2011 MERCEDES-BENZ CLS-CLASS check engine

Emission control
............................... 213
Information label ............................ 289
System warranties ........................... 19
Engine
Break-in recommendations ............176
Cleaning ......................................... 217
Compartment ................................ 178
Malfunction indicator
lamp ........................................ 28, 257
Messages in the multifunction
display ........................................... 243
Number .......................................... 289
Starting ............................................ 97
Turning off ..................................... 101
Engine (Technical data)
see Vehicle specification
Engine coolant
see Coolant
Engine oil
Adding ........................................... 180
Additives ........................................ 298
Checking level ............................... 179
Consumption ................................. 179
Messages in the multifunction
display ........................................... 246
Oil dipstick ..................................... 179
Recommended engine oils and oil
filter ............................................... 298
ESP ®
(Electronic Stability
Program) .............................................. 59
ETS .................................................. 60
Messages in the multifunction
display ................................... 229, 239
Warning lamp ................................. 255
ETD (Emergency Tensioning
Device) ................................................. 49
Safety guidelines ............................. 39
ETS (Electronic Traction System) ....... 60
Express operation Power windows ................................ 94
Tilt/sliding sunroof ........................152
Exterior lamp switch ........................... 87
Exterior rear view mirrors ..................84
Parking position ............................... 85
Exterior view of vehicle ......................26 F
Fastening the seat belts .....................47
First aid kit .........................................
224
Flat tire ............................................... 271
Lowering the vehicle ......................276
Mounting the spare wheel ............. 272
Preparing the vehicle .....................271
Spare wheel ........................... 271, 296
Floormats ........................................... 173
Fluids
Automatic transmission fluid ......... 297
Brake fluid ..................................... 297
Capacities ...................................... 296
Engine coolant ............................... 297
Engine oil ....................................... 297
Power steering fluid ....................... 297
Washer and headlamp cleaning
system ........................................... 297
Fog lamps ............................................. 89
Messages in the multifunction
display ................................... 247, 249
Front air bags
see Air bags
Front lamps
see Headlamps
Front passenger front air bag ............ 40
Messages in the multifunction
display ........................................... 230
Front passenger front air bag off
indicator lamp ............................. 41, 260
Fuel ..................................................... 176
Additives ........................................ 299
Capacity, fuel tank ......................... 297
Drive sensibly–safe fuel .................210
Fuel consumption statistics ...........125
Fuel filler flap and cap ................... 177
Fuel tank reserve warning
lamp ........................................ 29, 256
Premium unleaded gasoline ...........299
Refueling ........................................ 176
Requirements ................................ 299
Fuel filler flap ..................................... 177
Opening manually ..........................263
Fuels, coolants, lubricants etc. ........296 8
Index 219_AKB; 4; 54, en-US
d2ureepe,
Version: 2.11.8.1 2009-05-11T16:21:02+02:00 - Seite 8
ProCarManuals.com

Memory function .............................. 85
Vanity mirror ..................................
162
MOExtended system ......................... 277
MOExtended tires ..................... 277, 292
MON (Motor Octane Number) ..........299
Motor Octane Number see MON

Multicontour seat ................................ 80
Multifunction display ........................ 111
Symbol messages .......................... 238
Text messages ............................... 229
Vehicle status messages ............... 228
Multifunction display messages
ABS ....................................... 229, 239
Active headlamps .......................... 247
Advanced TPMS ..................... 236, 250
Air bags ......................................... 230
Air filter .......................................... 246
AIRMATIC DC (Dual Control) .......... 240
Alternator ...................................... 245
Automatic transmission ................. 235
Battery ........................................... 245
Brake fluid ..................................... 239
Brake pads ..................................... 238
Check engine ................................. 243
Coolant .......................................... 243
Corner-illuminating front fog
lamps ............................................. 249
Cruise control ................................ 233
Distronic ........................................ 233
Doors ............................................. 241
EBP ................................................ 239
Engine oil ....................................... 246
Engine service ............................... 243
ESP ®
...................................... 229, 239
Fog lamps .............................. 247, 249
Front passenger front air bag ........230
Gas cap .......................................... 246
Gear selector lever ........................235
High-beam lamps ........................... 248
Hood .............................................. 241
License plate lamps ....................... 248
Light sensor ................................... 248
Low-beam lamps ............................ 249
Parking brake ................................ 239
Parking lamps ................................ 248
PRE-SAFE ®
.................................... 229Reserve fuel ...................................
246
Reverse lamp ................................. 247
Side marker lamps .........................248
SmartKey ....................................... 241
SmartKey with KEYLESS-GO ..........241
SRS ................................................ 240
Tail lamps ...................................... 249
Tele Aid .......................................... 240
Tire inflation pressure ............235, 250
Tire pressure monitor .................... 236
Tires ...................................... 235, 250
TPMS ..................................... 236, 250
Trunk ............................................. 241
Turn signals ................................... 250
Washer fluid ................................... 242
Multifunction steering wheel
Adjustment ...................................... 82
Buttons .......................................... 110
Cleaning ......................................... 220
Easy-entry/exit feature ...........83, 124
Gearshift control ............................ 106
Heating ............................................ 83
Memory function .............................. 85
Overview .......................................... 29 N
Navigation menu ............................... 117
Navigation system see Separate operating instructions


