Key

safety warning


contributes to the protection of the environment


refer to the page indicated

CONTENTS
3
Direction indicators 126Hazard warning lamps 126Horn 126Tyre under-infl ation detection 127Braking assistance systems 128Trajectory control systems 129Emergency or assistance call 130Seat belts 131Airbags 135
■■■■■■■■■
VIII-SAFETY 126Î138
Electric parking brake 139Hill start assist 146Manual gearbox 147Gear effi ciency indicator 1486-speed electronic gearbox system 149Stop & Start 153Automatic gearbox 156Fixed centred controlssteering wheel 160Speed limiter 162Cruise control 164Parking space sensors 166Lane departure warning system 168Parking sensors 169Pneumatic suspension 171
■■■■■
■■■
■■■■■■
IX - DRIVING 139Î172
Bonnet 174Running out of fuel (Diesel) 176Petrol engines 177Diesel engines 178Checking levels 179Checks 181
■■■■■■
X - CHECKS 173Î 182
Temporary puncture repair kit 183Changing a wheel 186Changing a bulb 190Changing a fuse 19712 V battery 203Energy economy mode 206Towing the vehicle 207Towing a trailer 209Roof bars 210Very cold climate screen 210Accessories 211
■■■■■■■■■■■
XI - PRACTICALINFORMATION 183Î 212
Petrol engines 213Petrol weights 214Diesel engines 215Diesel weights 217Petrol/Diesel weights - commercial versions 221Dimensions 223Identifi cation markings 226
■■■■■
■■
XII - TECHNICALDATA 213 Î226
Emergency or assistance 227NaviDrive 231MyWay 275Audio system 307Video pack 329
■■■■■
AUDIO andTELEMATICS 227 Î336
VISUALSEARCH 337 Î 341
ALPHABETICALINDEX 342 Î 348

8
FAMILIARISATION

CITROËN
Grand C4 Picasso

Torch
Pneumatic rear
suspension

Allows the height of the rear
of the vehicle to be adjusted Access to
spare wheel

Temporary puncture repair kit

Depending on model, the kit is located either in the boot well or in the compartment under the left hand
second-row passenger (open the fl ap by turning the screw a quarter turn).
This kit is a complete system for a temporary repair ; it comprises a compressor and a sealant
cartridge. Luggage cover blind Luggage cover in
two sections
Torch


111


11 2



187



171



183


116
CITROËN
C4 Picasso


BOOT

Refer also to the section "Practical information - § Changing a wheel".



186

17
FAMILIARISATION

Recommended settings



- Heating/manual air conditioning:




- Digital air conditioning:
the fully automatic mode is recommended - press "AUTO"
.

Operate


For...





Cooling



or

Fully cold
to start,
then personal
settings

Maximum
to start,
then personal
settings

ON

ON when
starting,
then OFF


Heating




or

Fully hot
to start,
then personal
settings

Maximum
to start,
then personal
setting




ON when
starting,
then OFF


Demisting

Defrosting




Fully hot



OFF


VENTILATION

18
FAMILIARISATION

Seat belts not fastened/
unfastened warning lamp
This warning lamp informs you
if the driver’s or front passen-
ger’s seat belt is not fastened
(depending on model), and if
the front passenger’s (depend-
ing on model) or the second-row
passengers’ seat belts are unfastened.
The illuminated positions represent
those whose seat belts are not fastened/
unfastened.
Once the function has been activated,
when starting the engine, the system
automatically locks the doors once you
reach approximately 6 mph (10 km/h).
This function can be deactivated by
pressing button A
for more than two
seconds.

Tyre under-inflation detection

This function warns you if a tyre is de-
fl ated or punctured.
This system does not absolve the driver
of the need to regularly check the tyre
pressures.
The service warning lamp comes
on, and a vehicle outline is dis-
played, accompanied by a mes-
sage and an audible signal.
Under-infl ation warning
The STOP
warning lamp comes
on, and a vehicle outline is dis-
played, accompanied by a mes-
sage and an audible signal.
Puncture


41




127




89

MONITORING


Automatic central locking
Instrument panel


with multifunction screen A or C

with the MyWay or NaviDrive
multifunction screen


1.
Instrument panel.

2.
Multifunction screen.

3.
Control buttons.

4.
Warning lamps display zone.



31




32



Manual central locking

You can use electrical central locking or
unlocking by pressing on button A
.
If one of the doors is open or is not
closed properly, central locking will not
work.

