You can activate or deactivate the system bymeans of the multifunction screen configuration menu. The system state is memorised whenswitching off the ignition.
For more information on access to the parkingsensors menu, refer to "Configuration / Vehicleparameters" in the "Multifunction screens"section corresponding to your screen.
Operating faults

If there is an operating fault, when
reverse gear is engaged this
warnin
g lamp comes on in the
instrument panel, accompanied byan audible signal (short beep) and a message in the multifunction screen.

Programming
The system will be deactivated automatically when towing a trailer or when a bicycle carrier is fitted (vehiclefitted with a towbar or bicycle carrier recommended by CITROËN).
In bad or wintry weather, ensure that the sensors are not covered with mud,frost or snow.

Driving
134





Reversing camera

A reversing camera is activated automatically
when reverse gear is engaged.The colour image is provided in the navigationscreen.

The reversing camera cannot in any circumstances be a substitute for thevigilance and responsibility of the driver.

Clean the reversing camera regularlyusing a soft, dry cloth.

The space between the blue lines represents
the width of your vehicle except for the door
mirrors.
The blue lines represent the general direction of the vehicle.
The red line represents a distance of about30 cm beyond the edge of your vehicle's
rear bumper. The audible signal becomes
continuous from this limit.
The green lines represent distances of about 1
and 2 metres beyond the edge of your vehicle's
rear bumper.

Checks
140






Checking levels
Oil level


The check is carried out either when
the ignition is switched on using the oil level indicator in the instrument
panel, or using the dipstick.

Engine oil change

Refer to the MAINTENANCE AND
WARR ANT Y GUIDE for details of the inter val
for this operation.
In order to maintain the reliabilit
y of the engine
and emission control system, the use of
additives in the engine oil is prohibited.
It is normal to top up the oil levelbetween two ser vices (or oil changes). CITROËN recommends that you check
the level, and top up if necessary, every3 000 miles (5 000 kms). After topping up the oil, the check when switching on the ignition with the oil level indicator in the instrument panel is not valid during the 30 minutes after topping up. It will onl
y be correct if the vehicle is on level
ground and the engine has been off for more
than 30 minutes. Check all of these levels re
gularly, in line with the MAINTENANCE AND WARR ANT Y GUIDE. Top them up if necessary, unless other wise indicated.
If a level drops significantly, have the corresponding system checked by a CITROËN dealer or a qualified workshop.


Take care when working under the bonnet, as certain areas of the engine may be extremely hot (risk of burns) and the cooling fan could star t atany time (even with the ignition off).



Oil specifi cation

The oil must be the correct grade for your engine and conform to the manufacturer'srecommendations.
Th
e brake fluid level should be close
to the "MA X" mark. If it is not, check
the brake pad wear.
Brake fluid level

Changing the fl uid

Refer to the MAINTENANCE AND
WARR ANT Y GUIDE for details of the interval for this operation.

Fluid specifi cation

The brake fluid must conform to themanufacturer's recommendations and meet
the DOT3 or DOT4 standard.

11
Practical information
161
Rear lamps
1.Brake / sidelamps (P21/5W).2.Direction indicators (PY21W amber).3. Foglamp, right-hand side (PR21W red)Reversing lamp, left-hand side (P21W).
Changing bulbs
These four bulbs are changed from inside the boot: ) spread the four tabs and remove the bulb holder,
)
turn the bulb a quar ter of a turn and change it.
To r efit, carry out these operations in reverseorder.
Take care to engage the lamp unit in its guides,
while keeping it in line with the vehicle.
) open the boot,)
remove the access flap from the
corresponding side trim panel, )
unscrew the butterfly nut securing the lamp unit, )
unclip the lamp unit connector,)
extract the lamp unit carefully pulling in its
middle towards the outside,
Amber or red bulbs, such as thosefor the direction indicators and rear foglamp, must be replaced by bulbs of the same rating and colour. The lamps on the tailgate are dummyunits. They are there for aestheticpurposes only.

Practical information
164




















Changing a fuse
The extraction tweezer and the spare fuses are
located on the back of the dashboard fuseboxcover.
For access to them:)unclip the cover by pulling on the side, )remove the cover completely,)remove the pliers.

Changing a fuse

Before changing a fuse, the cause of the failure
must be identified and rectified. ) Identify the faulty fuse by checking thecondition of its filament.
)
Use the special tweezer to extract the fuse from its housing.)
Always replace the faulty fuse with a fuse of the same rating.)
Check the correspondence between the
number marked on the box, the rating
marked on the fuse and the tables below.
GoodFailed
CITROËN will not accept responsibilityfor the cost incurred in repairing your vehicle or for rectifying malfunctions resulting from the installation of accessories not supplied and notrecommended by CITROËN andnot installed in accordance with its instructions, in par ticular when thecombined consumption of all of the additional equipment connectedexceeds 10 milliamperes.



Installing electricalaccessories
Your vehicle's electrical system isdesigned to operate with standard or optional equipment.
Before installing other electrical equipment or accessories on your vehicle, contact a CITROËN dealer or aqualified workshop.
Access to the tools

11
Practical information
167

Engine compartment
fusebox

The fusebox is located in the enginecompartment near the battery (left-hand side).
Access to the fuses
)
Unclip the cover. )
Change the fuse (see correspondingparagraph). )
When you have finished, close the cover carefully to ensure correct sealing of the
fusebox.
All work on the fuses in the fusebox
located on the battery must be carriedout by a CITRO

Practical information
168
Fuse table
Fuse N°RatingFunctions
F120 AEngine control unit supply, cooling fan unit control relay, multifunction engine control main relay, injection pump (Diesel).
F
215 AHorn.
F
310 AFront / rear wash-wipe.
F420 ADaytime running lamps, LED daytime running lamps.
F
515 ADiesel heater (Diesel), par ticle filter additive pump (Diesel), air
flow sensor (Diesel), fuel pump (1.1i and 1.4i), blow-by heater and electrovalves (VTi).
F
610 A ABS/ESP control unit, secondary brake lamp switch.
F710 AElectric power steering, automatic gearbox.
F
825 AStarter motor control.
F9
10 ASwitching and protection unit (Diesel).
F10
30 AFuel heater (Diesel), blow-by heater (1.1i, 1.4i and Diesel),fuel pump (VTi), injectors and ignition coils (petrol), electronic
thermostat and canister purge electrovalve (1.1i and 1.4i).
F1
140 AHeater blower.

11
Practical information
169
Fuse N°RatingFunctions
F1230 A Windscreen wipers slow / fast speed.
F1
340 A Built-in systems inter face supply (ignition positive).
F14
30 A Valvetronic supply (VTi).
F1
510 A Right-hand main beam headlamps.
F1
610 A
Left-hand main beam headlamps.
F17 15 A
Left-hand dipped beam headlamps.
F18 15 A
Ri
ght-hand dipped beam headlamps.
F1
915 A Oxygen sensors and electrovalves (VTi), electrovalves (Diesel),
EGR electrovalve (Diesel).
F20 10 A Pumps, electronic thermostat
(VTi), water in fuel sensor (Diesel).
F2
15 A Fan assembly control supply, ABS/ESP.
