Page 1298 of 5598
![INFINITI QX56 2011 Factory Service Manual
DAS
DIAGNOSIS AND REPAIR WORK FLOWDAS-333
< BASIC INSPECTION > [LDW & LDP]
C
D
E
F
G H
I
J
K L
M B
N P A
>> GO TO 2.
2.SELF-DIAGNOSIS WITH CONSULT-III
1. Perform “All DTC Reading” with CONSULT-II INFINITI QX56 2011 Factory Service Manual
DAS
DIAGNOSIS AND REPAIR WORK FLOWDAS-333
< BASIC INSPECTION > [LDW & LDP]
C
D
E
F
G H
I
J
K L
M B
N P A
>> GO TO 2.
2.SELF-DIAGNOSIS WITH CONSULT-III
1. Perform “All DTC Reading” with CONSULT-II](/manual-img/42/57033/w960_57033-1297.png)
DAS
DIAGNOSIS AND REPAIR WORK FLOWDAS-333
< BASIC INSPECTION > [LDW & LDP]
C
D
E
F
G H
I
J
K L
M B
N P A
>> GO TO 2.
2.SELF-DIAGNOSIS WITH CONSULT-III
1. Perform “All DTC Reading” with CONSULT-III.
2. Check if the DTC is detected on the self-diagnosis results of “ICC/ADAS” and/or “LANE CAMERA”.
Is any DTC detected?
YES >> GO TO 5.
NO >> GO TO 3.
3.PRE-INSPECTION FOR DIAGNOSIS
Perform pre-inspection for diagnosis. Refer to DAS-335, "
Inspection Procedure".
>> GO TO 4.
4.ACTION TEST
Perform LDW/LDP system action test to check the operation status. Refer to DAS-336, "
Description".
>> GO TO 6.
5.TROUBLE DIAGNOSIS BY DTC
Perform trouble diagnosis for the detected DTC. Specify a malfunctioning part. Refer to DAS-310, "
DTC Index"
(ICC/ADAS) and/or DAS-316, "DTC Index" (LANE CAMERA).
>> GO TO 7.
6.SYMPTOM DIAGNOSIS
Perform symptom diagnosis. Specify malfunctioning part. Refer to DAS-395, "
Symptom Table".
>> GO TO 7.
7.MALFUNCTION PART REPAIR
Repair or replace the identified malfunctioning parts.
>> GO TO 8.
8.REPAIR CHECK (SELF-DIAGNOSIS WITH CONSULT-III)
Perform self-diagnosis with CONSULT-II I. Check that any DTC is not detected. Erase DTC if DTC is detected
before the repair. Check that DTC is not detected again.
Is any DTC detected?
YES >> GO TO 5.
NO >> GO TO 9.
9.REPAIR CHECK (ACTION TEST)
Perform LDW/LDP system action test . Also check the system operation.
Does it operate normally?
YES >> INSPECTION END
NO >> GO TO 4.
Diagnostic Work SheetINFOID:0000000006223728
DESCRIPTION
In general, each customer feels differently about an inci dent. It is important to fully understand the symptoms
or conditions for a customer complaint.
There are many operating conditions that lead to the malfunction. A good grasp of such conditions can make
troubleshooting faster and more accurate.
Some conditions may cause the lane departure warning lamp to stay ON.
Revision: 2010 May2011 QX56
Page 1299 of 5598
DAS-334
< BASIC INSPECTION >[LDW & LDP]
DIAGNOSIS AND REPAIR WORK FLOW
Utilize a work sheet sample to organize all of the information for troubleshooting.
KEY POINTS WHAT..... System and functions
WHEN..... Date, Frequencies
WHERE..... Road conditions
HOW..... Operating conditions, Symptoms
WORK SHEET SAMPLE
JSOIA0287GB
Revision: 2010 May2011 QX56
Page 1300 of 5598
DAS
PRE-INSPECTION FOR DIAGNOSISDAS-335
< BASIC INSPECTION > [LDW & LDP]
C
D
E
F
G H
I
J
K L
M B
N P A
PRE-INSPECTION FOR DIAGNOSIS
Inspection ProcedureINFOID:0000000006223729
1.CHECK CAMERA LENS AND WINDSHIELD
Are camera lens and windshield contaminated with foreign materials?
