1-8. Safety information
Before driving
CT200h_EE (OM76041E)
Installing child restraints
Follow the child restraint system manufacturer’s instructions. Firmly
secure child restraints to the seats using a seat belt or ISOFIX rigid
anchors. Attach the top strap when installing a child restraint.
Seat belts (An ELR belt
requires a locking clip.)
ISOFIX rigid anchors (ISO-
FIX child restraint system)
Lower anchors are provided
for the outer rear seats. (But-
tons displaying the location
of the anchors are attached to
the seats.)
Anchor brackets (for top
strap)
An anchor bracket is pro-
vided for outside rear seat.

2When driving
183
CT200h_EE (OM76041E)
2-1. Driving procedures
Driving the vehicle........... 184
Power (ignition) switch .... 196
EV drive mode ................. 201
Hybrid transmission ......... 204
Turn signal lever .............. 213
Parking brake ................... 214
Horn ................................. 215
2-2. Instrument cluster
Gauges and meters ........... 216
Indicators and warning
lights .............................. 222
Multi-information display 226
2-3. Operating the lights and wind-
shield wipers
Headlight switch.............. 232
Fog light switch ............... 237
Windshield wipers and
washer ............................ 239
Rear window wiper and
washer ............................ 245
Headlight cleaner switch .. 2472-4. Using other driving systems
Cruise control .................. 248
Dynamic radar cruise
control ............................ 252
Lexus parking
assist-sensor ................... 269
Rear view monitor system 275
Driving assist systems ..... 285
Hill-start assist control ..... 290
PCS (Pre-Crash Safety
system)........................... 292
2-5. Driving information
Cargo and luggage ........... 301
Winter driving tips ........... 304
Trailer towing .................. 308

189
2-1. Driving procedures
2
When driving
CT200h_EE (OM76041E)
CAUTION
When driving on slippery road surfaces
Sudden braking, acceleration and steering may cause tire slippage and
reduce your ability to control the vehicle, resulting in an accident.
Abrupt changes from shift position D to B and rapid changes in the engine
speed could cause the vehicle to skid, resulting in an accident.
After driving through a puddle, lightly depress the brake pedal to make
sure that the brakes are functioning properly. Wet brake pads may prevent
the brakes from functioning properly. If the brakes on only one side are
wet and not functioning properly, steering control may be affected, result-
ing in an accident.
When changing the shift position
Be careful not to change the shift position with the accelerator pedal
depressed.
Changing the shift position to any positions other than P or N may cause the
vehicle to accelerate abruptly, causing an accident and resulting in death or
serious injury.
After changing the shift position, make sure to confirm the current shift
position displayed on the shift position indicator inside the meter.
If you hear a squealing or scraping noise (brake pad wear indicators)
Have any authorized Lexus dealer or repairer, or another duly qualified and
equipped professional check and replace the brake pads as soon as possible.
Rotor damage may result if the pads are not replaced when needed.
It is dangerous to drive the vehicle when the wear limits of the brake pads
and/or those of the brake discs are exceeded.

197
2-1. Driving procedures
2
When driving
CT200h_EE (OM76041E)
Stopping the hybrid system
Stop the vehicle completely.
Set the parking brake. (P. 214)
Shift the shift position to P. (P. 2 0 7 )
Check that the shift position indicator shows P. (P. 204)
Press the “POWER” switch.
The hybrid system will stop, and the meter display will be
extinguished (the shift position indicator will be extinguished
a few seconds after the meter display).
Slowly release the brake pedal and check that the indica-
tor on the “POWER” switch is off.
Changing “POWER” switch modes
Modes can be changed by pressing the “POWER” switch with
the brake pedal released. (The mode changes each time the
switch is pressed.)
Off
The emergency flashers can
be used.
ACCESSORY mode
Some electrical components
such as the audio system can
be used.
The “POWER” switch indi-
cator turns amber.
ON mode
All electrical components can
be used.
The “POWER” switch indi-
cator turns amber.
STEP1
STEP2
STEP3
STEP4
STEP5

