2012 INFINITI G37 display

Black plate (188,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]4-10 Monitor, climate, audio, phone and voice recognition systemsVehicle information display GUID-72118AA1-81A8-4497-B910-2B74F0FB33B1
1. Push the INFO button on the control
panel.
2. Select an item from the INFO menu.
3. After viewing or adjusting the informa-
tion on the following screens, push the
BACK button to return to the INFO
menu.
See the separate Navigation System Own-
er ’ s Manual for the following items:
. Where am I?
. Traffic Info
. Weather Info
. Map Update
. Navigation Version SAA2479
SAA2480
Models with navigation system JVH0056M
JVH0057M
Models without navigation system

Black plate (189,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]Fuel Economy information GUID-189D7485-90CC-4656-8551-1D08F50ECB7D
The approximate distance to empty, aver-
age fuel economy and current fuel econo-
my will be displayed for reference.
To reset the average fuel economy (Avg
Fuel Econ), select the “ Reset Fuel Eco ” or
“ Reset ” key.
If the “ Fuel Eco History ” or “ View ” key is
selected, the average fuel consumption
history will be displayed in graph form
along with the average for the previous
Reset-to-Reset period.
The unit can be converted between “ US ”
and “ Metric ” . (See “ How to use SETTING
button ” (P.4-14).)
The fuel economy information may differ
from the information displayed on the
vehicle information display. This is due to
the timing difference in updating the
information and does not indicate a mal-
function. SAA2481
SAA2482
Models with navigation system SAA2830
SAA2722
Models without navigation system
Monitor, climate, audio, phone and voice recognition systems
4-11

Black plate (190,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]4-12 Monitor, climate, audio, phone and voice recognition systemsMaintenance information GUID-6CA2CDFA-FC15-42AA-9EFD-CE037A72365B
The maintenance intervals can be dis-
played for the engine oil, oil filter, tire
and other reminders.
To set a maintenance interval, select a
preferred item from the list.
You can also set to display a message to
remind you that the maintenance needs to
be performed.
The following example shows how to set
the engine oil maintenance information.
Use the same steps to set the other
maintenance information.
1. Set the interval (mileage) of the main-
tenance schedule. To determine the
recommended maintenance interval,
refer to your “ INFINITI Service and
Maintenance Guide ” .
2. To display the reminder automatically
when the desired distance is reached,
select the “ Reminder ” key.
3. Reset the driving distance to the new
maintenance schedule.
4. To return to the previous screen, push
the BACK button.
The unit can be converted between “ US ”
and “ Metric ” . (See “ How to use SETTING button ” (P.4-14).)
SAA3003
Models with navigation system
SAA1611
Models without navigation system

Black plate (191,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]The Reminder will be automatically dis-
played when the specified distance has
been driven and every time the ignition
switch is pushed to the ACC or ON position.
The reminder will not appear while driving.
Select the “ OK ” key to hide the reminder
for the rest of the current drive.
To stop the reminder from appearing,
perform one of the following actions:
. Select the “ Reset Distance ” .
. Deactivate the “ Reminder ” .
. Increase the “ Interval ” distance to be
more than the current distance being
tracked. SAA2483
Others information (models with
navigation system) GUID-9F534085-BC7A-4AD1-8E18-3219FFD95CE9
The Others information display will appear
when pushing the INFO button and select-
ing the “ Others ” key.
GPS Position: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
For the details of this item, see the
separate Navigation System Owner ’ s Man-
ual.
Voice Recognition: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
For the details of this item, see “ INFINITI
Voice Recognition system (models with
navigation system) ” (P.4-114). SAA2484
Models with navigation system
SAA2604
Models without navigation system
Monitor, climate, audio, phone and voice recognition systems
4-13

Black plate (192,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]4-14 Monitor, climate, audio, phone and voice recognition systemsHOW TO USE SETTING BUTTON GUID-0B7E72F0-D8E7-47AA-B3D3-9D835CB63205
The display as illustrated will appear when
the SETTING button is pushed.
For navigation settings, refer to the sepa-
rate Navigation System Owner ’ s Manual.
SAA2485
Models with navigation system
SAA2740
Models without navigation system Audio settings GUID-D7CDADA6-067E-460F-A13A-AC369FEA0D42
The display as illustrated will appear when
pushing the SETTING button and selecting
the “ Audio ” key.
Bass/Treble/Balance/Fade: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
To adjust the speaker tone quality and
sound balance, select the “ Bass ” , “ Treble ” ,
“ Balance ” or “ Fade ” key and adjust it with
the INFINITI controller.
These items can also be adjusted by
pushing and turning the AUDIO knob.
Speed Sensitive Vol.: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
The audio system ’ s volume is increased
with the vehicle speed. Select the “ Speed
Sensitive Vol. ” and adjust the effect level
with the INFINITI controller. The Speed
Sensitive Volume function is turned off
when the level is set to OFF. Increasing the
value will cause the volume to increase
faster with vehicle speed.
Precision Phased Audio (if so equipped): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
When this item is turned to ON, super high
pitch sound and super low pitch sound are
emphasized and midrange sound is played
naturally.

