2011 INFINITI QX56 sensor

DAS-152
< DTC/CIRCUIT DIAGNOSIS >[DCA]
C1A18 LASER AIMING INCMP
C1A18 LASER AIMING INCMP
DTC LogicINFOID:0000000006228088
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Start the engine.
2. Turn the DCA system ON.
3. Perform “All DTC Reading” with CONSULT-III.
4. Check if the “C1A18” is detected as the current malfunction in “Self Diagnostic Result” of “ICC/ADAS”.
Is
“C1A18” detected as the current malfunction?
YES >> Refer to DAS-152, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006228089
1.ADJUST LASER BEAM AIMING
Check if the “C1A18” is detected in “Self Diagnostic Result” of “LASER”.
Is
“C1A18” detected?
YES >> Refer to CCS-109, "ICC SENSOR : DTC Logic".
NO >> Replace the ADAS control unit. Refer to DAS-63, "
Removal and Installation".
DTC
(On board dis-
play) Trouble diagnosis
name DTC detecting condition Possible causes
C1A18 (18) LASER AIMING IN-
CMP
Laser beam aiming of ICC sensor is not adjusted  No laser beam aiming adjustment is
performed
 Laser beam aiming adjustment has
been interrupted
Revision: 2010 May2011 QX56

DAS
C1A21 UNIT HIGH TEMPDAS-153
< DTC/CIRCUIT DIAGNOSIS > [DCA]
C
D
E
F
G H
I
J
K L
M B
N P A
C1A21 UNIT HIGH TEMP
DTC LogicINFOID:0000000006228090
DTC DETECTION LOGIC
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn the ignition switch OFF.
2. Wait for 10 minutes or more to cool the ICC sensor.
3. Start the engine.
4. Turn the DCA system ON.
5. Perform “All DTC Readi ng” with CONSULT-III.
6. Check if the “C1A21” is detected as the current malfunction in “Self Diagnostic Result” of “ICC/ADAS”.
Is
“C1A21” detected as the current malfunction?
YES >> Refer to DAS-153, "Diagnosis Procedure".
NO >> Refer to GI-40, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000006228091
1.CHECK SELF-DIAGNOSIS RESULTS
Check if “C1A21” is detected in “S elf Diagnostic Result” of “LASER”.
Is
“C1A21” detected?
YES >> Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to
CCS-111, "
ICC SENSOR : DTC Logic".
NO >> Replace the ADAS control unit. Refer to DAS-63, "
Removal and Installation".
DTC
(On board dis-
play) Trouble diagnosis
name DTC detecting condition Possible causes
C1A21 (21) ICC SENSOR HIGH
TEMP
ICC sensor judges high temperature abnormality
Temperature around the ICC sensor
becomes high
Revision: 2010 May2011 QX56

DAS-158
< DTC/CIRCUIT DIAGNOSIS >[DCA]
C1A2A ICC SENSOR POWER SUPPLY CIRCUIT
C1A2A ICC SENSOR POWER SUPPLY CIRCUIT
DTC LogicINFOID:0000000006228098
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Start the engine.
2. Turn the DCA system ON.
3. Perform “All DTC Reading” with CONSULT-III.
4. Check if the “C1A2A” is detected as the current malfunction in “Self Diagnostic Result” of “ICC/ADAS”.
Is
“C1A2A” detected as the current malfunction?
YES >> Refer to DAS-158, "Diagnosis Procedure".
NO >> Refer to GI-40, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000006228099
1.CHECK SELF-DIAGNOSIS RESULTS
Check if “U1000” is detected ot her than “C1A2A” in “Self Diagnostic Result” of “ICC/ADAS”.
Is any DTC detected?
YES >> Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to
DAS-182, "
ADAS CONTROL UNIT : DTC Logic".
NO >> GO TO 2.
2.CHECK ICC SENSOR SELF-DIAGNOSIS
Check if any DTC is detected in “Self Diagnostic Result” of “LASER”.
Is any DTC detected?
YES >> Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to
CCS-55, "
DTC Index".
NO >> Replace ADAS control unit. Refer to DAS-63, "
Removal and Installation".
DTC
(On board display) Trouble diagnosis name DTC detecting condition Possible cause
C1A2A (80) ICC SEN PWR SUP CIR Abnormal powe
r supply voltage in ICC sensor Harness, connector, fuse
 ICC sensor
Revision: 2010 May2011 QX56

