2012 TOYOTA AVALON flat tire

538 6-1. Specifications
Glossary of tire terminology
Tire related termMeaning
Cold tire inflation
pressure Tire pressure when the vehicle has been
parked for three hours or more, or has not
been driven more than 1 mile or 1.5 km under
that condition
Maximum inflation
pressure The maximum cold inflated
pressure to which a
tire may be inflated, s hown on the sidewall of
the tire
Recommended
inflation pressure Cold tire inflation pressure recommended by a
manufacturer.
Accessory weight The combined weight (in excess of those stan-
dard items which may be replaced) of trans-
mission, power steering, power brakes, power
windows, power seats, radio and heater, to the
extent that these items are available as factory-
installed equipment (whether installed or not)
Curb weight The weight of a motor vehicle with standard
equipment, including the maximum capacity of
fuel, oil and coolant, and if so equipped, air
conditioning and additional weight optional
engine
Maximum loaded
vehicle weight The sum of:
(a) Curb weight
(b) Accessory weight
(c) Vehicle capacity weight
(d) Production options weight
Normal occupant
weight 150 lb. (68 kg) times the number of occupants
specified in the second column of Table 1
* that
follows

540 6-1. Specifications
Tire related termMeaning
Weather side The surface area of the rim not covered by the
inflated tire
Bead The part of the tire that is made of steel wires,
wrapped or reinforced by ply cords and that is
shaped to fit the rim
Bead separation A breakdown of the bond between components
in the bead
Bias ply tire A pneumatic tire in which the ply cords that
extend to the beads are laid at alternate angles
substantially less than 90 degrees to the cen-
terline of the tread
Carcass The tire structure, except tread and sidewall
rubber which, when inflated, bears the load
Chunking The breaking away of pieces of the tread or
sidewall
Cord The strands forming the plies in the tire
Cord separation The parting of cords from adjacent rubber com-
pounds
Cracking Any parting within the tread, sidewall, or inner-
liner of the tire ext
ending to cord material
CT A pneumatic tire with an inverted flange tire
and rim system in which the rim is designed
with rim flanges pointed radially inward and the
tire is designed to fit on the underside of the
rim in a manner that encloses the rim flanges
inside the air cavity of the tire
Extra load tire A tire designed to operate at higher loads and
at higher inflation pressures than the corre-
sponding standard tire

541
6-1. Specifications
6
Vehicle specifications
Tire related termMeaning
Groove The space between two adjacent tread ribs
Innerliner The layer(s) forming the inside surface of a
tubeless tire that contains the inflating medium
within the tire
Innerliner separation The parting of the innerliner from cord material
in the carcass
Intended outboard
sidewall (a)The sidewall that cont
ains a whitewall, bears
white lettering, or bears manufacturer, brand,
and/or model name molding that is higher or
deeper than the same molding on the other
sidewall of the tire, or
(b)The outward facing sidewall of asymmetrical
tire that has a particular side that must always
face outward when mounted on a vehicle
Light truck (LT) tire A tire designated by its manufacturer as prima-
rily intended for use on lightweight trucks or
multipurpose passenger vehicles
Load rating The maximum load that a tire is rated to carry
for a given inflation pressure
Maximum load rating The load rating for a tire at the maximum per-
missible inflation pressure for that tire
Maximum permissible
inflation pressure The maximum cold inflation pressure to which
a tire may be inflated
Measuring rim The rim on which a tire is fitted for physical
dimension requirements
Open splice Any parting at any junction of tread, sidewall, or
innerliner that extends to cord material
Outer diameter The overall diameter of an inflated new tire

542 6-1. Specifications
Tire related termMeaning
Overall width The linear distance between the exteriors of
the sidewalls of an inflated tire, including eleva-
tions due to labeling, decorations, or protective
bands or ribs
Passenger car tire A tire intended for use on passenger cars, mul-
tipurpose passenger vehicles, and trucks, that
have a gross vehicle weight rating (GVWR) of
10,000 lb. or less
Ply A layer of rubber-coated parallel cords
Ply separation A parting of rubber compound between adja-
cent plies
Pneumatic tire A mechanical device made of rubber, chemi-
cals, fabric and steel or
other materials, that,
when mounted on an automotive wheel, pro-
vides the traction and contains the gas or fluid
that sustains the load
Radial ply tire A pneumatic tire in which the ply cords that
extend to the beads are laid at substantially 90
degrees to the centerline of the tread
Reinforced tire A tire designed to operate at higher loads and
at higher inflation pressures than the corre-
sponding standard tire
Section width The linear distance between the exteriors of
the sidewalls of an inflated tire, excluding ele-
vations due to labeling, decoration, or protec-
tive bands

571
Alphabetical index
Emergency, in case of
If a warning light turns on ..... 479
If the electronic key does not
operate properly ................. 505
If the engine will not start...... 501
If the shift lever cannot be
shifted from P ..................... 503
If the battery is discharged .. 508
If the warning buzzer
sounds ............................... 479
If the warning light
turns on .............................. 479
If you have a flat tire ............ 491
If you lose your keys............. 504
If you think something is wrong ................................. 477
If your vehicle becomes
stuck................................... 515
If your vehicle has to be stopped in an emergency ................ 516
If your vehicle needs to be towed ................................. 473
If your vehicle overheats ...... 512
Engine Compartment........................ 406
Engine switch ............... 154, 158
Hood ..................................... 403
How to start the engine ........................ 154, 158
Identification number ............ 521
If the engine will not start...... 501
Ignition switch ............... 154, 158
Overheating .......................... 512
Engine compartment cover .... 407
Engine coolant Capacity ............................... 524
Checking .............................. 412
Preparing and checking before winter ...................... 219
Engine coolan t temperature
gauge ..................................... 169
Engine immobilizer system ...... 96 Engine oil
Capacity ................................522
Checking ...............................408
Preparing and checking before winter .......................219
Event data recorder ...................21
Floor mats.................................368
Fluid Brake .....................................414
Washer ..................................420
Fog lights Switch....................................182
Wattage .................................527
Foot light...................................346
Front passenger occupant classification system ............119
Front passenger’s seat belt reminder light.........................482
Front seats Adjustment ..............................59
Driving position memory..........63
Front turn signal lights Wattage .................................527
Fuel
Capacity ................................522
Fuel gauge ............................169
Fuel pump shut off system ....478
Gas station information .........580
Information ............................528
Refueling .................................92
Fuel door.....................................92
Fuel filler door ............................92
Fuel pump shut off system .....478
Fuses.........................................444
Garage door opener.................372
Gas station information...........580
Gauges ......................................169
Glove box..................................350
F
G

