2012 INFINITI G37 display

Black plate (261,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]SAA2517
Models with navigation system
SAA2438
Models without navigation system Music Box ®
settings GUID-EBF55FB9-4A2B-4B66-8082-A26C6DBA92D6
To set the Music box ®
hard drive/flash
memory to your preferred settings, select
the “ Menu ” key during playback, and the
“ Music Box Settings ” key with the INFINITI
controller, and then push the ENTER
button.
Music Box Used/Free Space: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Information about “ Saved Album ” , “ Saved
Track ” and “ Remaining Time ” is displayed.
Automatic Recording: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
When this item is turned to ON, the Music
Box ®
hard drive/flash memory automati-
cally starts recording when a CD is
inserted.
Delete Songs from Music Box: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Deletes the current song, selected songs or
albums by choosing from the list, or all
songs/albums in the Music Box ®
.
Recording Quality: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Set the recording quality of 105 kbps or
132 kbps. The default is set to 105 kbps.
CDDB Version (models with navigation
system)/Gracenote Database Version
(models without navigation system): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
The version of the built-in Gracenote Database is displayed.
Gracenote GUID-69AF800C-C11F-4941-B875-EB4F76825E2E
NOTE:
. The information contained in the Grace-
note Database is not fully guaranteed.
. The service of the Gracenote Database
on the Internet may be stopped with-
out prior notice for maintenance.
End-User License Agreement
USE OF THIS PRODUCT IMPLIES ACCEP-
TANCE OF THE TERMS BELOW.
Gracenote ®
MusicID ®
Terms of Use
This application or device contains soft-
ware from Gracenote, Inc. of Emeryville,
California ( “ Gracenote ” ). The software from
Gracenote (the “ Gracenote Software ” ) en-
ables this application to perform disc and/
or file identification and obtain music-
related information, including name, artist,
track, and title information ( “ Gracenote
Data ” ) from online servers or embedded
databases (collectively, “ Gracenote Ser-
vers ” ) and to perform other functions. You
may use Gracenote Data only by means of
the intended End-User functions of this
application or device. You agree that you
Monitor, climate, audio, phone and voice recognition systems
4-83

Black plate (264,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]4-86 Monitor, climate, audio, phone and voice recognition systems SAA1567
AUX Menu GUID-028F9869-7767-406B-A1DE-AB16A4EB4D4D
When the “ Setting ” key on the display is
selected while in the AUX mode, the menu
screen will be displayed.
Display Mode: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Choose the display mode from the follow-
ing items.
. Normal
. Wide
. Cinema SAA0451
CD/DVD/USB MEMORY CARE AND
CLEANING GUID-4EAEE317-77F3-4525-B6F0-95F17934528E
CD/DVD GUID-11617F31-8FAE-479F-A0DA-9DB80EE21C11
. Handle a CD/DVD by its edges. Never
touch the surface of the disc. Do not
bend the disc.
. Always place the discs in the storage
case when they are not being used.
. To clean a disc, wipe the surface from
the center to the outer edge using a
clean, soft cloth. Do not wipe the disc
using a circular motion.
Do not use a conventional record
cleaner or alcohol intended for indus- trial use.
. A new disc may be rough on the inner
and outer edges. Remove the rough
edges by rubbing the inner and outer
edges with the side of a pen or pencil
as illustrated.
USB memory GUID-CA5F5F5F-0A31-4007-B700-6C062828A2EB
. Never touch the terminal portion of the
USB memory.
. Do not place heavy objects on the USB
memory.
. Do not store the USB memory in highly
humid locations.
. Do not expose the USB memory to
direct sunlight.
. Do not spill any liquids on the USB
memory.
Refer to the USB memory Owner ’ s Manual
for the details.

Black plate (265,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]SAA2923
Models with navigation system
SAA2924
Models without navigation system 1. Audio source switch
2. Menu control switch (models with
navigation system) or audio tuning
switch (models without navigation
system)
3. Volume control switch
4. Back switch
STEERING-WHEEL-MOUNTED CON-
TROLS FOR AUDIO GUID-619B0EB1-40C6-4771-A31A-F210615026F9
Menu control switch (models with
navigation system) or audio tuning
switch (models without navigation
system) GUID-658196B2-17D0-4C26-B7B5-F266229BD7BC
While the display is showing a MAP
(navigation systems only), STATUS or Audio
screen, tilt the switch upward or downward
to select a station, track, CD or folder. For
most audio sources, tilting the switch up/
down for more than 1.5 seconds provides a
different function than tilting up/down for
less than 1.5 seconds.
AM and FM radio: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
. Tilting up/down for less than 1.5
seconds will increase or decrease the
preset station.
. Tilting up/down for more than 1.5
seconds will seek up or down to the next station.
. Pushing the menu control switch (mod-
els with navigation system) will show
the list of preset stations.
XM Satellite Radio: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
. Tilting up/down for less than 1.5
seconds will increase or decrease the
preset channel.
. Tilting up/down for more than 1.5
seconds will go to the next or previous
category.
. Pushing the menu control switch (mod-
els with navigation system) will show
the XM Menu.
iPod ®
(if so equipped): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
. Tilting up/down for less than 1.5
seconds will increase or decrease the
track number.
. Pushing the menu control switch will
show the iPod Menu.
CD: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
. Tilting up/down for less than 1.5
seconds will increase or decrease the
track number.
. Tilting up/down for more than 1.5
seconds will increase/decrease the
folder number (if playing compressed
Monitor, climate, audio, phone and voice recognition systems
4-87

