2012 INFINITI G37 ESP

Black plate (44,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]1-22 Safety — Seats, seat belts and supplemental restraint systemchildren. See “ Child restraints ” (P.1-23).
A child restraint may be secured in the
vehicle by using either the LATCH (Lower
Anchor and Tethers for CHildren) system or
with the vehicle seat belt. See “ Child
restraints ” (P.1-23) for more information.
INFINITI recommends that all pre-teens
and children be restrained in the rear seat.
Studies show that children are safer when
properly restrained in the rear seat than in
the front seat.
This is especially important because your
vehicle has a supplemental restraint sys-
tem (Air bag system) for the front passen-
ger. See “ Supplemental restraint system ”
(P.1-41).
INFANTS GUID-81981691-E72A-4BD1-8C1F-5BB0437EDCA7
Infants up to at least 1 year old should be
placed in a rear-facing child restraint.
INFINITI recommends that infants be placed
in child restraints that comply with Federal
Motor Vehicle Safety Standards or Cana-
dian Motor Vehicle Safety Standards. You
should choose a child restraint that fits
your vehicle and always follow the manu-
facturer ’ s instructions for installation and
use. SMALL CHILDREN GUID-4B9EA2FD-B4B7-4495-B26D-F98DBFB5E95B
Children that are over 1 year old and weigh
at least 20 lbs (9 kg) should remain in a
rear-facing child restraint as long as
possible up to the height or weight limit
of the child restraint. Forward-facing child
restraints are available for children who
outgrow rear facing child restraints and are
at least 1 year old. Refer to the manufac-
turer ’ s instructions for minimum and max-
imum weight and height
recommendations. INFINITI recommends
that small children be placed in child
restraints that comply with Federal Motor
Vehicle Safety Standards or Canadian
Motor Vehicle Safety Standards. You
should choose a child restraint that fits
your vehicle and always follow the manu-
facturer ’ s instructions for installation and
use.
LARGER CHILDREN GUID-68A06744-D08D-4184-A663-B44714919409
Children who are too large for child
restraints should be seated and restrained
by the seat belts which are provided. The
seat belt may not fit properly if the child is
less than 4 ft 9 in (142.5 cm) tall and
weighs between 40 lbs (18 kg) and 80 lbs
(36 kg). A booster seat should be used to obtain proper seat belt fit.
INFINITI recommends that a child be placed
in a commercially available booster seat if
the shoulder belt fits close to the face or
neck or if the lap portion of the seat belt
goes across the abdomen. The booster seat
should raise the child so that the shoulder
belt is properly positioned across the top,
middle portion of the shoulder and the lap
belt is low on the hips. A booster seat can
only be used in seating positions that have
a three-point type seat belt. The booster
seat should fit the vehicle seat and have a
label certifying that it complies with
Federal Motor Vehicle Safety Standards or
Canadian Motor Vehicle Safety Standards.
Once the child has grown so the shoulder
belt is no longer on or near the face and
neck, use the shoulder belt without the
booster seat.
WARNING Never let a child stand or kneel on any seat
and do not allow a child in the cargo area.
The child could be seriously injured or killed
in a sudden stop or collision.

Black plate (67,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]SSS0140
SSS0162 SSS0159
WARNING Front seat-mounted side-impact supplemen-
tal air bags and roof-mounted curtain side-
impact supplemental air bags:
. The front seat-mounted side-impact air
bags and roof-mounted curtain air bags
ordinarily will not inflate in the event of
a frontal impact, rear impact, rollover or
lower severity side collision. Always
wear your seat belts to help reduce the
risk or severity of injury in various kinds
of accidents. . The seat belts, side air bags and curtain
air bags are most effective when you are
sitting well back and upright in the seat.
The side air bag and curtain air bag
inflate with great force. Do not allow
anyone to place their hand, leg or face
near the side air bag on the side of the
seatback of the front seat or near the
side roof rails. Do not allow anyone
sitting in the front seats or rear outboard
seats to extend their hand out of the
window or lean against the door. Some
examples of dangerous riding positions
are shown in the previous illustrations.
. When sitting in the rear seat, do not
hold onto the seatback of the front seat.
If the supplemental side air bag inflates,
you may be seriously injured. Be espe-
cially careful with children, who should
always be properly restrained. Some
examples of dangerous riding positions
are shown in the illustrations.
. Do not use seat covers on the front
seatbacks. They may interfere with
supplemental side air bag inflation.
Safety — Seats, seat belts and supplemental restraint system
1-45

