2012 INFINITI G37 display

Black plate (242,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]4-64 Monitor, climate, audio, phone and voice recognition systems/ Next/Previous Chapter:
Select the “
” or “ ” key to skip the
chapter(s) of the disc forward/backward.
The chapters will advance/go back the
number of times this key is selected.
/ Commercial Skip:
This function is only for DVD-VIDEO, DVD-
VR. Select the “
” or “ ” key to skip
forward or backwards by the set amount as
defined in the DVD Settings menu.
Top Menu: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
When the “ Top Menu ” key is selected in
the screen while a DVD is being played, the
top menu specific to each disc will be
displayed. For details, see the instructions
on the disc. SAA2498
Example
DVD settings GUID-EF65036E-C53A-459C-BC1C-767A5BE8D439
Select the “ Settings ” key to adjust the
following settings.
Key (DVD-VIDEO): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Keys for the DVD menu operation are
displayed.
: Move the cursor to select a DVD
menu.
Enter: Enter the selected menu.
Move: Change the display location by
moving the operation key.
Back: Return to the previous screen. Hide: Hide the operation key.
Title Menu (DVD-VIDEO): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Some menus specific to each disc will be
shown. For details, see the instructions on
the disc.
Title Search (DVD-VIDEO, DVD-VR): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
The scene with the specified title will be
displayed each time the “ + ” side or “ − ”
side is selected.
Group Search (VIDEO CD): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
A scene in the specified group will be
displayed each time the “ + ” side or “ − ”
side is selected.
10 Key Search (DVD-VIDEO, VIDEO-CD, CD-
DA, DVD-VR): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Select the “ 10 Key Search ” key to open the
number entry screen. Input the number to
be searched and select the “ OK ” key. The
specified Title/Chapter or Group/Track will
be played.
Select No. (VIDEO-CD): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Select the “ Select No. ” key to open the
number entry screen. Input the number to
be searched and select the “ OK ” key. The
specified scene will be played.

Black plate (243,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]Angle (DVD-VIDEO): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
If the DVD contains different angles (such
as moving images), the current image
angle can be switched to another one.
Select the “ Angle ” key. The angle will
change each time the “ + ” side or “ − ” side
is selected.
Angle Mark (DVD-VIDEO): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
When this item is turned on, an angle mark
will be shown on the bottom of the screen
if the scene can be seen from a different
angle.
Menu Skip (DVD-VIDEO): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
DVD menus are automatically configured
and the contents will be played directly
when the “ Menu Skip ” key is turned on.
Note that some discs may not be played
directly even if this item is turned on.
CM Skip (DVD-VIDEO): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Select the “ CM Skip ” key. Choose the
setting time from 15, 30 or 60 seconds by
selecting the “ + ” side or “ − ” side.
DRC (DVD-VIDEO, DVD-VR): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
DRC (Dynamic Range Compression) auto-
matically adjusts the soundtrack volume
level to maintain a more even sound to the
speakers. DVD Language (DVD-VIDEO, VIDEO-CD): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Select the “ DVD Language ” key to open the
number entry screen. Input the number
corresponding to the preferred language
and select the “ OK ” key. The DVD top menu
language will be changed to the one
specified.
Display: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
To adjust the image quality of the screen,
select the preferred adjustment items.
Audio: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Select the preferred language for audio.
Subtitle (DVD-VIDEO, DVD-VR): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Select the preferred language for subtitles.
Display Mode (DVD-VIDEO, VIDEO-CD, DVD-
VR): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Select from the “ Full ” , “ Wide ” , “ Normal ” or
“ Cinema ” modes.
Title List (DVD-VR): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Select the preferred title from the list.
Play Mode: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Select the preferred play mode.
PG/PL Mode (DVD-VR): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Select the “ PG ” or “ PL ” mode. SAA2973
Automatic transmission models
SAA2610
Manual transmission models
Monitor, climate, audio, phone and voice recognition systems
4-65