DAS
C1A39 STEERING ANGLE SENSORDAS-165
< DTC/CIRCUIT DIAGNOSIS > [DCA]
C
D
E
F
G H
I
J
K L
M B
N P A
C1A39 STEERING ANGLE SENSOR
DTC LogicINFOID:0000000006228117
DTC DETECTION LOGIC
NOTE:
If DTC “C1A39” is detected along with DTC “U1000”, first diagnose the DTC “U1000”. Refer to DAS-182,
"ADAS CONTROL UNIT : DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Start the engine.
2. Turn the DCA system ON.
3. Perform “All DTC Readi ng” with CONSULT-III.
4. Check if the “C1A39” is detected as the current malfunction in self-diagnosis results of “ICC/ADAS”.
Is
“C1A39” detected as the current malfunction?
YES >> Refer to DAS-165, "Diagnosis Procedure".
NO >> Refer to GI-40, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000006228118
1.CHECK SELF-DIAGNOSIS RESULTS
Check if “U1000” is detected other than “C1A39” in “Self Diagnostic Result” of “ICC/ADAS”.
Is
“U1000” detected?
YES >> Perform the CAN communicati on system inspection. Repair or replace the malfunctioning parts.
Refer to DAS-182, "
ADAS CONTROL UNIT : DTC Logic".
NO >> GO TO 2.
2.CHECK ABS ACTUATOR AND ELECTRIC UNIT (C ONTROL UNIT) SELF-DIAGNOSIS RESULTS
Check if any DTC is detected in “Self Diagnostic Result” of “ABS”.
Is any DTC detected?
YES >> Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to
BRC-51, "
DTC Index".
NO >> Replace the ADAS control unit. Refer to DAS-63, "
Removal and Installation".
DTC
(On board dis-
play) Trouble diagnosis name DTC detecting condition Possible causes
C1A39 (39) STRG SEN CIR If the steering angle sensor is malfunction Steering angle sensor
Revision: 2010 May2011 QX56

DAS-176
< DTC/CIRCUIT DIAGNOSIS >[DCA]
U0126 STRG SEN CAN 1
U0126 STRG SEN CAN 1
DTC LogicINFOID:0000000006228133
DTC DETECTION LOGIC
NOTE:
If DTC “U0126” is detected along with DTC “U
1000”, first diagnose the DTC “U1000”. Refer to DAS-182,
"ADAS CONTROL UNIT : DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Start the engine.
2. Turn the DCA system ON.
3. Perform “All DTC Reading” with CONSULT-III.
4. Check if the “U0126” is detected as the current ma lfunction in “Self Diagnostic Result” of “ICC/ADAS”.
Is
“U0126” detected as the current malfunction?
YES >> Refer to DAS-176, "Diagnosis Procedure".
NO >> Refer to GI-40, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000006228134
1.CHECK SELF-DIAGNOSIS RESULTS
Check if “U1000” is detected ot her than “U0126” in “Self Diagnostic Result” of “ICC/ADAS”.
Is
“U1000” detected?
YES >> Perform the CAN communication system inspecti on. Repair or replace the malfunctioning parts.
Refer to DAS-182, "
ADAS CONTROL UNIT : DTC Logic".
NO >> GO TO 2.
2.CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) SELF-DIAGNOSIS RESULTS
Check if any DTC is detected in “Self Diagnostic Result” of “ABS”.
Is any DTC detected?
YES >> Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to
BRC-51, "
DTC Index".
NO >> Replace the ADAS control unit. Refer to DAS-63, "
Removal and Installation".
DTC
(On board dis-
play) Trouble diagnosis name DTC detecting condition Possible causes
U0126 (130) STRG SEN CAN CIR1 If ADAS control unit detects an error signal
that is received from steering angle sensor via
CAN communication
Steering angle sensor
Revision: 2010 May2011 QX56

DAS
U0235 ICC SENSOR CAN 1DAS-177
< DTC/CIRCUIT DIAGNOSIS > [DCA]
C
D
E
F
G H
I
J
K L
M B
N P A
U0235 ICC SENSOR CAN 1
DTC LogicINFOID:0000000006228135
DTC DETECTION LOGIC
NOTE:
If DTC “U0235” is detected along with DTC “U 1000”, first diagnose the DTC “U1000”. Refer to DAS-182,
"ADAS CONTROL UNIT : DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Start the engine.
2. Turn the DCA system ON.
3. Perform “All DTC Readi ng” with CONSULT-III.
4. Check if the “U0235” is detected as the current ma lfunction in “Self Diagnostic Result” of “ICC/ADAS”.
Is
“U0235” detected as the current malfunction?
YES >> Refer to DAS-177, "Diagnosis Procedure".
NO >> Refer to GI-40, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000006228136
1.CHECK ADAS CONTROL UNIT SELF-DIAGNOSIS RESULTS
Check if “U1000” is detected other than “U0235” in “Self Diagnostic Result” of “ICC/ADAS”.
Is
“U1000” detected?
YES >> Perform the CAN communicati on system inspection. Repair or replace the malfunctioning parts.
Refer to DAS-182, "
ADAS CONTROL UNIT : DTC Logic".
NO >> GO TO 2.
2.CHECK ICC SENSOR SELF-DIAGNOSIS RESULTS
Check if any DTC is detected in “Self Diagnostic Result” of “LASER”.
Is any DTC detected?
YES >> Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to
CCS-55, "
DTC Index".
NO >> Replace the ADAS control unit. Refer to DAS-63, "
Removal and Installation".
DTC
(On board dis-
play) Trouble diagnosis name DTC detecting condition Possible causes
U0235 (144) ICC SENSOR CAN
CIR1 If ADAS control unit detects an error signal
that is received from ICC sensor via ITS com-
munication
ICC sensor
Revision: 2010 May2011 QX56

