Monitoring
Manual test in the type 2 instrument panel central screen
This function allows you to check the status of the vehicle systems (reminder of the "activated"/"deactivated" status of the configurable functions) and to
display the aler ts log.
)With the engine running, to star t a manual
test, briefly press the ".../000"button on
the instrument panel. The followin
g information appears successively in the instrument panel central screen:
- engine oil level indicator(see corresponding section),
- ser vice indicator (see correspondingsection),
- under-inflation detection (if your vehicle
is fitted with this system; see the "Safety"section),
- current warnings and aler t messages,
if any (see corresponding section for the
warning lamp or system concerned),
- status of configurable functions(see "Multifunction screens").

This information also appears everytime the ignition is switched on(automatic test).

79Comfort










Recommendations for ventilation and air conditioning


If after an extended stop in sunshine, the interior temperature is veryhigh, first ventilate the passenger compartment for a few moments. Put the air flow control at a setting high enough to quickly change the air in the passenger compartment.
The air conditioning system does notcontain chlorine and does not present any danger to the ozone layer.

In order for these systems to be fully effective, follow the operation and maintenance guidelines below: )
To obtain an even air distribution, take care not to obstruct the exterior air intake grilles located at the base of the windscreen, the nozzles, the vents and the air outlets, as wellas the air extractor located in the boot. )
Do not cover the sunshine sensor, located on the dashboard; this is used for regulation of the digital air conditioning system. )
Operate the air conditioning system for at least 5 to 10 minutes, once or twice a monthto keep it in per fect working order. )
Ensure that the passenger compar tment filter is in good condition and have the filter elements replaced regularly (refer to the "Checks" section). We recommend the use of a combined passenger compartment filter. Thanks to its special active additive, it contributes to the purification of the air breathed by theoccupants and the cleanliness of the passenger compartment (reduction of allergic symptoms, bad odours and greasy deposits).)
To ensure correct operation of the air conditioning system, you are also advised to haveit checked regularly as recommended in the ser vicing booklet.
)
If the system does not produce cold air, switch it off and contact a CITROËN dealer or a qualified workshop.
When towing the maximum load on a steep gradient in high temperatures, switching off theair conditioning increases the available engine power and so improves the towing ability.


The condensation created by the air conditioning results in a dischargeof water under the vehicle which is perfectly normal.




Stop & Start
The heating and air conditioning systems only work when the engine is running. To maintaina comfor table temperature in the passenger compartment, you can temporarily deactivatethe Stop & Start system (see "Driving").

Do not throw the remote controlbatteries away, they contain metals which are harmful to the environment.
Take them to an approved collectionpoint.
Lost keys

Visit a CITROËN dealer with the vehicle's registration document, your personal identification documents and if possible the key code label.

The CITROËN dealer will be able to find the key code and the transponder code required toorder a new key.


Remote control

The high frequency remote control is a sensitive system; do not operate it while it is in your pocket as there is a possibility that it may unlock the vehicle, without you being aware of it.
Do not repeatedly press the buttons of your remote control out of range and out of sight of your vehicle. You run the risk of stopping it from working and the remote control would haveto be reinitialised.
The remote control does not operate when the key is in the ignition switch, even when the ignition is switched off, except for reinitialisation.


Locking the vehicle
Driving with the doors locked may make access to the passenger compar tment by theemergency services more difficult in an emergency. As a safety precaution (with children on board), remove the key from the ignition switchwhen you leave the vehicle, even for a shor t time.


Anti-theft protection

Do not make any modifications to the electronic engine immobiliser system; this couldcause malfunctions.

When purchasing a second-hand vehicle

Have the pairing of all of the keys in your possession checked by a CITROËN dealer, to ensure that only your keys can be used to open and star t the vehicle.

Visibility
Windscreen and headlamp
wash
)Pull the windscreen wiper stalk towards you. The windscreen wash then the
windscreen wipers operate for a fixed period.
The headlamp washers only operate when the
dipped beam headlamps are on .

Low screenwash/headlampwash level
On vehicle fitted with headlamp washers, the low level of this fluid is indicated by gauge in
the reservoir filler neck under the bonnet.Checking and topping up this fluid can only be
done when stationary with the engine off.
The driver should check the level of this fluid regularly, par ticularly duringwinter.
Refer to "Checks -
§ Screenwash/headlampwash level" for the procedure on checking thelevel.