Black plate (244,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]4-66 Monitor, climate, audio, phone and voice recognition systemsUSB INPUT OPERATION (if so
equipped) GUID-4B21241F-4ADE-4AD7-A63A-F1E74FC23C27
Audio main operation GUID-34A5649A-6666-4FBF-92EB-CF62FA20C513
Open the console lid and connect a USB
memory
* 1
as illustrated. Then, push the
DISC·AUX or AUX button repeatedly to
switch to the USB memory mode.
If the system has been turned off while the
USB memory was playing, pushing the
ON·OFF/VOL control knob will start the USB
memory. SAA2500
File selection (models with naviga-
tion system) GUID-9F3C0319-2176-4D68-992D-F00A08F7219C
When there are both audio and movie files
in the USB memory, the mode select
screen is displayed. Select the preferred
contents to play.
When there is only one type of file, the
audio or movie operation screen is dis-
played and starts to play.
If a video file restricts the number of
playbacks, a pop-up screen will appear to
confirm it is ok to play. Answer yes or no as
requested by the display. SAA2501
Models with navigation system
SAA2611
Models without navigation system

Black plate (245,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]Audio file operation GUID-9697F8FF-216E-483C-8A54-4173DBF087F8
or PLAY: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
When the DISC·AUX or AUX button is
pushed with the system off and the USB
memory inserted, the system will turn on.
If another audio source is playing and a
USB memory is inserted, push the
DISC·AUX or AUX button repeatedly until
the center display changes to the USB
memory mode.
Next/Previous File and Fast
Forward/Rewind: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
When the or button is pushed for
more than 1.5 seconds while a USB
memory is being played, the USB memory
will play while forwarding or rewinding.
When the button is released, the USB
memory will return to normal play speed.
When the
or button is pushed for
less than 1.5 seconds while the USB
memory is being played, the next track or
the beginning of the current track on the
USB memory will be played.
When the REW button is pushed for less
than 1.5 seconds within 3 seconds after
the current track started playing, the previous track will be played.
When the REW button is pushed for less
than 1.5 seconds after 3 seconds from
when the current track started playing, the
beginning of the current track will be
played.
The INFINITI controller can also be used to
select tracks when the USB memory is
being played.
Folder selection: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
To change to another folder in the USB
memory, turn the folder selector or choose
a folder displayed on the screen using the
INFINITI controller.
REPEAT (RPT), RANDOM (RDM): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
When the RPT button is pushed while the
USB memory is played, the play pattern
can be change as follows.
To change the play mode, push the RPT
button repeatedly and the mode will
change as follows.
Normal ? 1 Folder Repeat ? 1 Track
Repeat ? All Random ? 1 Folder Random
? Normal Text (models without navigation system): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
When the “ Text ” key is selected on the
screen using the INFINITI controller and
then the ENTER button is pushed while a
USB memory is being played, the music
information listed below will be displayed
on the screen.
. Folder title
. File title
. Song title
. Album Title
. Artist
Monitor, climate, audio, phone and voice recognition systems
4-67

Black plate (246,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]4-68 Monitor, climate, audio, phone and voice recognition systems SAA2502
Menu (models with navigation system): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
There are some options available during
playback. Select one of the following
options that are displayed on the screen
if necessary. Refer to the following infor-
mation for each item.
. Movie Playback
Switch to the movie playback mode.
This item is displayed only when a USB
memory contains movie files.
. Folder List/Track List
Displays the folder or track list. The
“ Movie Playback ” key is also displayed
in this list screen, and enables switch- ing to the movie playback mode.
. Play Mode
Select the preferred play mode.
SAA2503
Movie file operation (models with
navigation system) GUID-12E3E830-635E-44A0-AB33-1FC23A6DB8B2
Park the vehicle in a safe location for the
front seat occupants to operate the USB
memory while watching the images.
PLAY: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
When the DISC·AUX button is pushed with
the system off and the USB memory
inserted, the system will turn on.
If another audio source is playing and a
USB memory is inserted, push the
DISC·AUX button repeatedly until the cen-
ter display changes to the USB memory