YES >> Clean camera lens and windshield.
NO >> GO TO 2.
2.CHECK LANE CAMERA UNIT INSTALLATION CONDITION
Check lane camera unit installation condition (install ation position, properly tightened, a bent bracket).
Is it properly installed?
YES >> GO TO 3.
NO >> Install lane camera unit properly, and perform camera aiming. Refer to DAS-340, "
Description".
3.CHECK VEHICLE HEIGHT
Check vehicle height. Refer to FSU-21, "
Wheel Height".
Is vehicle height appropriate?
YES >> INSPECTION END
NO >> Repair vehicle to appropriate height.
Revision: 2010 May2011 QX56
Page 1310 of 5598
![INFINITI QX56 2011 Factory Service Manual
DAS
C1A00 CONTROL UNITDAS-345
< DTC/CIRCUIT DIAGNOSIS > [LDW & LDP]
C
D
E
F
G H
I
J
K L
M B
N P A
DTC/CIRCUIT DIAGNOSIS
C1A00 CONTROL UNIT
DTC LogicINFOID:0000000006223739
DTC DETECTION LOGIC
DTC CON INFINITI QX56 2011 Factory Service Manual
DAS
C1A00 CONTROL UNITDAS-345
< DTC/CIRCUIT DIAGNOSIS > [LDW & LDP]
C
D
E
F
G H
I
J
K L
M B
N P A
DTC/CIRCUIT DIAGNOSIS
C1A00 CONTROL UNIT
DTC LogicINFOID:0000000006223739
DTC DETECTION LOGIC
DTC CON](/manual-img/42/57033/w960_57033-1309.png)
DAS
C1A00 CONTROL UNITDAS-345
< DTC/CIRCUIT DIAGNOSIS > [LDW & LDP]
C
D
E
F
G H
I
J
K L
M B
N P A
DTC/CIRCUIT DIAGNOSIS
C1A00 CONTROL UNIT
DTC LogicINFOID:0000000006223739
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Start the engine.
2. Perform “All DTC Readi ng” with CONSULT-III.
3. Check if the “C1A00” is detected as the current malfunction in “Self Diagnostic Result” of “ICC/ADAS”.
Is
“C1A00” detected as the current malfunction?
YES >> Refer to DAS-345, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006223740
1.CHECK SELF-DIAGNOSIS RESULTS
Check if any DTC other than “C1A00” is detect ed in “Self Diagnostic Result” of “ICC/ADAS”.
Is any DTC detected?
YES >> Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to
DAS-38, "
DTC Index".
NO >> Replace the ADAS control unit. Refer to DAS-63, "
Removal and Installation".
DTC
(On board dis- play) Trouble diagnosis name DTC detecting condition Possible causes
C1A00 (0) CONTROL UNIT ADAS control unit inte
rnal malfunction ADAS control unit
Revision: 2010 May2011 QX56
Page 1311 of 5598
![INFINITI QX56 2011 Factory Service Manual
DAS-346
< DTC/CIRCUIT DIAGNOSIS >[LDW & LDP]
C1A01 POWER SUPPLY CIRCUIT 1,
C1A02 POWER SUPPLY CIRCUIT 2
C1A01 POWER SUPPLY CIRCUIT 1, C1A02 POWER SUPPLY CIRCUIT 2
DTC LogicINFOID:0000000006223741
D INFINITI QX56 2011 Factory Service Manual
DAS-346
< DTC/CIRCUIT DIAGNOSIS >[LDW & LDP]
C1A01 POWER SUPPLY CIRCUIT 1,
C1A02 POWER SUPPLY CIRCUIT 2
C1A01 POWER SUPPLY CIRCUIT 1, C1A02 POWER SUPPLY CIRCUIT 2
DTC LogicINFOID:0000000006223741
D](/manual-img/42/57033/w960_57033-1310.png)
DAS-346
< DTC/CIRCUIT DIAGNOSIS >[LDW & LDP]
C1A01 POWER SUPPLY CIRCUIT 1,
C1A02 POWER SUPPLY CIRCUIT 2
C1A01 POWER SUPPLY CIRCUIT 1, C1A02 POWER SUPPLY CIRCUIT 2
DTC LogicINFOID:0000000006223741
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Start the engine.