574 Alphabetical index
Seat heaters.............................. 363
Seating capacity....................... 217
SeatsAdjustment ........................59, 61
Adjustment precaution ......60, 62
Child seats/child restraint system installation .............. 130
Cleaning ................................ 389
Climate control ...................... 363
Climate control seat .............. 363
Driver’s seat position
memory .................................63
Head restraint..........................67
Properly sitting in the seat ..... 104
Seat heaters .......................... 363
Service reminder indicators .............................. 173
Shift lever Automatic transmission ......... 161
If the shift lever cannot be shifted from P...................... 503
Shift lock system ..................... 503
Shopping bag hooks ............... 370
Side airbags.............................. 106
Side marker lights Switch.................................... 178
Side mirror Adjustment ..............................82
Mirror position memory ...........63
Smart key system Antenna location .....................32
Entry function ..........................30
Starting the engine ................154
Spare tire Inflation pressure................... 526
Storage location .................... 491
Spark plug ................................ 524
Specifications........................... 520
Speedometer ............................ 169 Steering wheel
Adjustment .............................. 78
Audio switches ...................... 286
Climate switches ................... 236
Steering wheel memory .......... 63
Storage compartment.............. 354
Storage feature ........................ 349
Stuck If your vehicle becomes stuck ................................... 515
Sun visors ................................ 357
Switch
Emergency flasher switch ..... 472
Engine switch ................ 154, 158
Fog light switch ..................... 182
Hazard light switch ................ 472
Ignition switch ............... 154, 158
Light switches ....................... 178
Power door lock switch ........... 48
Power window switch .............. 85
Window lock switch ................. 85
Wipers and washer switch .... 189
Tail lights Replacing light bulbs ............. 465
Switch ................................... 178
Wattage................................. 527
Theft deterrent system
Alarm....................................... 99
Engine immobilizer system ..... 96
Theft prevention labels ........... 103
Tire inflation pressure ............. 526
Tire information Glossary ................................ 538
Size ....................................... 534
Tire identification number...... 533
Uniform Tire Quality
Grading ............................... 535
T

575
Alphabetical index
Tires
Chains .................................. 221
Checking .............................. 421
If you have a flat tire ............. 491
Inflation pressure .................. 526
Information ........................... 532
Replacing ............................. 491
Rotating tires ........................ 421
Size ...................................... 526
Snow tires............................. 222
Tire pressure warning
system........................ 422, 482
Tools......................................... 491
Total load capacity .................. 217
Towing Dinghy towing ....................... 225
Trailer towing ........................ 224
TRAC ........................................ 207
Trip information....................... 175
Trunk Extending a space ................ 371
Opener ................................... 54
Wattage ................................ 527
Turn signal lights Replacing light bulbs ............ 455
Switch ................................... 166
Wattage ................................ 527
Vanity lights Vanity lights .......................... 358
Wattage ................................ 527
Vanity mirrors .......................... 358
Vehicle identification number................................... 521
Vehicle data recording.............. 20
Vehicle load limits ................... 217
VSC ........................................... 207 Warning buzzers
Brake system ........................479
Downshifting..........................164
Open door ............................481
Seat belt reminder .................482
Warning lights Anti-lock brake system ..........481
Automatic heading light leveling system .... ...............481
Brake system ........................479
Charging system .... ...............480
Low fuel level ........................482
Malfunction indicator lamp ....480
Open door .............................481
Seat belt reminder light .........482
SRS airbags ..........................481
Tire pressure warning light .....................................482
Vehicle stability control..........481
Washer
Checking ...............................420
Preparing and checking before winter .......................219
Switch....................................189
Washing and waxing ...............386
Weight Cargo capacity ......................212
Load limits .............................217
Weight ...................................520
Wheels ......................................434
Window glasses ........................85
Window lock switch ...................85
Windows Power windows .......................85
Rear window defogger ..........237
Washer ..................................189
Windshield wipers ...................189
Winter driving tips ...................219
Wireless remote control key Locking/Unlocking ...................42
Replacing the battery ............440
WMA disc ..................................259
V
W

576
What to do if...
What to do if...
A tire puncturesP. 491If you have a flat tire
The engine does not start
P. 9 6Engine immobilizer system
P. 501If the engine will not start
P. 508If the battery is discharged
The shift lever cannot be
moved outP. 503If the shift lever cannot be shifted
from “P”
The engine coolant temperature
gauge enters the red zone
Steam can be seen coming
from under the hood
P. 512If your vehicle overheats
The key is lostP. 504If you lose your keys
The battery runs outP. 508If the battery is discharged
The doors cannot be lockedP. 4 7Doors
The horn begins to soundP. 9 9Alarm
The vehicle is stuck in mud
or sandP. 515If the vehicle becomes stuck
