2011 INFINITI QX56 relay

DAS-86
< SYSTEM DESCRIPTION >[DCA]
DIAGNOSIS SYSTEM (ADAS CONTROL UNIT)
STOP LAMP
ICC BUZZER
BRAKE ACTUATOR
NOTE:
The test can be performed only when the engine is running.
NOTE:
The test is finished in 10 seconds after starting
Te s t i t e mOper-
ation Description  MAIN switch indicator
 ICC system warning lamp
 IBA OFF indicator lamp
METER LAMP Off
Stops sending the following signals to exit from the test
 Meter display signal
 ICC warning lamp signal
 IBA OFF indicator lamp signal OFF
On Transmits the following signals to the combination meter via
CAN communication
 Meter display signal
 ICC warning lamp signal
 IBA OFF indicator lamp signal
ON
Te s t i t e m
Oper-
ation Description Stop lamp
STOP LAMP Off
Stops transmitting the ICC brake hold relay drive signal be-
low to end the test OFF
On Transmits the ICC brake hold relay drive signal ON
Test item Operation Description ICC warning chime operation
sound
ICC BUZZER MODE1
Transmits the buzzer output signals to the combination
meter via CAN communication Intermittent beep sound
Test start Starts the tests of “MODE1” — Reset Stops transmitting the buzzer output signal below to end
the test —
End Returns to the “SELECT TEST ITEM” screen —
Test item Operation Description “PRESS SENS” value
BRAKE ACTUATOR MODE1
Transmits the brake fluid pressure control signal to the
ABS actuator and electric unit (control unit) via CAN
communication 10 bar
MODE2 20 bar
MODE3 30 bar
Test start Starts the tests of “MODE1”, “MODE2” and “MODE3” —
Reset Stops transmitting the brake fluid pressure control signal
below to end the test —
End Returns to the “SELECT TEST ITEM” screen —
PKIB1767J
Revision: 2010 May2011 QX56

DAS-94
< ECU DIAGNOSIS INFORMATION >[DCA]
ADAS CONTROL UNIT
VHCL SPEED SE While driving Displays the ve-
hicle speed cal-
culated by
ADAS control unit
SET VHCL SPD While driving When vehicle speed is set Displays the set
vehicle speed
BUZZER O/P Engine running When the buzzer of the following system operates
 Vehicle-to-vehicle distance control mode
 DCA system
 FCW system
 IBA system
On
When the buzzer of the following system not operates
 Vehicle-to-vehicle distance control mode
 DCA system
 FCW system
 IBA system Off
THRTL SENSOR NOTE:
The item is indicated, but not monitored
0.0
ENGINE RPM Engine running Equivalent to ta-
chometer read- ing
WIPER SW Ignition switch ON Wiper not operating Off
Wiper LO operation Low
Wiper HI operation High
YAW R AT E NOTE:
The item is indicated, but not monitored
0.0
BA WARNING Engine running IBA OFF indicator lamp ON
 When IBA system is malfunctioning
 When IBA system is turned to OFF
On
IBA OFF indicator lamp OFF
 When IBA system is normal
 When IBA system is turned to ON Off
STP LMP DRIVE Drive the vehicle and activate
the vehicle-to-vehicle distance
control mode When ICC brake hold relay is activated On
When ICC brake hold relay is not activated Off
D RANGE SW Engine running When the selector lever is in “D” position or manual
mode
On
When the selector lever is in any position other than “D”
or manual mode Off
NP RANGE SW Engine running When the selector lever is
in “N”, “P” position On
When the selector lever is in any position other than “N”,
“P” Off
PKB SW Ignition switch ON When the parking brake is applied On
When the parking brake is released Off
PWR SUP MONI Engine running Power supply
voltage value of ADAS control unit
VHCL SPD AT While driving Va l u e o f A / T v e -
hicle speed sen- sor signal
THRTL OPENING Engine running Depress accelerator pedal Displays the
throttle position
Monitor item Condition Value/Status
Revision: 2010 May2011 QX56

