Screenwash and washer jets
Windscreen wash and
headlamp wash
Adjusting the jets
The front washers include an adjustment for the
height of delivery from the jets.
If you want to modify the factory setting, turn
the screw on each jet anti-clockwise, towards
the "+" to raise the jet or clockwise, towards the "-" to lower it.

Headlamp wash
)Pull the windscreen wiper stalk towards
you. The windscreen wash then the
windscreen wi
pers operate for a fixed period.
A few moments after releasing the wiper stalk,
there is a last wipe to clear any runs from thescreen. The headlam
ps operate when the vehicle is moving and when the dipped beam headlamps
are on. However, to reduce the consumption
of screenwash fluid, the headlamp wash onl
yoperates with every 7th use of the screenwash
or once every 25 miles (40 km), during a given journey.

271
7
Practical information

* Depending on version.
Ta k i ng out the spare wheel

The spare wheel is suppor ted by a carrier underneath the vehicle.












Access to the spare wheel *

)
Detach the wheel/box assembly from the
rear of the vehicle.) Remove the hook with its connection plate
to release the wheel/box assembly, asshown in the illustration.) Pull out the wheel to gain access to thebox.
)
Fold the concer tina board and put the left
hand third row seat into position (if your
vehicle has them). ) Raise the pre-cut section of carpet toexpose the nut for operating the spare
wheel carrier.) Using the extension 6 fitted to the end of
the wheelbrace, turn the nut clockwise to
unwind the carrier cable until the spare
wheel reaches the ground. Unwind thelength needed for access to the wheel.
Only a "space-saver" type of spare wheel can be fitted under the vehicle.

272
Practical information

A puncture wheel from the vehiclecannot be fitted under the vehicle. Itmust be carried in the boot. Use a cover to protect the boot.
)Press the tongue, slide the box cover to thecentre and remove it for access to the other
tools (jack and wheel bolt head finisher removal tool for alloy wheels).

Putting the spare wheel back in place
)Stow the corresponding tools in the box and close the cover. )Position the tool box on the ground.


Stowing the tools
)
Return the tools to the box and stow the box in the vehicle's boot. )
Wind in the carrier by turning the
wheelbrace clockwise: once the cable isfully wound in you should no longer feel
any resistance. ) Stow the other tools in the locations provided in the boot.

273
7
Practical information
) Pass the hook with its connection plate into
the wheel then the box, as illustrated.) Raise the wheel/box assembly underneath
the vehicle by turning the carrier drive nut
anticlockwise using the wheelbrace and
the extension.
) Tighten fully. When the cable is fully wound
in, rotation of the nut no longer presents
any resistance.
Check that the wheel is horizontally flat
against the floor.


)Position the spare wheel on the box so that
the positioning indicator will be introduced
into the bolt hole in the middle of the box.

282
Practical information
The direction indicator bulb is located below thefront lamp. )Turn the bulb holder a quar ter turn anti-clockwise. )Remove the bulb holder. )Change the failed bulb.For reassembly, carry out these operations in reverse order.

Direction indicators Front foglamps
)Unclip the finisher by pulling at the top.)Remove the two screws to remove the unit. )Turn the bulb holder a quar ter turn. )Remove the bulb holder. )Change the failed bulb.
For reassembly, carry out these operations in
reverse order, pressing on the finisher to refit it.


Faster flashing of a direction indicator warning lamp (left or right) indicates afailed bulb on that side.
Direction indicators (lightemitting diodes - LED)

For the replacement of this type of lamp, contact a CITROËN dealer or a qualified
workshop.

284
Practical information
Lamps on the tailgate
Model with LED lamps
Identi
fy the failed bulb.)Open the boot.)Remove the access cover.
Model with conventional bulb lamp
s
) Remove the three lamp fixing screws A . )
Disconnect the lamp connector. )
Carefully remove the lamp from the outsideby pressing the retaining clip B.
)Turn the bulb holder a quarter of a turnanti-clockwise and pull the bulb out.)Change the bulb.
For reassembly, carry out these operations in
reverse order.

286
Practical information
















Lamps on the tailgateModel with LED lamps
Model with conventional bulb lam
ps
Identify the failed bulb.)Open the boot.)Remove the access cover.
) Remove the three lamp fixing screws A.)
Disconnect the lamp connector. )
Carefully remove the lamp from its housing. )
Turn the bulb holder a quar ter of a turn
anti-clockwise and pull the bulb out.
) Change the bulb.
For reassembly, carry out these operations in reverse order.

.
