2013 Citroen C3 PICASSO technical data

.
Contents
Direction indicators 114
Hazard warning lamps 114
Horn 114
Emergency or assistance call 115
Braking assistance systems 115
Tr ajectory control systems 117
Front seat belts 118
Airbags 122
Safety
Parking brake 126
6-speed manual gearbox 126
Gear effi ciency indicator 127
6-speed electronic gearbox system 128
Hill start assist 132
Stop & Start 133
Speed limiter 136
Cruise control 138
Rear parking sensors 140
Reversing camera 142
Driving
Emergency or assistance 199
eMyWay 201
Audio system 255
Audio and telematics
Alphabetical index
Bonnet 144
Running out of fuel (Diesel) 145
Petrol engines 146
Diesel engines 147
Checking levels 148
Checks 150
Checks
Te m p o r a ry puncture repair kit 152
Changing a wheel 157
Changing a bulb 164
Changing a fuse 173
Battery 180
Energy economy mode 182
Changing a wiper blade 183
To w i ng the vehicle 184
To w i ng a trailer 186
Fitting roof bars 187
Accessories 188
Snow chains 190
Practical informationTechnical data
Petrol engines 191
Petrol weights 192
LPG engines 193
LPG weights 194
Diesel engines 195
Diesel weights 196
Dimensions 197
Identifi cation markings 198

Practical information
186








Towing a trailer, ...


Driving advice


Cooling

Towing a trailer on a slope increases the
temperature of the coolant.
As the fan is electrically controlled, its coolingcapacity is not dependent on the engine speed. )To lower the engine speed, reduce your speed.
The maximum towed load on a long incline depends on the gradient and the ambient
temperature.
In all cases, keep a check on the coolant
temperature.
Side wind
)
Take into account the increased sensitivityto side wind.

)
If the warning lamp and the
STOPwarning lamp come on,stop the vehicle and switch off
the engine as soon as possible. Towbar suitable for the attachment of a trailer or installation of a bic
ycle carrier, with additional lighting and signalling.

Distribution of loads
)
Distribute the load in the trailer so that the
heaviest items are as close as possible to
the axle and the nose weight approaches the
maximum permitted without exceeding it.
Air density decreases with altitude, thusreducing engine per formance. Above
1 000 metres, the maximum towed load must
be reduced by 10 % for every 1 000 metres of altitude.

We recommend the use of genuine CITROËN towbars and their harnesses that have been tested and approved from the design stage of your vehicle,and that the fitting of the towbar isentrusted to a CITROËN dealer or aqualified workshop.
If the towbar is not fitted by a CITROËN dealer, it is imperative that it isfitted in accordance with the vehiclemanufacturer's instructions.
Driving with a trailer places greater demands
on the towing vehicle and the driver must takepar ticular care. Your vehicle is primaril
y designed for transporting people and luggage, but it may also be used for towing a trailer.

R
efer to the "Technical data" section for detailsof the weights and towed loads which apply toyour vehicle.

12
Technical data
191
*
For Russia only.

**
The maximum power quoted is the type approved value obtained on a test bed, under the conditions defined in European legislation (directive 1999/99/CE).
PETROL ENGINESVTi 95VTi 115*VTi 120VTi 115 *VTi 120
Model codes:SH...8FP05FJ0*5FS05FJ8/P *5FS8/P

Cubic capacity (cc)
1 397 1 598 1 598
Bore x stroke
(mm)
77 x 75

77 x 85.8
77 x 85.8

Max power: EU standard (kW) **
70
84 *

88
84 *

88

Max power en
gine speed (rpm) 6 000
5 200
*
6 000
5 200
*6 000

Max torque: EU standard (Nm)13 6160
160

Max torque en
gine speed (rpm)
4 000

4 250

4 250


Fuel Unleaded
Unleaded
Unleaded

Catal
ytic converter yesyes yes
GEARBOXE
S
Manual(5-speed)
Manual (5-speed)Electronic gearbox system (6-speed)
OIL CAPACITIES
(in litres)
Engine (with filter replacement)
4.254.25 4.25
























Engines and gearboxes

Technical data
192
The GTW and towed load values indicated are valid up to a maximum altitude of 1 000 metres; the towed load mentioned must be reduced by 10 % for each additional 1 000 metres of altitude.
The speed of a towing vehicle must not exceed 60 mph (10 0 km/h) (comply with the legislation in force in your country).
High ambient temperatures may result in a reduction in the performance of the vehicle to protect the engine; if the ambient temperature is above 37 °C,
limit the towed load.
* For Russia only. ** The weight of the braked trailer can be increased, within the GTW limit, if the GVW of the towing vehicle is reduced by an equal amount; warning,
towing using a lightly loaded towing vehicle may have an adverse effect on its road holding.
PETROL ENGINESVTi 95VTi 115*VTi 120VTi 115 * VTi 120
GearboxesManualManualElectronic gearbox system (6-speed)
Model codes:SH...8FP05FJ0 *5FS05FJ8/P *5FS8/P


