5-2. Steps to take in an emergency
When trouble arises
CT200h_EE (OM76041E)
CAUTION
If the hybrid system has to be turned off while driving
Power assist for the brakes and steering wheel will be lost, making the brake
pedal harder to depress and the steering wheel heavier to turn. Decelerate as
much as possible before turning off the hybrid system.

648
6-1. Specifications
CT200h_EE (OM76041E)
Brakes
*1:Minimum pedal clearance when depressed with a force of 196 N
(20.0 kgf, 44.1 lbf) while the hybrid system is operating.
*2:Parking brake pedal travel when depressed with a force of 300 N (30.6
kgf, 67.5 lbf).
Steering
Pedal
clear-
ance
*1
Left-hand
drive vehicles
With an aluminum pedal
79 mm (3.11 in.) Min.
Without an aluminum pedal
77 mm (3.03 in.) Min.
Right-hand
drive vehicles
With an aluminum pedal
82 mm (3.23 in.) Min.
Without an aluminum pedal
80 mm (3.15 in.) Min.
Pedal free play1.0  6.0 mm (0.04  0.24 in.)
Parking brake pedal travel*28 11 clicks
Fluid typeSAE J1703 or FMVSS No. 116 DOT 3
Free playLess than 30 mm (1.2 in.)

651
6-1. Specifications
6
Vehicle specifica-
CT200h_EE (OM76041E)
NOTICE
ECO pressure
For optimizing fuel economy, ECO tire pressure is recommended. Tire pres-
sure affects traveling comfort, road noise and steering characteristics.

678
CT200h_EE (OM76041E)
Abbreviation list
Abbreviation/Acronym list
ABBREVIA-
TIONSMEANING
A/CAir Conditioning
ABSAnti-lock Brake System
ASLAutomatic Sound Levelizer
CRSChild Restraint System
DABDigital Audio Broadcast
DISPDisplay
ECOEconomy/Ecology
ECUElectronic Control Unit
EFIElectronic Fuel Injection
ELREmergency Locking Retractor
EONEnhanced Other Network
EPSElectric Power Steering
EVElectric Vehicle
LEDLight Emitting Diode
OBDOn Board Diagnostics
PCSPre-Crash Safety system
PWRPower
RDSRadio Data System
SRSSupplemental Restraint System

680