Black plate (266,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]4-88 Monitor, climate, audio, phone and voice recognition systemsaudio files).
. Pushing the menu control switch (mod-
els with navigation system) will show
the CD Menu.
DVD (models with navigation system): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
. Tilting up/down for less than 1.5
seconds will increase or decrease the
track number.
. Tilting up/down for more than 1.5
seconds will increase or decrease the
title number.
. Pushing the menu control switch will
select an item from the DVD display.
. When the transparent operation menu
appears, the switch will control the
menu.
USB (if so equipped): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
. Tilting up/down for less than 1.5
seconds will increase or decrease the
track number.
. Tilting up/down for more than 1.5
seconds will increase/decrease the
folder number
. Pushing the menu control switch will
show the USB Menu. Music Box ®
(if so equipped): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
. Tilting up/down for less than 1.5
seconds will increase or decrease the
track number.
. Tilting up/down for more than 1.5
seconds will increase/decrease the
album (folder) number (if playing com-
pressed audio files).
. Pushing the menu control switch will
show the Music Box ®
Menu.
Bluetooth ®
Audio (models with navigation
system): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
. Tilting up/down for less than 1.5
seconds will increase or decrease the
track number.
AUX (if so equipped): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
. Pushing the menu control switch (mod-
els with navigation system) will show
the AUX Menu.
BACK switch (models with
navigation system) GUID-06356188-0EBC-4773-83BB-C5A3DF870F32
Push this switch to go back to the previous
screen or cancel the selection if it is not
completed. Volume control switches GUID-F5A8FDCD-1001-46F7-ADD1-4F45904F01A4
Push the upper (+) or lower ( − ) side switch
to increase or decrease the volume.
Audio source switch GUID-1F9B9EBE-148A-4808-8151-23DFA61D14B8
Push the audio source switch to change
the mode as follows.
Type A:
. Models with navigation system
AM ? FM ? SAT ? CD/DVD ? Music
Box ®
? USB/iPod ®
? Bluetooth ®
Audio
. Models without navigation system
AM ? FM ? CD ? Music Box ®
?
USB/iPod ®
? SAT
Type B:
Preset A ? Preset B ? Preset C ? CD
Media not connected/inserted will be
skipped.

Black plate (269,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]. Do not place the cellular phone in an
area surrounded by metal or far away
from the in-vehicle phone module to
prevent tone quality degradation and
wireless connection disruption.
. While a cellular phone is connected
through the Bluetooth ®
wireless con-
nection, the battery power of the
cellular phone may discharge quicker
than usual.
. If the Bluetooth ®
Hands-Free Phone
System seems to be malfunctioning,
please visit www.InfinitiUSA.com/blue-
tooth for troubleshooting help.
. Some cellular phones or other devices
may cause interference or a buzzing
noise to come from the audio system
speakers. Storing the device in a
different location may reduce or elim-
inate the noise.
. Refer to the cellular phone Owner ’ s
Manual regarding the telephone pairing
procedure specific to your phone,
battery charging, cellular phone anten-
na, etc.
. The antenna display on the monitor will
not coincide with the antenna display
of some cellular phones. . Keep the interior of the vehicle as quiet
as possible to hear the caller ’ s voice
clearly as well as to minimize its
echoes.
. If reception between callers is unclear,
adjusting the incoming or outgoing call
volume may improve the clarity.
REGULATORY INFORMATION GUID-45C8809D-13C7-484B-BAAA-A89D504ED503
FCC Regulatory information GUID-636F13F0-6D27-42F0-A915-498885D2D5D5
. CAUTION: To maintain compliance with
FCC ’ s RF exposure guidelines, use only
the supplied antenna. Unauthorized
antenna, modification, or attachments
could damage the transmitter and may
violate FCC regulations.
. Operation is subject to the following
two conditions:
1. this device may not cause interference
and
2. this device must accept any interfer-
ence, including interference that may
cause undesired operation of the de-
vice
IC Regulatory information GUID-81DEAF38-3ED8-4146-81F8-1F111A551209
. Operation is subject to the following
two conditions: (1) this device may not
cause interference, and (2) this device must accept any interference, including
interference that may cause undesired
operation of the device.
. This Class B digital apparatus meets all
requirements of the Canadian Interfer-
ence-Causing Equipment Regulations.
Bluetooth trademark: Bluetooth ®
is a trademark
owned by Bluetooth SIG, Inc.,
and licensed to Clarion Co., Ltd.
VOICE COMMANDS GUID-DC1FBBFE-C9FC-4BE4-98EE-C78349271F4A
You can use voice commands to operate
various Bluetooth ®
Hands-Free Phone Sys-
tem features using the INFINITI Voice
Recognition system.
For more details, see “ INFINITI Voice
Recognition system (models with naviga-
tion system) ” (P.4-114).
Monitor, climate, audio, phone and voice recognition systems
4-91

