DAS-28
< SYSTEM DESCRIPTION >[ADAS CONTROL UNIT]
DIAGNOSIS SYSTEM (ADAS CONTROL UNIT)
STOP LAMP
ICC BUZZER
BRAKE ACTUATOR
NOTE:
The test can be performed only when the engine is running.
NOTE:
The test is finished in 10 seconds after starting
Te s t i t e mOper-
ation Description  MAIN switch indicator
 ICC system warning lamp
 IBA OFF indicator lamp
METER LAMP Off
Stops sending the following signals to exit from the test
 Meter display signal
 ICC warning lamp signal
 IBA OFF indicator lamp signal OFF
On Transmits the following signals to the combination meter via
CAN communication
 Meter display signal
 ICC warning lamp signal
 IBA OFF indicator lamp signal
ON
Te s t i t e m
Oper-
ation Description Stop lamp
STOP LAMP Off
Stops transmitting the ICC brake hold relay drive signal be-
low to end the test OFF
On Transmits the ICC brake hold relay drive signal ON
Test item Operation Description ICC warning chime operation
sound
ICC BUZZER MODE1
Transmits the buzzer output signals to the combination
meter via CAN communication Intermittent beep sound
Test start Starts the tests of “MODE1” — Reset Stops transmitting the buzzer output signal below to end
the test —
End Returns to the “SELECT TEST ITEM” screen —
Test item Operation Description “PRESS SENS” value
BRAKE ACTUATOR MODE1
Transmits the brake fluid pressure control signal to the
ABS actuator and electric unit (control unit) via CAN
communication 10 bar
MODE2 20 bar
MODE3 30 bar
Test start Starts the tests of “MODE1”, “MODE2” and “MODE3” —
Reset Stops transmitting the brake fluid pressure control signal
below to end the test —
End Returns to the “SELECT TEST ITEM” screen —
PKIB1767J
Revision: 2010 May2011 QX56

DAS-32
< ECU DIAGNOSIS INFORMATION >[ADAS CONTROL UNIT]
ADAS CONTROL UNIT
VHCL SPEED SE While driving Displays the ve-
hicle speed cal-
culated by
ADAS control unit
SET VHCL SPD While driving When vehicle speed is set Displays the set
vehicle speed
BUZZER O/P Engine running When the buzzer of the following system operates
 Vehicle-to-vehicle distance control mode
 DCA system
 FCW system
 IBA system
On
When the buzzer of the following system not operates
 Vehicle-to-vehicle distance control mode
 DCA system
 FCW system
 IBA system Off
THRTL SENSOR NOTE:
The item is indicated, but not monitored
0.0
ENGINE RPM Engine running Equivalent to ta-
chometer read- ing
WIPER SW Ignition switch ON Wiper not operating Off
Wiper LO operation Low
Wiper HI operation High
YAW R AT E NOTE:
The item is indicated, but not monitored
0.0
BA WARNING Engine running IBA OFF indicator lamp ON
 When IBA system is malfunctioning
 When IBA system is turned to OFF
On
IBA OFF indicator lamp OFF
 When IBA system is normal
 When IBA system is turned to ON Off
STP LMP DRIVE Drive the vehicle and activate
the vehicle-to-vehicle distance
control mode When ICC brake hold relay is activated On
When ICC brake hold relay is not activated Off
D RANGE SW Engine running When the selector lever is in “D” position or manual
mode
On
When the selector lever is in any position other than “D”
or manual mode Off
NP RANGE SW Engine running When the selector lever is
in “N”, “P” position On
When the selector lever is in any position other than “N”,
“P” Off
PKB SW Ignition switch ON When the parking brake is applied On
When the parking brake is released Off
PWR SUP MONI Engine running Power supply
voltage value of ADAS control unit
VHCL SPD AT While driving Va l u e o f A / T v e -
hicle speed sen- sor signal
THRTL OPENING Engine running Depress accelerator pedal Displays the
throttle position
Monitor item Condition Value/Status
Revision: 2010 May2011 QX56

DAS-36
< ECU DIAGNOSIS INFORMATION >[ADAS CONTROL UNIT]
ADAS CONTROL UNIT
Fail-safe
INFOID:0000000006223477
If a malfunction occurs in each system, ADAS contro l unit cancels each control, sounds a beep, and turns ON
the warning lamp or indicator lamp.
