2012 MAZDA MODEL 2 Owners Manual

Black plate (329,1)
Reporting Safety Defects (U.S.A.)
If you believe that your vehicle has a defect which could cause a crash or could
cause injury or death, you should immediately inform the National Highway
Traffic Safety Administration (NHTSA) in addition to notifying Mazda Motor
Corporation (Your Mazda Importer/Distributor).
If NHTSA receives similar complaints, it may open an investigation, and if it
finds that a safety defect exists in a group of vehicles, it may order a recall and
remedy campaign. However, NHTSA cannot become involved in individual
problems between you, your dealer, or Mazda Motor Corporation (Your Mazda
Importer/Distributor).
To contact NHTSA, you may call the Vehicle Safety Hotline toll-free at 1-888-
327-4236 (TTY:1-800-424-9153) ; go to http://www.safercar.gov; or write to:
Administrator, NHTSA, 1200 New Jersey Avenue, SE., Washington, DC,
20590. You can also obtain other information about motor vehicle safety from
http://www.safercar.gov.
NOTE
If you live in the U.S.A., all correspondence to Mazda Motor Corporation should be forwarded to:
Mazda North American Operations
7755 Irvine Center Drive
Irvine, California 92618-2922
or
P.O. Box 19734
Irvine, CA 92623-9734
Customer Assistance Center or toll free at 1 (800) 222-5500
If you live outside of the U.S.A., please contact the nearest Mazda Distributor shown (page 9-11) in
this booklet.
Customer Information and Reporting Safety Defects
Reporting Safety Defects
9-41
Mazda2_8CC7-EA-11H_Edition2 Page329
Monday, September 26 2011 1:55 PM
Form No.8CC7-EA-11H

Black plate (330,1)
Reporting Safety Defects (Canada)
Canadian customers who wish to report a safety-related defect to Transport Canada, Defect
Investigations and Recalls, may telephone the toll free hotline 1-800-333-0510, or contact
Transport Canada by mail at: Transport Canada, ASFAD, Place de Ville Tower C, 330
Sparks Street, Ottawa ON K1A 0N5.
For additional road safety information, please visit the Road Safety website at:
http://www.tc.gc.ca/roadsafety/menu.htm
9-42
Customer Information and Reporting Safety Defects
Reporting Safety Defects
Mazda2_8CC7-EA-11H_Edition2 Page330
Monday, September 26 2011 1:55 PM
Form No.8CC7-EA-11H

Black plate (331,1)
Service Publications
Factory-authorized Mazda service publications are available for owners who wish to do
some of their own maintenance and repair.
When requesting any of our publications through an Authorized Mazda Dealer, refer to the
chart below.
If they do not have what you need in stock, they can order it for you.
PUBLICATION ORDER NUMBERPUBLICATION DESCRIPTION
9999-95-026B-12 2012 WORKSHOP MANUAL (English)
9999-95-077G-12 2012 WIRING DIAGRAM (English)
9999-95-002C-12 (U.S.A. only) 2012 OWNER'S MANUAL
9999-EC-002C-12 (Canada only) 2012 OWNER'S MANUAL
9999-PR-002C-12 (Puerto Rico only) 2012 OWNER'S MANUAL
9999-95-MODL-12 2012 SERVICE HIGHLIGHTS
qWORKSHOP MANUAL:
Covers recommended maintenance and repair procedures of the drive train, body and
chassis.
qWIRING DIAGRAM:
Provides electrical schematics as well as component location for the entire electrical
system.
qOWNER'S MANUAL:
This booklet contains information regarding the proper care and operation of your vehicle.
This is not a technician's manual.
qSERVICE HIGHLIGHTS:
Provides description and operation of the many systems of your Mazda.
Customer Information and Reporting Safety Defects
Service Publications
9-43
Mazda2_8CC7-EA-11H_Edition2 Page331
Monday, September 26 2011 1:55 PM
Form No.8CC7-EA-11H

Black plate (332,1)
9-44
Mazda2_8CC7-EA-11H_Edition2 Page332
Monday, September 26 2011 1:55 PM
Form No.8CC7-EA-11H

Black plate (333,1)
10Specifications
Technical information about your Mazda.
Identification Numbers ............................................................... 10-2Vehicle Information Labels ..................................................... 10-2
Specifications ............................................................................... 10-4 Specifications .......................................................................... 10-4
Personalization Features ............................................................ 10-7 Personalization Features .......................................................... 10-7
10-1
Mazda2_8CC7-EA-11H_Edition2 Page333
Monday, September 26 2011 1:55 PM
Form No.8CC7-EA-11H

Black plate (334,1)
Vehicle Information Labels
qVehicle Identification Number
The vehicle identification number legally
identifies your vehicle. The number is on
a plate attached to the cowl panel located
on the left corner of the dashboard. This
plate can easily be seen through the
windshield.
qMotor Vehicle Safety Standard Label
qChassis Number
Open the cover shown in the figure to
check the chassis number.
qVehicle Emission Control
Information Label
10-2
Identification Numbers
Mazda2_8CC7-EA-11H_Edition2 Page334
Monday, September 26 2011 1:55 PM
Form No.8CC7-EA-11H

Black plate (335,1)
qTire Pressure Label
qEngine Number
Forward
Identification Numbers
10-3
Mazda2_8CC7-EA-11H_Edition2 Page335
Monday, September 26 2011 1:55 PM
Form No.8CC7-EA-11H

Black plate (336,1)
Specifications
qEngine
Item Specification
Type DOHC-16V in-line, 4-cylinder
Bore × Stroke 78.0 × 78.4 mm (3.07 × 3.09 in)
Displacement 1,498 ml (1,498 cc, 91.4 cu in)
Compression ratio 10.0
qElectrical System
Item Classification
Battery 12V-40AH/5HR, 12V-52AH/5HR
Spark-plug number DENSO SK16PR-E13
Spark-plug gap 1.2―1.3 mm (0.047 ―0.051 in)
CAUTION
When cleaning the iridium plugs, do not use a wire brush. The fine particulate
coating on the iridium alloy and platinum tips could be damaged.
q Lubricant Quality
Lubricant type and classification
Engine oil Refer to Recommended Oil on page 8-12.
Manual transaxle oil API Service GL-4
SAE 75W-80
Automatic transaxle fluid Mazda Genuine ATF M-V
Brake/Clutch fluid SAE J1703 or FMVSS116 DOT-3
q Capacities
(Approximate Quantities)
Item Capacity
Engine oil With oil filter replacement 3.9 L (4.1 US qt, 3.4 Imp qt)
Without oil filter replacement 3.7 L (3.9 US qt, 3.3 Imp qt)
Coolant Manual transaxle 5.1 L (5.4 US qt, 4.5 Imp qt)
Automatic transaxle 5.4 L (5.7 US qt, 4.8 Imp qt)
Manual transaxle oil 2.91 L (3.07 US qt, 2.56 Imp qt)
Automatic transaxle fluid 7.0 L (7.4 US qt, 6.2 Imp qt)
Fuel tank 42.8 L (11.3 US gal, 9.41 Imp gal)
Check oil and fluid levels with dipsticks or reservoir gauges.
10-4
Specifications
Mazda2_8CC7-EA-11H_Edition2 Page336
Monday, September 26 2011 1:55 PM
Form No.8CC7-EA-11H