Black plate (247,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]mode.
Operation keys: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
To operate the USB memory, select the
desired key displayed on the operation
screen using the INFINITI controller.
Pause
Select the “ ” key to pause the movie
file. To resume playing the movie file,
select the “
” key.
Play
Select the “ ” key to start playing a
movie file, for example, after pausing a
movie file.
STOP
Select the “
” key to stop playing a
movie file.
Skip (Next chapter)
Select the “
” key to skip the chapter(s)
of the disc forward. The chapters will
advance the number of times the ENTER
button is pushed. Skip (Previous chapter)
Select the “
” key to skip the chapter(s)
of the disc backward. The chapters will go
back the number of times the “
” key is
selected.
List: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Select the “ List ” key on the movie file
operation screen to display the file list. SAA2504
Example
Settings: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Select the “ Settings ” key to adjust the
following settings.
. Audio File Playback
Switch to the audio playback mode.
This item is displayed only when the
USB memory contains the audio files.
. Play Mode
Select the “ Normal ” or “ 1 Track Re-
peat ” play mode.
. 10 Key Search
Select the “ 10 Key Search ” key to open
the number entry screen.
Monitor, climate, audio, phone and voice recognition systems
4-69

Black plate (248,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]4-70 Monitor, climate, audio, phone and voice recognition systemsInput the number to be searched and
select the “ OK ” key.
The specified folder/file will be played.
. Display
To adjust the image quality of the
screen, select the preferred adjustment
items.
. DRC
DRC (Dynamic Range Compression)
automatically adjusts the soundtrack
volume level to maintain a more even
sound to the speakers.
. Audio
Select the preferred language for audio.
. Subtitle
Select the preferred language for sub-
title.
. Display Mode
Select the “ Normal ” , “ Wide ” , “ Cinema ”
or “ Full ” mode. Bluetooth ®
STREAMING AUDIO
(models with navigation system) GUID-384085FE-4107-49E0-ABDF-8432D24FAAB8
Your INFINITI is equipped with Bluetooth ®
Streaming Audio. If you have a compatible
Bluetooth ®
device with streaming audio
(A2DP profile), you can set up the wireless
connection between your Bluetooth ®
de-
vice and the in-vehicle audio system. This
connection allows you to listen to the
audio from the Bluetooth ®
device using
your vehicle speakers. It also may allow
basic control of the device for playing and
skipping audio files using the AVRCP
Bluetooth ®
profile. All Bluetooth ®
Devices
do not have the same level of controls for
AVRCP. Please consult the manual for your
Bluetooth ®
Device for more details.
Once your Bluetooth ®
device is connected
to the in-vehicle audio system, it will
automatically reconnect whenever the de-
vice is present in the vehicle and you select
Bluetooth ®
Audio from your audio system.
You do not need to manually reconnect for
each usage.
Wireless LAN (Wi-Fi) and the Bluetooth ®
functions share the same frequency band
(2.4 GHz). Using the Bluetooth ®
and the
wireless LAN functions at the same time
may slow down or disconnect the commu- nication and cause undesired noise. It is
recommended that you turn off the wire-
less LAN (Wi-Fi) when using the Bluetooth ®
functions.
Regulatory information GUID-6C3C217B-4E76-422B-A1AB-9113DCE019A0
FCC Regulatory information: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
. CAUTION: To maintain compliance with
FCC ’ s RF exposure guidelines, use only
the supplied antenna. Unauthorized
antenna, modification, or attachments
could damage the transmitter and may
violate FCC regulations.
. Operation is subject to the following
two conditions:
1) This device may not cause inter-
ference and
2) This device must accept any inter-
ference, including interference that
may cause undesired operation of
the device
IC Regulatory information: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
. Operation is subject to the following
two conditions:
1) This device may not cause inter-
ference, and
2) This device must accept any inter-
ference, including interference that

Black plate (250,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]4-72 Monitor, climate, audio, phone and voice recognition systems SAA2507
3. A confirmation screen will be dis-
played. Select “ No ” .
Note: Selecting “ Yes ” will only connect
the hands free phone portion of a
Bluetooth ®
device. SAA3005
4. Choose a PIN code to use with the
compatible Bluetooth ®
audio device
using the number input screen. The
PIN code will need to be entered into
the Bluetooth ®
audio device after step
5. Select the “ OK ” key. SAA3006
5. The standby message screen will ap-
pear. Operate the compatible Blue-
tooth ®
audio device. For the
connecting procedure of the audio
device, see the Bluetooth ®
audio in-
structions.
When the connecting is completed, the
screen will return to the Bluetooth ®
setup display.