Te r m i n a l N o .
(Wire color) Description
Condition Va l u e
(Approx.)
+ − Signal name Input/
Output
1
(V/W)
Ground Warning systems
switch
InputIgnition
switch ON When warning systems
switch is not pressed
12 V
When warning systems
switch is pressed 0 V
3
(R/Y) IBA OFF switch Input Ignition
switch
ON When IBA OFF switch is
not pressed
12 V
When IBA OFF switch is
pressed 0 V
4
(LG/B) Warning systems ON
indicator
OutputIgnition
switch ON Warning systems ON indi-
cator ON
0 V
Warning systems ON indi-
cator OFF 12 V
5
(R) ICC brake hold relay
drive signal
OutputIgnition
switch ON —12 V
At “STOP LAMP” test of
“Active test” 0 V
6
(B) Ground — Ignition
switch ON —0 V
7
(L) ITS communication-H — — — —
8
(Y) ITS communication-L — — — —
12
(G/R) Warning buzzer signal Output Ignition
switch ON Warning buzzer operation 0 V
Warning buzzer not oper-
ating
12 V
14
(L) CAN -H — — — —
15
(P) CAN -L — — — —
16
(W/G) Ignition power supply Input Ignition switch ON Battery Voltage
System Buzzer Warning lamp/Indicator lamp Description
Vehicle-to-vehicle distance control mode High-pitched
toneICC system warn
ing lamp Cancel
Conventional (fixed speed) cruise control mode High-pitched
tone
ICC system warn
ing lamp Cancel
Intelligent Brake Assist (IBA) High-pitched
toneIBA OFF indicator lamp Cancel
Forward Collision Warning (FCW) High-pitched
toneIBA OFF indicator lamp Cancel
Distance Control Assist (DCA) High-pitched
tone
ICC system warn
ing lamp Cancel
Lane Departure Warning (LDW) — Lane departure warning lamp Cancel
Revision: 2010 May2011 QX56

DAS-66
< SYSTEM DESCRIPTION >[DCA]
COMPONENT PARTS
SYSTEM DESCRIPTION
COMPONENT PARTS
Component Parts LocationINFOID:0000000006223498
1. ICC steering switch 2. Information display, ICC system
warning lamp, buzzer
(On the combination meter)3. AV control unit
Refer to AV- 9 , "
Component Parts Lo-
cation"
4. Transfer control unit
Refer to DLN-10, "
Component Parts
Location"
5. ICC brake hold relay 6. ECM
Refer to EC-16, "
Component Parts
Location"
7. ICC sensor 8. TCM
Refer to TM-10, "
A/T CONTROL
SYSTEM : Component Parts Loca-
tion" 9. ABS actuator and el
ectric unit (con-
trol unit)
Refer to BRC-10, "
Component Parts
Location"
10. Accelerator pedal actuator 11. Stop lamp switch 12. ICC brake switch
13. Steering angle sensor
Refer to BRC-10, "
Component Parts
Location"
14. ADAS control unit
Refer to DAS-13, "
Component Parts
Location"
A. Back side of engine room (RH) B. Front bumper (center) C. Upper side of brake pedal
JSOIA0364ZZ
Revision: 2010 May2011 QX56

DAS
COMPONENT PARTSDAS-67
< SYSTEM DESCRIPTION > [DCA]
C
D
E
F
G H
I
J
K L
M B
N P A
Component DescriptionINFOID:0000000006223499
Component Description
ADAS control unit  ADAS control unit calculates a target distance between vehicles and a target speed,
based on signals received from each sensor and switch to transmit a brake fluid pres-
sure control signal to ABS actu ator and electric unit (control unit) via CAN communica-
tion
 ADAS control unit transmits the buzzer output signal to the combination meter via CAN communication
 ADAS control unit transmits an accelerator pedal feedback force control signal to the accelerator pedal actuator via ITS communication
ICC sensor  ICC sensor detects light reflected from a vehicle ahead by irradiating laser forward and
calculates a distance from the vehicle ahead and a relative speed, based on the detect-
ed signal
 ICC sensor transmits the presence/absence of vehicle ahead and the distance from the vehicle to ADAS control unit via ITS communication
ECM ECM transmits the accelerator pedal position signal, ICC brake switch signal, stop lamp
switch signal, ICC steering switch signal, etc. to ADAS control unit via CAN communica-
tion
ABS actuator and electric unit (control
unit)  ABS actuator and electric unit (control unit
) transmits the vehicle speed signal (wheel
