2011 Lexus IS F ECO mode

380
4-3. Do-it-yourself maintenance
IS F_EE
Tire rotation
It is not possible to rotate the tires, as the front and rear tire sizes are differ-
ent.
Tire replacement
P. 3 8 5
Low profile tires
Generally, low profile tires will wear more rapidly and tire grip performance
will be reduced on snowy and/or icy roads when compared to standard tires.
Be sure to use snow tires or tire chains
* on snowy and/or icy roads and
drive carefully at a speed appropriate for road and weather conditions.
*: Tire chains cannot be mounted on 19-inch tires.
CAUTION
When inspecting or replacing tires
Observe the following precautions to prevent accidents.
Failure to do so may cause damage to parts of the drive train, as well as dan-
gerous handling characteristics, which may lead to an accident resulting in
death or serious injury.
Do not mix tires of different makes, models or tread patterns.
Also, do not mix tires of remarkably different treadwear.
Do not use tire sizes other than those recommended by Lexus.
Do not mix differently constructed tires (radial, bias-belted or bias-ply
tires).
Do not mix summer, all season and snow tires.
Do not use tires that have been used on another vehicle.
Do not use tires if you do not know how they were used previously.

442
5-2. Steps to take in an emergency
IS F_EE
Once(Comes on for 10 sec-
onds.)
(Flashing)
Indicates that
the key battery
is low.Replace the bat-
tery. (P. 390)

Indicates that
the “ENGINE
START STOP”
switch has been
turned twice to
ACCESSORY
mode without
starting the
engine when a
closed door is
opened.
Press the
“ENGINE
START STOP”
switch while
applying the
brakes.

(Flashing)
Indicates that
the steering lock
has not released
within 3 seconds
of pressing the
“ENGINE
START STOP”
switch.Press the
“ENGINE
START STOP”
switch again
while turning
the steering
wheel with the
brake pedal
depressed.
Inte-
rior
buzzerExte-
rior
buzzer
Warning messageDetailsCorrection
procedure

5
455
5-2. Steps to take in an emergency
When trouble arises
IS F_EE
Emergency start function
When the engine does not start, the following steps can be used as
an interim measure to start the engine if the “ENGINE START
STOP” switch is functioning normally:
Set the parking brake.
Put the shift lever in P.
Set the “ENGINE START STOP” switch to ACCESSORY
mode.
Press and hold the “ENGINE START STOP” switch for
about 15 seconds while depressing the brake pedal firmly.
Even if the engine can be started using the above steps, the system
may be malfunctioning. Have the vehicle checked by any autho-
rized Lexus dealer or repairer, or another duly qualified and
equipped professional.
STEP1
STEP2
STEP3
STEP4

5
461
5-2. Steps to take in an emergency
When trouble arises
IS F_EETo change “ENGINE START STOP” switch modes: Within
10 seconds of the buzzer sounding, release the brake pedal
and press the “ENGINE START STOP” switch. Modes can
be changed each time the switch is pressed. (P. 147)
To start the engine: Press the “ENGINE START STOP”
switch within 10 seconds after the buzzer sounds, keeping
the brake pedal depressed.
In the event that the engine still cannot be started, contact any
authorized Lexus dealer or repairer, or another duly qualified and
equipped professional.
Stopping the engine
Shift the shift lever to P and press the “ENGINE START STOP” switch as
you normally do when stopping the engine.
Replacing the key battery
As the above procedure is a temporary measure, it is recommended that the
electronic key battery be replaced immediately when the battery depletes.
(P. 390)
Alarm
Using the mechanical key to lock the doors will not set the alarm system.
If a door is unlocked using the mechanical key when the alarm system is set,
the alarm may be triggered.
STEP3