Black plate (271,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]Phone menu display.
PHONE SELECTION GUID-55FEE7E0-1713-47B1-B3A9-605D3DAAC920
Up to 5 cellular phones can be registered
to the system. To switch to connect another
cellular phone, push PHONE button and
select the “ Connected Phones ” key. The
registered cellular phones are shown on
the list. If you select a cellular phone that
is different from the one currently con-
nected, the newly selected phone will be
connected to the system.
VEHICLE PHONEBOOK GUID-9C55C4DB-C8AB-40D9-9A84-A06D2C3EF82D
This vehicle has two phonebooks available
for hands-free use. Depending on the
phone, the system may automatically
download the entire cell phone ’ s phone-
book into the “ Handset Phonebook ” . For
the details about downloading a phone-
book, see “ Phone setting ” (P.4-98). If a
phonebook does not automatically down-
load, the vehicle phonebook may be set for
up to 1,000 entries. This phonebook allows
the recording of a name to speak while
using voice recognition. SAA2521
1. Push the PHONE button and select the
“ Vehicle Phonebook ” key.
2. Select the “ Add New ” key at the top of
the screen. SAA2522
3. Choose the method for entering the
phonebook entry. For this example,
select “ Enter Number by Keypad ” .
4. Enter the digits and select the “ OK ”
key. (See “ How to use touch screen
(models with navigation system) ” (P.4-
5).)
Monitor, climate, audio, phone and voice recognition systems
4-93

Black plate (272,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]4-94 Monitor, climate, audio, phone and voice recognition systems SAA2523
5. Select the “ Voicetag ” key to record a
name to speak when using the INFINITI
Voice Recognition system.
6. Select the “ Store ” key and prepare to
speak the name after the tone.
7. When the voicetag is successfully
saved, select the “ OK ” key to save the
phonebook entry.
8. After the phonebook entry is saved, it
will show a screen that is ready to call
the number. Press the BACK button to
return to the Vehicle Phonebook.
There are different methods to input a
phone number. Select one of the following options instead of “ Enter Number by Key-
pad ” in step 3.
. Copy from Call History
The system will show a list of incoming,
outgoing or missed calls that were
downloaded from the connected cellu-
lar phone (depending on the phone ’ s
compatibility). Select one of these
entries to save in the vehicle phone-
book.
. Copy from the Handset
The system will show the connected
cellular phone ’ s phonebook that was
downloaded (depending on the
phone ’ s compatibility). Select one of
these entries to save in the vehicle
phonebook. SAA2620
Editing the Vehicle Phonebook GUID-595130B1-D7D0-45B8-8BB0-FEE71007B86A
1. Push the PHONE button and select the
“ Vehicle Phonebook ” key.
2. Select the desired entry from the
displayed list.
3. Select the “ Edit ” key.
4. Select the desired item to change.

Black plate (273,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]SAA2523
The following editing items are available:
. Entry #
Changes the displayed number of the
selected entry.
. Name
Edit the name of the entry using the
keypad displayed on the screen.
. Number
Edit the phone number using the key-
pad displayed on the screen.
. Type
Select an icon from the icon list.
. Voicetag
Confirm and store the voicetag. Voice- tags allow easy dialing using the
INFINITI Voice Recognition system.
(See “ INFINITI Voice Recognition system
(models with navigation system) ” (P.4-
114).)
To delete an entry, select the “ Delete ” key
at step 3.
SAA2524
MAKING A CALL GUID-0C40BF3A-B58B-4CB6-9E2E-8530EF09E8AF
To make a call, follow this procedure.
1. Push the PHONE button on the instru-
ment panel or the
button on the
steering wheel. The “ PHONE ” screen
will appear on the display.
2. Select the “ Handset Phonebook ” key
on the “ PHONE ” menu.
3. Select the desired entry from the list.
4. Confirm the correct entry by selecting
for the correct number from the list.
Monitor, climate, audio, phone and voice recognition systems
4-95
