2012 JEEP GRAND CHEROKEE reset

of which forward gear is selected. PARK, RE-
VERSE, and NEUTRAL will continue to operate.
The Malfunction Indicator Light (MIL) may be
illuminated. Limp Home Mode allows the ve-
hicle to be driven to an authorized dealer for
service without damaging the transmission.
In the event of a momentary problem, the
transmission can be reset to regain all forward
gears by performing the following steps:
1. Stop the vehicle.
2. Shift the transmission into PARK.
3. Turn the ignition switch to the LOCK/OFF
position.
4. Wait approximately 10 seconds.
5. Restart the engine.
6. Shift into the desired gear range. If the
problem is no longer detected, the transmis-
sion will return to normal operation.
NOTE:
Even if the transmission can be reset, we
recommend that you visit your authorized
dealer at your earliest possible conve-nience. Your authorized dealer has diagnos-
tic equipment to determine if the problem
could recur.
If the transmission cannot be reset, authorized
dealer service is required.
Electronic Range Select (ERS) Operation
The Electronic Range Select (ERS) shift control
allows the driver to limit the highest available
gear when the shift lever is in the DRIVE
position. For example, if you shift the transmis-
sion into 3 (third gear), the transmission will
never shift above third gear, but will shift down
into second and first gear normally.
You can switch between DRIVE and ERS mode
at any vehicle speed. When the shift lever is in
the DRIVE position, the transmission will oper-
ate automatically, shifting between all available
gears. Tapping the shift lever to the left (-) will
downshift the transmission, activate ERS mode,
display the current gear in the instrument clus-
ter, and maintain that gear as the top available
gear. Once in ERS mode, tapping the shift lever
to the left (-) or right (+) will change the top
available gear.
To exit ERS mode, simply press and hold the
shift lever to the right (+) until “D” is once again
displayed in the shift lever position indicator in
the instrument cluster.
WARNING!
Do not downshift for additional engine braking
on a slippery surface. The drive wheels could
lose their grip and the vehicle could skid,
causing an accident or personal injury.
Screen Display
12 34D
Actual Gear(s)
Allowed 1 1-2 1-3 1-4 1-5
NOTE:
To select the proper gear position for maxi-
mum deceleration (engine braking), simply
press and hold the shift lever to the left (-).
The transmission will shift to the range from
which the vehicle can best be slowed down.
225

If the transmission operating temperature ex-
ceeds normal operating limits, the powertrain
controller will modify the transmission shift
schedule and expand the range of torque con-
verter clutch engagement. This is done to pre-
vent transmission damage due to overheating.
If the transmission becomes extremely hot, the
“Transmission Temperature Warning Light” may
illuminate and the transmission may downshift
out of Overdrive until the transmission cools
down.
NOTE:
Use caution when operating a heavily
loaded vehicle at low speeds (such as tow-
ing a trailer up a steep grade, or in stop-
and-go traffic) during hot weather. In these
conditions, torque converter slip can im-
pose a significant additional heat load on
the cooling system. Downshifting the trans-
mission to the lowest possible gear (when
climbing a grade), or shifting to NEUTRAL
(when stopped in heavy traffic) can help to
reduce this excess heat generation.
During cold temperatures, transmission opera-
tion may be modified depending on engine andtransmission temperature as well as vehicle
speed. This feature improves warm up time of
the engine and transmission to achieve maxi-
mum efficiency. Engagement of both the torque
converter clutch and the top overdrive gear are
inhibited until the transmission fluid is warm
(refer to the “Note” under “Torque Converter
Clutch” in this section). During extremely cold
temperatures (-16°F [-27°C] or below), opera-
tion may briefly be limited to first and direct
gears only. Normal operation will resume once
the transmission temperature has risen to a
suitable level.
Transmission Limp Home Mode
Transmission function is monitored electroni-
cally for abnormal conditions. If a condition is
detected that could result in transmission dam-
age, Transmission Limp Home Mode is acti-
vated. In this mode, the transmission remains in
direct gear regardless of which forward gear is
selected. PARK, REVERSE, and NEUTRAL will
continue to operate. The Malfunction Indicator
Light (MIL) may be illuminated. Limp Home
Mode allows the vehicle to be driven to an
authorized dealer for service without damaging
the transmission.
In the event of a momentary problem, the
transmission can be reset to regain all forward
gears by performing the following steps:
1. Stop the vehicle.
2. Shift the transmission into PARK.
3. Turn the ignition switch to the LOCK/OFF
position.
4. Wait approximately 10 seconds.
5. Restart the engine.
6. Shift into the desired gear range. If the
problem is no longer detected, the transmis-
sion will return to normal operation.
NOTE:
Even if the transmission can be reset, we
recommend that you visit your authorized
dealer at your earliest possible conve-
nience. Your authorized dealer has diagnos-
tic equipment to determine if the problem
could recur.
If the transmission cannot be reset, authorized
dealer service is required.
229