151Fittings
230 V/50 Hz power socket

A 230 V/50 Hz socket (maximum power: 120 W)
is fitted to the centre console.
To use the socket:)lift the front armrest cover for access to itscompartment,)check that the warning lamp is on green, )connect your multimedia or other electricaldevice (telephone charger, laptop computer,CD-DVD player, baby food warmer...).
This socket works with the engine running, as
well as in ST
OP mode on Stop & Star t.
In the event o
f a fault with the socket, the green
warning lamp flashes.
Have it checked by a CITROËN dealer or a qualified workshop.
Connect only one device at a time to the socket (no extension or multi-wayconnector).Connect only devices with class IIinsulation (shown on the device). As a safety measure, when electricalconsumption is high and whenrequired by the vehicle's electrical system (particular weather conditions, electrical overload...), the current
supply to the socket will be cut off;the green warning lamp goes off.







12 V accessory
socket
) To connect a 12 V accessory (max power: 120 W), lift the cover and connect a suitable adaptor.

201Driving
SituationsConsequences
To a p p l
y the electric parking brake:)
immobilise the vehicle and switch off the ignition. )
pull the control for at least 5 seconds or until application is complete.)
switch on the ignition and check the switching on of the electric parking brake
warning lamps.
The application is slower than during normal operation.
To release the electric parkin
g brake:)
switch on the ignition.)
pull the control and hold it for approximately 3 seconds then release it.
If the braking warning lamp is flashing or if the warning lamps do not come on with
the ignition on, these procedures will not work. Place the vehicle on level ground
and have it checked by a CITROËN dealer or a qualified workshop. and possibl
y


flashin
g

Display of the message "Parking brake fault" and of thefollowing warning lamps:

- Only the automatic application on switching off the engine and automatic
release on acceleration functions are available.

- The manual application/release of the electric parking brake and theemergency braking are not available.
an
d possibly
flashin
g



Battery fault

- If the battery warning lamp comes on you must stop immediately as soon as
the traffic allows. Stop and immobilise your vehicle (if necessary, place the
two chocks under the wheels).

- Apply the electric parking brake before switching off the engine.

Stopping the vehicle
Operating fault

With the ignition on, the flashing of AUTO
,
accompanied by an audible signal and amessage in the screen, indicates a malfunction
of the gearbox.
Have it checked by a CITROËN dealer or a qualified workshop.
When immobilising the vehicle, withthe engine running, you must place thegear lever in neutral N
. Before carrying out any work in the engine compar tment, ensure that thegear lever is in neutral N
and that the parking brake is applied. Whatever the circumstances, you mustmanually apply the parking brake whenparking, unless the parking brake is programmed in automatic mode. Be
fore switching off the engine, you can:


- move to position N
to engage neutral,
or

- leave the
gear engaged; in this case, it will
not be possible to move the vehicle.
To engage reverse gear R, the vehicle must be
immobilised with your foot on the brake pedal. )Select position R.

At low high speed, if reverse gear is requested,
the N indicator flashes and the gearbox goes
into neutral automatically. To engage reverse, put the gear lever in position N , then position R.
In both cases, you must apply the parkingbraketo immobilise the vehicle.
Reverse

Engagement of reverse gear is accompanied by an audible signal.

Invalid value during manualoperation
This symbol is displayed if a gear
is not engaged correctly (selector
between two positions).

Stopping the vehicle
Before switching off the engine, you canengage position Por N
to place the gearbox in neutral.
In both cases, apply the parking brake toimmobilise the vehicle, unless it is programmedto automatic mode.

If the lever is not in position P, when thePdriver's door is opened or approximately45 seconds after the ignition is switched off, there is an audible signal and amessage appears.)Return the lever to position P
; the audible signal stops and themessage disappears.


Operating fault

When the ignition is on, the lighting of this
warning lamp, accompanied by an audible
signal and a message in the multifunction
screen, indicates a gearbox malfunction.
In this case, the gearbox switches to back-up
mode and is locked in 3rd
gear. You may feel
a substantial knock when changing from Pto R
and from N
to R
. This will not cause any
damage to the gearbox.
Do not exceed 60 mph (10 0 km/h), local speed restrictions permitting.
Have it checked by a CITROËN dealer or aqualified workshop.
This warning lamp may also come on if a door
is opened.
You risk damaging the gearbox:


- if you press the accelerator and brake pedals at the same time,

- if you force the lever from position Pto another position when the batteryis flat.

To reduce fuel consumption when stationary for long periods with the engine running (traffic jam...), positionthe gear lever at Nand apply theparking brake, unless it is programmed in automatic mode.