Black plate (108,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]2-30 Instruments and controlsINFINITI VEHICLE IMMOBILIZER
SYSTEM GUID-CB62A730-6D41-4D19-9D5A-68BEE6A43E01
The INFINITI Vehicle Immobilizer System
will not allow the engine to start without
the use of the registered Intelligent Key.
Never leave these keys in the vehicle.
Statement related to section 15 of FCC
rules for INFINITI Vehicle Immobilizer
System (CONT ASSY - CARD SLOT)
FCC Notice:
For USA:
This device complies with Part 15 of the
FCC Rules. Operation is subject to the
following two conditions: (1) This device
may not cause harmful interference, and
(2) this device must accept any interfer-
ence received, including interference that
may cause undesired operation.
NOTE:
Changes or modifications not expressly
approved by the party responsible for
compliance could void the user ’ s authority
to operate the equipment. For Canada:
This device complies with RSS-210 of
Industry Canada. Operation is subject to
the following two conditions: (1) this
device may not cause interference, and
(2) this device must accept any interfer-
ence, including interference that may
cause undesired operation of the device.
SIC2045
Security indicator light GUID-8038519A-3397-41F4-B7BF-EDCD0A1F79A5
The security indicator light is located on
the meter panel. It indicates the status of
the INFINITI Vehicle Immobilizer System.
The light blinks after the ignition switch
was in the LOCK position. This function
indicates the security systems equipped on
the vehicle are operational.
If the INFINITI Vehicle Immobilizer System
is malfunctioning, this light will remain on
while the ignition switch is in the ON
position.

Black plate (131,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]SIC3241
Passenger side power window
switch GUID-074E0937-F90F-4461-9B0E-2784EFE2207B
The passenger side switch will open or
close only the corresponding window. To
open or close the window, push down or
pull up the switch and hold it. SIC3289
Sedan — Type A
SIC3285
Sedan — Type B SIC3288
Coupe
Automatic operation (for front door
windows or all door windows) GUID-9BF62CC8-4855-4483-8A55-EA5AB10E4305
To fully open or close the window, com-
pletely push down or pull up the switch
and release it; it need not be held. The
window will automatically open or close all
the way. To stop the window, just push or
lift the switch in the opposite direction.
A light push or pull on the switch will cause
the window to open or close until the
switch is released.
Instruments and controls
2-53

Black plate (141,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]NOTE:
Changes or modifications not expressly
approved by the party responsible for
compliance could void the user ’ s authority
to operate the equipment.
For Canada:
This device complies with RSS-210 of
Industry Canada. Operation is subject to
the following two conditions: (1) this
device may not cause interference, and
(2) this device must accept any interfer-
ence, including interference that may
cause undesired operation of the device.
Instruments and controls
2-63

Black plate (148,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]3-6 Pre-driving checks and adjustmentsdoor, push the power door lock switch to
the unlock position
* 2
.
Lockout protection GUID-F17FC232-6651-4027-B680-5A82DB2977B3
When the power door lock switch (driver or
front passenger) is moved to the lock
position with the Intelligent Key in the port
and any door open, all doors will lock and
unlock automatically. With the Intelligent
Key left in the vehicle (not in the Intelligent
Key port) and any door open, all doors will
unlock automatically and a chime will
sound after the door is closed.
These functions help to prevent the In-
telligent Key from being accidentally
locked inside the vehicle.
AUTOMATIC DOOR LOCKS GUID-A10FB110-3B3F-40BA-97F3-3C215C27FFEF
. All doors lock automatically when the
vehicle speed reaches 15 MPH (24
km/h).
. All doors unlock automatically when the
ignition switch is placed in the OFF
position.
The automatic unlock function can be
deactivated or activated. To deactivate or
activate the automatic door unlock system,
perform the following procedure: 1. Close all doors.
2. Place the ignition switch in the ON
position.
3. Within 20 seconds of performing Step
2, push and hold the power door lock
switch to the
position (UNLOCK) for
more than 5 seconds.
4. When activated, the hazard indicator
will flash twice. When deactivated, the
hazard indicator will flash once.
5. The ignition switch must be placed in
the OFF and ON position again between
each setting change.
When the automatic door unlock system is
deactivated, the doors do not unlock when
the ignition switch is placed in the OFF
position. To unlock the door manually, use
the inside lock knob or the power door lock
switch (driver ’ s or front passenger ’ s side). SPA2470
CHILD SAFETY REAR DOOR LOCK
(Sedan) GUID-DE27EA42-B974-4087-AC65-39A603A3ECDA
The child safety rear door lock helps
prevent doors from being opened acciden-
tally, especially when small children are in
the vehicle.
When the levers are in the lock position
* 1
, the rear doors can be opened only
from the outside.
To disengage, move the levers to the
unlock position
* 2
.