DAS
U0428 STRG SEN CAN 2DAS-181
< DTC/CIRCUIT DIAGNOSIS > [DCA]
C
D
E
F
G H
I
J
K L
M B
N P A
U0428 STRG SEN CAN 2
DTC LogicINFOID:0000000006228143
DTC DETECTION LOGIC
NOTE:
If DTC “U0428” is detected along with DTC “U 1000”, first diagnose the DTC “U1000”. Refer to DAS-182,
"ADAS CONTROL UNIT : DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Start the engine.
2. Turn the DCA system ON.
3. Perform “All DTC Readi ng” with CONSULT-III.
4. Check if the “U0428” is detected as the current ma lfunction in “Self Diagnostic Result” of “ICC/ADAS”.
Is
“U0428” detected as the current malfunction?
YES >> Refer to DAS-181, "Diagnosis Procedure".
NO >> Refer to GI-40, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000006228144
1.CHECK SELF-DIAGNOSIS RESULTS
Check if “U1000” is detected other than “U0428” in “Self Diagnostic Result” of “ICC/ADAS”.
Is
“U1000” detected?
YES >> Perform the CAN communicati on system inspection. Repair or replace the malfunctioning parts.
Refer to DAS-182, "
ADAS CONTROL UNIT : DTC Logic".
NO >> GO TO 2.
2.CHECK ABS ACTUATOR AND ELECTRIC UNIT (C ONTROL UNIT) SELF-DIAGNOSIS RESULTS
Check if any DTC is detected in “Self Diagnostic Result” of “ABS”.
Is any DTC detected?
YES >> Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to
BRC-51, "
DTC Index".
NO >> Replace the ADAS control unit. Refer to DAS-63, "
Removal and Installation".
DTC
(On board dis-
play) Trouble diagnosis name DTC detecting condition Possible causes
U0428 (131) STRG SEN CAN CIR2 If ADAS control unit detects an error signal
that is received from steering angle sensor via
CAN communication
Steering angle sensor
Revision: 2010 May2011 QX56

DAS
U1502 ICC SENSOR CAN COMM CIRCDAS-189
< DTC/CIRCUIT DIAGNOSIS > [DCA]
C
D
E
F
G H
I
J
K L
M B
N P A
U1502 ICC SENSOR CAN COMM CIRC
DTC LogicINFOID:0000000006228159
DTC DETECTION LOGIC
NOTE:
If DTC “U1502” is detected along with DTC “U 1000”, first diagnose the DTC “U1000”. Refer to DAS-182,
"ADAS CONTROL UNIT : DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Start the engine.
2. Turn the DCA system ON.
3. Perform “All DTC Readi ng” with CONSULT-III.
4. Check if the “U1502” is detected as the current ma lfunction in “Self Diagnostic Result” of “ICC/ADAS”.
Is
“U1502” detected as the current malfunction?
YES >> Refer to DAS-189, "Diagnosis Procedure".
NO >> Refer to GI-40, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000006228160
1.CHECK SELF-DIAGNOSIS RESULTS
Check if “U1000” is detected other than “U1502” in “Self Diagnostic Result” of “ICC/ADAS”.
Is
“U1000” detected?
YES >> Perform the CAN communicati on system inspection. Repair or replace the malfunctioning parts.
Refer to DAS-182, "
ADAS CONTROL UNIT : DTC Logic".
NO >> GO TO 2.
2.CHECK ICC SENSOR SELF-DIAGNOSIS RESULTS
Check if any DTC is detected in “Self Diagnostic Result” of “LASER”.
Is any DTC detected?
YES >> Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to
CCS-55, "
DTC Index".
NO >> Replace the ADAS control unit. Refer to DAS-63, "
Removal and Installation".
DTC
(On board dis-
play) Trouble diagnosis name DTC detecting condition Possible causes
U1502 (147) ICC SEN CAN COMM
CIR ADAS control unit detects an error signal that is
received from ICC sensor via CAN communi-
cation
ICC sensor
Revision: 2010 May2011 QX56