- Unladen wei
ght 1 201
1 204 1 205


- Kerb wei
ght
1 276
1 279

1 280



-
Payload
546
549
564
-
Gross vehicle weight (GVW)1747

1 753
1 769

-
Gross train weight (GTW)on a 12% gradient
2 597
2 603

2 619
- Braked trailer (within GTW limit)

on a 10% or 12% gradient 850
850850

- Braked trailer **
(with load transfer within theGTW limit)1 100

1 100
1 100



-
Unbraked trailer
635
635
640



- Recommended nose weight
54 54 54

Weights and towed loads (kg)

12
Technical data
193
LPG ENGINEVTi 95
Model codes:SH...8FN0/GPL
Cubic capacit
y (cc)
1 397
Bore x stroke
(mm) 77 x 75
Max. power: EU standard
(kW) *
70

Max. power speed
(rpm)
6 000

Max torque: EU standard
(Nm)
13 6

Max. torque speed (rpm)

4 000

Fuel LPG / Unleaded

Catal
ytic converter

Yes
GEARBOX

Manual(5-speed)

OIL CAPACITY (in litres)
En
gine (with filter replacement)
4.25


*
The maximum power quoted is the type approved value obtained on a test bed, under the conditions defined in European legislation (directive 1999/99/CE).
























Engine and gearbox

Technical data
194
LPG ENGINEVTi 95
GearboxManual
Model codes:SH...8FN0/GPL


- Unladen wei
ght
1 301



- Kerb wei
ght

1 376



-
Payload446
- Gross vehicle weight (GVW)1747
- Gross train weight (GTW)on a 12 % slope
2 597
- Braked trailer
(within GTW limit)

on a 12 % slope 850
- Braked trailer * (with load transfer within theGTW limit)

1 100



- Unbraked trailer
650



- Recommended nose wei
ght
54
* The weight of the braked trailer can be increased, within the GTW limit, if the GVW of the towing vehicle is reduced by an equal amount; warning,
towing using a lightly loaded towing vehicle may have an adverse effect on its road holding.
The
GTW and towed load values indicated are valid up to a maximum altitude of 1 000 metres; the towed load mentioned must be reduced by 10 % for each additional 1 000 metres of altitude.
The speed of a towing vehicle must not exceed 60 mph (10 0 km/h) (comply with the legislation in force in your country).
High ambient temperatures may result in a reduction in the per formance of the vehicle to protect the engine; if the ambient temperature is above 37 °C,
limit the towed load.

Weights and towed loads (kg)

12
Technical data
195
DIESEL ENGINESHDi 90 PEFe-HDi 90 PEFHDi 115 PEF
Model codes: SH...9HP09HP8/P/S9HD8

Cubic capacity (cc) 1 5601 560
1 560

Bore x stroke (mm)
75 x 88.3

75 x 88.375 x 88.3

Max power: EU standard
(kW) *
68
68
84
Max power en
gine speed (rpm)
4 000

4 000
3 600

Max torque: EU standard (Nm)230
230
270

Max torque engine speed (rpm)
1 750 1 750 1 750

Fuel Diesel Diesel
Diesel

Catal
ytic converter yes yesyes
P
article emission filter yes
yesyes

GEARBOXE
SManual (5-speed)
Electronic gearbox system(6-speed)Manual (6-speed)
OIL CAPACITIES
(in litres)
Engine (with filter replacement) 3.75
3.753.75

.../
S : e-HDi model fitted with Stop & Star t.

























Engines and gearboxes


*
The maximum power quoted is the type approved value obtained on a test bed, under the conditions defined in European legislation (directive 1999/99/CE).

Technical data
196
* The weight of the braked trailer can be increased, within the GTW limit, if the GV W of the towing vehicle is reduced by an equal amount; warning,
towing using a lightly loaded towing vehicle may have an adverse effect on its road holding.
DIESEL ENGINESHDi 90 PEFe- HDi 90 PEFHDi 115 PEF
GearboxesManualElectronic gearbox systemManual
Model codes:SH...9HP09HP8/P/S9HD8


- Unladen weight 1 2771 313
1 318



- Kerb wei
ght
1 3521 388

1 393



-
Payload
502 498

489

-
Gross vehicle weight (GVW)

1 779

1 811
1 807
-
Gross train weight (GTW)
on a 12% gradient
2 979
3 011
2 757
- Braked trailer
(within GTW limit)

on a 10% or 12% gradient 1 2001 200
950
- Braked trailer * (with load transfer with the GTW limit)

1 2001 200

1 200



- Unbraked trailer
675
675
675



- Recommended nose wei
ght 54
54 54
The
GTW and towed load values indicated are valid up to a maximum altitude of 1 000 metres; the towed load mentioned must be reduced by 10 % for each additional 1 000 metres of altitude.
The speed of a towing vehicle must not exceed 60 mph (10 0 km/h) (comply with the legislation in force in your country).
High ambient temperatures may result in a reduction in the performance of the vehicle to protect the engine; if the ambient temperature is above 37 °C,
limit th
e towed load.
Weights and towed loads (kg)