speed), stop lamp signal and VDC/TCS/ABS system operat ion condition to ADAS con-
trol unit via CAN communication
 ABS actuator and electric unit (control unit ) controls the brake, based on a brake fluid
pressure control signal received from ADAS control unit via CAN communication
TCM TCM transmits the signal related to A/T control to ADAS control unit via CAN communi-
cation
Combination meter Performs the following operations using the signals received from the ADAS control unit
via the CAN communication
 Displays the DCA system operation status using the meter display signal
 Illuminates the ICC system warning lamp using the ICC warning lamp signal
 Operates the buzzer (ICC warning chime) using the buzzer output signal
Dynamic driver assistance switch
(On the ICC steering switch) ECM receives an ICC steering switch (dynamic driver assistance switch) signal and trans-
mits the signal to ADAS control unit via CAN communication
ICC brake hold relay ICC brake hold relay activates the stop lamp by ICC brake hold relay drive signal (stop
lamp drive signal) outputted by the ADAS control unit
ICC brake switch  ICC brake switch is turned OFF and stop lamp switch is turned ON, when depressing the brake pedal
 ICC brake switch signal is input to ECM. These signals are transmitted from ECM to ADAS control unit via CAN communication
 Stop lamp switch signal is input to ECM and ABS actuator and electric unit (control unit). These signals are transmitted from ECM and ABS actuator and electric unit (control
unit) to ADAS control unit via CAN communication
Stop lamp switch
Transfer control unit
Transfer control unit transmits a mode selection state of 4WD shift switch to the ADAS
control unit via CAN communication
AV control unit AV control unit transmits the system selection signal to the ADAS control unit via CAN
communication
Steering angle sensor Measures the rotation amount, rotation speed, and rotation direction of steering wheel,
and then transmits them to ADAS control unit via CAN communication
Accelerator pedal actuator Accelerator pedal actuator receives an accelerator pedal feedback force control signal
from the ADAS control unit via ITS communication and pushes back the accelerator pedal
Revision: 2010 May2011 QX56

DAS-70
< SYSTEM DESCRIPTION >[DCA]
SYSTEM
FUNCTION DESCRIPTION
When a vehicle is detected ahead The vehicle ahead detection indicator comes ON.
When vehicle approaches a vehicle ahead If the driver is not depressing the accelerator pedal, t
he system activates the brakes to decelerate smoothly
as necessary. If the vehicle ahead comes to a stop, the vehicle decelerates to a standstill within the limita-
tions of the system.
 If the driver is depressing the accelerator pedal, the system moves the accelerator pedal upward to assist
the driver to release the accelerator pedal.
When brake operation by driver is required The system alerts the driver by a warning chime and blinking the vehicle ahead detection indicator. If the
driver is depressing the accelerator pedal after the wa rning, the system moves the accelerator pedal upward
to assist the driver to switch to the brake pedal.
CAUTION:
If the vehicle ahead comes to a stan dstill, the vehicle decelerates to a standstill within the limitations
of the system. The system will release brake control wi th a warning chime once it judges the vehicle is
at a standstill. To prevent the vehicle from moving , the driver must depress the brake pedal. [The sys-
tem will resume control automatically once the system reaches 5 km/h (3 MPH)].
NOTE:
 Depending on the position of the accelerator pedal, the system may not be able to assist the driver to
release the accelerator pedal appropriately.
 When the driver depresses the accelerator pedal even further while the system is moving the acce\
lerator pedal upward, the accelerator pedal control will be canceled.
