2012 Peugeot 508 Owner's Manual - RHD (UK, Australia)

10
223
Technical data
ENGINES AND GEARBOXES
Petrol engines1.6 litre VTi120 hp1.6 litre THP15 6 hp
Gearboxes
Electronic gear control (6-speed)
Manual(6-speed)


Automatic (6-speed)
Model codes8D5FH8/P - 8E5FH8/P8D5FS8/P - 8E5FS8/P 8D5FV8 - 8E5FV8

8D5FNA - 8E5FNA 8D5FVA - 8E5FVA

Cubic capacity (cc) 1 598
1 598

Bore x stroke (mm) 77 x 85.877 x 85.8

Max power: EU standard (kW) 858811 0115

Max power engine speed
(rpm)
6 000
6 000
Max torque: EU standard
(Nm)160

240

Max torque en
gine speed (rpm)
4 250
1 400

Fuel
Unleaded
Unleaded

Catalytic converter yes yes
OIL CAPACITIES (in litres)

Engine (with filter replacement) 4.25
4.25

224
Technical data
WEIGHTS AND TOWED LOADS (in kg)
Petrol engines1.6 litre VTi120 hp1.6 litre THP156 hp
GearboxesElectronic gear control (6-speed)


Manual(6-speed)
Automatic(6-speed)

Model codes
8D5FH8/P - 8E5FH8/P 8D5FS8/P - 8E5FS8/P 8D5FV8 - 8E5FV8
8D5FNA - 8E5FNA 8D5FVA - 8E5FVA
OutlineSaloon
SW
Saloon SW
Saloon
SW


- Unladen wei
ght 1 390
1 410
1 400
1 500
1 410
1 430



- Kerb weight *

1 465 1 485
1 475
1 575
1 485
1 505


- Gross vehicle wei
ght (GV W)
1 945
2 0551 9952 140
2 015
2 10 0



- Gross train weight (GT W)

on a 12 % gradient 3 245 3 355 3 495 3 640 3 615 3 600


- Braked trailer
(within GTW limit) on a 10 % or 12 % gradient
1 300

1 3001 5001 500
1 500

1 500



- Braked trailer **
(with load transfer within
the GTW limit)1 575 1 5751 775
1 775
1 775
1 775



-
Unbraked trailer

730
740735

745

740
750



- Recommended nose weight 7575

*

The kerb weight is equal to the unladen weight + driver (75 kg).
**

The weight of the braked trailer can be increased, within the GTW limit, if the GV W of the towing vehicle is reduced by an equal amount; warning,
towing using a lightly loaded towing vehicle may have an adverse effect on its road holding.
The GTW and towed load values indicated are valid up to a maximum altitude of 1 000 metres; the towed load mentioned must be reduced by 10 % for each additional 1 000 metres of altitude.
The speed of a towing vehicle must not exceed 60 mph (10 0 km/h) (comply with the legislation in force in your country).
High ambient temperatures may result in a reduction in the performance of the vehicle to protect the engine; if the ambient temperature is above 37 °C,
limit th
e towed load.

10
225
Technical data
* The kerb weight is equal to the unladen weight + driver (75 kg).
** The weight of the braked trailer can be increased, within the GTW limit, if the GVW of the towing vehicle is reduced by an equal amount; warning,
towing using a lightly loaded towing vehicle may have an adverse effect on its road holding.
WEIGHTS AND TOWED LOADS (in kg)
Petrol engine1.6 litre THP 160 hp
Gearbox

Manual(6-speed)
Model code

-
Outine
Saloon
SW


- Unladen wei
ght -
-


- Kerb wei
ght *-
-



- Gross vehicle wei
ght (GV W)
-
-


- Gross train wei
ght (GTW)

on a 12 % gradient -
-



- Braked trailer
(within GTW limit) on a 10 % or 12 % gradient--



- Braked trailer **
(with load transfer within the GTW limit)
-
-


-
Unbraked trailer --



- Recommended nose weight
-
The GTW and towed load values indicated are valid up to a maximum altitude of 1 000 metres; the towed load mentioned must be reduced b
y 10 % for
each additional 1 000 metres of altitude.
The speed of a towing vehicle must not exceed 60 mph (10 0 km/h) (comply with the legislation in force in your country).
High ambient temperatures may result in a reduction in the performance of the vehicle to protect the engine; if the ambient temperature is above 37 °C, limit the towed load.

226
Technical data
Diesel engine1.6 litre HDi110 h p
Gearboxes
Manual(5-speed)


Electronic gear control (6-speed)

Model codes8D9HL0 - 8E9HL08D9HR8/PS - 8E9HR8/PS
Outline
Saloon
SWSaloonSW
Cubic capacit
y (cc)
1 560
1 560

Bore x stroke (mm)75 x 88.3

75 x 88,3

Max power: EU standard
(kW)
82
82
Max power en
gine speed (rpm) 3 600
3 600

Max torque: EU standard
(Nm) 240
270

Max torque engine speed (rpm) 1 750
1 750

F
uel Diesel

Catalytic conver ter
yes

Particle emission filter
yes
OIL CAPACITIES (in litres)