5
463
5-2. Steps to take in an emergency
When trouble arises
IS F_EE
Starting the engine when the battery is discharged
The engine cannot be started by push-starting.
To prevent battery discharge
Turn off the headlights and the audio system while the engine is off.
Turn off any unnecessary electrical components when the vehicle is run-
ning at a low speed for an extended period, such as in heavy traffic, etc.
Charging the battery
The electricity stored in the battery will discharge gradually even when
the vehicle is not in use, due to natural discharge and the draining effects
of certain electrical appliances. If the vehicle is left for a long time, the
battery may discharge, and the engine may be unable to start. (The bat-
tery recharges automatically during driving.)
Start the engine of the second vehicle. Increase the
engine speed slightly and maintain at that level for
approximately 5 minutes to recharge the battery of your
vehicle.
Open and close any of the doors with the “ENGINE
START STOP” switch OFF.
Maintain the engine speed of the second vehicle and turn
the “ENGINE START STOP” switch to IGNITION ON
mode, then start the vehicle's engine.
Once the vehicle’s engine has started, remove the jumper
cables in the exact reverse order in which they were con-
nected.
Once the engine starts, have the vehicle checked at any autho-
rized Lexus dealer or repairer, or another duly qualified and
id fil iblSTEP2
STEP3
STEP4
STEP5

494
Alphabetical index
IS F_EE
Electric power steering ..............206
Electronic key
If the electronic key does not
operate properly .................458
Emergency, in case of
If a warning message is
displayed ............................431
If the engine will not start.....454
If the shift lever cannot be
shifted from P .....................456
If the vehicle has a discharged
battery.................................462
If the warning buzzer sounds425
If the warning light turns on .425
If you have a flat tire ...........444
If you lose your keys ............457
If you think something is
wrong .................................423
If your electronic key does not
operate properly .................458
If your vehicle becomes stuck ....
468
If your vehicle has to be
stopped in an emergency ....469
If your vehicle needs to be
towed ..................................417
If your vehicle overheats ......465
Emergency flashers
Switch ...................................416Engine
ACCESSORY mode ............ 146
Compartment ....................... 366
Engine switch ...................... 146
Hood .................................... 363
How to start the engine ........ 146
Identification number .......... 473
If the engine will not start .... 454
Ignition switch ..................... 146
Overheating ......................... 465
Engine compartment cover....... 367
Engine coolant
Capacity ............................... 477
Checking .............................. 372
Preparing and checking before
winter................................. 222
Engine coolant temperature
gauge ...................................... 161
Engine immobilizer system ........ 92
Engine oil
Capacity ............................... 475
Checking .............................. 369
Preparing and checking before
winter................................. 222
EPS ........................................... 206E

499
Alphabetical index
IS F_EE
Service reminder indicators ......164
Shift lever
If the shift lever cannot
be shifted from P ................456
Transmission ........................150
Shift lever light..........................320
Shift lock system .......................456
Shopping bag hooks ..................347
Side airbags ...............................105
Side mirrors
Adjusting and folding .............81
Mirror position memory .........62
Side turn signal lights
Wattage .................................481
Smart entry & start system
Entry function .........................36
Starting the engine ................146
Spare tire
Inflation pressure ..................480
Storage location ....................444
Spark plug .................................478
Specifications ............................472
Speedometer ..............................161Steering wheel
Adjustment............................. 76
Audio switches .................... 278
Steering wheel position
memory ............................... 62
Storage feature.......................... 324
Stuck
If your vehicle becomes stuck ...
468
Sun visors ................................. 330
Sunshade..................................... 86
Switch
Airbag manual ON/OFF ...... 135
Emergency flasher switch.... 416
Engine switch ...................... 146
Fog light switch ................... 175
F-sport mode total control
switch ........................ 153, 209
Hazard light switch .............. 416
Ignition switch ..................... 146
Light switches ...................... 172
Power door lock switch ......... 54
Power window switch............ 82
Satellite switches ................. 333
SNOW switch ...................... 152
Transmission shift
switches ..................... 153, 155
Window lock switch.............. 82
Wiper and washer switch..... 176
