2013 Citroen C3 ECO mode

Monitoring
42
Tr ip computer, a few definitions
Range
(miles or km)The distance which can still be
travelled with the fuel remainingin the tank. Related to theaverage fuel consumption over
the last few miles (kilometres)
travelled.
Current fuel consumption
(mpg or l/100 km or km/l) Calculated over the last few seconds.


Average fuel consumption
(mpg or l/100 km or km/l)
Calculated since the last trip
computer reset.
Average speed
(mph or km/h)Calculated since the last trip computer reset.

Distance travelled
(miles or km)
Calculated since the last tripcomputer reset.

When the ran
ge falls below 20 miles (30 km),
dashes are displayed. After filling with at least 5 litres of fuel, the range is recalculated and is
displayed when it exceeds 60 miles (10 0 km).


Distance remaining to destination
(miles or km)
This is the distance remaining to be
travelled to the final destination. Itcan be entered by the user.
If the distance is not entered, dashes
are displayed in place of the digits.

Stop & Start time counter
(minutes / seconds or hours /
minutes) If your vehicle is fitted with Stop &Start, a time counter calculates the
time spent in STOP mode during ajourney. It resets to zero every time the
ignition is switched on with the key.



If dashes are displayed continuously while driving in place of the digits, contact a CITROËN dealer or a qualified workshop.


This value may vary following a changein the style of driving or the relief,resulting in a significant change in thecurrent fuel consumption.
This function is only displayed from 20 mph (30 km/h).

2
Multifunction screens
49

"Telephone" Menu
With Audio system on, once this menu is selected you can configure your Bluetooth
hands-free system (pairing), view the various
telephone directories (list of calls, ser vices...)and manage your calls (call, hang up, secondcall, secret mode...).
For more information on the "Telephone"
function, refer to the Audio system par t of the"Audio and telematics" section.
Choice of language
Once this menu has been selected, you canchange the language used by the display
(Deutsch, English, Espanol, Français, Italiano,
Nederlands, Portu
gues, Portugues-Brasil,
Türkçe * ).

For safety reasons, configuration by the
driver of the multifunction screen mustonly be done when stationary.



Display confi guration

Once this menu has been selected, you can gain access to the following settings:


- brightness-video setting,

-
date and time setting,

- selection of units.
Once the fuel consumption units havebeen changed to mpg, the informationin the screen relating to speed and distance also changes to mph and miles respectively.
*
Accordin
g to country of destination. Settin
g the date and time)Select the " Set date and time" function
using the " " or " " button. )Press "OK"
to confirm the selection. )Adjust the settings one by one using the " " or "
" button then confirm with "OK".)Then select the "OK"
box in the screenand confirm.

3
Comfort
57

















Digital air conditioning

The air conditioning operates when the engine is running, as well as in STOP mode with Stop & Star t.


Automatic operation


1. Automatic "comfort" programme
Press the "AUTO"
button.
The "AUTO"symbol is displayed.
We recommend that
you use this mode.
It provides optimised automatic control of
all of the following functions: passenger compartment temperature, air flow, air distribution and air intake, in accordance with
the comfort value that you have chosen.
This system is designed to operate effectivelyin all seasons, with the windows closed.
2. Temperature adjustment
The value indicated on the display corresponds
to a level of comfor t and not to a temperature in
de
grees Celsius or Fahrenheit.
Pr
ess the ""
and ""
buttons to change this value. A setting around
the value 21 enables optimum comfor t to be obtained. However,depending on your requirements, asetting between 18 and 24 is usual.


3. Automatic "visibility" programme
The automatic comfor t programme may not be sufficient for rapid demisting or
defrosting of the windscreen and side
windows (humidity, several passengers,
ice, etc.).
In this case, select the automatic visibility
programme. The button
3 indicator lamp comeson.
The system automatically controls the air conditioning and the flow of air and provides optimum air distribution to the windscreen andside windows. It deactivates air recirculation 5
.
To exit this programme, press button 3
again or "AUTO"
, the indicator lamp on the button goes off and "AUTO"
is displayed.



Manual override

It is possible to adjust one or more functions
manually while leaving the other functions in automatic mode.
The "AUTO"symbol switches off.
To return to automatic mode, press the
"AUTO"button.
For your comfor t, when the engine isswitched off, the settings are retained until the engine is switched on again. To prevent too great a distribution of cold air when the engine is cold, the air flow will only reach its optimum level gradually.
On entering the vehicle, if the interior is very cold or hot, there is no need to change the value displayed in order to reach the required level of comfort.The system corrects the temperaturedifference automatically and as quickly as possible.
Switching to manual mode may not besuitable (temperature, humidity, odour, condensation) and does not provideoptimum comfort.

Access
70

















Window controls System which opens or closes a window manually or automatically. It is fitted with a system which provides protection if an obstacle is detected on the
one-touch models and a deactivation system to prevent misuse of the rear switches on all models.
1.Driver's electric window.2.Passenger's electric window.3.Rear right electric window.4.Rear left electric window.5. Deactivating the rear electric windowand door switches. Electric windows )Press or pull the switch. The
window stops as soon as theswitch is released.