2. Turn the LDP system ON.
3. Perform “All DTC Reading” with CONSULT-III.
4. Check if the “C1A01” or “C1A02” is detected as t he current malfunction in “Self Diagnostic Result” of “ICC/
ADAS”.
Is
“C1A01” or “C1A02” detected as the current malfunction?
YES >> Refer to DAS-346, "Diagnosis Procedure".
NO >> Refer to GI-40, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000006223742
1.CHECK ADAS CONTROL UNIT POWER SUPPLY AND GROUND CIRCUIT
Check power supply and ground circuit of ADAS control unit. Refer to DAS-387, "
ADAS CONTROL UNIT :
Diagnosis Procedure".
Is the inspection result normal?
YES >> Replace the ADAS control unit. Refer to DAS-63, "Removal and Installation".
NO >> Repair or replace the malfunctioning parts.
DTC
(On board dis-
play) Trouble diagnosis
name DTC detecting condition Possible causes
C1A01 (1) POWER SUPPLY
CIR The battery voltage sent to ADAS control unit re-
mains less than 7.9 V for 5 seconds
Connector, harness, fuse
ADAS control unit
C1A02
(2) POWER SUPPLY
CIR 2 The battery voltage sent to ADAS control unit re-
mains more than 19.3 V for 5 seconds
Revision: 2010 May2011 QX56
Page 1312 of 5598
![INFINITI QX56 2011 Factory Service Manual
DAS
C1A03 VEHICLE SPEED SENSORDAS-347
< DTC/CIRCUIT DIAGNOSIS > [LDW & LDP]
C
D
E
F
G H
I
J
K L
M B
N P A
C1A03 VEHICLE SPEED SENSOR
DTC LogicINFOID:0000000006223743
DTC DETECTION LOGIC
NOTE:
If DTC INFINITI QX56 2011 Factory Service Manual
DAS
C1A03 VEHICLE SPEED SENSORDAS-347
< DTC/CIRCUIT DIAGNOSIS > [LDW & LDP]
C
D
E
F
G H
I
J
K L
M B
N P A
C1A03 VEHICLE SPEED SENSOR
DTC LogicINFOID:0000000006223743
DTC DETECTION LOGIC
NOTE:
If DTC](/manual-img/42/57033/w960_57033-1311.png)
DAS
C1A03 VEHICLE SPEED SENSORDAS-347
< DTC/CIRCUIT DIAGNOSIS > [LDW & LDP]
C
D
E
F
G H
I
J
K L
M B
N P A
C1A03 VEHICLE SPEED SENSOR
DTC LogicINFOID:0000000006223743
DTC DETECTION LOGIC
NOTE:
If DTC “C1A03” is detected along with DTC “U1000” or “C1A04”, first diagnose the DTC “U1000” or “C1A04”.
Refer to DAS-374, "
ADAS CONTROL UNIT : DTC Logic" for DTC “U1000”.
Refer to DAS-348, "
DTC Logic" for DTC “C1A04”.
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Start the engine.
2. Turn the LDP system ON.
3. Drive the vehicle at 30 km/h (19 MPH) or more. CAUTION:
Always drive safely.
4. Stop the vehicle.
5. Perform “All DTC Readi ng” with CONSULT-III.
6. Check if the “C1A03” is detected as the current malfunction in “Self Diagnostic Result” of “ICC/ADAS”.
Is
“C1A03” detected as the current malfunction?
YES-1 (Lane departure warning lamp: ON)>>Refer to DAS-347, "Diagnosis Procedure".