 When the driver is depressing the accelerator pedal, the brake control by the system is not operated.
 When the driver is depressing the brake pedal, neither the brake control nor the alert by the system oper-
ates.
 When the ICC system is set, the DCA system will be canceled.
OPERATION DESCRIPTION
ICC sensor calculates a distance from a vehicle ahead and a relative speed to transmit the ICC sensor signal
to the ADAS control unit via ITS communication. Based on the received signal, the ADAS control unit trans-
mits a control signal to the accelerator pedal actuator via ITS communication and to the ABS actuator control
unit (control unit) via CAN communication.
Combination
meter CAN commu-
nicationMeter display
signal
Vehicle ahead detec-
tion indicator signal
Transmits a signal to display a state of the system on
the information display
DCA system switch in-
dicator signal
ICC warning lamp signal Transmits an ICC warning lamp signal to turn ON the
ICC system warning lamp
Buzzer output signal Transmits a buzzer output signal to activate the buzz-
er
ICC sensor ITS commu-
nicationVehicle speed signal
Transmits a vehicle speed calculated by the ADAS
control unit
Steering angle sensor signal Transmits a steering angle sensor signal received
from the steering angle sensor
Accelerator
pedal actuator ITS commu-
nicationAccelerator pedal position signal
Transmits an accelerator pedal angle calculated by
the ADAS control unit
Accelerator pedal feedback force control
signal Transmits a target actuation force value calculated by
the ADAS control unit
ICC brake hold
relay ICC brake hold relay drive signal
Activates the brake hold relay and turns ON the stop
lamp
Reception unit Signal name Description
Revision: 2010 May2011 QX56

DAS-82
< SYSTEM DESCRIPTION >[DCA]
DIAGNOSIS SYSTEM (ADAS CONTROL UNIT)
Monitored item
[Unit]
ALL SIG(ICC)
MAIN SIG (ICC)
MAIN SIG
(LDW/LDP)
MAIN SIG
(BSW/BSI)
Description
MAIN SW
[On/Off] ×× × × Indicates [On/Off] status as judged from ICC steering switch signal (ECM trans-
mits ICC steering switch signal through CAN communication)
SET/COAST SW
[On/Off] ×× Indicates [On/Off] status as judged from ICC steering switch signal (ECM trans-
mits ICC steering switch signal through CAN communication)
CANCEL SW
[On/Off] ××
Indicates [On/Off] status as judged from ICC steering switch signal (ECM trans-
mits ICC steering switch signal through CAN communication)
RESUME/ACC SW
[On/Off] ×× Indicates [On/Off] status as judged from ICC steering switch signal (ECM trans-
mits ICC steering switch signal through CAN communication)
DISTANCE SW
[On/Off] × Indicates [On/Off] status as judged from ICC steering switch signal (ECM trans-
mits ICC steering switch signal through CAN communication)
CRUISE OPE
[On/Off] ××
Indicates whether controlling or not (ON means “controlling”)
BRAKE SW
[On/Off] ×× × × Indicates [On/Off] status as judged from ICC brake switch signal (ECM transmits
ICC brake switch signal through CAN communication)
STOP LAMP SW
[On/Off] ×× × × Indicates [On/Off] status as judged from stop lamp switch signal (ECM transmits
stop lamp switch signal through CAN communication)
IDLE SW
[On/Off] ×
Indicates [On/Off] status of idle switch read from ADAS control unit through CAN
communication (ECM transmits On/Off status through CAN communication)
SET DISTANCE
[Short/Mid/Long] ××
Indicates set distance memorized in ADAS control unit
CRUISE LAMP
[On/Off] ××
Indicates [On/Off] status of MAIN switch indicator output
OWN VHCL
[On/Off] ×
Indicates [On/Off] status of own vehicle indicator output
VHCL AHEAD
[On/Off] ×
Indicates [On/Off] status of vehicle ahead detection indicator output