NECK-PRO active front head
restraints ............................................. 50
Resetting ....................................... 264
Net, parcel ......................................... 157
Night security illumination .............. 122
Normal occupant weight .................. 207
Number, vehicle identification
(VIN) ................................................... 289 O
Occupant Classification System see

OCS (Occupant Classification
System)
Occupant distribution ....................... 207
Occupant safety Air bags ........................................... 37
Children and air bags ....................... 3712
Index 219_AKB; 4; 54, en-US
d2ureepe,
Version: 2.11.8.1 2009-05-11T16:21:02+02:00 - Seite 12
ProCarManuals.com

Technical data (engine)
see Vehicle specification
Technical data (weights)
see Vehicle specification
Tele Aid ............................................... 164
Emergency calls ............................. 165
Information button .........................167
Initiating an emergency call
manually ........................................ 166
Messages in the multifunction
display ........................................... 240
Remote door unlock ...................... 168
Roadside Assistance button .......... 166
Search & Send ............................... 168
SOS button .................................... 166
Stolen Vehicle Recovery Services .. 169
System self-test ............................. 165
Telephone ............................................. 29
Answering/ending a call ................ 126
Hands-free microphone ...................33
Menu ............................................. 125
Operation ....................................... 125
Phone book .................................... 126
Redialing ........................................ 127
Temperature
Coolant .......................................... 109
Interior temperature ......................147
Outside .................................. 113, 120
Tether anchorage points
see Children in the vehicle
Tie-down hooks ................................. 157
Tightening torque Wheels ........................................... 277
TIN (Tire Identification Number) ...... 207
Tire and Loading Information
placard ............................................... 193
Tire and loading terminology ...........205
Tire Identification Number see TIN
Tire inflation pressure
Checking ........................................ 185
Important notes on ........................ 184
Label on the inside of fuel filler
flap ................................................ 185
Placard on driver’s door B-pillar ..... 193
Tire labeling ....................................... 201
Tire load rating .................................. 206Tire ply composition and material
used ....................................................
207
Tire pressure loss warning system .
186
Tire Pressure Monitoring System
(TPMS) ................................................ 188
Messages in the multifunction
display ................................... 236, 250
Tires ........................................... 182, 291
Advanced Tire Pressure
Monitoring System (Advanced
TPMS) ............................................ 190
Air pressure ................................... 183
Care and maintenance ................... 198
Cleaning ......................................... 199
Direction of rotation, spinning .......197
Important notes on tire inflation
pressure ........................................ 184
Inflation pressure ........................... 185
Information placard ....................... 193
Inspection ...................................... 198
Labeling ......................................... 201
Load index ............................. 202, 206
Load rating .................................... 206
Messages in the multifunction
display ................................... 235, 250
MOExtended .................................. 292
Ply composition and material
used ............................................... 207
Problems under-/overinflation ...... 185
Retreads ........................................ 182
Rims and tires (technical data) ...... 291
Rotation ......................................... 200
Service life ..................................... 198
Sizes .............................................. 291
Snow chains .................................. 208
Speed rating .......................... 203, 207
Storing ........................................... 199
Temperature .......................... 184, 200
Terminology ................................... 205
Tire Identification Number ............. 207
Tire pressure loss warning system . 186
Tire Pressure Monitoring System
(TPMS) ........................................... 188
TPMS low tire pressure/
malfunction telltale ........................ 259
Traction ................................. 199, 207
Tread ............................................. 207
Tread depth ........................... 198, 20816
Index 219_AKB; 4; 54, en-US
d2ureepe,
Version: 2.11.8.1 2009-05-11T16:21:02+02:00 - Seite 16
ProCarManuals.com