27
FAMILIARISATION
DRIVING

Stop & Start


Engine going into STOP mode
The "ECO"
warning lamp comes
on in the instrument panel and
the engine goes into stand-by:


- with the 6-speed electronic gear-
box system
; at speeds below
4 mph (6 km/h), press the brake
pedal or put the selector lever into
neutral (position N)
.
In certain circumstances the STOP
mode may not be available; the "ECO"

warning lamp fl ashes for a few sec-
onds, then goes off.



153
The "ECO"
warning lamp goes
off and the engine restarts:


- with the selector lever in position A

or M
, release the brake pedal,

- or with the selector lever in posi-
tion N
and the brake pedal released,
change to position A
or M
,

- or select reverse gear.
In certain circumstances, START mode
may be invoked automatically; the
"ECO"
warning lamp fl ashes for a few
seconds, then goes off.



154

Deactivation/Reactivation
You can deactivate the system at any
time by pressing the "ECO OFF"
but-
ton; the button’s warning lamp comes
on.
The system is reactivated automati-
cally every time you start the engine
with the key.

Before refuelling or doing any-
thing under the bonnet, you
must switch off the ignition
with the key.



154


Going into engine START mode

28
FAMILIARISATION
DRIVING

Ignition switch



●
S: Steering lock

To release the steering lock, operate
the steering slightly while turning the
key, but without forcing.

●
M: Ignition on, running position


●
D: Starter

Release the key as soon as the en-
gine starts. Do not operate the starter
when the engine is running.




81


1.
Cruise control mode On/Off.

2.
Programming a speed/Reducing
the programmed value.

3.
Cruise control On/Off.

4.
Programming a speed/Increasing
the programmed value.
In order to be programmed or activated,
the vehicle speed must be higher than
25 mph (40 km/h), with at least fourth
gear engaged on a manual gearbox
(second gear for the 6-speed electronic
gearbox system or automatic gearbox).

Cruise control




164


1.
Limiter mode On/Off.

2.
Decrease the programmed value.

3.
Speed limiter On/Off.

4.
Increase the programmed value.


Speed limiter




162

I
33
MONITORING









Indicator and warning lamps

Visual indicators informing the driver that a system is in
operation (operation or deactivation indicator lamps) or of
the occurrence of a fault (warning lamp).

When the ignition is switched on
Certain warning lamps come on for a few seconds when
the vehicle's ignition is switched on.
When the engine is started, these same warning lamps
should go off.
If they remain on, before moving off, refer to the informa-
tion on the warning lamp concerned.
Associated warnings
The illumination of certain warning lamps may be accompanied
by an audible signal and a message in the multifunction screen.

Operation indicator lamps
If one of the following indicator lamps comes on, this confi rms
that the corresponding system has come into operation.
The warning lamps may come on continuously (fi xed)
or fl ash.
Certain warning lamps may come on in two different
modes. Only by relating the type of illumination to the
operating status of the vehicle can it be ascertained whether
the situation is normal or whether a fault has occurred.


Warning lamp


is on


Cause


Action/Observations





Left-hand
direction
indicato

r


fl ashing with
buzzer. The lighting stalk is pushed down.





Right-hand
direction
indicator


fl ashing with
buzzer. The lighting stalk is pushed up.






Sidelamps


fi xed. The lighting stalk is in the
"Sidelamps" position.




Dipped beam
headlamps


fi xed. The lighting stalk is in the "Dipped
beam headlamps" position.




Main beam
headlamps


fi xed. The lighting stalk is pulled towards
you. Pull the stalk to return to dipped
beam headlamps.





Hazard
warning
lamps


fl ashing with
audible signal. The hazard warning lamps switch,
located on the dashboard, has been
operated. The left-hand and right-hand direction
indicators and their associated indicator
lamps fl ash simultaneously.
