2012 VOLKSWAGEN TIGUAN Owners Manual

Removing and reinstalling head restraints

Fig. 49 Removing the front head restraints.

Fig. 50 Removing the rear head restraints.

Installing the front head restraints
x Position head restraint properly over the head restraint guides of the respective seat backrest and insert the head restraint into the guides until it clicks.
x Push the head restraint down while pressing button (1).
x Adjust the head restraint according to the occupant's size ⇒  Adjusting front and rear head restraints.
Removing the rear head restraints
x Unlock the rear bench and fold it forward ⇒ page 145, Luggage compartment.
x Pull the head restraint all the way up ⇒ .
x Slide a flat object, such as a plastic credit card, underneath the right side of the cap on the right-
hand seat guide rod ⇒ fig. 50 (2) to unlock the head restraint.
x Use one hand to hold the release button in with the flat object. With your other hand, lift the same guide rod slightly to expose a notch in the rod at the bottom (can be seen and felt with fingers). The right-hand guide rod is now released.
x To release the left-hand guide rod, press button (1) in (towards guide rod) and hold.
x Pull the head restraint out completely while holding button (1).
x Fold the backrest of the rear bench back so that it locks securely.
Installing the rear head restraints
x Unlock the rear bench and fold it forward ⇒  Luggage compartment.
x Position head restraint properly over the head restraint guides of the respective seat backrest and insert the head restraint into the guides.
x Push the head restraint down while pressing button (1).
x Fold the backrest of the rear bench back so that it locks securely.
x Adjust the head restraint according to the occupant's size ⇒  Adjusting front and rear head restraints.
WARNING
Driving without head restraints or with improperly adjusted head restraints increases the risk of serious injuries in a collision.
x Always drive with the head restraints in place and properly adjusted to help minimize the risk of neck injury in crash.
x Always reinstall head restraints as soon as possible so that vehicle occupants are properly protected.
NOTICE
When removing or reinstalling the head restraint, take care that the head restraint does not strike the headliner or the back of the front seat. The headliner or other parts of the vehicle could otherwise be damaged.

Adjusting the steering wheel position

Fig. 51 Manual adjustment for steering wheel position.

Fig. 52 Steering wheel: 9 o'clock and 3 o'clock positions.

WARNING
Improper use of the steering column adjustment feature can result in serious personal injury and even death.
x Always pull the lever ⇒ fig. 51 (1) firmly upward after adjusting the steering column so that the steering wheel does not change position suddenly while the vehicle is moving.
x Never adjust the steering column while the vehicle is moving. If you find that you need to adjust the steering wheel while driving, stop the vehicle in a safe place and make the proper adjustment.
x Never adjust the steering wheel so that it points toward your face. Always make sure that the steering wheel points toward your chest. Otherwise, the airbag system cannot protect you properly in the event of a crash.
x Always hold the steering wheel on the outside of the steering wheel rim with your hands
at the 9 o'clock and 3 o'clock positions ⇒ fig. 52 to help reduce the risk of serious personal injury if the driver airbag inflates.
x Never hold the steering wheel at the 12 o'clock position or with your hands anywhere inside the steering wheel or on the steering wheel hub. Holding the steering wheel the wrong way increases the risk of severe injury to the arms, hands, and head if the driver airbag deploys.
Center armrest

Fig. 53 Front center armrest.

Fig. 54 Folded down rear center armrest.

Seat functions

Function Action for seat heating ⇒ fig. 55
Switch on: Press the A or e button. Seat heating is switched on to maximum.
Adjusting heating level: Press the button A or e repeatedly until the desired heating level is set.
Switch off: Press the button A or e repeatedly until all indicator lights in the button are off.

Special seat heating features
On the driver side the seat heating will resume at the setting that was set when the ignition was switched off. However, this feature only works if the ignition is switched back on within 10 minutes.
People suffering from a low level of perceived pain or a lowered awareness of pain as from
medication, paralysis, or chronic illness (e.g. diabetes) should NEVER use the seat heating feature ⇒ 
.
The use of seat heating by persons with these conditions could result in burns to the back, buttocks, and legs that may take a long time to heal and may never heal completely. If you have any of these conditions, you should take regular breaks and get out of the vehicle, particularly on long trips. Consult your doctor for advice regarding your specific condition.
WARNING
Certain medical conditions, such as paralysis and diabetes, and certain medications, can increase the risk of serious burns when the seat heating feature is switched on.
x Vehicle occupants who have a low level of perceived pain or a lowered awareness of pain can receive serious burns to the back, buttocks, and legs that take a long time to heal or may never heal completely.
x Never use the seat heating feature if you or your passengers are at risk of being burned because of a medical condition. Take regular breaks and get out of the vehicle, particularly on long trips. Consult your doctor for advice regarding your specific condition.
x Never let exposed skin remain in contact with the seat upholstery when the seat heating is being used.
WARNING
A wet seat can cause the seat heating to malfunction and increase the risk of serious burns.
x Always make sure the seats are dry before using the seat heating.
x Never sit on the seat with wet clothes.
x Never put damp or wet things including clothes on the seat.
x Never spill liquids on the seats.
NOTICE
x To help prevent damage to electrical and other parts in the seat, do not kneel on the front seats or apply concentrated pressure to a small area of the seat or backrest.

x Liquids, sharp objects and things that do not let the heat in the seat escape into the air, including, for example, a child restraint, a blanket or seat covers on the seat can damage seat heating.
x If you smell an odor, immediately shut off seat heating and have it checked by an authorized Volkswagen dealer or authorized Volkswagen Service Facility.
x Never install leather upholstery on a vehicle with seat heating that originally had cloth upholstery. The seat heating elements for seats with cloth seats will overheat if the cloth upholstery is replaced with leather upholstery.
Switch off seat heating when it is not needed to help reduce unnecessary fuel consumption.
Memory seat

Fig. 56 On the outer side of the driver seat: Memory buttons.