G
Warning!
The SRS self-check has detected a
malfunction when the SRS indicator lamp
+
R does not come on at all
R fails to go out after approximately
4 seconds after the engine was started
R comes on after the engine was started or
while driving
For
your safety, we strongly recommend that
you contact an authorized Mercedes-Benz
Center immediately to have the system
checked. Otherwise the SRS may not be
activated when needed in an accident, which
could result in serious or fatal injury. The SRS
might also deploy unexpectedly and
unnecessarily which could also result in injury
as well.
In addition, improper work on the SRS creates
a risk of rendering the SRS inoperative or
causing unintended air bag deployment. Work
on the SRS must therefore only be performed
by qualified technicians. Contact an
authorized Mercedes-Benz Center.
If it is necessary to modify an air bag system
to accommodate a person with disabilities,
contact an authorized Mercedes-Benz Center.
USA only: Call our Customer Assistance
Center at 1-800-FOR-MERCedes
(1-800-367-6372) for details. Air bags
G
Warning!
Air bags are designed to reduce the potential
of injury and fatality in certain
R frontal impacts (front air bags and driver’s
side knee bag)
R side impacts (side impact air bags and
window curtain air bags)
R rollovers (window curtain air bags) However, no system available today can
completely eliminate injuries and fatalities.
Deployment of the air bags temporarily
releases a small amount of dust from the air
bags. This dust, however, is neither harmful
to

your health, nor does it indicate a fire in the
vehicle. The dust might cause some
temporary breathing difficulty for people with
asthma or other breathing trouble. To avoid
this, you may wish to get out of the vehicle as
soon as it is safe to do so. If you have any
breathing difficulty but cannot get out of the
vehicle after the air bag inflates, then get fresh
air by opening a window or door. G
Warning!
To reduce the risk of injury when the front air
bags
inflate, it is very important for the driver
and front passenger to always be in a properly
seated position and to wear their respective
seat belt.
For maximum protection in the event of a
collision always be in normal seated position
with your back against the seat backrest.
Fasten your seat belt and make sure it is
properly positioned on your body.
Since the air bag inflates with considerable
speed and force, a proper seating position
and correct positioning of the hands on the
steering wheel will help to keep you at a safe
distance from the air bag. Occupants who are
not wearing their seat belt, are not seated
properly or are too close to the air bag can be
seriously injured or killed by an air bag as it
inflates with great force instantaneously:
R Sit with the seat belt properly fastened in a
position that is as upright as possible with
your back against the seat backrest.
R Move the driver’s seat as far back as
possible, still permitting proper operation
of vehicle controls. The distance from the
center of the driver’s chest to the center of
the air bag cover on the steering wheel
must be at least 10 inches (25 cm) or more.
You should be able to accomplish this by Occupant safety
37
Safety and security
219_AKB; 4; 54, en-US
d2ureepe, Version: 2.11.8.1 2009-05-11T16:21:02+02:00 - Seite 37 Z
ProCarManuals.com

weight category determined by weight sensor
readings from the front passenger seat.
The system does not deactivate
R
the front passenger side impact air bag
R the window curtain air bag
R the Emergency Tensioning Devices (ETDs)
To
be classified correctly, the front passenger
must sit
R with the seat belt properly fastened
R in a position that is as upright as possible
with the back against the seat backrest
R with the feet on the floor
If the occupant’s weight is transferred to
another object in the vehicle (e.g. by leaning
on armrests), the OCS may not be able to
properly approximate the occupant’s weight
category.
Furthermore, the occupant weight may
appear to increase or decrease due to the
following:
R objects hanging on the seat
R objects lodged underneath the seat
R objects stuffed between the seat and
middle console
R objects stuffed between the seat and door
R other passengers pushing on the seat
R objects applying pressure to the back of
the seat
Always make sure the seat has clearance
in all directions at all times.
If your seat, including the trim cover and
cushion, needs to be serviced in any way, take
the vehicle to an authorized Mercedes-Benz
Center.
Only seat accessories approved by
Mercedes-Benz may be used.
Both the driver and the front passenger
should always use the 04
indicator lamp as an indication of whether or
not the front passenger is properly
positioned. G
Warning!
If the 04 indicator lamp
illuminates when an adult or someone larger
than a small individual is in the front
passenger seat, have the front passenger
reposition himself or herself in the seat until
the 04 indicator lamp goes out,
or

