2013 Citroen C3 technical data

.
.
Contents
Direction indicators 105
Hazard warning lamps 105
Horn 106
Emergency or assistance call 106
Braking assistance systems 107
Tr ajectory control systems 108
Front seat belts 109
Airbags 111
Safety
Parking brake 115
6-speed manual gearbox 115
Gear effi ciency indicator 116
Electronic gearbox 117
Automatic gearbox 121
Stop & Start 124
Hill start assist 127
Speed limiter 128
Cruise control 130
Rear parking sensors 132
Reversing camera 134
Driving
Emergency or assistance 195
eMyWay 197
Audio system 251
Audio and telematics
Alphabetical index
Bonnet 136
Running out of fuel (Diesel) 137
Petrol engines 138
Diesel engines 139
Checking levels 140
Checks 142
Checks
Te m p o r a ry puncture repair kit 144
Changing a wheel 149
Snow chains 156
Changing a bulb 157
Changing a fuse 164
Battery 171
Energy economy mode 174
Changing a wiper blade 175
To w i ng the vehicle 176
To w i ng a trailer 178
Audio pre-equipment 180
Accessories 182
Practical informationTechnical data
Petrol engines 184
Petrol wei
ghts 185
LPG engines 187
LPG weights 188
Diesel engines 189
Diesel weights 191
Dimensions 193
Identifi cation markings 194
Visual search

Practical information
178








Towing a trailer


Driving advice


Side wind
)Take into account the increased sensitivity
to side wind. T
owbar suitable for the attachment of atrailer or installation of a bicycle carrier, with additional lighting and signalling.

Distribution of loads
)Distribute the load in the trailer so that the heaviest items are as close as possible to
the axle and the nose weight approaches the maximum permitted without exceeding it.
Air density decreases with altitude, thus
reducing engine performance. Above
1 000 metres, the maximum towed load must
be reduced b
y 10 % for every 1 000 metres of altitude.We recommend the use of genuineCITROËN towbars and their harnessesthat have been tested and approvedfrom the design stage of your vehicle, and that the fitting of the towbar is entrusted to a CITROËN dealer or a qualified workshop.If the towbar is not fitted by a CITROËNdealer, it is imperative that it is fitted in accordance with the vehicle manufacturer's instructions.

Drivin
g with a trailer places greater demands
on the towing vehicle and the driver must take
particular care.
Your vehicle is primaril
y designed for
transporting people and luggage, but it mayalso be used for towing a trailer.

R
efer to the "Technical data" section for details
of the weights and towed loads which apply to your vehicle.

Technical data
184
Model codes:SC...ZMZ0HMZ0HMZ0/PHMZ0/PS8FP0/P5FS05FS9
EnginesVTi 68VTi 82e-VTi 82VTi 95VTi 120
Gearboxes Manual(5-speed)
Manual
(5 speed)

Electronic
(5-speed)
Electronic(5-speed)
Electronic
(5-speed)

Manual(5-speed)

Automatic(4-speed)


Cubic capacity (cc) 999

1 199
1 1991 3971 598

Bore x stroke
(mm)

71 x 84.1

75 x 90.5
75 x 90.577 x 7577 x 85.8

Max power: EU standard (kW) *

5060
60

70
88

Max power engine speed (rpm) 6 000
5 750
5 750
6 000
6 000

Max torque: EU standard
(Nm) 95

118
118

136
160

Max torque engine speed (rpm) 3 000
2 750

2 750
4 000

4 250

F
uel Unleaded Unleaded
Unleaded Unleaded
Unleaded

Catalytic converter
YesYes

Yes
Yes

Yes

OIL CAPACITIES
(in litres)

Engine (with filter replacement) 3.253.25
3.25
4.25
4.25

























Petrol engines and gearboxes
*

The maximum power corresponds to the value type approved on a test bed, under conditions defined by European legislation (Directive 1999/99/EC).

12
Technical data
185
The GTW and towed load values indicated are valid up to a maximum altitude of 1 000 metres; the towed load mentioned must be reduced by 10 % for each additional 1 000 metres of altitude.
The speed of a towing vehicle must not exceed 60 mph (10 0 km/h) (comply with the legislation in force in your country).
High ambient temperatures may result in a reduction in the performance of the vehicle to protect the engine; if the ambient temperature is above 37 °C,
limit th
e towed load.

Petrol weights and towed loads (in kg)
EnginesVTi 68VTi 82e-VTi 82
GearboxesManualManualElectronicElectronic
Model codes:SC...ZMZ0HMZ0HMZ0/PHMZ0/PS



- Unladen weight 973
975
1 060
980



- Kerb wei
ght 1 048
1 0501 135 1 055


- Gross vehicle wei
ght (GV W)

1 500

1 511 1 515

1 540



-
Gross train weight (GTW)

on a 12 % gradient 1 950
2 3112 315 2 340



- Braked trailer
(within GTW limit) on a 12 % gradient
450
800
800800



- Braked trailer * (with load transfer within the
GTW limit) 7751 100 1 100

1 100



-
Unbraked trailer
450
520
520520



- Recommended nose weight
46

46

4646

* The weight of the braked trailer can be increased, within the GTW limit, if the GVW of the towing vehicle is reduced by an equal amount. Warning:
towing using a lightly loaded towing vehicle may have an adverse effect on its road holding.