DAS-98
< ECU DIAGNOSIS INFORMATION >[DCA]
ADAS CONTROL UNIT
Fail-safe
INFOID:0000000006223511
If a malfunction occurs in each system, ADAS contro l unit cancels each control, sounds a beep, and turns ON
the warning lamp or indicator lamp.
Te r m i n a l N o .
(Wire color) Description
Condition Va l u e
(Approx.)
+ − Signal name Input/
Output
1
(V/W)
Ground Warning systems
switch
InputIgnition
switch ON When warning systems
switch is not pressed
12 V
When warning systems
switch is pressed 0 V
3
(R/Y) IBA OFF switch Input Ignition
switch
ON When IBA OFF switch is
not pressed
12 V
When IBA OFF switch is
pressed 0 V
4
(LG/B) Warning systems ON
indicator
OutputIgnition
switch ON Warning systems ON indi-
cator ON
0 V
Warning systems ON indi-
cator OFF 12 V
5
(R) ICC brake hold relay
drive signal
OutputIgnition
switch ON —12 V
At “STOP LAMP” test of
“Active test” 0 V
6
(B) Ground — Ignition
switch ON —0 V
7
(L) ITS communication-H — — — —
8
(Y) ITS communication-L — — — —
12
(G/R) Warning buzzer signal Output Ignition
switch ON Warning buzzer operation 0 V
Warning buzzer not oper-
ating
12 V
14
(L) CAN -H — — — —
15
(P) CAN -L — — — —
16
(W/G) Ignition power supply Input Ignition switch ON Battery Voltage
System Buzzer Warning lamp/Indicator lamp Description
Vehicle-to-vehicle distance control mode High-pitched
toneICC system warn
ing lamp Cancel
Conventional (fixed speed) cruise control mode High-pitched
tone
ICC system warn
ing lamp Cancel
Intelligent Brake Assist (IBA) High-pitched
toneIBA OFF indicator lamp Cancel
Forward Collision Warning (FCW) High-pitched
toneIBA OFF indicator lamp Cancel
Distance Control Assist (DCA) High-pitched
tone
ICC system warn
ing lamp Cancel
Lane Departure Warning (LDW) — Lane departure warning lamp Cancel
Revision: 2010 May2011 QX56

DAS
C1A13 STOP LAMP RELAYDAS-141
< DTC/CIRCUIT DIAGNOSIS > [DCA]
C
D
E
F
G H
I
J
K L
M B
N P A
C1A13 STOP LAMP RELAY
DTC LogicINFOID:0000000006228076
DTC DETECTION LOGIC
NOTE:
If DTC “C1A13” is detected along with DTC “U1000”, first diagnose the DTC “U1000”. Refer to DAS-182,
"ADAS CONTROL UNIT : DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE (1)
1. Start the engine.
2. Perform the active test item “STOP LAMP” with CONSULT-III.
3. Perform “All DTC Reading”.
4. Check if the “C1A13” is detected as the current malfunction in the “Self Diagnostic Result” of “ICC/ADAS”.
Is
“C1A13” detected as the current malfunction?
YES >> Refer to DAS-141, "Diagnosis Procedure".
NO >> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE (2)
1. Drive at the vehicle speed of 40 km/h (25 MPH) or more for approximately 60 seconds or more without the
brake pedal depressed.
CAUTION:
Always drive safely.
NOTE:
If it is outside the above condition, repeat step 1.
2. Perform “All DTC Reading”.
3. Check if the “C1A13” is detected as the current malfunction in the “Self Diagnostic Result” of “ICC/ADAS”.
Is
“C1A13” detected as the current malfunction?
YES >> Refer to DAS-141, "Diagnosis Procedure".
NO >> Refer to GI-40, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000006228077
1.CHECK SELF-DIAGNOSIS RESULTS
Check if “U1000” is detected other than “C1A13” in “Self Diagnostic Result” of “ICC/ADAS”.
Is
“U1000” detected?
YES >> Perform the CAN communicati on system inspection. Repair or replace the malfunctioning parts.
Refer to DAS-182, "
ADAS CONTROL UNIT : DTC Logic".
NO >> GO TO 2.
2.CHECK STOP LAMP SWITCH
Check that “STOP LAMP SW” operate normally in “DATA MONITOR” of “ICC/ADAS”.
DTC
(On board dis-
play) Trouble diagnosis name DTC detecting condition Possible causes
C1A13 (13) STOP LAMP RLY FIX  Stop lamp inactive state continues for 0.3
seconds or more despite the outputting of
an ICC sensor ICC brake hold relay drive
signal
 The stop lamp remains ON for 60 seconds or more under the following conditions:
- Driving at 40 km/h or more
- No stop lamp drive signal output from ICC
sensor
- No brake operation  Stop lamp switch circuit
 ICC brake switch circuit
 ICC brake hold relay circuit
 Stop lamp switch
 ICC brake switch
 ICC brake hold relay
 Incorrect stop lamp switch installation
 Incorrect ICC brake switch installation
ECM
 ABS actuator and elec
tric unit (control
unit)
Revision: 2010 May2011 QX56