check whether objects are caught under or
around the seat.
In the event of a collision, the air bag control
unit will not allow front passenger front air bag
deployment when the OCS has classified the
front passenger seat occupant as weighting
as much as or less than a typical 12-month-
old child in a standard child restraint or if the
front passenger seat is classified as being
empty.
When the OCS senses that the front
passenger seat occupant is classified as
being up to or less than the weight of a typical
12-month-old child in a standard child
restraint, the 04 indicator lamp
will illuminate when the engine is started and
remain illuminated, indicating that the front
passenger front air bag is deactivated.
When the OCS senses that the front
passenger seat is classified as being empty,
the 04 indicator lamp will
illuminate when the engine is started and
remain illuminated, indicating that the front
passenger front air bag is deactivated.
When the OCS senses that the front
passenger seat occupant is classified as
being heavier than the weight of a typical
12-month-old child seated in a standard child
restraint or as being a small individual (such
as a young teenager or a small adult), the
04 indicator lamp will illuminate
for approximately 6 seconds when the engine
is started and then, depending on occupant
weight sensor readings from the seat, remain
illuminated or go out. With the
04 indicator lamp illuminated,
the front passenger front air bag is
deactivated. With the 04 42
Occupant safety
Safety and security
219_AKB; 4; 54, en-US
d2ureepe,
Version: 2.11.8.1 2009-05-11T16:21:02+02:00 - Seite 42
ProCarManuals.com

indicator lamp out, the front passenger front
air bag is activated.
When the OCS senses that the front
passenger seat occupant is classified as an
adult or someone larger than a small
individual,
the 04 indicator lamp
will illuminate for approximately 6 seconds
when the engine is started and then go out,
indicating that the front passenger front air
bag is activated.
If the 04 indicator lamp is
illuminated, the front passenger front air bag
is deactivated and will not be deployed.
If the 04 indicator lamp is not
illuminated, the front passenger front air bag
is activated and will be deployed
R in the event of certain frontal impacts
R if impact exceeds a preset deployment
threshold
R independently of the side impact air bags
If the front passenger front air bag is
deployed, the rate of inflation will be
influenced by
R the rate of relevant vehicle deceleration as
assessed by the air bag control unit
R the front passenger’s weight category as
identified by the OCS
For more information on air bag display
messages in the multifunction display, see
(Y page 230). G
Warning!
According to accident statistics, children are
safer when properly restrained in the rear
seating positions than in the front seating
position. Thus, we strongly recommend that
children

be placed in the rear seats whenever
possible. Regardless of seating position,
children 12 years old and under must be
seated and properly secured in an appropriate
infant restraint, toddler restraint, or booster
seat recommended for the size and weight of
the child. The infant or child restraint must be properly
secured with the vehicle’s seat belt, the seat
belt

and top tether strap, or lower anchors and
top tether strap, fully in accordance with the
child seat manufacturer’s instructions.
Occupants, especially children, should always
sit as upright as possible, wear the seat belt
properly and use an appropriately sized infant
restraint, toddler restraint, or booster seat
recommended for the size and weight of the
child.
Children can be killed or seriously injured by
an inflating air bag. Note the following
important information when circumstances
require you to place a child in the front
passenger seat:
R Your vehicle is equipped with air bag
technology designed to deactivate the front
passenger front air bag in your vehicle
when the system senses the weight of a
typical 12-month-old child or less along
with the weight of a standard appropriate
child restraint on the front passenger seat.
R A child in a rear-facing child restraint on the
front passenger seat will be seriously
injured or even killed if the front passenger
front air bag inflates in a collision which
could occur under some circumstances,
even with the air bag technology installed
in your vehicle. The only means to
completely eliminate this risk is to never
place a child in a rear-facing child restraint
in the front seat. We therefore strongly
recommend that you always place a child
in a rear-facing child restraint in a backseat.
R If you must install a rear-facing child
restraint on the front passenger seat
because circumstances require you to do
so, make sure the 04
indicator lamp is illuminated, indicating
that the front passenger front air bag is
deactivated. Should the 04
indicator lamp not illuminate or go out while
the restraint is installed, please check
installation. Periodically check the Occupant safety
43
Safety and security
219_AKB; 4; 54, en-US
d2ureepe, Version: 2.11.8.1 2009-05-11T16:21:02+02:00 - Seite 43 Z
ProCarManuals.com

