2011 INFINITI QX56 BATTERY CONNECTORS

LAN
TPMS BRANCH LINE CIRCUITLAN-189
< DTC/CIRCUIT DIAGNOSIS > [CAN SYSTEM (TYPE 3)]
C
D
E
F
G H
I
J
K L
B A
O P
N
TPMS BRANCH
LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000006256347
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cabl e from the negative terminal.
3. Check the terminals and connectors of the low ti re pressure warning control unit for damage, bend and
loose connection (unit side and connector side).
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect the connector of low tire pressure warning control unit.
2. Check the resistance between the low tire pressure warning control unit harness connector terminals.
Is the measurement value within the specification?
YES >> GO TO 3.
NO >> Repair the low tire pressure warning control unit branch line.
3.CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circuit of the lo w tire pressure warning control unit. Refer to WT-51,
"Diagnosis Procedure".
Is the inspection result normal?
YES (Present error)>>Replace the low tire pressure warning control unit. Refer to WT-65, "Removal and
Installation".
YES (Past error)>>Error was detected in the low tire pressure warning control unit branch line.
NO >> Repair the power supply and the ground circuit.
Low tire pressure warning control unit harness connector Resistance (Ω)
Connector No. Terminal No.
M96 2 1 Approx. 54 – 66
Revision: 2010 May2011 QX56

LAN-190
< DTC/CIRCUIT DIAGNOSIS >[CAN SYSTEM (TYPE 3)]
IPDM-E BRANCH LINE CIRCUIT
IPDM-E BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000006256348
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Check the following terminals and connectors fo r damage, bend and loose connection (unit side and con-
nector side).
-IPDME/R
- Harness connector E105
- Harness connector M77
- Harness connector M19 (Without ICC system)
- Harness connector B2 (Without ICC system)
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect the connector of IPDM E/R.
2. Check the resistance between the IPDM E/R harness connector terminals.
Is the measurement value within the specification?
YES >> GO TO 3.
NO >> Repair the IPDM E/R branch line.
3.CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circuit of the IPDM E/R. Refer to PCS-31, "
Diagnosis Procedure".
Is the inspection result normal?
YES (Present error)>>Replace the IPDM E/R. Refer to PCS-32, "Removal and Installation".
YES (Past error)>>Error was detec ted in the IPDM E/R branch line.
NO >> Repair the power supply and the ground circuit.
IPDM E/R harness connector Resistance (Ω)
Connector No. Terminal No.
E13 27 26 Approx. 108 – 132
Revision: 2010 May2011 QX56

LAN
ADP BRANCH LINE CIRCUITLAN-191
< DTC/CIRCUIT DIAGNOSIS > [CAN SYSTEM (TYPE 3)]
C
D
E
F
G H
I
J
K L
B A
O P
N
ADP BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000006256349
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cabl e from the negative terminal.
3. Check the following terminals and connectors for damage, bend and loose connection (unit side and con- nector side).
- Driver seat control unit
- Harness connector B460
- Harness connector B24
- CAN gateway (With ICC system)
Is the inspection result normal?
YES (With ICC system)>>GO TO 2.
YES (Without ICC system)>>GO TO 3.
NO >> Repair the terminal and connector.
2.CHECK HARNESS CONTI NUITY (OPEN CIRCUIT)
1. Disconnect the connector of CAN gateway.
2. Check the continuity between the CAN gateway harness connector terminals.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Check the harness and repair the root cause (CAN communication circuit 2). Refer to LAN-57,
"System Diagram".
3.CHECK HARNESS FOR OPEN CIRCUIT
1. Connect the connector of CAN gateway. (With ICC system)
2. Disconnect the connector of driver seat control unit.
3. Check the resistance between the driver s eat control unit harness connector terminals.
Is the measurement value within the specification?
YES >> GO TO 4.
NO >> Repair the driver seat control unit branch line.
4.CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circuit of the driver seat control unit. Refer to ADP-67, "
DRIVER SEAT
CONTROL UNIT : DiagnosisProcedure".
Is the inspection result normal?
YES (Present error)>>Replace the driver seat control unit. Refer to ADP-135, "Removal and Installation".
YES (Past error)>>Error was detected in the driver seat control unit branch line.
NO >> Repair the power supply and the ground circuit.
CAN gateway harness connector Continuity
Connector No. Terminal No.
M125 46Existed
10 12 Existed
Driver seat control unit harness connector Resistance (Ω)
Connector No. Terminal No.
B451 1 17 Approx. 54 – 66
Revision: 2010 May2011 QX56