DAS-142
< DTC/CIRCUIT DIAGNOSIS >[DCA]
C1A13 STOP LAMP RELAY
Is the inspection result normal?
YES >> GO TO 10.
NO >> GO TO 3.
3.CHECK STOP LAMP SWITCH INSTALLATION
1. Turn ignition switch OFF.
2. Check stop lamp switch for correct installation. Refer to BR-7, "
Inspection and Adjustment".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Adjust stop lamp switch installation. Refer to BR-7, "
Inspection and Adjustment".
4.CHECK STOP LAMP SWITCH
1. Disconnect stop lamp switch connector.
2. Check stop lamp switch. Refer to DAS-137, "
Component Inspection (Stop Lamp Switch)".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Replace stop lamp switch.
5.CHECK STOP LAMP FOR ILLUMINATION
1. Turn the ignition switch OFF.
2. Check that the stop lamp is illuminated by depressing the brake pedal to turn the stop lamp ON.
3. Remove ICC brake hold relay.
Is the inspection result normal?
YES >> GO TO6.
NO >> Check the stop lamp circuit, and repair or replace the malfunctioning parts.
6.CHECK HARNESS BETWEEN STOP LAMP SWITCH AND ECM
1. Turn the ignition switch OFF.
2. Disconnect stop lamp switch, ECM, rear combination lamp, and high-mounted stop lamp connectors.
3. Check for continuity between the stop lamp s witch harness connector and the ECM harness connector.
4. Check for continuity between stop la mp switch harness connector and ground.
Is the inspection result normal?
YES >> GO TO 7.
NO >> Repair the harnesses or connectors.
7.CHECK ICC BRAKE HOLD RELAY CIRCUIT
1. Connect ICC brake hold relay.
2. Disconnect the stop lamp switch connector.
3. Check that the stop lamp does not illuminate when brake pedal is not depressed.
Is the inspection result normal?
YES >> GO TO 9.
NO >> GO TO 8.
8.CHECK ICC BRAKE HOLD RELAY
1. Remove ICC brake hold relay
2. Check ICC hold relay. Refer to DAS-146, "
Component Inspection".
Is the inspection result normal?
Stop lamp switch ECM Continuity
Connector Terminal Connector Terminal
E115 2 E80 158 Existed
Stop lamp switch GroundContinuity
Connector Terminal
E115 2 Not existed
Revision: 2010 May2011 QX56

DAS
C1A13 STOP LAMP RELAYDAS-143
< DTC/CIRCUIT DIAGNOSIS > [DCA]
C
D
E
F
G H
I
J
K L
M B
N P A
YES >> GO TO 9.
NO >> Replace ICC brake hold relay.
9.PERFORM SELF-DIAGNOSIS OF ECM
1. Connect all connectors again if the connectors are disconnected.
2. Turn ignition switch ON.
3. Perform “All DTC Reading”.
4. Check if any DTC is detected in “Self Diagnostic Result” of “ENGINE”. Refer to EC-98, "
DTC Index".
Is any DTC detected?
YES >> Repair or replace the malfunctioning part s identified by the self-diagnosis result.
NO >> Replace ADAS control unit. Refer to DAS-63, "
Removal and Installation".
10.CHECK ICC BRAKE HOLD RELAY POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Remove ICC brake hold relay.
3. Check the voltage between ICC brake hold relay harness connector and ground.
Is the inspection result normal?
YES >> GO TO 11.
NO >> Repair or replace ICC brake hold relay power supply circuit.
11 .CHECK HARNESS BETWEEN AND ICC BRAKE HOLD RELAY AND ADAS CONTROL UNIT
1. Disconnect ADAS control unit connectors.
2. Check for continuity between ICC brake hold re lay harness connector and ADAS control unit harness
connector.
3. Check for continuity between ADAS control unit harness connector and ground.
Is the inspection result normal?
YES >> GO TO 12.
NO >> Repair the harnesses or connectors.
12.CHECK ADAS CONTROL UNIT STANDARD VOLTAGE
1. Connect all connectors again if the connectors are disconnected.
2. Turn ignition switch ON.
3. Perform “STOP LAMP” on “Active Test” of “ICC/ ADAS”, and then check the voltage between ADAS con-
trol unit harness connector and ground.
Te r m i n a l
Voltag e
(Approx.)
(+) (–)
ICC brake hold relay
Ground
Connector Terminal
E64 1 Battery
voltage
ICC brake hold relay ADAS control unit Continuity
Connector Terminal Connector Terminal
E64 2 B61 5 Existed
ICC brake hold relay GroundContinuity
Connector Terminal
E64 2 Not existed
Revision: 2010 May2011 QX56

