the desiredposition.4.Forwards-backwards adjustment of the
seat position Lift the control bar and slide the seatforwards or backwards.5.Adjustment of the driver's lumbar
supportTurn the wheel to obtain the desired level of lumbar support.

Comfort
Switch on the ignition or star t the engine if the vehicle has gone into economy mode.
The electric functions of the driver's seat are active for about 45 secondsafter opening the front door. They are deactivated about 45 seconds after switching off the ignition and in economy mode.

To reactivate them, switch on the ignition.

Electric
1.Adjustment of the seat cushion angleand height, and for wards-backwards adjustment)Raise or lower the front of the control
to adjust the seat cushion angle. )Raise or lower the rear of the control
to raise or lower the seat.)Simultaneously raise or lower the
front and rear of the control in order
to raise or lower the entire seat. 2.Adjustment of the backrest angle Move the control forwards or backwards
to adjust the backrest angle.
3.Adjustment of driver's lumbar
support Press the control switches to obtain
the desired level of lumbar suppor t.
4. Manual adjustment of the cushion
Pull on the grip to adjust the length of
the cushion.

Storing driving positions
System which stores the electrical settings
of the driver's seat and the head-up display settings. It enables you to store up to two positions using the buttons on the side of the driver's seat.

Storing a position usingbuttons M / 1 / 2

)
Switch on the ignition. )
Adjust your seat and the head-up display.)
Press button M
, then press button 1or 2within four seconds.
An audible signal indicates that the positionhas been stored.
Storing a new position cancels the previous
position.

Recalling a stored position
)Briefly press button 1
or 2to recall the corresponding position.
An audible signal indicates the end of the
adjustment.
You can interrupt the current movementby pressing button M, 1
or 2
or by using one of the seat controls. A stored position cannot be recalled while driving. Recalling stored positions is deactivated 45 seconds after switching off the ignition.

Comfort
The head restraint is fitted with a framewith notches which prevents it from lowering; this is a safety device in caseof impact.
The adjustment is correct when theupper edge of the head restraint is level with the top of the head.Never drive with the head restraints removed; they must be in place andadjusted correctly.

Head restraint height and
angle adjustment
)To raise a head restraint, pull it upwards. )To remove the head restraint, press thelug A
and pull the head restraint upwards. )To put the head restraint back in place,
engage the head restraint stems in the
openings keeping them in line with the seat back. )To lower the head restraint, press the lug Aand push down on the head restraint at thesame time. )To a djust the angle of the head restraint, tilt
its lower part forwards or rearwards.

Massage function
This function provides the driver with a back
massage. It only operates when the engine is running or in STOP mode of the Stop & Start
system.


Activation
)
Press this switch.

The warning lamp comes on and the massage function is activated for a period of 1 hour.
During this time, massage is performed in6 cycles of 10 minutes (6 minutes of massagefollowed by 4 minutes break).
After one hour, the function is deactivated, the
warning lamp goes off.

Deactivation
You can deactivate the massage function at any time by pressing this switch.
Heated seats control
)Use the adjustment wheel to switch on and
select the level of heating required:

0:
Off. 1:Low.2:Medium.3:
High.

With the en
gine running, the front seats can beheated separately.
