DAS
SYSTEM
DAS-283
< SYSTEM DESCRIPTION >[LDW & LDP]
C
D
E
F
G H
I
J
K L
M B
N P A
 After the operating conditions are satisfied, the c ontrol continues until the vehicle speed reaches approxi-
mately 60 km/h (40 MPH).
 The LDP system may not function properly, depending on the situation. Refer to DAS-288, "
Precautions for
Lane Departure Warning/Lane Departure Prevention".
Bulb Check Action and Fail-safe Indication
LANE DEPARTURE PREVENTION (LDP) SYSTEM : Fail-safe (ADAS Control Unit)
INFOID:0000000006223708
If a malfunction occurs in each system, ADAS control unit cancels eac h control, sounds a beep, and turns ON
the warning lamp or indicator lamp.
Vehicle condition/ Driver's operation Indication on the combination meter Buzzer
Ignition switch
OFF ⇒ ON
(Bulb check) —
When DTC is detected
(Except “C1B01” and “C1B03”) Beep
Camera aiming is not completed
(“C1B01”is detected)
NOTE:
This is detected while driving the vehicle and the indication remains ON
until the ignition switch is turned OFF
Temporary disabled status at high temperature
(“C1B03”is detected)
Beep
When the dynamic driver assistance switch is pressed
[When the settings of LDP system, DCA system on the navigation screen
are both “OFF”] —
JPOIA0017GB
JPOIA0019GB
JPOIA0020GB
JPOIA0036GB
System Buzzer Warning lamp/Indicator lamp Description
Vehicle-to-vehicle distance control mode High-pitched
tone
ICC system warning lamp Cancel
Conventional (fixed speed) cruise control mode High-pitched
toneICC system warning lamp Cancel
Intelligent Brake Assist (IBA) High-pitched
toneIBA OFF indicator lamp Cancel
Forward Collision Warning (FCW) High-pitched
tone
IBA OFF indicator lamp Cancel
Distance Control Assist (DCA) High-pitched
toneICC system warning lamp Cancel
Lane Departure Warning (LDW) — Lane departure warning lamp Cancel
Revision: 2010 May2011 QX56

DAS-286
< SYSTEM DESCRIPTION >[LDW & LDP]
OPERATION
NOTE:
After the operating conditions of warning are satisfied,
the warning continues until the vehicle speed reaches
approximately 60 km/h (40 MPH). Refer to DAS-277, "
LANE DEPARTURE WARNING (LDW) SYSTEM : Sys-
tem Description".
LANE DEPARTURE PREVENTION (LDP) SYSTEM
LANE DEPARTURE PREVENTION (LDP) SY STEM : Switch Name and Function
INFOID:0000000006223712
LANE DEPARTURE PREVENTION (LDP) SYSTEM : Menu Displayed by Pressing
Each Switch
INFOID:0000000006223713
INDICATOR LAMP AND WARNING LAMP
Vehicle condition/ Driver's operation Action Driver warning
systems ON in- dicator Indication on the combination
meter Buzzer
Less than Ap-
prox. 60 km/h
(40 MPH) Close to lane marker No action ON OFF —
Approx. 70
km/h (45
MPH) or more Close to lane marker
Warning
 Buzzer sounds
 Warning lamp blinks ON
Short con-
tinuous
beeps
 Close to lane marker
 Turn signal ON (Deviate side) No action ON OFF —
JPOIA0018GB
JSOIA0369ZZ
No. Switch name Description
1 Dynamic driver assistance switch Turns LDP system ON/OFF
(When the setting of LDP system on the navigation system setting screen is ON)
2 LDP system settings screen
(Navigation system settings screen) The setting of LDP system can be switched between ON and OFF
JSOIA0243ZZ
Revision: 2010 May2011 QX56

DAS
ACTION TESTDAS-337
< BASIC INSPECTION > [LDW & LDP]
C
D
E
F
G H
I
J
K L
M B
N P A
After the operating conditions of warning are satisf ied, the warning continues until the vehicle speed
reaches approximately 60 km/h (40 MPH). Refer to DAS-277, "
LANE DEPARTURE WARNING (LDW)
SYSTEM : System Description".
>> GO TO 2.
2.CHECK LDP SYSTEM SETTING
1. Start the engine.
2. Check that the LDP system setting can be enabled/disabled on the navigation screen.
3. Turn OFF the ignition switch and wait for 30 seconds or more.
4. Check that the previous setting is saved when the engine starts again.
>> GO TO 3.
3.ACTION TEST FOR LDP
1. Enable the setting of the LDP system on the navigation screen.
2. Turn dynamic driver assistance switch ON (LDP ON indicator lamp is ON).
NOTE:
LDW system is OFF.
3. Check the LDP operation according to the following table.
Vehicle condition/ Driver's operation Action Indication on the combination meter Buzzer
Less than Ap- prox. 60 km/h
(40 MPH) Close to lane marker No action —
JPOIA0021GB
Revision: 2010 May2011 QX56
