2012 JEEP GRAND CHEROKEE SRT Owners Manual

Interior Care
Use MOPARTotal Clean or equivalent to clean fabric
upholstery and carpeting.
Interior Trim should be cleaned starting with a damp
cloth, a damp cloth with MOPARTotal Clean or equiva-
lent, then MOPARSpot & Stain Remover or equivalent
if absolutely necessary. Do not use harsh cleaners or
Armor All. Use MOPARTotal Clean or equivalent to
clean vinyl upholstery.
Leather Seat Care & Cleaning
MOPARTotal Clean or equivalent is specifically recom-
mended for leather upholstery.
Your leather upholstery can be best preserved by regular
cleaning with a damp soft cloth. Small particles of dirt
can act as an abrasive and damage the leather upholstery
and should be removed promptly with a damp cloth.
Stubborn soils can be removed easily with a soft cloth
and MOPARTotal Clean or equivalent. Care should betaken to avoid soaking your leather upholstery with any
liquid. Please do not use polishes, oils, cleaning fluids,
solvents, detergents, or ammonia based cleaners to clean
your leather upholstery. Application of a leather condi-
tioner is not required to maintain the original condition.
WARNING!
Do not use volatile solvents for cleaning purposes.
Many are potentially flammable, and if used in
closed areas they may cause respiratory harm.
Glass Surfaces
All glass surfaces should be cleaned on a regular basis
with MOPARGlass Cleaner or any commercial
household-type glass cleaner. Never use an abrasive type
cleaner. Use caution when cleaning inside rear windows
equipped with electric defrosters. Do not use scrapers or
other sharp instruments which may scratch the elements.7
MAINTAINING YOUR VEHICLE 503

When cleaning the rear view mirror, spray cleaner on the
towel or rag that you are using. Do not spray cleaner
directly on the mirror.
Cleaning Plastic Instrument Cluster Lenses
The lenses in front of the instruments in this vehicle are
molded in clear plastic. When cleaning the lenses, care
must be taken to avoid scratching the plastic.
1. Clean with a wet soft rag. A mild soap solution may be
used, but do not use high alcohol content or abrasive
cleaners. If soap is used, wipe clean with a clean damp
rag.
2. Dry with a soft cloth.
Seat Belt Maintenance
Do not bleach, dye or clean the belts with chemical
solvents or abrasive cleaners. This will weaken the fabric.
Sun damage will also weaken the fabric.If the belts need cleaning, use MOPARTotal Clean, a
mild soap solution, or lukewarm water. Do not remove
the belts from the vehicle to wash them.
Replace the belts if they appear frayed or worn or if the
buckles do not work properly.
FUSES
Totally Integrated Power Module
The Totally Integrated Power Module is located in the
engine compartment. This center contains cartridge fuses
and mini fuses. A description of each fuse and compo-
nent may be stamped on the inside cover, otherwise the
cavity number of each fuse is stamped on the inside cover
that corresponds to the following chart.
504 MAINTAINING YOUR VEHICLE

Cavity Cartridge
FuseMini
FuseDescription
J01 40 Amp
GreenAir Suspension
J02 30 Amp
PinkPower Liftgate
Module
Cavity Cartridge
FuseMini
FuseDescription
J03 30 Amp
PinkTrailer Tow
J04 25 Amp
NaturalDriver Door Node
J05 25 Amp
NaturalPassenger Door
Node
J06 40 Amp
GreenAntilock Brakes
Pump/Stability
Control System
J07 30 Amp
PinkAntilock Brakes
Valve/Stability
Control System
J08 40 Amp
GreenPower Seat
J09 30 Amp
PinkE-Brake
Totally Integrated Power Module
7
MAINTAINING YOUR VEHICLE 505

Cavity Cartridge
FuseMini
FuseDescription
J10 30 Amp
PinkHeadlamp Wash
Relay Contact
J11 30 Amp
PinkDrive Train Control
Module
J12 30 Amp
PinkRear Defroster
J13 60 Amp
YellowMain Ignition Off
Draw (IOD)
J14 20 Amp
BlueTrailer Tow
Lamps/Park Lamps
J15 40 Amp
GreenFront Cabin Fan/
Blower
J17 40 Amp
GreenStarter Motor Sole-
noidCavity Cartridge
FuseMini
FuseDescription
J18 20 Amp
BluePowertrain Control
Module/Powertrain
Control Module
Transmission Range
J19 60 Amp
YellowRadiator Fan Motor
HI/Radiator Fan
Motor Low
J20 30 Amp
PinkFront Wiper
J21 20 Amp
BlueFront/Rear Washer
Control
J22 25 Amp
NaturalSunroof Module
M1 15 Amp
BlueStop Lamps
506 MAINTAINING YOUR VEHICLE