Technical data
186
The GTW and towed load values indicated are valid up to a maximum altitude of 1 000 metres; the towed load mentioned must be reduced by 10 % for each additional 1 000 metres of altitude.
The speed of a towing vehicle must not exceed 60 mph (10 0 km/h) (comply with the legislation in force in your country).
High ambient temperatures may result in a reduction in the performance of the vehicle to protect the engine; if the ambient temperature is above 37 °C,
limit the towed load.

Petrol weights and towed loads (in kg)
Petrol enginesVTi 95VTi 120
GearboxesElectronicManualAutomatic
Model codes: SC...8FP0/P5FS05FS9



- Unladen weight 1 079
1 075
1 089



- Kerb weight 1 154 1 150
1 164


- Gross vehicle wei
ght (GV W)
1 581
1 5791 612


-
Gross train weight (GTW)
on a 12 % gradient2 481 2 479
2 512



- Braked trailer
(within the GTW limit)
on a 12 % gradient 900
900
900



- Braked trailer *
(with load transfer within the
GTW limit) 1 150
1 150
1 150



- Unbraked trailer
570570
570



- Recommended nose wei
ght
46

46
46
* The weight of the braked trailer can be increased, within the GTW limit, if the GVW of the towing vehicle is reduced by an equal amount. Warning:
towing using a lightly loaded towing vehicle may have an adverse effect on its road holding.

12
Technical data
187
For more information on the operation and use of your LPG vehicle, refer to the specific insert attached to the other vehicle documents.

























LPG engine and gearbox

Model codes:SC...KFT0/GPLKFT0/1GPL
Engine1.4 i
Gearbox

Manual (5-speed)


Cubic capacity (cc)

1 360

Bore x stroke
(mm) 75 x 77
Max. power: EU standard
(kW)
*
51.5 / 54
Max. power speed
(rpm)

5 200 / 5 200
Max torque: EU standard
(Nm)

115 / 118

Max. torque speed
(rpm) 3 300 / 3 300

Fuel LPG / Unleaded

Catalytic converter Yes
OIL CAPACITY (in litres)


Engine (with filter replacement) 3.0


*
The maximum power corresponds to the value type approved on a test bed, under conditions defined by European legislation (Directive 1999/99/EC).

Technical data
188
The GTW and towed load values indicated are valid up to a maximum altitude of 1 000 metres; the towed load mentioned must be reduced by 10 % for each additional 1 000 metres of altitude.
The speed of a towing vehicle must not exceed 60 mph (10 0 km/h) (comply with the legislation in force in your country).
High ambient temperatures may result in a reduction in the performance of the vehicle to protect the engine; if the ambient temperature is above 37 °C,
limit the towed load.
LPG weights and towed loads (in kg)
Engines1.4 i
GearboxeManual
Model codes:SC...KFT0/GPLKFT0/1GPL



- Unladen weight1 070



- Kerb wei
ght
1 145


- Gross vehicle wei
ght (GV W)

1 529



-
Gross train weight (GTW)

on a 12 % slope 2 329



- Braked trailer (within GTW limit) on a 12 % slope
1 000



- Braked trailer *
(with load transfer within the
GTW limit)
1 000



-
Unbraked trailer
500



- Recommended nose wei
ght 44
* The weight of the braked trailer can be increased, within the GTW limit, if the GVW of the towing vehicle is reduced by an equal amount; warning,
towing using a lightly loaded towing vehicle may have an adverse effect on its road holding.

12
Technical data
189

*
The maximum power corresponds to the value type approved on a test bed, under conditions defined by European legislation (Directive 1999/99/EC).
























Diesel engines and gearboxes
Model codes: SC...8HR48HP4/PS9HK0
EnginesHDi 70 PEFe-HDi 70 PEFHDi 75
GearboxesManual (5-speed)Electronic
(5-speed)
Manual (5-speed)
Cubic capacity (cc) 1 398

1 398

1 560

Bore x stroke (mm)
73.7 x 8273.7 x 82 75 x 88.3

Max. power: EU standard
(kW)
* 50
50
55

Max. power engine speed (rpm)
4 000
4 000 4 000
Max. torque: EU standard
(Nm)160

160185

Max. torque en
gine speed (rpm)
1 750
1 750
1 500

F
uel DieselDiesel
Diesel

Catalytic converter Yes
YesYes

Particle emissions
filter (PEF) Ye s
Ye s
No

OIL CAPACITIES
(in litres)







Engine (with filter replacement) 3.75
3.753.75

.../S
: e-HDi model fitted with Stop & Start.