Black plate (193,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]Driver ’ s Audio Stage (if so equipped): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
When this feature is turned to ON, better
sound will be provided to the driver ’ s
position. The driver can enjoy a more crisp
and clear sound that is specialized for the
driver ’ s position. The effect of this feature
depends on the type of music that is
played. For some music, it may be difficult
to realize the effect of this feature.
DivX ®
Registration Code (models with
navigation system): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
The registration code for a device that is
used to download DivX ®
files will be
displayed on the screen. If a disc is loaded
or a USB memory is connected to the audio
system, this function will not be activated.
Display Album Cover Art (models with
navigation system): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
When this item is turned to ON, the album
cover image is displayed when playing
iPod ®
or MP3 music files through a CD,
DVD or USB memory. When the image is
not properly embedded in the file or
device, the image will not be displayed.
Phone settings (models with navi-
gation system) GUID-A9EB693D-4F7B-4278-B820-B3F3D33948EC
For details of the “ Phone ” settings, see “ Bluetooth ®
Hands-Free Phone System
(models with navigation system) ” (P.4-90).
Bluetooth ®
settings (models with
navigation system) GUID-FFACA73C-B4C1-4E1C-A598-A293A0413F83
For details of the “ Bluetooth ®
” settings,
see “ Bluetooth ®
Hands-Free Phone System
(models with navigation system) ” (P.4-90).
SAA2554
Volume and Beeps settings (models
with navigation system) GUID-44D75C4E-8923-4415-A792-D085A7A10E2E
The display as illustrated will appear when
pushing the SETTING button, selecting the
“ Volume & Beeps ” key.
Audio Volume: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
To increase or decrease the audio volume,
select the “ Audio Volume ” and adjust it
with the INFINITI controller. You can also
adjust the audio volume by turning the
VOLUME control knob.
Monitor, climate, audio, phone and voice recognition systems
4-15

Black plate (194,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]4-16 Monitor, climate, audio, phone and voice recognition systemsGuidance Volume: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
To adjust the guidance voice volume select
the “ Guidance Volume ” and adjust it with
the INFINITI controller.
You can also adjust the guidance voice
volume by turning the VOLUME control
knob while voice guidance is being an-
nounced.
Ringtone/Incoming Call/Outgoing Call: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
For the details of these items, see “ Blue-
tooth ®
Hands-Free Phone System (models
with navigation system) ” (P.4-90).
Switch Beeps: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
When this item is turned to ON, you will
hear a beep sound when you use a button.
Guidance Voice: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
When this item is turned to ON, you will
hear voice guidance in the navigation
operation or in other operations.
NOTE:
When the voice guidance is being an-
nounced during audio playback, turning
the volume knob does not adjust the
music level; it adjusts the guidance
volume level. If voice guidance is not
being heard, please check the Guidance
Volume level. JVH0176M
Switch Beeps settings (models
without navigation system) GUID-30A93832-9708-46BA-BCA4-DE520CD32369
The “ Switch Beeps ” screen will appear
when pushing the SETTING button, select-
ing the “ Switch Beeps ” key with the
INFINITI controller and pushing the ENTER
button.
Switch Beeps: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
When this item is turned to ON, you will
hear a beep sound when you use a button. SAA2486
Display settings (models with na-
vigation system) GUID-7F2FE76E-2EC3-4BEE-A8D4-537CDE0931E2
The display as illustrated will appear when
pushing the SETTING button and selecting
the “ Display ” key.
Display Adjustment: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
To adjust the display settings, select the
“ Display Adjustment ” key. The following
settings are available.
. Display
To turn off the screen, push the ENTER
button and turn the “ Display ” indicator off.
The other method is to push and hold the
“
OFF ” button for more than 2 seconds.

Black plate (195,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]When any mode button is pushed with the
screen off, the screen turns on for further
operation. The screen will turn off auto-
matically 5 seconds after the operation is
finished.
To turn on the screen, set this item to the
ON position, or push and hold the “
OFF ” button.
. Brightness/Contrast/Background Color
To adjust the brightness and contrast of
the screen, select the “ Brightness ” or
“ Contrast ” key.
Then, you can adjust the brightness and
the contrast using the INFINITI controller.
For information on the “ Background Color ”
key, refer to the separate Navigation
System Owner ’ s Manual.
Color Theme: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Choose the theme color of the menu screen
from “ Black ” , “ Brown ” or “ Silver ” . SAA2115
Display settings (models without
navigation system) GUID-C75B97D4-D5F7-4B17-A5C5-8C3FBEEC66A2
The “ Display ” screen will appear when
pushing the SETTING button, selecting
“ Display ” key with the INFINITI controller
and pushing the ENTER button.
Display: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
To turn off the screen, push the ENTER
button and turn the “ ON ” indicator off.
When any mode button is pushed with the
screen off, the screen turns on for further
operation. The screen will turn off auto-
matically 5 seconds after the operation is
finished. To turn on the screen, set this item to the
“ ON ” position or push the “
OFF ”
button.
Brightness/Contrast/Background Color: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
To adjust the brightness, contrast and
background color of the screen, select the
appropriate “ Brightness ” , “ Contrast ” or
“ Background Color ” key and push the
ENTER button.
Then, you can adjust the brightness and
the contrast using the INFINITI controller.
Switch the background color to the day-
time mode or the nighttime mode by
pushing the ENTER button.
Monitor, climate, audio, phone and voice recognition systems
4-17