YES-2 (Lane departure warning lamp: OFF)>>Refer to CCS-87, "
Diagnosis Procedure".
NO >> Refer to GI-40, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000006223744
1.CHECK SELF-DIAGNOSIS RESULTS
Check if “C1A04” or “U1000” is detected other than “C1A03” in “Self Diagnostic Result” of “ICC/ADAS”.
Is any DTC detected?
YES >> Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to
DAS-310, "
DTC Index".
NO >> GO TO 2.
2.CHECK ABS ACTUATOR AND ELECTRIC UNIT (C ONTROL UNIT) SELF-DIAGNOSIS RESULTS
Check if any DTC is detected in “Self Diagnostic Result” of “ABS”.
Is any DTC detected?
YES >> Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to
BRC-51, "
DTC Index".
NO >> Replace the ADAS control unit. Refer to DAS-63, "
Removal and Installation".
DTC
(On board
display) Trouble diagnosis
name DTC detecting condition Possible causes
C1A03 (3) VHCL SPEED SE
CIRC If the vehicle speed signal (wheel speed) from
ABS actuator and electric unit (control unit) re-
ceived by the ADAS control unit via CAN com-
munication, are inconsistent Wheel speed sensor
ABS actuator and electric unit (control
unit)
ADAS control unit
Revision: 2010 May2011 QX56
Page 1313 of 5598
![INFINITI QX56 2011 Factory Service Manual
DAS-348
< DTC/CIRCUIT DIAGNOSIS >[LDW & LDP]
C1A04 ABS/TCS/VDC SYSTEM
C1A04 ABS/TCS/VDC SYSTEM
DTC LogicINFOID:0000000006228186
DTC DETECTION LOGIC
NOTE:
If DTC “C1A04” is detected along with DTC INFINITI QX56 2011 Factory Service Manual
DAS-348
< DTC/CIRCUIT DIAGNOSIS >[LDW & LDP]
C1A04 ABS/TCS/VDC SYSTEM
C1A04 ABS/TCS/VDC SYSTEM
DTC LogicINFOID:0000000006228186
DTC DETECTION LOGIC
NOTE:
If DTC “C1A04” is detected along with DTC](/manual-img/42/57033/w960_57033-1312.png)
DAS-348
< DTC/CIRCUIT DIAGNOSIS >[LDW & LDP]
C1A04 ABS/TCS/VDC SYSTEM
C1A04 ABS/TCS/VDC SYSTEM
DTC LogicINFOID:0000000006228186
DTC DETECTION LOGIC
NOTE:
If DTC “C1A04” is detected along with DTC “U
1000”, first diagnose the DTC “U1000”. Refer to DAS-374,
"ADAS CONTROL UNIT : DTC Logic".
Diagnosis ProcedureINFOID:0000000006228187
1.CHECK SELF-DIAGNOSIS RESULTS
1. Perform “All DTC Reading” with CONSULT-III.
2. Check if the “U1000” is detected other than “C1A 04” in “Self Diagnostic Result” of “ICC/ADAS”.
Is
“U1000” detected?
YES >> Perform the CAN communication system inspecti on. Repair or replace the malfunctioning parts.
Refer to DAS-374, "
ADAS CONTROL UNIT : DTC Logic".
NO >> GO TO 2.
2.CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) SELF-DIAGNOSIS RESULTS
Check if any DTC is detected in “Self Diagnostic Result” of “ABS”.
Is any DTC detected?
YES >> Perform diagnosis on the detected DTC and repair or replace the malfunctioning parts. Refer to
BRC-51, "
DTC Index".
NO >> Replace the ADAS control unit. Refer to DAS-63, "
Removal and Installation".