202
2-1. Driving procedures
CT200h_EE (OM76041E)
Situations in which EV drive mode cannot be turned on
It may not be possible to turn EV drive mode on in the following situations.
If it cannot be turned on, a buzzer will sound and a message will be shown
on the multi-information display.
The temperature of the hybrid system is high.
The vehicle has been left in the sun, driven on a hill, driven at high
speeds, etc.
The temperature of the hybrid system is low.
The vehicle has been left in temperatures lower than about 0 C (32 F)
for a long period of time etc.
The gasoline engine is warming up.
The hybrid battery (traction battery) is low.
An “Energy monitor” display of level 3 or lower may indicate a low bat-
tery level. (P. 4 5 )
Vehicle speed is high.
The accelerator pedal is depressed firmly or the vehicle is on a hill etc.
The windshield defogger is in use.
Switching to EV drive mode when the gasoline engine is cold
If the hybrid system is started while the gasoline engine is cold, the gasoline
engine will start automatically after a short period of time in order to warm
up. In this case, you will become unable to switch to EV drive mode.
After the hybrid system has started and the “READY” indicator has illumi-
nated, press the EV drive mode switch before the gasoline engine starts to
switch to EV drive mode.

203
2-1. Driving procedures
2
When driving
CT200h_EE (OM76041E)
Automatic cancellation of EV drive mode
When driving in EV drive mode, the gasoline engine may automatically
restart in the following situations. When EV drive mode is canceled, a
buzzer will sound and the EV drive mode indicator will flash and go off.
The hybrid battery (traction battery) becomes low.
The remaining battery level indicated in the “Energy monitor” display is
level 2 or lower. (P. 4 5 )
Vehicle speed becomes high.
The accelerator pedal is depressed firmly or the vehicle is on a hill etc.
When it is possible to inform the driver of automatic cancelation in advance,
a prior notice screen will appear on the multi-information display.
 Possible driving distance when driving in EV drive mode
In EV drive mode, it is possible to drive up to about 1 km (1/2 mile) if driv-
ing at a speed of about 45 km/h (28 mph) or less. (The distance that is possi-
ble depends on the hybrid battery [traction battery] level and driving
conditions.)
Fuel economy
CT200h is designed to achieve the best possible fuel economy during nor-
mal driving (using the gasoline engine and electric motor [traction motor]).
Driving in EV drive mode more than necessary may lower fuel economy.
CAUTION
While driving
When driving in EV drive mode, pay special attention to the area around the
vehicle. Because there is no engine noise, pedestrians, people riding bicy-
cles or other people and vehicles in the area may not be aware of the vehicle
starting off or approaching them, so take extra care while driving.

212
2-1. Driving procedures
CT200h_EE (OM76041E)
NOTICE
Hybrid battery (traction battery) charge
If the shift position is in N, the hybrid battery (traction battery) will not be
charged. To help prevent the battery from discharging, avoid leaving the N
position selected for an extended period of time.
Situations where P position control system malfunctions are possible
If any of the following situations occurs, P position control system malfunc-
tions are possible.
Immediately stop the vehicle in a safe place on level ground, apply the park-
ing brake, and then contact any authorized Lexus dealer or repairer, or
another duly qualified and equipped professional.
When the “P LOCK MALFUNCTION” appears on the multi-information
display. (P. 567)
When the shift position indicator remains off.
Notes regarding shift lever and P position switch operation
Avoid repeatedly operating the shift lever and P position switch in quick
succession.
The system protection function may activate and it will not be temporarily
possible to shift the shift position other than P. If this happens, please wait
for a while before attempting to change the shift position again.

216
CT200h_EE (OM76041E)
2-2. Instrument cluster
Gauges and meters
The following gauges and meters and display illuminate when the
“POWER” switch is in ON mode:
Hybrid System Indicator
Displays hybrid system output or regeneration level
Tachometer (if equipped)
Displays the engine speed in revolutions per minute
Speedometer
Displays the vehicle speed
ECO lamp and SPORT lamp (if equipped)
Changes colors according to driving mode
Fuel gauge
Displays the quantity of fuel remaining in the tank
Multi-information display
P. 226
Outside temperature
The temperature range that can be displayed is from -40 C (-40 F)
to 50 C (122 F)