ICC WARNING
[On/Off] ×
Indicates [On/Off] status of ICC system warning lamp output
VHCL SPEED SE
[km/h] or [mph] ×× × × Indicates vehicle speed calculated from ADAS control unit through CAN commu-
nication [ABS actuator and electric unit (c
ontrol unit) transmits vehicle speed sig-
nal (wheel speed) through CAN communication]
SET VHCL SPD
[km/h] or [mph] ××
Indicates set vehicle speed memorized in ADAS control unit
BUZZER O/P
[On/Off] ×
Indicates [On/Off] status of ICC warning chime output
THRTL SENSOR
[deg] ××
NOTE:
The item is displayed, but it is not monitored
ENGINE RPM
[rpm] × Indicates engine speed read from ADAS control unit through CAN communication
(ECM transmits engine speed signal through CAN communication)
WIPER SW
[OFF/LOW/HIGH] × Indicates wiper [OFF/LOW/HIGH] status (BCM transmits front wiper request sig-
nal through CAN communication)
YAW R AT E
[deg/s] ×
NOTE:
The item is displayed, but it is not monitored
BA WARNING
[On/Off] ×
Indicates [On/Off] status of IBA OFF indicator lamp output
STP LMP DRIVE
[On/Off] ××
Indicates [On/Off] status of ICC brake hold relay drive output
D RANGE SW
[On/Off] × Indicates [On/Off] status of “D” or “M” positions read from ADAS control unit
through CAN communication; ON when position “D” or “M” (TCM transmits shift
position signal through CAN communication).
Revision: 2010 May2011 QX56

DAS
DIAGNOSIS SYSTEM (ADAS CONTROL UNIT)
DAS-85
< SYSTEM DESCRIPTION > [DCA]
C
D
E
F
G H
I
J
K L
M B
N P A
ACTIVE TEST
CAUTION:
 Never perform “Active Test” while driving the vehicle.
 The “Active Test” cannot be performed when th e following systems warning lamp is illuminated.
- ICC system warning lamp
- Lane departure warning lamp
- BSW warning lamp
- IBA OFF indicator lamp (IBA system ON)
 Shift the selector lever to “P” po sition, and then perform the test.
METER LAMP
NOTE:
The test can be performed only when the engine is running.
BSW SYSTEM ON
[On/Off] ×
Indicates [On/Off] status of BSW system
4WD SW
[AUTO, 4H, 4L] ×××
Indicates [On/Off] status as judged from current 4WD mode signal (Transfer con-
trol unit transmits current 4WD mode signal through CAN communication)
Monitored item
[Unit]
ALL SIG
(ICC)
MAIN SIG (ICC)
MAIN SIG
(LDW/LDP)
MAIN SIG
(BSW/BSI)
Description
Test item Description
METER LAMP The ICC system warning lamp, MAIN switch indicator and IBA OFF indicator lamp can be illuminated
by ON/OFF operations as necessary
STOP LAMP The ICC brake hold relay can be operated by ON/OFF operations as necessary, and the stop lamp
can be illuminated
ICC BUZZER Sounds a buzzer used for following systems by arbitrarily operating ON/OFF
 Intelligent Cruise Control (ICC)
 Distance Control Assist (DCA)
 Forward Collision Warning (FCW)
 Intelligent Brake Assist (IBA)
BRAKE ACTUATOR Activates the brake by an arbitrary operation
Active Pedal The accelerator pedal actuator can be operated as necessary
DCA INDICATOR The DCA system switch indicator can be illuminated by ON/OFF operations as necessary
LDP BUZZER Sounds a buzzer used for following systems by arbitrarily operating ON/OFF
 Lane Departure Warning (LDW)
 Lane Departure Prevention (LDP)
 Blind Spot Warning (BSW)
WARNING SYSTEM IND The warning systems ON indicator (on warning systems switch) can be illuminated by ON/OFF op-
erations as necessary
LDP ON IND The LDP ON indicator lamp can be illuminated by ON/OFF operations as necessary
LANE DEPARTURE W/L The lane departure warning lamp can be illuminated by ON/OFF operations as necessary
BSW/BSI WARNING LAMP The BSW warning lamp can be illuminated by ON/OFF operations as necessary
Revision: 2010 May2011 QX56