or
- you attempt to clean an outside door
handle
R Remember that the engine can be started
by anyone with a SmartKey that is left
inside the vehicle.
Possibility 1 (One SmartKey in the vehicle,
one SmartKey outside the vehicle):
If you leave the SmartKey behind when
exiting and locking the vehicle, no message
appears in the multifunction display.
Possibility 2 (One SmartKey in the vehicle,
no SmartKey outside the vehicle):
When exiting and trying to lock the vehicle,
the message Key Detected In Vehicle
appears in the multifunction display. The
vehicle will not be locked.
Factory setting X
Global unlocking: Pull an outside door
handle.
Unless you open a door or the trunk within
approximately 40 seconds after unlocking
the vehicle:
R The vehicle will be locked again.
R The anti-theft alarm system will be
rearmed. X
Global locking: Press lock button : on an
outside door handle. Selective setting If you frequently travel alone, you may wish
to reprogram the SmartKey. Pulling the
driver’s outside door handle will then only
unlock the driver’s door and the fuel filler flap.
X
Switching on/off: Press and hold buttons
% and & simultaneously for
approximately 6 seconds until the battery
check lamp (Y page 69) flashes twice.
KEYLESS-GO will then function as follows:
X Unlocking driver’s door and fuel filler
flap: Pull the driver’s outside door handle.
X Global unlocking: Pull any outside door
handle other than the driver’s outside door
handle.
X Global locking: Press lock button : on an
outside door handle. Checking SmartKey batteries
Example illustration: SmartKey with KEYLESS-GO
X
Press button & or % on the
SmartKey.
Battery check lamp : comes on briefly to
indicate that the SmartKey batteries are in
order.
If the battery check lamp does not come on
briefly during check, the SmartKey batteries
are discharged.
X Replace the batteries ( Y page 264).
i You can obtain the required batteries at
any authorized Mercedes-Benz Center. Locking and unlocking
69Controls in detail
219_AKB; 4; 54, en-US
d2ureepe, Version: 2.11.8.1 2009-05-11T16:21:02+02:00 - Seite 69 Z
ProCarManuals.com

Starter switch positions
SmartKey
G
Observe Safety notes, see page 52. Starter switch
g
For removing SmartKey (gear selector
lever must be in park position P)
1 Power supply for some electrical
consumers, e.g. wipers
2 Ignition (power supply for all electrical
consumers) and driving position
3 Starting position
When you switch on the ignition, all lamps in
the instrument cluster come on. The low-
beam headlamp indicator lamp, high-beam
headlamp indicator lamp, and turn signal
indicator lamps will only come on if activated.
If a lamp in the instrument cluster fails to
come on when the ignition is switched on,
have it checked and replaced if necessary. If
a lamp in the instrument cluster remains on
after starting the engine or comes on while
driving, refer to “Lamps in instrument cluster”
(Y page 251).
If the SmartKey is left in starter switch
position 0 for an extended period of time, it
can no longer be turned in the starter switch.
In this case, the steering is locked. To unlock,
remove SmartKey from the starter switch and
reinsert.
The steering is locked when the SmartKey is
removed from the starter switch. X
Always remove the SmartKey from the
starter switch when the engine is not in
operation.
This will help to prevent accelerated vehicle
battery discharge or a completely
discharged vehicle battery.
If the SmartKey cannot be turned in the
starter switch, the vehicle battery may not be
sufficiently charged.
X Check the vehicle battery and charge it if
necessary ( Y page 279).
or
X Get a jump start (Y page 280). KEYLESS-GO
G
Observe Safety notes, see page 52.
Vehicles equipped with the KEYLESS-GO
feature are supplied with a SmartKey with
integrated KEYLESS-GO function.
The SmartKey must be present in the vehicle.
Pressing the KEYLESS-GO start/stop button
without depressing the brake pedal
corresponds to the various starter switch
positions (Y page 76).
Pressing the KEYLESS-GO start/stop button
with the brake pedal firmly depressed will
start the engine (Y page 97).
The function of the SmartKey overrules the
KEYLESS-GO function.
X Make sure the automatic transmission is in
park position P.
X Do not depress the brake pedal. 76
Starter switch positionsControls in detail
219_AKB; 4; 54, en-US
d2ureepe,
Version: 2.11.8.1 2009-05-11T16:21:02+02:00 - Seite 76
ProCarManuals.com