Engine (with filter replacement) 3.25

10
227
Technical data
ENGINES AND GEARBOXES
Diesel engines2.0 litre HDi 14 0 hp2.0 litre HDi163 hp
GearboxesManual (6-speed)


Automatic
(6-speed)Manual (6-speed)

Model codes8DRHR8 - 8ERHR8 8DRHF8 - 8ERHF88DRHHA - 8ERHHA 8DRHDA - 8ERHDA
8DRHH8 - 8ERHH8

OutlineSaloon
SWSaloon SWSaloon SW
Cubic capacit
y (cc) 1 997 1 997
Bore x stroke
(mm)
85 x 88 85 x 88
Max power: EU standard
(kW) 10 0103
10 0120

Max power en
gine speed (rpm)
4 000
3 750

Max torque: EU standard (Nm)
320340

Max torque engine speed (rpm) 2 000
2 000

Fuel

Diesel

Catalytic converter
yes

Particle emission filter yesno
OIL CAPACITIES (in litres)



En
gine (with filter replacement) 5.255

228
Technical data
ENGINES AND GEARBOXES
Dieselengine2.2 litre HDi204 hp
Gearbox
Automatic
(6-speed)
Model codes
8D4HLA - 8E4HLA
OutlineSaloon
SW
Cubic capacit
y (cc)

2 179

Bore x stroke (mm)
85 x 96
Max power: EU standard
(kW) 15 0
Max power en
gine speed (rpm) 3 500

Max torque: EU standard (Nm)
450

Max torque engine speed (rpm) 2 000

F
uel Diesel

Catalytic conver ter
yes

Particle emissions filter
yes
OIL
CAPACITIES (in litres)

Engine (with filter replacement) 5.25

10
229
Technical data
each additional 1 000 metres of altitude.
The speed of a towing vehicle must not exceed 60 mph (10 0 km/h) (comply with the legislation in force in your country).
High ambient temperatures may result in a reduction in the performance of the vehicle to protect the engine; if the ambient temperature is above 37 °C,
limit the towed load.


*
The kerb wei
ght is equal to the unladen weight + driver (75 kg).

**
The weight of the braked trailer can be increased, within the GTW limit, if the GV W of the towing vehicle is reduced by an equal amount; warning,
towing using a lightly loaded towing vehicle may have an adverse effect on its road holding.
WEIGHTS AND TOWED LOADS (in kg)
Diesel engines1.6 litre HDi 110 hp
Gearboxes

Manual(5-speed)


Electronic gear control (6-speed)
Model codes8D9HL0 - 8E9HL0

8D9HR8/PS - 8E9HR8/PS
OutlineSaloonSW
SaloonSW


- Unladen wei
ght 1 4051 425 1 410
1 430



- Kerb wei
ght *

1 480 1 500
1 485 1 505


- Gross vehicle wei
ght (GV W)
1 975
2 080
2 005
2 10 0



- Gross train wei
ght (GT W)
on a 12% gradient 3 175 3 18 0 3 205 3 200


- Braked trailer
(within GTW limit) on a 10% or 12% gradient
1 200
1 100

1 200

1 100



- Braked trailer
**
(with load transfer with theGTW limit)
1 475
1 400
1 475
1 400



-
Unbraked trailer
740

745740

750



- Recommended nose wei
ght
75

230
Technical data
The GTW and towed load values indicated are valid up to a maximum altitude of 1 000 metres; the towed load mentioned must be reduced by 10 % for each additional 1 000 metres of altitude.
The speed of a towing vehicle must not exceed 60 mph (10 0 km/h) (comply with the legislation in force in your country).
High ambient temperatures may result in a reduction in the per formance of the vehicle to protect the engine; if the ambient temperature is above 37 °C,
limit the towed load.


* The kerb weight is equal to the unladen weight + driver (75 kg).
** The weight of the braked trailer can be increased, within the GTW limit, if the GV W of the towing vehicle is reduced by an equal amount; warning,
towing using a lightly loaded towing vehicle may have an adverse effect on its road holding.
WEIGHTS AND TOWED LOADS (in kg)
Diesel engines2.0 litre HDi140 hp2.0 litre HDi163 hp
GearboxesManual (6-speed)


Automatic
(6-speed)

Manual (6-speed)

Model codes
8DRHR8 - 8ERHR8
8DRHF8 - 8ERHF8
8DRHHA - 8ERHHA 8DRHDA - 8ERHDA
8DRHH8 - 8ERHH8
OutlineSaloon
SW
Saloon SW
Saloon
SW


- Unladen wei
ght1 430
1 500
1 520
1 540
1 480
1 500



- Kerb weight *


1 505
1 575
1 595
1 615 1 555 1 575


- Gross vehicle wei
ght (GV W)
2 065
2 1402 105
2 18 0
2 075
2 140



- Gross train wei
ght (GT W)
on a 12% gradient 3 565 3 640 3 205 3 380 3 5753 640


- Braked trailer
(within GTW limit) on a 10% or 12% gradient
1 500

1 500

1 100

1 2001 500

1 500



- Braked trailer **
(with load transfer with the GTW limit)
1 775
1 775
1 375
1 475
1 775
1 790



- Unbraked trailer
750

750



- Recommended nose wei
ght
75
