2012 Lexus GX460 Owner's Manual

151
1
1-7. Safety information
Before driving
GX460_U.S.A. (OM60J00U)
Installing child restraints
Follow the child restraint system manufacturer’s instructions. Firmly
secure child restraints to the seats using the LATCH anchors or a seat belt.
Attach the top tether strap when installing a child restraint.
The lap/shoulder belt can be used if your child restraint system is not com-
patible with the LATCH (Lower Anchors and Tethers for Children) system.
Child restraint LATCH anchors
LATCH anchors are provided
for the right side second seat
and between the center and left
side second seats. (Buttons dis-
playing the location of the
anchors are attached to the
seats.)
Seat belts equipped with a child
restraint locking mechanism
(ALR/ELR belts except driver’s
seat belt) (→P. 8 7 )

152
1-7. Safety information
GX460_U.S.A. (OM60J00U)
Installation with LATCH system
Fold the seatback forward. Then
return the seatback and secure it
at the first lock position (most
upright position). (→P. 6 7 )
Anchor bracket (for top tether
strap)
Anchor brackets are provided
for each second seats.
STEP1

153
1-7. Safety information
1
Before driving
GX460_U.S.A. (OM60J00U)Ty p e A
Flip the cover (vehicles with third
seats), and latch the hooks of lower
straps onto the LATCH anchors. If
the child restraint has a top tether
strap, the top tether strap should
be latched onto the top tether
strap anchor. (→P. 1 6 0 )
For owners in Canada:
The symbol on a child restraint sys-
tem indicates the presence of a
lower anchorage system.
Ty p e B Flip the cover (vehicles with third
seats), and latch the buckles onto
the LATCH anchors. If the child
restraint has a top tether strap, the
top tether strap should be latched
onto the top tether strap anchor.
(→P. 1 6 0 )
For owners in Canada:
The symbol on a child restraint sys-
tem indicates the presence of a
lower anchorage system.
Canada only
STEP2
Canada only
STEP2

154
1-7. Safety information
GX460_U.S.A. (OM60J00U)
Installing child restraints using a seat belt (child restraint lock function
belt)
■ Rear facing  Infant seat/convertible seat
Fold the seatback forward. Then
return the seatback and secure it
at the first lock position (most
upright position). (→P. 6 7 )
Place the child restraint system on
the rear seat facing the rear of the
vehicle.
Run the seat belt through the child
restraint system and insert the
plate into the buckle. Make sure
that the belt is not twisted.
STEP1
STEP2
STEP3

155
1-7. Safety information
1
Before driving
GX460_U.S.A. (OM60J00U)Fully extend the shoulder belt and
allow it to retract to put it in lock
mode. In lock mode, the belt can-
not be extended.
While pushing the child restraint
system down into the rear seat,
allow the shoulder belt to retract
until the child restraint system is
securely in place.
After the shoulder belt has
retracted to a point where there is
no slack in the belt, pull the belt to
check that it cannot be extended.
STEP4
STEP5

156
1-7. Safety information
GX460_U.S.A. (OM60J00U)■
Forward facing  Convertible seat
Fold the seatback forward. Then
return the seatback and secure it
at the first lock position (most
upright position). (→P. 6 7 )
Place the child restraint system on
the seat facing the front of the vehi-
cle.
Run the seat belt through the child
restraint system and insert the
plate into the buckle. Make sure
that the belt is not twisted.
STEP1
STEP2
STEP3

157
1-7. Safety information
1
Before driving
GX460_U.S.A. (OM60J00U)Fully extend the shoulder belt and
allow it to retract to put it in lock
mode. In lock mode, the belt can-
not be extended.
While pushing the child restraint
system into the rear seat, allow the
shoulder belt to retract until the
child restraint system is securely in
place.
After the shoulder belt has
retracted to a point where there is
no slack in the belt, pull the belt to
check that it cannot be extended.
If the child restraint has a top tether strap, the top tether strap
should be latched onto the top tether strap anchor. (
→P. 1 6 0 )
STEP4
STEP5
STEP6

158
1-7. Safety information
GX460_U.S.A. (OM60J00U)■
Booster seat
Fold the seatback forward. Then
return the seatback and secure it
at the first lock position (most
upright position). (→P. 6 7 )
Place the child restraint system on
the seat facing the front of the vehi-
cle.
STEP1
STEP2