DTC
(On board dis-
play) Trouble diagnosis
name DTC detecting condition Possible causes
C1A04 (4) ABS/TCS/VDC CIRC
If a malfunction occu
rs in the VDC/TCS/ABS
system ABS actuator and electric unit (control
unit)
Revision: 2010 May2011 QX56
Page 1314 of 5598
![INFINITI QX56 2011 Factory Service Manual
DAS
C1A05 BRAKE SW/STOP LAMP SWDAS-349
< DTC/CIRCUIT DIAGNOSIS > [LDW & LDP]
C
D
E
F
G H
I
J
K L
M B
N P A
C1A05 BRAKE SW/STOP LAMP SW
DTC LogicINFOID:0000000006228188
DTC DETECTION LOGIC
NOTE:
If DT INFINITI QX56 2011 Factory Service Manual
DAS
C1A05 BRAKE SW/STOP LAMP SWDAS-349
< DTC/CIRCUIT DIAGNOSIS > [LDW & LDP]
C
D
E
F
G H
I
J
K L
M B
N P A
C1A05 BRAKE SW/STOP LAMP SW
DTC LogicINFOID:0000000006228188
DTC DETECTION LOGIC
NOTE:
If DT](/manual-img/42/57033/w960_57033-1313.png)
DAS
C1A05 BRAKE SW/STOP LAMP SWDAS-349
< DTC/CIRCUIT DIAGNOSIS > [LDW & LDP]
C
D
E
F
G H
I
J
K L
M B
N P A
C1A05 BRAKE SW/STOP LAMP SW
DTC LogicINFOID:0000000006228188
DTC DETECTION LOGIC
NOTE:
If DTC “C1A05” is detected along with DTC “U1000”, first diagnose the DTC “U1000”. Refer to DAS-374,
"ADAS CONTROL UNIT : DTC Logic".
Diagnosis ProcedureINFOID:0000000006228189
1.CHECK SELF-DIAGNOSIS RESULTS
1. Perform “All DTC Readi ng” with CONSULT-III.
2. Check if the “U1000” is detect ed other than “C1A05” in “Self Diagnostic Result” of “ICC/ADAS”.
Is
“U1000” detected?
YES >> Perform the CAN communicati on system inspection. Repair or replace the malfunctioning parts.
Refer to DAS-374, "
ADAS CONTROL UNIT : DTC Logic".
NO >> GO TO 2.
2.CHECK STOP LAMP SWIT CH AND ICC BRAKE SWITCH
Check that “STOP LAMP SW” and “BRAKE SW” operate normally in “DATA MONITOR” of “ICC/ADAS”.
Is the inspection result normal?
YES >> GO TO 3.
NO-1 >> When “BRAKE SW” operation is malfunctioning: GO TO 4.
NO-2 >> When “STOP LAMP SW” operation is malfunctioning: GO TO 9.
3.CHECK STOP LAMP SWITCH
Check that “STOP LAMP SW” operate no rmally in “DATA MONITOR” of “ABS”.
Is the inspection result normal?
YES >> GO TO 14.
NO >> GO TO 9.
4.CHECK ICC BRAKE SWITCH INSTALLATION
1. Turn ignition switch OFF.
2. Check ICC brake switch for correct installation. Refer to BR-7, "
Inspection and Adjustment".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Adjust ICC brake switch installation. Refer to BR-7, "
Inspection and Adjustment".
5.ICC BRAKE SWITCH INSPECTION
1. Disconnect ICC brake switch connector.
2. Check ICC brake switch. Refer to DAS-352, "
Component Inspection (ICC Brake Switch)".
Is the inspection result normal?
DTC
(On board dis-
play) Trouble diagnosis
name DTC detecting condition Possible causes
C1A05 (5) BRAKE SW/STOP L
SW A mismatch between a stop lamp switch signal
and a ICC brake switch signal received from
ECM and a stop lamp signal received from the
ABS actuator and electric
unit (control unit) con-
tinues for 10 seconds or more with vehicle
speeds at approximately 40 km/h or more Stop lamp switch circuit
ICC brake switch circuit
Stop lamp switch
ICC brake switch
Incorrect stop lamp switch installa-
tion
Incorrect ICC brake switch installa- tion
ECM
ABS actuator and electric unit (con-
trol unit)
Revision: 2010 May2011 QX56