DAS-144
< DTC/CIRCUIT DIAGNOSIS >[DCA]
C1A13 STOP LAMP RELAY
Is the inspection result normal?
YES >> GO TO 13.
NO >> Replace ADAS control unit. Refer to
DAS-63, "
Removal and Installation".
13.CHECK ICC BRAKE HOLD RELAY POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Check the voltage between ICC brake hold relay harness connector and ground.
Is the inspection result normal?
YES >> GO TO 14.
NO >> Repair or replace ICC brake hold relay power supply circuit.
14.CHECK HARNESS BETWEEN ICC BR AKE HOLD RELAY AND ECM
1. Disconnect ECM, rear combination lamp, and high- mounted stop lamp connectors and remove ICC brake
hold relay.
2. Check for continuity between ICC brake hold relay harness connector and ECM harness connector.
3. Check for continuity between ICC brake hold relay harness connector and ground.
Is the inspection result normal?
YES >> GO TO 15.
NO >> Repair the harnesses or connectors.
15.CHECK ICC BRAKE HOLD RELAY
1. Remove ICC brake hold relay.
2. Check ICC brake hold relay. Refer to DAS-146, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 16.
NO >> Replace ICC brake hold relay.
16.CHECK STOP LAMP SWITCH
Check that “STOP LAMP SW” operate norma lly in “DATA MONITOR” of “ABS”.
Te r m i n a l
Condition
Vo l ta g e
(Approx.)
(+) (–)
ADAS control unit
GroundActive Test
item
“STOP LAMP”
Connector Terminal
B61 5 Off
Battery
voltage
On 0 V
Te r m i n a l
Vo l ta g e
(Approx.)
(+) (–)
ICC brake hold relay
Ground
Connector Terminal
E64 3 Battery
voltage
ICC brake hold relay ECM Continuity
Connector Terminal Connector Terminal
E64 5 E80 158 Existed
ICC brake hold relay GroundContinuity
Connector Terminal
E64 5 Not existed
Revision: 2010 May2011 QX56

DAS
C1A13 STOP LAMP RELAYDAS-145
< DTC/CIRCUIT DIAGNOSIS > [DCA]
C
D
E
F
G H
I
J
K L
M B
N P A
Is the inspection result normal?
YES >> GO TO 21.
NO >> GO TO 17.
17.CHECK STOP LAMP SWITCH INSTALLATION
1. Turn ignition switch OFF.
2. Check stop lamp switch for correct installation. Refer to BR-7, "
Inspection and Adjustment".
Is the inspection result normal?
YES >> GO TO 18.
NO >> Adjust stop lamp switch installation. Refer to BR-7, "
Inspection and Adjustment".
18.CHECK STOP LAMP SWITCH
1. Disconnect stop lamp switch connector.
2. Check stop lamp switch. Refer to DAS-137, "
Component Inspection (Stop Lamp Switch)".
Is the inspection result normal?
YES >> GO TO 19.
NO >> Replace stop lamp switch.
19.CHECK STOP LAMP SWITCH POWER SUPPLY CIRCUIT
1. Connect stop lamp switch connector.
2. Check the voltage between stop lamp switch harness connector and ground.
Is the inspection result normal?
YES >> GO TO 20.
NO >> Repair or replace stop lamp switch power supply circuit.
20.CHECK HARNESS BETWEEN STOP LAMP SWITCH AND ABS ACTUATOR AND ELECTRIC UNIT
(CONTROL UNIT)
1. Turn the ignition switch OFF.
2. Disconnect stop lamp switch, ABS actuator and electric unit (control unit) connectors.
3. Check for continuity between the stop lamp swit ch harness connector and the ABS actuator and electric
unit (control unit) harness connector.
4. Check for continuity between stop lamp switch harness connector and ground.
Is the inspection result normal?
YES >> GO TO 21.
NO >> Repair the harnesses or connectors.
21.PERFORM SELF-DIAGNOSIS OF ECM
1. Connect all connectors again if the connectors are disconnected.
Te r m i n a l
Voltag e
(Approx.)
(+) (–)
Stop lamp switch
Ground
Connector Terminal
E115 3 Battery
voltage
Stop lamp switch ABS actuator and electric
unit (control unit) Continuity
Connector Terminal Connector Terminal
E115 4 E36 17 Existed
Stop lamp switch GroundContinuity
Connector Terminal
E115 4 Not existed
Revision: 2010 May2011 QX56
