2011 TOYOTA SIENNA Navigation Manual

SIENNA_Entry_Navi_U
OM45459U
9

10
0U5111aX
No.NameFunctionPage
1
Northup or
headingup
symbolThis symbol indicates a map view with
north−up or heading−up. Touching this
symbol changes the map orientation.
38
2Scale indicatorThis figure indicates the map scale.36
3“MAP/VOICE”
buttonPush this button to repeat a voice guid-
ance, cancel one touch scroll, start
guidance, and disp lay the current posi-
tion.
29, 72
4“DEST” buttonPush this button to display the “Destina-
tion” screen.12, 14, 16, 17, 40, 41
5“MENU” buttonPush this button to display the “Menu”
screen.88, 90, 91, 92,94, 108, 194
6“DISP/TILT”
buttonPush this button to display the “Display”
screen.22, 135
Quick guide —
— Overview buttons and guidance screen

11
No.NameFunctionPage
7“INFO” buttonPush this button to display the “Informa-
tion” screen.126, 130, 136, 139
8Zoom out buttonTouch this button to reduce the map
scale.36
9“Mark”
Touch th is button to register the current
position or the cursor position as a
memory point.
31
10“Route”Touch this button to change the route.74, 76
11“Map View”
Touch this button to browse information
about guidance route, to set the Points
of Interest to be displayed on the
screen, or to record the route.
80, 82, 83, 84
12“  OFF”
Touch this button to obtain a broader
view. Some of the buttons on the
screen are not displayed. They are dis-
played again by touching “ON”.
11 2
13Zoom in buttonTouch this button to magnify the map
scale.36
14Foot print map
buttonTouch this button to display the foot print
map and the building information.37
15
Screen
configuration
buttonTouch this button to change the screen
mode.34
16
Distance and
time to
destinationDisplays the distance, the estimated
travel time to the destination, and the
estimated arrival time at the destination.
73
17XM NavTraffic
markThis mark is displayed when XM  Nav-
Traffic information is received.11 8
18
“GPS” mark
(Global
Positioning
System)Whenever the vehicle is receiving sig-
nals from the GPS, this mark is dis-
played.
182

12
1Push “DEST” button.
2Touch .
If home has not been registered, you can
register it by touching
.
3There are 11 different methods
to search your home.
See “Destination search” on page 41.
4Touch “Enter”.
The “Memory Point” screen is displayed.
— Registering home

13
5Touch “OK”.
Registration of home is complete.
You can also register home by touching
the “MENU” button. (See “ — Registering
home” on page 102.)
You can change the icon, quick access,
name, location and phone number. (See
“ — Editing memory points” on page 96.)

14
1Push “DEST” button.
2Touch one of the quick access
buttons.
You can set a memory point to one of the
quick access buttons which has not been
set.
3There are 12 different methods
to search preset memory points.
See “Destination search” on page 41.
4Touch “Enter”.
The “Memory Point” screen is displayed.
— Registering preset memory points
(Quick access)

15
5Touch “OK”.
Registration of preset memory points is
complete.
You can also register preset memory
points by touching the “MENU” button.
(See “ — Registering memory points” on
page 95.)
You can change the icon, quick access,
name, location and phone number. (See
“ — Editing memory points” on page 96.)
The registered points can be used on the
“Destination” screen. (See “ — Destina-
tion search by Quick access” on page 44.)

16
1Push “DEST” button.
2There are 12 different methods
to search destinations.
See “Destination search” on page 41.
3Touch “Enter”.
The navigation system performs a search
for the route.
4Touch “Guide”, and start driv-
ing.
Routes other than the one recommended
can also be selected. (See “Starting route
guidance” on page 63.)
5Guidance to the destination is
given via voice and on the guid-
ance screen.
— Operation flow: guiding the route