Cavity Cartridge
FuseMini
FuseDescription
M2 20 Amp
YellowElectronic Limit
Slip Differential/
Air Suspension
M3 20 Amp
YellowLiftgate/Headrest
M5 25 Amp
Natural115V AC Power
Inverter
M6 20 Amp
YellowCigar Lighter
M7 20 Amp
YellowPower Outlet #2
(Switchable)
M8 20 Amp
YellowFront Heated Seat
& Steering Wheel
M9 20 Amp
YellowRear Heated SeatsCavity Cartridge
FuseMini
FuseDescription
M10 15 Amp
BlueVideo/Universal
Garage Door
Opener
M11 10 Amp
RedHeating, Ventilation
& Air Conditioning
(Climate Control
System)
M12 30 Amp
GreenRadio/Amplifier
M13 20 Amp
YellowInstrument Cluster
M14 20 Amp
YellowBack Up Camera –
If Equipped
7
MAINTAINING YOUR VEHICLE 507

Cavity Cartridge
FuseMini
FuseDescription
M15 20 Amp
YellowPower Seat
Module(s)/
Adaptive Cruise
Control/Audio
Telematics/Daytime
Running Lights
Relay/Air Suspen-
sion Module/
Instrument Cluster
M16 10 Amp
RedOccupant Restraint
Controller
M18 15 Amp
BlueStop Lamp
M19 25 Amp
NaturalAutomatic Shut-
down 1 and 2
M20 15 Amp
BlueInstrument ClusterCavity Cartridge
FuseMini
FuseDescription
M21 20 Amp
YellowAutomatic Shut-
down 3
M22 10 Amp
RedHorns (Low/High)
– Right
M23 10 Amp
RedHorns (Low/High)
– Left
M24 25 Amp
NaturalRear Wiper
M25 20 Amp
YellowFuel Pump Motor
Output/Diesel Lift
Pump (Export
Only)
M26 10 Amp
RedDriver Door Switch
Bank
508 MAINTAINING YOUR VEHICLE

Cavity Cartridge
FuseMini
FuseDescription
M27 10 Amp
RedIgnition Switch/
Wireless Control
Module/Keyless
Entry Module
M28 15 Amp
BluePowertrain
Controller/
Transmission Con-
troller
M29 10 Amp
RedTire Pressure Moni-
tor – If Equipped
M30 15 Amp
BlueJ1962 Diag Connec-
tor
M31 20 Amp
YellowBackup Lamps
M32 10 Amp
RedOccupant Restraint
ControllerCavity Cartridge
FuseMini
FuseDescription
M33 10 Amp
RedPowertrain
Controller/
Transmission Con-
troller
M34 10 Amp
RedPark Assist
Module/Climate
Control System
Module/Infra Red
Sensor/Compass
Module
M35 15 Amp
BlueLeft Rear
Parklamps
M36 20 Amp
YellowPower Outlet
M37 10 Amp
RedAntilock Brakes/
Stability Control
System Module
7
MAINTAINING YOUR VEHICLE 509

Cavity Cartridge
FuseMini
FuseDescription
M38 25 Amp
NaturalAll Door Lock
&Unlock
CAUTION!
•When installing the totally integrated power mod-
ule cover, it is important to ensure the cover is
properly positioned and fully latched. Failure to
do so may allow water to get into the totally
integrated power module and possibly result in a
electrical system failure.
(Continued)
CAUTION! (Continued)
•When replacing a blown fuse, it is important to
use only a fuse having the correct amperage rating.
The use of a fuse with a rating other than indicated
may result in a dangerous electrical system over-
load. If a properly rated fuse continues to blow, it
indicates a problem in the circuit that must be
corrected.
VEHICLE STORAGE
If you are leaving your vehicle dormant for more than
21 days you may want to take steps to protect your
battery. You may:
•Remove fuse #27 in the Totally Integrated Power
Module (TIPM) labeled Ignition-Off Draw (IOD#1).
•Or, disconnect the negative cable from the battery.
510 MAINTAINING YOUR VEHICLE