Black plate (198,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]4-20 Monitor, climate, audio, phone and voice recognition systemspassenger ’ s side door is pushed to be
unlocked, only the corresponding door is
unlocked first. All the doors can be
unlocked if the door unlock operation is
performed again within 60 seconds.
When this item is turned to OFF, all the
doors will be unlocked after the door
unlock operation is performed once.
Intelligent Key Lock/Unlock: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
When this item is turned to ON, door lock/
unlock function by pushing the door
handle request switch will be activated.
Return All Settings to Default: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Select this item and then select “ YES ” to
return all settings to the default. SAA2490
Models with navigation system
SAA1092
Models without navigation system Language & Units settings GUID-2D1FB194-339E-4AB6-A28E-3E1121BEF0F9
The Language & Units settings display will
appear when pushing the SETTING button,
selecting the “ Language & Units ” key with
the INFINITI controller and pushing the
ENTER button.
For models with the navigation system,
select the “ Others ” key to show the
“ Language & Units ” key.
Select Language: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Select the “ Select Language ” key. Choose
“ English ” , “ Français ” or “ Español ” for your
favorite display appearance.
If you select the “ Français ” key, the French
language will be displayed, so please use
the French Owner ’ s Manual. To obtain a
French Owner ’ s Manual, see “ Owner ’ s
Manual/Service Manual order information ”
(P.9-28).
Select Units: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Select the “ Select Units ” key. Choose “ US ”
(Mile, 8 F, MPG) or “ Metric ” (km, 8 C, L/100
km) for your favorite display appearance.
Voice Recognition settings (models
with navigation system) GUID-CA02A577-3092-4FA9-B79C-9BA33C2AE64F
For details about the “ Voice Recognition ”
settings, see “ INFINITI Voice Recognition

Black plate (215,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]AUTOMATIC CLIMATE CONTROL
(Type C) GUID-4DC8C348-FAB4-42B1-9378-82EE0A7F7A61
Automatic operation (AUTO) GUID-EB1D0668-6562-4CBB-ABF3-5A4B2EF4A7B9
The AUTO mode may be used year-round
as the system automatically controls con-
stant temperature, air flow distribution and
fan speed after the desired temperature is
set manually.
To turn off the heater and air conditioner,
push the “ OFF ” button.
Cooling and dehumidified heating: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
1. Push the “ AUTO ” button.
(The AUTO indicator light will illuminate
and “ AUTO ” will appear on the display.)
2. If the A/C indicator light does not
illuminate, push the “ A/C ” button.
(The A/C indicator light will illuminate.)
3. Turn the temperature control dial (dri-
ver ’ s side) to set the desired tempera-
ture. .
The temperature can be set within
the following range.
— For U.S.: 60 to 90 8 F (16 to 32 8 C)
— For Canada: 64 to 90 8 F (18 to
32 8 C) .
When the DUAL indicator light is
turned off:
— Pushing the driver ’ s side “ AUTO ”
button changes both the driver ’ s
and front passenger ’ s side tem-
perature.
— Pushing the passenger ’ s side
“ DUAL ” button changes only the
front passenger ’ s side tempera-
ture. (The DUAL indicator light
will illuminate and “ DUAL ” will
appear on the display.) .
To set separate desired tempera-
tures for the driver and front pas-
senger, push the “ DUAL ” button, the
indicator light illuminates, and then
turn the corresponding temperature
control dial. .
To cancel the separate temperature
setting, push the “ DUAL ” button, the
indicator light turns off, and the
driver ’ s side temperature setting will
be applied to both the driver ’ s and
front passenger ’ s sides.
A visible mist may be seen coming from the
ventilators in hot, humid conditions as the
air is cooled rapidly. This does not indicate
a malfunction. Heating (A/C off): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
1. Push the “ AUTO ” button.
(The AUTO indicator light will illuminate
and “ AUTO ” will appear on the display.)
2. If the A/C indicator light illuminates,
push the “ A/C ” button.
(The A/C indicator light will turn off.)
3. Turn the temperature control dial to set
the desired temperature. .
When the DUAL indicator light is
turned off:
— Pushing the driver ’ s side “ AUTO ”
button changes both the driver ’ s
and front passenger ’ s side tem-
perature.
— Pushing the passenger ’ s side
“ DUAL ” button changes only the
front passenger ’ s side tempera-
ture. (The DUAL indicator light
will illuminate and “ DUAL ” will
appear on the display.) .
To set separate desired tempera-
tures for the driver and front pas-
senger, push the “ DUAL ” button, the
indicator light illuminates, and then
turn the corresponding temperature
control dial.
Monitor, climate, audio, phone and voice recognition systems
4-37
