2013 Acura ILX navigation update

15Quick Reference Guide
Troubleshooting
For more Information
(P193)
Why does the vehicle position icon on the map “lag” a
short distance behind my actual position, especially at
intersections?
This is normal. The navigation system is unaware of the
width of intersections. Large differences in vehicle position
can indicate a temporary loss of the GPS signal.
Why does the “time to destination” display sometimes
increase even though I am getting closer to my
destination?
The “time to destination” is based on your actual road
speed and traffic conditions to give you a better estimate
of arrival time.
Why does my clock frequently change the time forward
and backward by one hour?
The clock setting is automatically updated based on your
GPS location. If you normally drive between two time
zones, the clock may keep adjusting the time. You can
turn this feature off.
2Clock Adjustment
P. 55
How do I specify a destination when an entered city or
street could not be found?
Try entering the street first. Some cities are lumped in with
a major metro area. In rural “unverified” areas or new
subdivisions, streets may be missing or only partially
numbered.
How do I turn on the navigation system voice guidance?
1.Press the INFO button. Rotate i to select Set up and
press u. Check that Volume is not set to OFF.
2.Move y to select Other, rotate i to select Basic
Settings, and press u. Set Voice Recognition Tutor
to ON if you want the system to provide confirmations
and system prompts.
My battery was disconnected or went dead, and the
navigation system is asking for a code. Where do I find it?
In most cases, you do not need to enter a code. Simply
press and hold the VOL 9 (Volume/Power) button for two
seconds; the system should reactivate.
2System Initialisation
P. 206

68
XX
Entering a Destination
XAddress
Navigation
3.Rotate i to select the destination
city from the list. Press u.X
Next, you are prompted to enter
a street name. 2Selecting a Street
P. 69
HDEST/ROUTE button
X Address
X City
The name of the city where you are currently located is displayed.
1.Enter the name of a different city,
or move r to select OK for the
current city.
X
Move r to select LIST to display
a list of cities.
■Selecting a City
1Selecting a City
Vehicle position may not be displayed when:•The automobile is travelling off-road.•The vehicle position data cannot be updated.
You do not need to enter spaces or symbols
(e.g., &, -, %). Partial matches are supported
(e.g., “ANGELES” to find “LOS ANGELES”).

146
XX
Playing Hard Disc Drive (HDD) Audio
XUpdating Gracenote® Album Info
Audio
Updating Gracenote® Album InfoHAUDIO button (in HDD or DISC mode)
X AUDIO MENU
X HDD Setup
Update the Gracenote® Album Info (Gracenote® Media Database) that is included
with the navigation system.
1.Insert the update disc into the disc
slot or connect the USB flash drive
that includes the update.
2.Rotate i to select Update
Gracenote Info. Press u.
3.Rotate i to select USB or Disc
update source media. Press u.
4.Rotate i to select Yes on the
confirmation screen. Press u.
X
The system updates the
Gracenote information.
5.Rotate i to select OK on the
confirmation screen. Press u.
1Updating Gracenote® Album Info
To acquire updated files:•Consult a dealer.•Canada: Visit www.acura.ca.
Once you perform an update, any information
you edited before will be overwritten or erased.
Remaining capacity Maximum capacity
Gracenote version
number

183
Other Features
This section describes the useful functions incorporated into the
navigation system.
Calendar................................................ 184
Calculator.............................................. 186
Unit Conversion ................................... 186
Information Functions.......................... 188
Scenic Road Information ...................... 188
System/Device Information ................... 188
Map Update Status .............................. 189
Roadside Assistance ............................. 189
Key to ZAGAT Ratings .......................... 190
Show Wallpaper ................................... 191
Multi-View Rear Camera...................... 192

188Other Features
Information FunctionsScenic Road InformationHINFO button
X Other
X Scenic Road Information
View a list of scenic roads for each state (U.S. only).
1.Rotate i to select a state. Press
u.
2.Rotate i to select a scenic road.
Press u.
3.Rotate i to set the place as a
destination or add to the
destination list. Press u.
System/Device InformationHINFO button
X Other
X System/Device Information
View database, software, device, and vehicle identification information.
1Scenic Road Information
If you select a scenic road that runs through
multiple states, only the portion of the road in
the selected state is displayed. You can also set
the scenic road as a destination or waypoint.1System/Device Information
You will need this information when ordering a
map update.
2Obtaining a Navigation Update Data
P. 211

189
XX
Information Functions
XMap Update Status
Other Features
Map Update StatusHINFO button
X Map Update Status
Check the map data update status when updating the map database.
Roadside AssistanceHINFO button
X Other
X Roadside Assistance
Acura Roadside Assistance is provided as a service to Acura clients. Use this feature
to call for assistance when a Bluetooth-compatible phone is paired to Bluetooth®
HandsFreeLink®.
Rotate i to select Call. Press u to
begin dialing.
1Map Update Status
This operation is only available during a database
update.
2Obtaining a Navigation Update Data
P. 2111Roadside Assistance
Your Bluetooth-compatible phone must be
paired to use this feature.
2Pairing a Phone P. 164

193
Troubleshooting
Troubleshooting................................... 194
Map, Voice, Entering Destinations ........ 194
Guidance, Routing ............................... 196
Update, Coverage, Map Errors ............. 198
Display, Accessories.............................. 198
Multi-View Rear Camera ...................... 198
Miscellaneous Questions ...................... 199
Error Messages...................................... 200
Navigation System ................................ 200
Disc Player............................................ 201
iPod® .................................................. 202
USB Flash Drive .................................... 203

196
XX
Troubleshooting
XGuidance, Routing
Troubleshooting
Guidance, Routing
Problem
Solution
The navigation system does not route me the same
way I would go or the same way as other mapping
systems.
The navigation system attempts to generate the optimal route. You can change the
route preferences used when calculating a route. 2Changing the Route Preference
P. 88
The street I’m on is not shown on the map screen.
The mapping database is constantly undergoing revision. You can access the most
recent information on the internet. 2Map Coverage
P. 211
The vehicle position icon is not following the road and
the “GPS icon” text in the upper left hand corner of
the screen is white or missing.
• Check that the GPS antenna (located in the dashboard) is not blocked. For best
reception, remove items from the dashboard, such as radar detectors, cell phones,
or loose articles.
• Metallic tinting or other aftermarket devices can interfere with the GPS reception.
Please consult a dealer. 2GPS System
P. 208
The blue highlighted route and voice guidance
stopped or turned into a blue/pink dashed line before I
got to my destination.
Your route has entered an unverified area. 2Unverified Area Routing
P. 50
How do I stop the map from rotating as I drive along?
Press the ENTER button to display the Map Menu. Select Map Information > North-
up, or say d “Display north-up” to change the map orientation.
Sometimes, I cannot select between the North-up and
Heading-up map orientations.
The Heading-up map orientation can only be shown in the lower scales (80 m - 1.6 km
scales). 2Map Scale and Functions
P. 108
The “time to destination” display sometimes increases
even though I am getting closer to my destination.
If your speed reduces due to slower traffic, the navigation system updates the “time to
destination” based on your actual road speed to give you a better estimate of arrival
time.
The vehicle position icon on the map “lags” a short
distance behind, especially when I arrive at an
intersection.
This is normal. The navigation system is unaware of the width of intersections. Large
differences in vehicle position can indicate a temporary loss of the GPS signal. 2GPS System
P. 208