LAN-192
< DTC/CIRCUIT DIAGNOSIS >[CAN SYSTEM (TYPE 3)]
E-SUS BRANCH LINE CIRCUIT
E-SUS BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000006256351
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Check the following terminals and connectors fo r damage, bend and loose connection (unit side and con-
nector side).
- Air levelizer control module
- CAN gateway (With ICC system)
Is the inspection result normal?
YES (With ICC system)>>GO TO 2.
YES (Without ICC sy stem)>>GO TO 3.
NO >> Repair the terminal and connector.
2.CHECK HARNESS CONTI NUITY (OPEN CIRCUIT)
1. Disconnect the connector of CAN gateway.
2. Check the continuity between the CA N gateway harness connector terminals.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Check the harness and repair the root cause (CAN communication circuit 2). Refer to LAN-57,
"System Diagram".
3.CHECK HARNESS FOR OPEN CIRCUIT
1. Connect the connector of CAN gateway. (With ICC system)
2. Disconnect the connector of air levelizer control module.
3. Check the resistance between the air leveliz er control module harness connector terminals.
Is the measurement value within the specification?
YES >> GO TO 4.
NO >> Repair the air levelizer control module branch line.
4.CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circuit of the air levelizer control module. Refer to SCS-89,
"DiagnosisProcedure".
Is the inspection result normal?
YES (Present error)>>Replace the air levelizer control module. Refer to SCS-94, "Removal and Installation".
YES (Past error)>>Error was detected in t he air levelizer control module branch line.
NO >> Repair the power supply and the ground circuit.
CAN gateway harness connector Continuity
Connector No. Terminal No.
M125 46Existed
10 12 Existed
Air levelizer control mo dule harness connector
Resistance (Ω)
Connector No. Terminal No.
B84 16 7 Approx. 54 – 66
Revision: 2010 May2011 QX56

LAN
PWBD BRANCH LINE CIRCUITLAN-193
< DTC/CIRCUIT DIAGNOSIS > [CAN SYSTEM (TYPE 3)]
C
D
E
F
G H
I
J
K L
B A
O P
N
PWBD BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000006256353
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cabl e from the negative terminal.
3. Check the following terminals and connectors for damage, bend and loose connection (unit side and con- nector side).
- Automatic back door control module
- CAN gateway (With ICC system)
Is the inspection result normal?
YES (With ICC system)>>GO TO 2.
YES (Without ICC system)>>GO TO 3.
NO >> Repair the terminal and connector.
2.CHECK HARNESS CONTI NUITY (OPEN CIRCUIT)
1. Disconnect the connector of CAN gateway.
2. Check the continuity between the CAN gateway harness connector terminals.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Check the harness and repair the root cause (CAN communication circuit 2). Refer to LAN-57,
"System Diagram".
3.CHECK HARNESS FOR OPEN CIRCUIT
1. Connect the connector of CAN gateway. (With ICC system)
2. Disconnect the connector of automatic back door control module.
3. Check the resistance between the automatic bac k door control module harness connector terminals.
Is the measurement value within the specification?
YES >> GO TO 4.
NO >> Repair the automatic back door control module branch line.
4.CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circuit of t he automatic back door control module. Refer to DLK-116,
"AUTOMATIC BACK DOOR CONTROL UNIT : Diagnosis Procedure".
Is the inspection result normal?
YES (Present error)>>Replace the automat ic back door control module. Refer to DLK-262, "Removal and
Installation".
YES (Past error)>>Error was detected in the automatic back door control module branch line.
NO >> Repair the power supply and the ground circuit.
CAN gateway harness connector Continuity
Connector No. Terminal No.
M125 46Existed
10 12 Existed
Automatic back door control module harness connector Resistance (Ω)
Connector No. Terminal No.
B26 7 6 Approx. 54 – 66
Revision: 2010 May2011 QX56