One-touch electric windows
There are two methods of
operation:


- manual mod
e)Press or pull the switch gently.
The window stops as soon as the switch
i
s released. -automatic mode)Press or pull the switch fully. The window
opens or closes completely when theswitch is released. )Pressing the switch again stops themovement of the window.

The electric window switches
remain operational for approximately 45 seconds after the ignition is switchedoff or until a front door is opened.During this period of 45 seconds, if youopen a door while opening a window,the window stops. The ignition mustthen be switched on again to operate the windows.

Visibility
80
C. Foglamp selection ring.
The
foglamps operate with the dipped and mainbeam headlamps.
Rear fo
glamp
Rotate and release the rin
g C:)
forwards a first time to switch on the front foglamps,)
forwards a second time to switch on the
rear foglamp,) rearwards a first time to switch off the rear foglamp,)
rearwards a second time to switch of thefront fog lamps.
Model with rear foglamp only
)
To switch on the foglamp, turn the ring Cforwards.
When the lighting is switched off automatically (with AUTO model), the foglamp and the dipped beam headlamps will remain on. )
To switch off all of the lighting, turn the
ring Crearwards.
Model with front foglamps and a
rear foglamp Front and rear foglamps When the lighting is switched o
ff automatically
(with AUTO model) or when the dippedheadlamps are switched off manually, the
foglamps and sidelamps will remain on. )Turn the ring rear wards to switch off the
foglamps, the sidelamps will then switch
off.



In good or rainy weather, by both day and night, the front foglamps and the rear foglamp are prohibited. In thesesituations, the power of their beams may dazzle other drivers.
Do not forget to switch off the front foglamps and the rear foglamp whenthey are no longer necessary.

5
Visibility
87
Version with Zenith windscreen
1.Rear side reading lamps
2.Rear cour tesy lamp
Central or rear courtesy lamps

Version without Zenith windscreen
A.Central courtesy lamp


Front side reading lamps
)
With the ignition on, the first press of thecorresponding switch switches on the
reading lamp concerned in permanent
lighting mode. ) Following a second press, it comes on:
- when the vehicle is unlocked,
- when the key is removed from the ignition,
- when a door is opened,
- when the remote control locking button
is pressed, in order to locate your
v
ehicle. In this position, the courtes
y lamp
comes on gradually:
- when the vehicle is unlocked,
- when the ke
y is removed from the ignition,
- when a door is opened,
- when the remote control lockin
g button is
activated, in order to locate your vehicle.
It switches o
ff gradually:
- when the vehicle is locked,
- when the ignition is switched on,
-
30 seconds after the last door is closed.
Permanentl
y off.

Permanent lighting.
It switches o
ff gradually:


- when the vehicle is locked,

- when the i
gnition is switched on,

- 30 seconds after the last door is closed.
To switch o
ff the rear cour tesy lamp, place it in
the "permanently off" position.









Courtesy lamps Selection and control of the various passenger compartment lamps.

In permanent lighting mode, the lighting durationvaries, according to the circumstances:-with the ignition off, approximately ten minutes,-in energy economy mode, approximately thirty seconds,
-with the engine running, unlimited.

Visibility
88








Interior mood lighting


Switching on

At night, the illumination of the central
dashboard storage compar tment comes
on automatically when the sidelamps are switched on.
On cer tain versions, three lamps located in the
suppor t between the roof and the automatic
da
y/night interior mirror come on as well.


Switching off

The interior mood lighting switches off
automatically when the sidelamps areswitched off.
It can be switched off manually using the
instrument panel lighting rheostat button.
) With the lighting on, press several times on
the left hand button of the instrument panel
to pro
gressively reduce the dashboard lighting level.) Press again to reduce the lighting level
to the minimum and switch off the interior
mood lighting.
This comes on automatically when the boot is
opened and goes off automatically when the boot is closed.




Boot lamp
The dimmed passenger compar tment lighting improves visibility in the vehicle when the light
is poor.
The lighting time varies according tothe circumstances:

- when the ignition is off, approximately ten minutes,

- in energy economy mode,approximately thirty seconds,

- when the engine is running, no limit.

Driving
116








Gear shift indicator


The system adapts its gear change recommendation according to thedriving conditions (slope, load, ...) andthe demands of the driver (power, acceleration, braking, ...). The system never suggests:


- engaging first gear,

- engaging reverse gear,

- engaging a lower gear. S
ystem which reduces fuel consumption by advising the driver to change up.
With an electronic gearbox, the system is only active in Manual mode.
Operation
Depending on the driving situation and your
vehicle's equipment, the system may advise you to skip one (or more) gear(s). You can follow this instruction without engaging the
intermediate gears.
The
gear engagement recommendations mustnot be considered compulsory. In fact, the configuration of the road, the amount of trafficand safety remain determining factors whenchoosing the best gear. Therefore, the driver remains responsible for deciding whether or not
to follow the advice given by the system.
This function cannot be deactivated.
Example:


- You are in third
gear.
The information appears in the instrument panel in the form of an arrow.
On vehicles with manual gearbox, the arrow can be accompanied by the recommendedgear.

- Yo u
press the accelerator pedal.

- The s
ystem may suggest that you engage ahigher gear.
