2012 TOYOTA SIENNA turn signal

701
4-3. Do-it-yourself maintenance
4
Maintenance and care
SIENNA_U (OM45477U)
FuseAmpereCircuit
24 FAN 60 A Electric cooling fans
25 HAZ 15 A Turn signal lights, gauges and
meters
26 RSE 15 A Rear seat entertainment system
27 MIRROR
*310 A Outside rear view mirror control,
outside rear view mirror heaters
28 AMP 30 A Audio system
29 VSC NO.2 30 A Vehicle dynamics integrated man-
agement, ABS, vehicle stability
control
30 ST 30 A Starting system
31 P/I 40 A Horn, left-hand headlight (low
beam), right-hand headlight (low
beam)
32 H-LP MAIN
*140 A Discharge headlight
SPARE
*430 A Spare-fuse
33 AM2
*530 A “ST NO.2”, “GAUGE NO.2” and
“IG2” fuses
34 VSC NO.1 50 A Vehicle dynamics integrated man-
agement, ABS, vehicle stability
control

709
4-3. Do-it-yourself maintenance
4
Maintenance and care
SIENNA_U (OM45477U)
Light bulbs
You may replace the following bulbs by yourself. The difficulty level
of replacement varies depending on the bulb. If necessary bulb
replacement seems difficult to perfor m, contact your Toyota dealer.
For more information about replacing other light bulbs, contact your
Toyota dealer.
■ Preparing for light bulb replacement
Check the wattage of the light bulb to be replaced. ( P. 796)
■ Turning off the power back door main switch
P. 8 4
■ Front bulb locations
Fog light Headlight high beam
and daytime running
lights Headlight
low beam
Front turn signal/parking
and front side marker
lights

710 4-3. Do-it-yourself maintenance
SIENNA_U (OM45477U)
Replacing light bulbs■ Headlight low beams (halogen bulb)
For left side only:
Open the fuse box cover. ( P. 696)
Unplug the connector while
pushing the lock release.
■ Rear bulb locations
Back-up lightRear turn
signal light
License plate
lightsTail light
STEP1
STEP2

713
4-3. Do-it-yourself maintenance
4
Maintenance and care
SIENNA_U (OM45477U)
■
Front turn signal/parking and front side marker lights
For left side only:
Open the fuse box cover. ( P. 696)
Vehicles without discharge headlights Turn the bulb base counterclock-
wise.
Vehicles with discharge headlights
Remove the light bulb.
STEP1
STEP2
STEP2
STEP3

714 4-3. Do-it-yourself maintenance
SIENNA_U (OM45477U)■
Rear turn signal lights
Remove the securing bolts and
remove the unit.
Turn the bulb base counterclock-
wise.
Remove the light bulb.
STEP1
STEP2
STEP3

722
SIENNA_U (OM45477U)
5-1. Essential information
Emergency flashers
NOTICE
■To prevent battery discharge
Do not leave the emergency flashers on longer than necessary when the
engine is not running.
Use the emergency flashers if th e vehicle malfunctions or is
involved in an accident.
Press the switch to flash all
the turn signal lights. To turn
them off, press the switch
once again.

796 6-1. Specifications
SIENNA_U (OM45477U)
Light bulbs
A: D4S discharge bulbsB: H11 halogen bulbs
C: HB3 halogen bulbs D: Wedge base bulbs (clear)
E: Wedge base bulbs (amber) F: Double end bulbs
Light BulbsBulb No.WTy pe
Exterior Headlights (low beam)
Discharge bulbs
Halogen bulbs 
35
55 A
B
Headlights (high beam) 9005 60 C
Front fog lights 55 B
Front turn signal/parking/side
marker lights 3457NAK 28/8 E
Rear turn signal lights WY21W 21 E
Tail lights W5W 5 D
Back-up lights 921 16 D
License plate lights W5W 5 D
Outer foot lights W6W 6 D
Interior Front personal/interior lights W5W 5 D
Rear personal/interior lights W5W 5 D
Luggage compartment light
5F
Vanity lights 2.8 F
Front door courtesy lights 5D

818 6-2. Customization
SIENNA_U (OM45477U)
ItemFunctionDefault settingCustomizedsetting
Power
sliding door
(if equipped)
(
P. 67) Operation signal
(buzzer)
Off On
Opening and closing
operation One short push Push and hold
Automatic
light control
system
( P. 266) Time elapsed before
headlights automati-
cally turn off after doors
are closed
*
30 seconds
0 second
60 seconds
90 seconds
Daytime running light
system (U.S.A. only) On Off
Light sensor sensitivity Level 3 Level 1 to 5
Automatic High Beam
(if equipped)
*On Off
Alarm
system
( P. 162) Time elapsed before
the alarm is set
14 seconds 30 seconds
Multi-
information
display
( P. 252) Language selection
*English
French
Spanish