CAUTION!
Using a transmission fluid other than the
manufacturer’s recommended fluid may
cause deterioration in transmission shift qual-
ity and/or torque converter shudder. Using a
transmission fluid other than the manufactur-
er’s recommended fluid will require more fre-
quent fluid and filter changes. Refer to “Fluids,
Lubricants, and Genuine Parts” in “Maintain-
ing Your Vehicle” for further information.
Special Additives
Automatic Transmission Fluid (ATF) is an engi-
neered product and its performance may be
impaired by supplemental additives. Therefore,
do not add any fluid additives to the transmis-
sion. The only exception to this policy is the use
of special dyes to aid in detecting fluid leaks. In
addition, avoid using transmission sealers as
they may adversely affect seals.CAUTION!
Do not use chemical flushes in your transmis-
sion as the chemicals can damage your trans-
mission components. Such damage is not
covered by the New Vehicle Limited Warranty.
Fluid Level Check – 3.6L And 3.0L Diesel
Engine
Routine fluid level checks are not required. For
this reason, the dipstick is omitted. Your autho-
rized dealer can check your transmission fluid
level using a special service dipstick.
If you notice fluid leakage or transmission mal-
function, have your authorized dealer check
the transmission fluid level. Operation with an
improper fluid level can greatly reduce the life
of your transmission.CAUTION!
• Using a transmission fluid other than the
manufacturer’s recommended fluid may
cause deterioration in transmission shift
quality and/or torque converter shudder.
Using a transmission fluid other than that
recommended by the manufacturer will re-
quire more frequent fluid and filter changes.
Refer to “Fluids, Lubricants, and Genuine
Parts” in “Maintaining Your Vehicle” for fur-
ther information.
• The fluid level is preset at the factory and it
does not require adjustment under normal
operating conditions. If a transmission fluid
leak occurs, visit your authorized dealer
immediately. Severe damage to the trans-
mission may occur. Your authorized dealer
has the proper tools to adjust the fluid level
accurately.
314

MAINTENANCE SCHEDULE
Maintenance Schedule – Gasoline
Engine
The Scheduled Maintenance services listed in
this manual must be done at the times or
mileages specified to protect your vehicle war-
ranty and ensure the best vehicle performance
and reliability. More frequent maintenance may
be needed for vehicles in severe operating
conditions, such as dusty areas and very short
trip driving. Inspection and service should also
be done anytime a malfunction is suspected.
The oil change indicator system will remind you
that it is time to take your vehicle in for sched-
uled maintenance.
On Electronic Vehicle Information Center
(EVIC) equipped vehicles “Oil Change Re-quired” will be displayed in the EVIC and a
single chime will sound, indicating that an oil
change is necessary.
The oil change indicator message will illumi-
nate approximately 7,000 miles (11 200 km)
after the most recent oil change was per-
formed. Have your vehicle serviced as soon as
possible, within 500 miles (800 km).
NOTE:
•
The oil change indicator message will not
monitor the time since the last oil change.
Change your vehicles oil if it has been
6 months since your last oil change even
if the oil change indicator message is
NOT illuminated.
• Change your engine oil more often if you
drive your vehicle off-road for an ex-
tended period of time. •
Under no circumstances should oil
change intervals exceed 7,500 miles
(12 000 km) or 6 months, whichever
comes first.
Your authorized dealer will reset the oil change
indicator message after completing the sched-
uled oil change. If this scheduled oil change is
performed by someone other than your autho-
rized dealer the message can be reset by
referring to the steps described under ”Elec-
tronic Vehicle Information Center” in “Under-
standing Your Instrument Panel” for further in-
formation.
332

Octane Rating, Gasoline (Fuel)......262
Odometer ..................160
Trip ....................160
Off-Pavement Driving (Off-Road) .....239
Off-Road Driving (Off-Pavement) .....239
Oil Change Indicator ...........172
Oil Change Indicator, Reset .......172
Oil, Engine .................302
Capacity .................326
Change Interval .............302
Diesel ..................303
Dipstick .................302
Filter ...................304
Identification Logo ...........302
Materials Added to ...........304
Recommendation .......302,303,326
Synthetic .................303
Viscosity ............... 303,326
Onboard Diagnostic System .......301
Operator Manual (Owner’s Manual) .....6
Outside Rearview Mirrors ..........67
Overdrive ............... 226,230
Overdrive OFF Switch ........226,230
Overhead Console .............138
Overheating, Engine .........164,282
Owner’s Manual (Operator Manual) .....6Paint Care
.................315
Paint Damage ...............315
Park Sense System, Rear .........131
Parking Brake ...............244
Personal Settings .............179
Pets ......................55
Pets, Transporting ..............55
Phone, Cellular ...............74
Phone, Hands-Free (Uconnect™) .....74
Polishing and Waxing ...........316
Power Door Locks ................21
Lift Gate ..................27
Mirrors ...................68
Outlet (Auxiliary Electrical Outlet) . . . 142
Seats .................. 94,95
Steering ............... 242,243
Sunroof ............... 139,140
Tilt/Telescoping Steering Column . . . 114
Windows ..................24
Pregnant Women and Seat Belts .....37
Preparation for Jacking ..........283
Pretensioners Seat Belts .................34
Programmable Electronic Features ....
179
Programming Transmitters
(Remote Keyless Entry) ...........17 Quadra-Lift
.................236
Quadra-Trac ................231
Radial Ply Tires ..............253
Radio (Sound Systems) ..........183
Radio Operation ..............204
Rain Sensitive Wiper System .......112
Rear Axle (Differential) ..........312
Rear Camera ................136
Rear Cross Path ...............72
Rear Cupholder ..............144
Rear Fog Lights ..............164
Rear Park Sense System .........131
Rear Seat, Folding .............100
Rear Window Defroster ..........150
Rear Window Features ..........149
Rear Wiper/Washer ............149
Rearview Mirrors ..............67
Recorder, Event Data ............46
Recreational Towing ............276
Shifting into Transfer Case Neutral
(N) ....................277
Shifting out of Transfer Case Neutral
(N) ....................279
Refrigerant .................305
Reminder, Seat Belt .............37
371