LAN-194
< DTC/CIRCUIT DIAGNOSIS >[CAN SYSTEM (TYPE 3)]
CAN COMMUNICATION CIRCUIT
CAN COMMUNICATION CIRCUIT
Diagnosis ProcedureINFOID:0000000006256359
1.CONNECTOR INSPECTION
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Disconnect all the unit connectors on CAN communication circuit.
4. Check terminals and connectors for damage, bend and loose connection.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS CONTI NUITY (SHORT CIRCUIT)
Check the continuity between t he data link connector terminals.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Check the harness and repair the root cause.
3.CHECK HARNESS CONTI NUITY (SHORT CIRCUIT)
Check the continuity between the data link connector and the ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Check the harness and repair the root cause.
4.CHECK ECM AND IPDM E/R TERMINATION CIRCUIT
1. Remove the ECM and the IPDM E/R.
2. Check the resistance between the ECM terminals.
3. Check the resistance between the IPDM E/R terminals.
Is the measurement value within the specification?
YES >> GO TO 5.
NO >> Replace the ECM and/or the IPDM E/R.
5.CHECK SYMPTOM
Connect all the connectors. Check if the symptoms descri bed in the “Symptom (Results from interview with
customer)” are reproduced.
Data link connector Continuity
Connector No. Terminal No.
M4 6 14 Not existed
Data link connector
GroundContinuity
Connector No. Terminal No.
M4 6 Not existed
14 Not existed
ECM Resistance (Ω)
Te r m i n a l N o .
146 151 Approx. 108 – 132
IPDM E/R Resistance (Ω)
Te r m i n a l N o .
27 26 Approx. 108 – 132
Revision: 2010 May2011 QX56

LAN
CAN COMMUNICATION CIRCUITLAN-195
< DTC/CIRCUIT DIAGNOSIS > [CAN SYSTEM (TYPE 3)]
C
D
E
F
G H
I
J
K L
B A
O P
N
Inspection result
Reproduced>>GO TO 6.
Non-reproduced>>Start the diagnosis again. Follow
the trouble diagnosis procedure when past error is
detected.
6.CHECK UNIT REPRODUCTION
Perform the reproduction test as per the following procedure for each unit.
1. Turn the ignition switch OFF.
2. Disconnect the battery cabl e from the negative terminal.
3. Disconnect one of the unit connectors of CAN communication circuit.
NOTE:
ECM and IPDM E/R have a termination circuit. Check other units first.
4. Connect the battery cable to the negative terminal. Check if the symptoms described in the “Symptom
(Results from interview with customer)” are reproduced.
NOTE:
Although unit-related error symptoms occur, do not confuse them with other symptoms.
Inspection result
Reproduced>>Connect the connector. Check other units as per the above procedure.
Non-reproduced>>Replace the unit whose connector was disconnected.
Revision: 2010 May2011 QX56

LAN-196
< DTC/CIRCUIT DIAGNOSIS >[CAN SYSTEM (TYPE 4)]
MAIN LINE BETWEEN ABS AND DLC CIRCUIT
DTC/CIRCUIT DIAGNOSIS
MAIN LINE BETWEEN
ABS AND DLC CIRCUIT
Diagnosis ProcedureINFOID:0000000006256366
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Check the following terminals and connectors for damage, bend and loose connection (connector side and harness side).
- Harness connector E107
- Harness connector M82
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS CONTI NUITY (OPEN CIRCUIT)
1. Disconnect the following harness connectors.
- ABS actuator and electric unit (control unit)
- Harness connectors E107 and M82
2. Check the continuity between the ABS actuator and electric unit (control unit) harness connector and the
harness connector.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair the main line between the ABS actuat or and electric unit (control unit) and the harness
connector E107.
3.CHECK HARNESS CONTI NUITY (OPEN CIRCUIT)
Check the continuity between the harness connector and the data link connector.
Is the inspection result normal?
YES (Present error)>>Check CAN system type decision again.
YES (Past error)>>Error was detected in the main li ne between the ABS actuator and electric unit (control
unit) and the data link connector.
NO >> Repair the main line between the harness connector M82 and the data link connector.
ABS actuator and electric unit (control unit)
harness connector Harness connector
Continuity
Connector No. Terminal No. Connector No. Terminal No.
E36 41
E107 1 Existed
27 6 Existed
Harness connector Data link connector Continuity
Connector No. Terminal No. Connector No. Terminal No.
M82 1
M4 6 Existed
6 14 Existed
Revision: 2010 May2011 QX56
